language TOYOTA SEQUOIA 2021 Accessories, Audio & Navigation (in English)

3TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
3-5. Tips for operating the navi-gation system
GPS (Global Positioning Sys-tem) ............................. 114
Map database version and covered area ............... 116
4-1. Basic operation Quick reference............. 120
Some basics ................. 121
4-2. Radio operation
AM/FM/SiriusXM
® Satellite
Radio ........................... 125
4-3. Media operation USB memory................. 133
iPod/iPhone (Apple CarPlay) .................................... 135
Android Auto ................. 138
Bluetooth
® audio ........... 139
4-4. Audio/visual remote con- trols
Steering switches .......... 143
4-5. Setup Audio settings ............... 144
4-6. Tips for operating the audio/visual system
Operating information ... 146
4-7. Rear seat entertainment system
Rear seat entertainment sys-tem features ................ 155
Some basics ................. 1564-8. Rear seat entertainment
system operation
Playing A Blu-ray Disc™ (BD) and DVD discs .... 163
Playing an audio CD and MP3/WMA/AAC discs.. 173
Playing an SD card........ 174
Using the DLNA mode ... 182
Using the Miracast™ mode .................................... 186
Using the external mode 188
4-9. Tips for operating rear seat entertainment system
Operating information .... 190
5-1. Voice command system operation
Voice command system 218
Natural language under- standing ....................... 221
Command list ................ 222
6-1. Information display Receiving weather informa-tion............................... 228
Data services settings ... 230
4Audio/visual system
5Voice command system
6Information

181-1. Basic function
Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.Select to change the selected
language, operation sound
settings, etc. ( P.60)
Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P.40)
(Gray)
While in this condition,
sound quality during
phone calls may dete-
riorate.
Indicates that the cel-
lular phone is not con-
nected via Bluetooth
®.
IndicatorsConditions“Setup” screen
“Setup” screen
A
B

592-4. Other settings
2
Basic function
2-4.Other settings
1Press the “MENU” button.
2 Select “Setup”.
 If the general settings screen
is not displayed, select “Gen-
eral”.
3 Select the desired items to
be set.
 “Clock”
Select to change the time zone and
select “On” or “Off” or “Auto”
*1 for daylight saving time, automatic
adjustment of the clock, etc.
(
 P. 6 1 )
 “Language”
Select to change the language. The
language setting of Apple Car-
Play/Android Auto can only be
changed on the connected device.
“Customize Home Screen”
Select to change the display infor-
mation/area on the home screen
and the home screen layout.
( P. 2 9 )
 “Projection Settings”*2
Select to set automatic Apple Car-
Play/Android Auto connection
establishment on/off. ( P.62)
 “Beep”
Select to turn the beep sound
on/off.
“Theme Setting”
Select to change the screen theme
setting.
“Unit of Temperature”*1
Select to change the unit of tem-
perature.
“Units of Measurement”
Select to change the unit of mea-
sure for distance/fuel consumption.
“Auto Change to Screen”*1
Select to set automatic screen
changes from the audio control
screen to the home screen to
on/off. When set to on, the screen
will automatically r eturn to the
home screen from the audio control
screen after 20 seconds.
 “Keyboard Layout”
General settings
Settings are available for
clock, operation sounds,
etc.
Displaying the general
settings screen
General settings screen

622-4. Other settings
The driver settings feature will
allow the system to link some
preferences (such as audio pre-
sets, screen theme, language,
etc.) to a paired Bluetooth
®
phone.
1 Display the general settings
screen. ( P.60)
2 Select “Driver Setting”.
3 Select “Enable This Feature”.
1 Select “Manually Select
Linked Settings”.
2 Select the desired phone.
 After a few seconds, loaded
screen automatically switches
to the home screen. Registered or changed per-
sonal settings will be deleted or
returned to their default condi-
tions.
1
Display the general settings
screen. ( P. 6 0 )
2 Select “Delete Personal
Data”.
3 Select “Delete”.
4 Select “Yes” when the confir-
mation screen appears.
Examples of settings that can be
returned to their default conditions:
Navigation settings*
Audio settings
 Phone settings
etc.*: Premium Audio only
*: Vehicles equipped with DCM
only. This function is not made
available in some countries or
areas.
When the automatic update
check function is enabled, if a
software update is available
from the Cloud, a message will
be displayed.
1 Display the general settings
screen. ( P. 6 0 )
2 Select “Software Update Set-
ting”.
Driver settings
Manually select linked set-
tings
Deleting personal data
Software update settings
*

