4346-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C047U■
Initializing the tire pressure warning system
Initialize the system
with the tire inflation pressure adjusted to the speci-
fied level.
■If the tread on snow tires wea rs down below 0.16 in. (4 mm)
The effectiveness of the tires as snow tires is lost.
■Situations in which the tire pressure warning system may not op er-
ate properly
●In the following cases, the tire pressure warning system may no t operate
properly.
• If non-genuine Toyota wheels are used.
• A tire has been replaced with a tire that is not an OE (Original Equip-
ment) tire.
• A tire has been replac ed with a tire that is not of the specif ied size.
• Tire chains, etc., are equipped.
• An auxiliary-supported ru n-flat tire is equipped.
• If a window tint that affects the radio wave signals is instal led.
• If there is a lot of snow or ice on the vehicle, particularly around the
wheels or wheel housings.
• If the tire inflation pressure is extremely higher than the sp ecified
level.
• If wheel without the tire pressure warning valve and transmitt er is
used.
• If the ID code on the tire pressure warning valves and transmi tters is
not registered in the tire pressure warning computer.
●Performance may be affected in the following situations.
• Near a TV tower, electric power plant, gas station, radio stat ion, large
display, airport or other facilit y that generates strong radio waves or
electrical noise
• When carrying a portable radio, cellular phone, cordless phone or
other wireless communication device
If tire position information is not correctly displayed due to the radio
wave conditions, the display may be corrected by driving and ch anging
the radio wave conditions.
●When the vehicle is parked, the time taken for the warning to s tart or go
off could be extended.
●When tire inflation pressure declines rapidly for example when a tire has
burst, the warning may not function.

4657-1. Essential information
SEQUOIA_OM_USA_OM0C047U
7
When trouble arises
If the vehicle is submerged or water on the
road is rising
●If the door can be opened, open the door and exit the vehicle.
● If the door can not be opened, open the window using the power
window switch and ens ure an escape route.
● If the window can be opened, exit the vehicle through the windo w.
● If the door and window cannot be opened due to the rising water ,
remain calm, wait until the water level inside the vehicle rises to the
point that the water pressure inside of the vehicle equals the water
pressure outside of the vehicle and then open the door after wa iting
for the rising water to enter the vehicle, and exit the vehicle . When
the outside water level exc eeds half the height of the door, the door
cannot be opened from the inside due to water pressure.
■ Water level exceeds the floor
When the water level exceeds the floor and time has passed, the electrical
equipment will get damaged, the power windows will not operate, the engine
stop, and the vehicle may not be able to get moving.
■ Using an emergency escape hammer
*
Laminated glass is used in the windshield on this vehicle.
Laminated glass cannot be shattered with an emergency hammer
*.
Tempered glass is used in the windows on this vehicle.
*: Contact your Toyota dealer or aftermarket accessory manufacturer for fur-
ther information about an emergency hammer.
This vehicle is not designed to be able to drive on roads that are
deeply flooded with water. Do not drive on roads where the
roads may be submerged or the water may be rising. It is dan-
gerous to remain in the vehicle, if it anticipated that the veh icle
will be flooded or set a drift. Re main calm and follow the follow-
ing.
WARNING
■ Caution while driving
Do not drive on roads where the roads may be submerged or the w ater may
be rising. Otherwise the vehicle may be damaged and cannot move, as well
as become flooded and set a drift, which may lead to death.

5428-1. Specifications
SEQUOIA_OM_USA_OM0C047U
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which
a tire may be inflated, shown on the sidewall
of the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
*
that follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below

5558-2. Customization
8
Vehicle specifications
SEQUOIA_OM_USA_OM0C047U■
Power back door (
P. 118)
■Power windows ( P. 165)
■Power back window ( P. 1 6 8 )
■Rear window wiper and washer ( P. 241)
FunctionDefault settingCustomized
setting
Switch operation Push and holdOne short
push—— O
Wireless remote control
linked operation On Off—— O
Operation signal volume Off
On—— O
Operation when door
locksPossible Impossible—— O
Time elapsed before back
door closing function is
activated when pushing
switch in the luggage
compartment1.5 seconds
0 seconds
—— O1 seconds
2 seconds
FunctionDefault settingCustomized
setting
Door key linked operation Open and close Open only—— OClose only
Off
FunctionDefault settingCustomizedsetting
Linked back door key
operation Open and closeOpen only—— OClose only
Sensitivity of jam protec-
tion function Level 1 Level 2 to 4
—— O
FunctionDefault settingCustomized
setting
Washer linkage wiper con-
trol On Off—— O
Drip prevention function On
Off—— O

