1513-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
● Press button “1” or “2”.
● Operate any of the seat adjustment switches (only cancels seat position
recall).
● Operate the tilt and telescopic steering control switch (only cancels steering
wheel position recall).
■ Seat positions that can be memorized ( P. 136)
The adjusted positions other than the position adjusted by lumb ar support
switch can be recorded.
■ Operating the driving position m emory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■ In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be sl ightly different
when it is recalled.

1523-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C021U_20MY
Each key can be registered to recall your preferred driving position.
■Registering procedure
Record your driving position to button “1” or “2” before perfor ming
the following:
Carry only the key you want to register, and then close the dri ver’s
door.
If 2 or more keys are in the vehicle, the driving position cann ot be
recorded properly.
Check that the shift lever is in P.
Turn the engine switch to ON.
Recall the driving position that you want to record.
While pressing the recalled
button, press and hold the
door lock switch (either lock
or unlock) until the buzzer
sounds.
If the button could not be regis-
tered, the buzzer sounds contin-
uously for approximately 3
seconds.
■
Recall procedure
Make sure that the doors are locked before recalling the drivin g
position. Carry the key that has been registered to the driving
position, and then unlock and open the driver’s door using the
wireless remote control.
The driving position will move to the recorded position (not in cluding the
steering wheel).
If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.
Turn the engine switch to ACC or ON, or fasten a seat belt.
The seat and steering wheel will move to the recorded position.
Memory recall function
1
2
3
4
1
2

1533-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY■
Cancelation procedure
Carry only the key you want to cancel and then close the driver
’s
door.
If 2 or more keys are in the vehicle, the driving position cann ot be
canceled properly.
Turn the engine switch to ON.
While pressing the “SET” button, press and hold the door lock
switch (either lock or unlock) until the buzzer sounds twice.
If the button could not be canceled, the buzzer sounds continuo usly for
approximately 3 seconds.
■ Recalling the driving position u sing the memory recall function
Different driving positions can be registered for each key. The refore, the driv-
ing position that is recalled may be different depending on the key being car-
ried.
■ Customization
The unlock door settings of the memory recall function can be customized.
(Customizable features: P. 544)
WARNING
■Seat adjustment caution
Take care during seat adjustment so that the seat does not stri ke the rear
passenger or squeeze your body against the steering wheel.
1
2

1543-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C021U_20MY
Head restraints
Up
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Center seat
Up
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Outer seats
To u s e
Lift up the head restraint until it
locks.
To f o l d
Pull the head restraint lock release
lever to fold the head restraint.
Head restraints are provided for all seats.
Front and second seats
Lock release button
Third seats
Lock release button

1553-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY
■Removing the head restraints
■ Installing the head restraints
■ Adjusting the height of the head restraints (front and second o uter
seats)
■ Adjusting the second and third center seat head restraint
Always raise the head restraint one level from the stowed posit ion when
using. Pull the head restraint up while pressing
the lock release button.
The head restraint of second center seat
(if equipped) and third outer seats cannot
be removed.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
WARNING
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
● Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
● Do not drive with the head restraints removed.
Lock release button
Lock release
button

1563-4. Adjusting the steering wheel and mirrors
SEQUOIA_OM_USA_OM0C021U_20MY
Steering wheel
Manual adjustment type
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
Power adjustment type
Operating the switch moves the steering wheel in the following direc-
tions:
Up
Down
Toward the driver
Away from the driver
The steering wheel ca n be adjusted to a comfortable position.
Adjustment procedure
1
2

1573-4. Adjusting the steering wheel and mirrors
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY
To sound the horn, press on or
close to the mark.
■The steering wheel can be adjusted when (power adjustment type)
The engine switch is in ACC or ON.
■ Automatic adjustment of the st eering position (if equipped)
A desired steering position can be entered to memory and recall ed automati-
cally by the driving position memory system. ( P. 149)
■ Power easy access system (vehicles with driving position memory )
The steering wheel move in accordance with engine switch mode a nd the
driver’s seat belt condition. ( P. 149)
■ After adjusting the steering wheel (manual adjustment type)
Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.
Horn
WARNING
■Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and caus e an acci-
dent, resulting in death or serious injury.
■ After adjusting the steering wheel (manual adjustment type)
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causi ng an
accident, resulting in death or serious injury.

1583-4. Adjusting the steering wheel and mirrors
SEQUOIA_OM_USA_OM0C021U_20MY
Inside rear view mirror
The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.
■Manual anti-glare insi de rear view mirror
Normal position
Anti-glare position
The rear view mirror’s position ca n be adjusted to enable suffi-
cient confirmation of the rear view.
Adjusting the height of rear view mirror
Anti-glare function

1593-4. Adjusting the steering wheel and mirrors
3
Operation of each component
SEQUOIA_OM_USA_OM0C021U_20MY■
Auto anti-glare inside rear view mirror
Responding to the level of brightness of the headlights of vehi cles
behind, the reflected light is automatically reduced.
Changing automatic anti- glare function mode
On/off
When the automatic anti-glare function is in ON mode, the indic ator illumi-
nates.
The function will set to ON mode each time the engine switch is turned to
ON.
Pressing the button turns the function to OFF mode. (The indicator also
turns off.)
Ty p e AType B
IndicatorIndicator

1603-4. Adjusting the steering wheel and mirrors
SEQUOIA_OM_USA_OM0C021U_20MY
■To prevent sensor error (auto anti-glare type)
Type A
Type B
■ If a sun visor interferes
Hold and rotate the mirror to adjust the
support.
WARNING
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an ac cident,
resulting in death or serious injury.
To ensure that the sensors operate prop-
erly, do not touch or cover them.
To ensure that the sensors operate prop-
erly, do not touch or cover them.
