942-1. Instrument cluster
Owners Manual_USA_M0C043_en
Engine coolant temperature gauge
Displays the engine coolant temperature
Speedometer
Displays the vehicle speed
Voltmeter
Displays the charge state
Engine oil pressure gauge
Displays the engine oil pressure
Odometer and trip meter ( P.95)
■The meters and display illumi-
nate when
The power swit ch is in ON.
■Tachometer needle feature
The tachometer needle will fade in
or out during the engine starting or
stopping, respectively.
The needle is completely visible
after the engine is turned on or
turned off.
■Clock settings screen
If clock setting item is displayed
when is selected on the multi-
information display, the system may
be malfunctioning. Have the vehicle
inspected by your Toyota dealer.
■Outside temperature display
●In the following si tuations, the cor-
rect outside tempe rature may not
be displayed, or the display may
take longer than normal to
change.
• When stopped, or driving at low
speeds (less than 12 mph [20
km/h])
• When the outside temperature
has changed suddenly (at the
entrance/exit of a garage, tunnel,
etc.)
●When “--” or “E” is displayed, the
system may be malfunctioning.
Take your vehicle to your Toyota
dealer.
●Displays the outsi de temperature
within the range of -40°F (-40°C)
to 122°F (50°C).
●When the outside temperature is
approximately 37°F (3°C) or
lower, the indicator will flash
for approximately 10 seconds,
then stay on.
■Liquid crystal display
 P. 9 8
■Customization
Settings (e. g. mete r display) can be
changed on screen of the multi-
information display. ( P.101)
WARNING
■The information display at
low temperatures
Allow the interior of the vehicle to
warm up before using the liquid
crystal information display. At
extremely low temperatures, the
information disp lay monitor may
respond slowly, and display
changes may be delayed.

4676-3. Do-it-yourself maintenance
Owners Manual_USA_M0C043_en
6
Maintenance and care
 Items
Clean funnel
■Adding engine oil
If the oil level is below or near
the low level mark, add engine
oil of the same type as that
already in the engine.
1 Remove the oil filler cap by
turning it counterclockwise.
2 Add engine oil slowly, check-
ing the dipstick.
3 Install the oil filler cap by
turning it clockwise.
■Engine oil consumption
A certain amount of engine oil will
be consumed while driving. In the
following situatio ns, oil consump-
tion may increase, and engine oil
may need to be ref illed in between
oil maintenance intervals.
●When the engine is new, for
example directly after purchasing
the vehicle or after replacing the
engine
●If low quality oil or oil of an inap-
propriate viscosity is used
●When driving at high engine
speeds or with a heavy load,
when towing, or when driving
while accelerating o r decelerating
frequently
●When leaving the engine idling for a long time, or when driving fre-
quently through heavy traffic
■After changing the engine oil
The engine oil maintenance data
should be reset. Pe rform the follow-
ing procedures:
1 Press or of the meter
control switches and select .
2 Press or of the meter
control switches, select the
“Vehicle Settings” and then press
.
3 Press or of the meter
control switches, select the “Oil
Maintenance” and then press
.
4 Select the “Yes” and push .
“Reset Complete” is displayed
on the multi-info rmation display.
WARNING
■Used engine oil
●Used engine oil contains poten-
tially harmful contaminants
which may cause skin disorders
such as inflammation and skin
cancer, so care should be taken
to avoid prolonged and
repeated contact. To remove
used engine oil from your skin,
wash thoroughly with soap and
water.
●Dispose of used oil and filters
only in a safe and acceptable
manner. Do not dispose of used
oil and filters in h ousehold trash,
in sewers or onto the ground.
Call your Toyota dealer, service
station or auto parts store for
information concerning recy-
cling or disposal.
●Do not leave used engine oil
within the reach of children.

606Alphabetical Index
Owners Manual_USA_M0C043_en
L
Lane Tracing Assist (LTA)...... 261 Operation ............................. 261
Warning lights....................... 512
Warning messages............... 271
Language (multi-information dis- play) ....................................... 101
LATCH anchors ........................ 64
Lever Auxiliary catch lever ............. 464
Hood lock release lever........ 464
Shift lever ............................. 218
Turn signal lever ................... 221
Wiper lever ........................... 235
License plate lights Light switch .......................... 228
Replacing light bulbs ............ 498
Light bulbs Replacing ............................. 498
Lights Ambient lights....................... 419
Automatic High Beam system........................................... 231
Fog light switch .................... 231
Headlight switch ................... 228
Interior lights................. 418, 419
Luggage compartment light 125, 129
Personal lights...................... 419
Replacing light bulbs ............ 498
Trailering light ....................... 173
Turn signal lever ................... 221
Vanity lights .......................... 440
Wattage ................................ 557
LTA (Lane Tracing Assist) ...... 261 Operation ............................. 261
Warning lights....................... 512
Warning messages............... 271 Luggage compartment features
...............................................425Bed hooks ............................425
Deck divider..........................426
Luggage compartment light 125, 129
M
Maintenance Do-it-yourself maintenance ..462
General maintenance ...........457
Maintenance data .................548
Maintenance requirements ...456
Malfunction indicator lamp ....510
Manual headlight leveling dial ...............................................230
Menu icons ................................98
Meter Boost Meter ............................96
Clock ......................................93
Engine oil pressure gauge......93
Hybrid Power Meter ................96
Indicators ................................91
Instrument panel light control .96
Meter control switches............98
Meters ....................................93
Multi-information display.........97
Pitch and roll gauges ..............96
Settings ................................101
Tow gauges ............................96
Voltmeter ................................93
Warning lights .................89, 509
Warning messages ...............519
Meter control switches.............98
