TOYOTA SIENNA 2012 XL30 / 3.G User Guide

SIENNA_U (OM45477U)
11
A
Vehicles without overhead consoles
: If equipped
Rear air conditioning system
P. 398
Front personal lights
P. 570
Rear personal light
P. 570
Vanity mirrors
P. 591
Inside rear viewmirror
P. 138
SRS curtain shield airbag P. 168
Sun visors
P. 590
SRS curtain shield airbags
P. 168

SIENNA_U (OM45477U)
12
Pictorial indexInterior
A
Vehicles with overhead consoles
Personal/interior lights
P. 568Vanity mirrors
P. 591
Rear air conditioning system
P. 401
Inside rear view mirror Garage door opener

P. 138
P. 609
Rear interior lights
P. 566
Rear seat entertainment system
P. 488
Compass
P. 617
Personal/interior light main switch
Personal/interior lights
Power back door switch

Power sliding door switches

Moon roof switches

P. 567
P. 568
P. 83
P. 68
P. 150
Sun visors
P. 590
Rear ceiling lights
P. 570
Rear moon roof switch
P. 150

SIENNA_U (OM45477U)
13
B
Door lock switch P. 61Window lock switch P. 144
Driving position memory switches P. 120
: If equipped
Inside lock button P. 61
Power window switches P. 144

SIENNA_U (OM45477U)
14
C
Pictorial indexInterior
Vehicles with a console box type A
A/V input port
 P. 516
Cup holders P. 579
Power outlet (120 V AC)
P. 594
Console box P. 575
Cup holders P. 579Auxiliary box P. 585

SIENNA_U (OM45477U)
15
C
Vehicles with a console box type B
: If equipped
A/V input port P. 516
Cup holders P. 579
Power outlet (120 V AC)
P. 594
Console box P. 575
Cup holders P. 579Auxiliary box P. 585
Auxiliary box P. 585

SIENNA_U (OM45477U)
16
Pictorial indexInstrument panel
Headlight switch
Turn signal lever
Fog light switch

P. 266
P. 241
P. 280
Windshield wiper and washer switch
Rear window wiper and washer switch P. 282
P. 290
Gauges and meters
P. 244
Audio system
Navigation system*
P. 407
Multi-information display
Clock

P. 252
P. 592
Fuel filler
door opener
P. 155
Auxiliary box
Coin holder
P. 585
P. 589Hood release lever P. 651
Parking brake pedal P. 242
Tilt and telescopic steering
lock release lever
P. 137
SRS knee airbag P. 168
Pre-collision braking off switch P. 337

SIENNA_U (OM45477U)
17
A
: If equipped
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
VSC OFF switch P. 329
Outside rear view mirror
switches
P. 140
Power quarter window
switch
 P. 148
Intuitive parking assist
switch
 P. 314
Headlight beam level
control dial
 P. 269
Power sliding door main switch
Power back door main switch
P. 70
P. 84

SIENNA_U (OM45477U)
18
Pictorial indexInstrument panel
B
Talk switch* P. 535
Audio remote control
switches
 P. 463
Telephone switch* P. 535
Distance switch P. 298
Engine (ignition) switch
(vehicles without a smart key system)
P. 226
Cruise control switch P. 293, 298

SIENNA_U (OM45477U)
19
C
Shift lock override button P. 764
Engine (ignition) switch
(vehicles with a smart key system)
P. 229
Shift lever P. 236
Emergency flasher switch P. 722
: If equipped
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.

SIENNA_U (OM45477U)
20
Instrument panelPictorial index
D
Vehicles with a manual air conditioning system
Vehicles with an automatic air conditioning system
Air conditioning system P. 380
Air conditioning system P. 388
Rear window defogger switch P. 405
Rear window defogger switch P. 405
