3515-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
Luggage compartment features
The cargo hooks are provided for
securing loose items.
The cargo net itself is not included as original equipment.
To hang the cargo net, use the
cargo net hooks.
Cargo hooks
Cargo net hooks

3525-3. Using the storage features
SEQUOIA_OM_USA_OM0C013U_19MY
To hang shopping bags, use the
grocery bag hooks.
Grocery bag hooks

3535-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
Ty p e A
Pull the lever upwards to lift the
deck board.
Type B (if equipped)
Open the cover.
Storage compartment

3545-3. Using the storage features
SEQUOIA_OM_USA_OM0C013U_19MY
WARNING
■When the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their stowed positions.
■ Caution while driving
Keep the auxiliary box closed. Injuries may result in the event of an accident
or sudden braking.
NOTICE
■ To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on them.
■ Grocery bag hook weight capacity
Do not hang any object heavier than 8.8 lb. (4 kg) on the groce ry bag hooks.

3555-4. Other interior features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
Other interior features
■Main visor
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
■Sub visor (if equipped)
Flip it down.
Sun visors

3565-4. Other interior features
SEQUOIA_OM_USA_OM0C013U_19MY
Vehicles without vanity light
Open the cover.
Vehicles with vanity light
Open the cover.
The light turns on when the cover
is opened.
Adjust the brightness of the
light.
Vanity mirrors
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended
periods while the engine is not running.

3575-4. Other interior features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY■
12 V DC
Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power c onsumption of 120 W).
When using electronic goods, make sure that the power consumption
of all the connected power outlets is less than 120 W.
Power outlets
Instrument panelFront console box (outside)
(if equipped)
Open the lid. Open the lid.
Luggage compartment
Open the lid.

3585-4. Other interior features
SEQUOIA_OM_USA_OM0C013U_19MY
Front console box (inside)
Lift the lid while pulling up the
knob to release the lock.
Open the lid.
■120 V AC (if equipped)
Accessories that use less than 100 W.
Open the lid.
1
2

3595-4. Other interior features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
■The power outlets can be used when
12 V DC
The engine switch is in the “ACC” or “ON” position.
120 V AC
The engine switch is in the “ON” position.
NOTICE
●To avoid damaging the power outlets, close the power outlet lid when the
power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short
circuit.
● To prevent blown fuse:
12 V DC
Do not use an accessory that uses more than 12 V 10 A.
120 V AC
Do not use a 120 V AC appliance that requires more than 100 W.
If a 120 V AC appliance that consumes more than 100 W is used, the pro-
tection circuit will cut the power supply.
● To prevent battery discharge, do not use the power outlet longer than nec-
essary when the engine is not running.
● The following 120 V AC appliances may not operate properly even if their
power consumption is under 100 W:
• Appliances with high initial peak wattage
• Measuring devices that process precise data
• Other appliances that require an extremely stable power supply

3605-4. Other interior features
SEQUOIA_OM_USA_OM0C013U_19MY
Push the lid.
The mirror can be adjusted by
pushing the mirror edge.
Conversation mirror
1
2
WARNING
■Caution while driving
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and an accident , resulting
in death or serious injury.
