3154-6. Driving tips
4
Driving
SEQUOIA_OM_USA_OM0C013U_19MY
Perform the following according to the driving conditions:
● Do not try to forcibly open a window or move a wiper that is fr ozen.
Pour warm water over the frozen area to melt the ice. Wipe away
the water immediately to prevent it from freezing.
● To ensure proper operation of the climate control system fan,
remove any snow that has accumulated on the air inlet vents in
front of the windshield.
● Check for and remove any excess ic e or snow that may have accu-
mulated on the exterior lights, vehicle’s roof, chassis, around the
tires or on the brakes.
● Remove any snow or mud from the bottom of your shoes before
getting in the vehicle.
Accelerate the vehicle slowly, keep a safe distance between you and
the vehicle ahead, and drive at a reduced speed suitable to roa d con-
ditions.
● Park the vehicle and move the shift lever to P without setting the
parking brake. The parking brake may freeze up, preventing it from
being released. If the vehicle is parked without setting the pa rking
brake, make sure t o block the wheels.
Failure to do so may be dangerou s because it may cause the vehi-
cle to move unexpectedly, pos sibly leading to an accident.
● If the vehicle is parked without setting the parking brake, confirm
that the shift lever c annot be moved out of P
*.
*: The shift lever will be locked if it is attempted to be shifte d from P to any
other position without depressing the brake pedal. If the shift lever can be
shifted from P, there may be a problem with the shift lock syst em. Have the
vehicle inspected by your Toyota dealer immediately.
Before driving the vehicle
When driving the vehicle
When parking the vehicle

5088-1. Specifications
SEQUOIA_OM_USA_OM0C013U_19MY
This information has been prepared in accordance with regulations
issued by the National Highway Tr affic Safety Administration of the
U.S. Department of Transportation.
It provides the purchasers and/or prospective purchasers of Toyota
vehicles with info rmation on uniform ti re quality grading.
Your Toyota dealer will help answer any questions you may have as
you read this information.
■DOT quality grades
All passenger vehicle tires must conform to Federal Safety Requ ire-
ments in addition to these grades. Quality grades can be found
where applicable on the tire sidewall between tread shoulder an d
maximum section width.
For example: Treadwear 200 Traction AA Temperature A
■Treadwear
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a s peci-
fied government t est course.
For example, a tire graded 150 would wear one and a half (1 - 1 /2)
times as well on the government course as a tire graded 100.
The relative performance of tires depends upon the actual condi -
tions of their use. Performance ma y differ significantly from the norm
due to variations in driving habits, service practices and diff erences
in road characteristics and climate.
■Traction AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B and C ,
and they represent the tire’s ability to stop on wet pavement a s
measured under controlled conditions on specified government te st
surfaces of asphalt and concrete.
A tire marked C may have p oor traction performance.
Warning: The traction grade assigned to this tire is based on b raking
(straight ahead) traction tests and does not include cornering (turn-
ing) traction.
Uniform Tire Quality Grading

546Alphabetical index
SEQUOIA_OM_USA_OM0C013U_19MY
Child safety ................................ 55Airbag precautions .................. 40
Back door precautions .......... 114
Battery precautions ....... 403, 483
Child restraint system ............. 56
How your child should
wear the seat belt ................. 32
Installing child restraints ......... 60
Moon roof precautions .......... 158
Power window lock switch .... 149
Power window precautions ... 151
Rear door child-protectors .... 106
Removed key battery precautions ......................... 425
Seat belt extender precautions ........................... 37
Seat belt precautions .............. 34
Seat heater precautions........ 332
Child-protectors....................... 106
Cleaning ........................... 378, 381 Aluminum wheels.................. 379
Exterior ................................. 378
Interior................................... 381
Seat belts .............................. 382
Climate control seat ................ 333
Compass .................................. 372
Condenser ................................ 399
Console box ..................... 340, 342
Conversation mirror ................ 360
Cooling system Engine overheating ............... 484
Cruise control .......................... 256
Cup holders.............................. 345
Curtain shield airbags ............... 38
Customizable features ............ 516 Daytime running light
system.................................... 210
Defogger Outside rear view mirrors ..... 323
Rear window ......................... 323
Windshield ............................ 323
Dimension ................................ 490
Dinghy towing.......................... 197
Display Multi-information display ......... 90
Warning message................. 457
Do-it-yourself maintenance .... 390
Door courtesy lights ............... 335 Wattage ................................ 500
Doors Automatic door locking and
unlocking systems .............. 107
Back door ............................. 110
Door lock ...................... 104, 110
Door windows ....................... 149
Open door warning buzzer ... 460
Outside rear view mirrors ..... 145
Rear door child-protector ...... 106
Side doors ............................ 104
Drive information....................... 91
Driver’s seat position memory .................................. 133
Driving ...................................... 160 Break-in tips.......................... 162
Correct driving posture ........... 26
Driving assist systems .......... 302
Off-road precautions ............. 309
Procedures ........................... 160
Winter drive tips .................... 314D

553Alphabetical index
SEQUOIA_OM_USA_OM0C013U_19MY
Seat belt reminder light........... 451
Seat belts.................................... 28Adjusting the seat belt ............ 31
Automatic Locking Retractor (ALR) .................... 32
Child restra int system
installation ............................ 60
Cleaning and maintaining the seat belt ........................ 382
Comfort guide ......................... 33
Emergency Locking
Retractor (ELR) .................... 32
How to wear your seat belt ..... 28
How your child should wear
the seat belt .......................... 32
Pregnant women, proper
seat belt use ......................... 34
Reminder light and buzzer .... 451
Seat belt extender................... 32
Seat belt pretensioners ........... 31
SRS warning light ................. 448
Seat heaters ............................. 332
Seat position memory ............. 133
Seat ventilators ........................ 332
Seating capacity ...................... 177 Seats ................................. 120, 122
Adjustment.................... 120, 122
Adjustment
precautions................. 121, 131
Child seats/child restraint
system installation . ............... 60
Cleaning ............................... 381
Climate control seat .............. 332
Driving position memory ....... 133
Head restraints ..................... 138
Properly sitting in the seat ...... 26
Seat heaters ......................... 332
Seat position memory ........... 133
Seat ventilators ..................... 332
Sensor Automatic headlight system .......... ...................... 210
Automatic High Beam system .......... ...................... 212
Inside rear view mirror .......... 144
Intuitive parking assist .......... 270
LDA (Lane Departure Alert)................................... 248
PCS (Pre-Collision system)......... ...................... 230
Service reminder indicators ..... 80
S
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