5598-3. Items to initialize
8
Vehicle specifications
SEQUOIA_OM_USA_OM0C047U
Items to initialize
*: If equipped
The following item must be initialized for normal system opera-
tion after such cases as the battery being reconnected, or main -
tenance being performed on the vehicle:
ItemWhen to initializeReference
Power windowWhen functioning abnormallyP. 1 6 6
Power back windowWhen functioning abnormallyP. 1 6 9
Moon roofWhen functioning abnormallyP. 1 7 3
Power back door*
• After reconnecting or chang- ing the battery.
• After changing a fuse.
P. 1 2 1
Message indicating main-
tenance is required
(U.S.A. only)After the maintenance is per-
formedP. 4 0 8
Tire pressure warning
system
• When rotating the tires on vehicles differing with front
and rear tire inflation pres-
sures.
• When changing the tire infla- tion pressure by changing
traveling speed or load
weight, etc.
• When changing the tire size.
P. 4 3 0

575What to do if... (Troubleshooting)
SEQUOIA_OM_USA_OM0C047U
●Did you press the engine switch while firmly depressing the brake pedal?
( P. 214)
●Is the shift lever in P? ( P. 216)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 129)
●Is the steering wheel unlocked? (P. 217)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 509)
●Is the battery discharged? (P. 5 1 1 )
●Is the engine switch in ON?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in ON. ( P. 223)
●It is locked automatically to prevent theft of the vehicle. ( P. 2 1 7 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 165)
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches

579Alphabetical index
SEQUOIA_OM_USA_OM0C047U
Back doorBack door.............................. 118
Back window ......................... 168
Wireless remote control ........ 119
Back window ............................ 168
Back-up lights Replacing light bulbs............. 456
Wattage ................................ 532
Battery ...................................... 425 Battery checking ................... 425
If the vehicle battery
is discharged ...................... 511
Preparing and checking
before winter....................... 336
Voltmeter ................................ 94
Warning light ......................... 472
Blind Spot Monitor (BSM) ....... 297
Bluetooth
® *
Bluetooth® audio*
Bluetooth® phone*
Bottle holders .......................... 371
Brake Fluid ...................................... 423
Parking brake........................ 226
Warning light ......................... 472
Brake assist ............................. 324
Break-in tips ............................. 178
Brightness control Instrument panel light
control................................... 96
BSM (Blind Spot Monitor) ....... 297 Care .................................. 400, 404
Aluminum wheels ................. 401
Exterior ................................. 400
Interior .................................. 404
Seat belts.............................. 405
Cargo capacity......................... 193
Cargo hooks ............................ 373
Cargo net hooks ...................... 373
CD player
*
Center differential lock ........... 318
Chains ...................................... 338
Child restraint system............... 58 Booster seats, definition ......... 59
Booster seats, installation....... 69
Convertible seats, definition ... 59
Convertible seats,
installation ...................... 66, 68
Front passenger occupant classification syst em ............ 51
Infant seats, definition............. 59
Infant seats, installation .......... 66
Installing CRS with LATCH anchors ............ 64
Installing CRS with seat belts...................................... 66
Installing CRS
with top tether strap.............. 70
BC
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

580Alphabetical index
SEQUOIA_OM_USA_OM0C047U
Child safety ................................ 57Airbag precautions .................. 42
Back door precautions .......... 122
Battery precautions ....... 426, 514
Child restraint system ............. 58
How your child should
wear the seat belt ................. 34
Installing child restraints ......... 62
Moon roof precautions .......... 174
Power window lock switch .... 165
Power window precautions ... 167
Rear door child-protectors .... 115
Removed key battery precautions ......................... 449
Seat belt extender precautions ........................... 39
Seat belt precautions .............. 36
Seat heater precautions........ 354
Child-protectors....................... 115
Cleaning ........................... 400, 404 Aluminum wheels.................. 401
Exterior ................................. 400
Interior................................... 404
Seat belts .............................. 405
Climate control seat ................ 355
Compass .................................. 395
Condenser ................................ 422
Console box ..................... 363, 365
Cooling system Engine overheating ............... 515
Cruise control .......................... 276
Cup holders.............................. 368
Curtain shield airbags ............... 40
Customizable features ............ 548 Daytime running light
system.................................... 229
Defogger Outside rear view mirrors ..... 345
Rear window ......................... 345
Windshield ............................ 345
Dimension ................................ 522
Dinghy towing.......................... 213
Display Multi-information display ......... 98
Warning message................. 481
Do-it-yourself maintenance .... 413
Door courtesy lights ............... 357 Wattage ................................ 532
Doors Automatic door locking and
unlocking systems .............. 116
Back door ............................. 118
Door lock ...................... 113, 118
Door windows ....................... 165
Open door warning buzzer ... 484
Outside rear view mirrors ..... 161
Rear door child-protector ...... 115
Side doors ............................ 113
Drive information....................... 99
Driver’s seat position memory .................................. 149
Driving ...................................... 176 Break-in tips.......................... 178
Correct driving posture ........... 28
Driving assist systems .......... 324
Off-road precautions ............. 331
Procedures ........................... 176
Winter drive tips .................... 336D

