TOYOTA SEQUOIA 2022 Owners Manual

3515-1. Using the air conditioning system and defogger
5
Interior features
SEQUOIA_OM_USA_OM0C047U■
Change the airflow mode
To change the airflow mode,
press the button.
The indicator comes on.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Press .
The air conditioning system begins to operate. Air outlets and fan speed
are automatically adjusted according to the temperature setting .
Adjust the temperature setting.
To stop the operation, press .
Using automatic mode
1
2
3

3525-1. Using the air conditioning system and defogger
SEQUOIA_OM_USA_OM0C047U■
Location of a
ir outlets
The air outlets and air volume
changes according to the
selected airflow mode.
■Adjusting the position of the roof side air outlets
Direct air flow to the left or right,
up or down.
Air outlets

3535-1. Using the air conditioning system and defogger
5
Interior features
SEQUOIA_OM_USA_OM0C047U
■Button lock function
During the “SYNC” mode is on, the rear air conditioning system buttons will
be automatically locked. ( P. 344)
appears on the display when the buttons are locked.
To unlock the buttons, choose the “SYNC” mode is off.
NOTICE
■ To prevent battery discharge
Do not leave the air conditioning system on longer than necessa ry when the
engine is stopped.

3545-1. Using the air conditioning system and defogger
SEQUOIA_OM_USA_OM0C047U
Seat heaters/seat ventilators
: If equipped
The seat heaters warm the seats and the seat ventilators main-
tain good airflow by blowing air through the seats.
WARNING
●Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physical ly chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
● Observe the following precautions to prevent the minor burns or overheat-
ing
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the sea t and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent battery discharge, do not use the functions when the engine is
off.

3555-1. Using the air conditioning system and defogger
5
Interior features
SEQUOIA_OM_USA_OM0C047U■
Front seats
Vehicles without ventilator
On
The indicator light comes on.
Adjusts the seat temperature
The further you move the dial
upward, the warmer the seat
becomes.
Off
Move the dial fully downward.
The indicator light turns off.
Vehicles with ventilator
Off
Set the dial to 0. The indicator
turns off.
Heats the seats
The indicator comes on. The
higher the number, the warmer
the seats become.
Blows air from the seats
The indicator comes on. The
higher the number, the stronger
the airflow becomes.
Seat heaters/ventilators

3565-1. Using the air conditioning system and defogger
SEQUOIA_OM_USA_OM0C047U■
Rear seat (vehicles with rear console box)
High heating temperature
The indicator (yellow) comes
on.
Press lightly on the opposite
side to turn off.
Low heating temperature
The indicator (green) comes
on.
Press lightly on the opposite
side to turn off.
■The seat heaters/seat ventilators can be used when
The engine switch is in ON.

3575-2. Using the interior lights
5
Interior features
SEQUOIA_OM_USA_OM0C047U
Interior lights list
Outer foot lights (if equipped)
Interior light ( P. 360)
Personal/interior lights ( P. 3 5 9 )
Engine switch light
Footwell lights
Door courtesy lights
Auxiliary lighting

3585-2. Using the interior lights
SEQUOIA_OM_USA_OM0C047U
On
The personal/interior lights cannot
be individually turned off.
Door position
The personal/interior lights come
on when a door is opened. They
turn off when the doors are closed.
Off
The personal/interior lights and
interior light can be individually
turned on or off.
Personal/interior light main switch

3595-2. Using the interior lights
5
Interior features
SEQUOIA_OM_USA_OM0C047U■
Front
Turns the lights on/off
■Center
Turns the lights on/off
■Rear
Turns the lights on/off
Personal/interior lights
Ty p e AType B

3605-2. Using the interior lights
SEQUOIA_OM_USA_OM0C047U
Door position on
The interior light comes on when a
back door is opened. It turns off
when the door is closed.
Off
On
■Illuminated entry system
The lights automatically turn on/off according to the engine switch mode,
whether the doors are locked/unlocked, and whether the doors ar e open/
closed.
■ To prevent the battery from being discharged
If the lights remain on when the door is not fully closed and the personal/inte-
rior light main switch is in door position, the lights will go off automatically
after 20 minutes.
■ Customization
Setting (e.g. the time elapsed before lights turn off) can be c hanged.
(Customizable features: P. 548)
Interior light
NOTICE
■To prevent battery discharge
Do not leave the lights on longer than necessary when the engin e is not
running.
