TOYOTA SEQUOIA 2020 Owners Manual (in English)

1413-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY■
Before folding dow
n the second seats
Adjust the head restraints to
the downmost position.
Stow the rear seat belt buck-
les.
Folding down the second seats
1
2

1423-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C021U_20MY■
Folding down the second seats
Pull the lever to unlock the seatback and then fold the seatbac
k
down.
■After folding down the second seat (if equipped)
Fold out the board from the
seatback.
Separated typeBench type

1433-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY■
Getting in the vehicle
Pull up the lever and fold down
the seatback. The seat will slide
forward.
Move the seat to the front-most
position.
■Getting out of the vehicle
Depress the release pedal and
fold down the seatback. The
seat will slide forward.
Move the seat to the front-most
position.
Make sure that no passenger is
seated on the second seat
before depressing the release
pedal.
■
After passengers have entered/exited the vehicle
Lift up the seatback and slide t he seat backward until it locks.
Moving a second seat for a ccess to the third seats

1443-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C021U_20MY■
Before folding down the third seats
Stow the third center seat belt. (
P. 3 2 )
Adjust the center head
restraint to the downmost
position.
Stow the third seat belt buck-
les.
Folding down the third seats
1
2
3

1453-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY■
Folding down the third
seats (manual type)
Pull the head restraint lock
release lever to fold the head
restraint.
Pull the lever to unlock the seatback and then fold the seatbac k
down.
1
2
From rear door sideFrom back door side

1463-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C021U_20MY■
Folding down the third
seat (power type)
Press and hold the seatback folding switch until the seatback f olds
down fully and the buzzer sounds.
The outside head restraints are folded automatically.
■ The power third seat can be folded down/returned when
Turn the engine switch OFF or the shift lever is in P, with the rear door
opened (from rear door side) or back door opened (from back doo r side).
From rear door sideFrom back door side

1473-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY
WARNING
■When folding the rear seatbacks down
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shi ft the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the lugga ge compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a colli sion, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hi ps and apply
restraint forces directly to the abdomen, or your neck may cont act the
shoulder belt, increasing the risk of death or serious injury i n the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts t o avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● Do not depress the second seat release pedal from the third seat while the
second seat is occupied.
■ After returning the rear seat back to the upright position
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Make sure the seatback is securely locked by pushing it forward and rear-
ward on the top.
● Check that the seat belts are not twisted or caught in the seat back.

1483-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C021U_20MY
NOTICE
■Stowing the seat belts
The seat belts and the buckles must be stowed.
■ Second seatback board wei ght capacity (if equipped)
Do not place any object heavier than 220 lb. (100 kg) on the se cond seat-
back board.
■ Before sliding the second center seat to the most forward posit ion
(vehicles with bench type second seat)
Ensure that the cup holder on the front console box is closed.

1493-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY
Driving position memor y
The steering wheel will automatically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have
been performed, the steering
wheel will automatically
adjusted to a position that
allows driver to enter and exit
the vehicle easily. • The shift lever has been shifted to P.
• The engine switch has been turned to ON.
• The driver’s seat belt has been unfastened.
When any of the following has be en performed, the steering wheel
will automatically return to their original positions. • The engine switch has been turned to ACC or ON.
• The driver’s seat belt has been fastened.
: If equipped
This feature automatically adjusts the front seats, steering wh eel
and outside rear view mirrors to make entering and exiting the
vehicle easier or to suit your preferences.
Power easy access system

1503-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C021U_20MY
Your preferred driving position (the position of the driver’s seat, steer-
ing wheel and outside rear view mirrors) can be recorded and re called
by pressing a button.
Two different driving positions can be recorded into memory.
■Recording procedure
Check that the shift lever is in P.
Turn the engine switch to ON.
Adjust the driver’s seat, steerin g wheel, and outside rear view
mirrors to the desired positions.
While pressing the “SET”
button, or within 3 seconds
after the “SET” button is
pressed, press button “1” or
“2” until the buzzer sounds.
If the selected button has
already been preset, the previ-
ously recorded position will be
overwritten.
■
Recall procedure
Check that the shift lever is in P.
Turn the engine switch to ON.
Press one of the buttons for
the driving position you want
to recall until the buzzer
sounds.
Driving position memory
1
2
3
4
1
2
3