583Alphabetical index
SEQUOIA_OM_USA_OM0C047U
HooksCargo hooks ......................... 373
Cargo net hooks ................... 373
Grocery bag hooks ............... 374
Retaining hooks (floor mat)..... 26
Horn .......................................... 157
I/M test ...................................... 412
Identification Engine................................... 524
Vehicle .................................. 524
Ignition switch
(engine switch) ...................... 214
Illuminated entry system ........ 360
Immobilizer system ................... 76
Indicators ................................... 91
Initialization Maintenance ......................... 408
Moon roof.............................. 173
Power back window .............. 169
Power windows ..................... 166
Tire pressure warning
system ......... ....................... 430
Inside rear view mirror ............ 158
Instrument panel light
control ...................................... 96
Interior lights............................ 357
Intuitive parking assist............ 290 Function ................................ 290
Warning message ......... 483, 485 Jack
Vehicle-equipped jack .......... 494
Jack handle .............................. 497
Jam protection function Moon roof ............................. 172
Power back door................... 121
Power back window .............. 169
Power windows..................... 166
Keyless entry ........................... 108 Wireless remote control ........ 108
Keys .......................................... 108 Engine switch ....................... 214
Key number plate ................. 108
Keyless entry ........................ 108
Replacing the battery............ 448
Wireless remote control key...................................... 108
Knee airbags .............................. 40
Lane Departure Alert (LDA) .... 268
Language ................................. 100
LATCH anchors ......................... 64
LDA (Lane Departure Alert) .... 268
Lever Auxiliary catch lever.............. 416
Hood lock release lever ........ 416
Shift lever.............................. 220
Turn signal lever ................... 225
Wiper lever ................... 238, 241
License plate lights ................. 227
Light switch ........................... 227
Replacing light bulbs ............ 458
Wattage ................................ 532
Light bulbs Replacing.............................. 453
Wattage ................................ 532
I
J
K
L
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

585Alphabetical index
SEQUOIA_OM_USA_OM0C047U
Outer foot lights....................... 357
Outside rear view mirrors ....... 161Adjusting and folding ............ 161
BSM (Blind Spot Monitor) ..... 297
Outside rear view mirror defoggers ................. 345
Outside temperature display ...................................... 94
Overhead console ................... 367
Overheating, Engine................ 515
Parking brake ........................... 226 Operation .............................. 226
Parking brake engaged warning buzzer/
message ............................. 484
Parking lights ........................... 227 Light switch ........................... 227
Replacing light bulbs............. 459
PCS (Pre-Collision system) .... 255 Enabling/disabling
the system ................... ....... 259
Pen holder ................................ 363
Personal lights ......................... 359
Power back window ................ 168 Jam protection function......... 169
Operation .............................. 168
Power outlets ........................... 379
Power steering
Fluid .............................. 424, 530
Warning light ......................... 473 Power windows ....................... 165
Door lock linked window
operation ............................ 166
Jam protection function ........ 166
Operation .............................. 165
Window lock switch .............. 165
Pre-Collision system (PCS) ...................................... 255
Enabling/disabling the system ......... ................. 259
Radiator .................................... 422
Radio
*
RCTA (Rear Cross Traffic Alert)....................................... 297
Rear air conditioning system.................................... 350
Rear console box .................... 365
Rear seats
Adjustment............................ 138
Folding down ................ 141, 144
Rear side sunshade ................ 385
Rear step bumper .................... 121
Rear turn signal lights ............ 225 Replacing light bulbs ............ 454
Turn signal lever ................... 225
Wattage ................................ 532
Rear view mirror
Inside rear view mirror .......... 158
Outside rear view mirrors ..... 161
Rear view monitor system
*
Rear window ............................ 168
Rear window defoggers .......... 345
Rear window wiper .................. 241
PR
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