1634-8. Rear seat entertainment system operation
4
Audio/visual system
4-8.Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the menu screen
Displaying the option screen
Changing the audio language
Selecting a chapter
Turning on the BD/DVD
mode
Playing A Blu-ray
Disc™ (BD) and DVD
discs
This system can play Blu-
ray Disc™ (BD) videos with
digital sound. In addition to
commercial BD and DVD
titles, AVCHD, BDAV videos
and Video CD can be played
on this system, so digital TV
recorded by home digital
video recorders and
BD/DVD home videos
recorded by home digital
video cameras can also be
played on this system.
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
WA R N I N G
●BD/DVD video precaution
• Conversational speech on some
BDs/DVDs is recorded at a low
volume to emphasize the
impact of sound effects. If you
adjust the volume assuming
that the conversations represent
the maximum volume level that
the BD/DVD will play, you may
be startled by louder sound
effects or startled when you
change to a different audio
source. Loud sounds may have
a significant impact on the
human body or pose a driving
hazard. Keep this in mind when
you adjust the volume.
Remote controller
A
B
C
D
E
F
G
H
I
J
K

1664-8. Rear seat entertainment system operation
Searching for a chapter
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage
Changing the angle
Displaying the color key but-
tons
Displaying the 10 key pad
Displaying the secondary
video (Picture-in-picture)
Changing the secondary
audio
Displaying the menu screen
Changing the playback mode
Changing the audio channel
Searching by track
Returning to the previous
page screen (with the disc
menu displayed)
Proceeding to the next page
screen (with the disc menu
displayed)
BD video
Some BD video discs have a
pop-up navigation menu that
can be called up and be oper-
ated on the screen without inter-
rupting playback. 1
Select “Pop-up Menu”.
2 Select the menu item, and
press the “ENT” button to
enter.
BD video, DVD video,
AVCHD, BDAV
1 Select “Title”, “Chapter” or
“Search”.
2 Input the title number or
chapter number, and select
“OK”.
BD video, DVD video, BDAV
The angle can be changed for
discs that are multi-angle com-
patible when the angle mark
appears on the screen.
1 Select “Angle”.
Displaying the pop-up menu
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU
&KDQJLQJWKHDQJOH

1674-8. Rear seat entertainment system operation
4
Audio/visual system
2Each time “Angle” is
selected, the angle changes.
BD video, DVD video, AVCHD
The subtitle language can be
changed for discs with multiple
subtitle languages.
1 Select “Subtitle”.
2 Each time “Subtitle” is
selected, another language
available on the disc is
selected.
“Hide”: Subtitle can be hidden.
BD video
“Style”: Subtitle style can be
changed.
BD video, DVD video,
AVCHD, BDAV
The audio language can be
changed for discs with multiple
audio languages.
1 Select “Audio”.
2 Each time “Audio” is
selected, another language
available on the disc is
selected.
BDAV, Video CD
The audio channel can be
changed for discs with multiple
audio channels.
1 Each time “Main/Sub” is
selected, the mode changes
in the following order:
“Main”: Main audio channel
Changing the subtitle lan-
guage
Changing the audio lan-
guage
Changing the audio channel

1704-8. Rear seat entertainment system operation
2Select the settings to be
changed. After the settings
are changed, select “OK”.
Changing the initial audio
language
Changing the initial subtitle
language
Changing the initial lan-
guage of the disc menu
Setting the angle mark
Setting the DVD parental
control level
Setting the BD parental con-
trol age
Setting a quick playback
Setting a sound dynamic
range
Restores default settings
BD history data such as
bookmarks and resume point can be deleted.
 Select or to show the
next or previous page.
■Changing the initial audio
language
1 Select “Audio Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.194)
■Changing the initial subtitle
language
1 Select “Subtitle Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.194)
A
B
C
D
E
F
G
H
I
J

1714-8. Rear seat entertainment system operation
4
Audio/visual system
■Changing the initial lan-
guage of the disc menu
1 Select “Menu Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.194)
■Setting the angle mark
If the BD/DVD disc has angle
options, you can turn the angle
mark on/off.
1 Each time “Angle Mark” is
selected, “On” or “Off” can be
selected.
■Setting the DVD parental
control level
DVD video
The level of viewer restrictions
can be set.
1 Select “Parental Control
Level”. 2
Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Select a restriction level (1-
8).
■Setting the BD parental con-
trol age
BD video
The age of viewer restrictions
can be set.
1 Select “BD Parental Control
Age”.

1794-8. Rear seat entertainment system operation
4
Audio/visual system
MovieTurning off the option screen
Displaying the detail informa-
tion
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Changing the playback mode
Changing the audio channel
Displaying the top menu
screen
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage
1 Select “Detailed Information”. 2
Detail informations of the
video are displayed.
SD video
SD AVCHD
Movie
SD video, SD AVCHD
1 Select “Title” or “Chapter”.
Displaying the detail infor-
mations of the video
A
B
C
D
E
F
G
H
I
J
K
L
M
N
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU
