6-1. Specifications
6
Vehicle specifications
SIENNA_U (OM45477U)
Tire related termMeaning
CT A pneumatic tire with an inverted flange tire
and rim system in which the rim is designed
with rim flanges pointed radially inward and the
tire is designed to fit on the underside of the
rim in a manner that encloses the rim flanges
inside the air cavity of the tire
Extra load tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Groove The space between two adjacent tread ribs
Innerliner The layer(s) forming the inside surface of a
tubeless tire that contains the inflating medium
within the tire
Innerliner separation The parting of the innerliner from cord material
in the carcass
Intended outboard
sidewall (a) The sidewall that contains a whitewall,
bears white lettering, or bears manufac-
turer, brand, and/or model name molding
that is higher or deeper than the same
molding on the other sidewall of the tire, or
(b) The outward facing sidewall of an asym- metrical tire that has a particular side that
must always face outward when mounted
on a vehicle
Light truck (LT) tire A tire designated by its manufacturer as prima-
rily intended for use on lightweight trucks or
multipurpose passenger vehicles
Load rating The maximum load that a tire is rated to carry
for a given inflation pressure
Maximum load rating The load rating for a tire at the maximum per-
missible inflation pressure for that tire

812 6-1. Specifications
SIENNA_U (OM45477U)
Tire related termMeaning
Maximum permissible
inflation pressure The maximum cold inflation pressure to which
a tire may be inflated
Measuring rim The rim on which a tire is fitted for physical
dimension requirements
Open splice Any parting at any junction of tread, sidewall, or
innerliner that extends to cord material
Outer diameter The overall diameter of an inflated new tire
Overall width The linear distance between the exteriors of
the sidewalls of an inflated tire, including eleva-
tions due to labeling, decorations, or protective
bands or ribs
Passenger car tire A tire intended for use on passenger cars, mul-
tipurpose passenger vehicles, and trucks, that
have a gross vehicle weight rating (GVWR) of
10,000 lb. or less
Ply A layer of rubber-coated parallel cords
Ply separation A parting of rubber compound between adja-
cent plies
Pneumatic tire A mechanical device made of rubber, chemi-
cals, fabric and steel or
other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load
Radial ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread

813
6-1. Specifications
6
Vehicle specifications
SIENNA_U (OM45477U)
Tire related termMeaning
Reinforced tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Section width The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
Sidewall That portion of a tire between the tread and
bead
Sidewall separation The parting of the rubber compound from the
cord material in the sidewall
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass

814 6-1. Specifications
SIENNA_U (OM45477U)
*: Table 1  Occupant loading and distri bution for vehicle normal load
for various designated seating capacities
Tire related termMeaning
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehi- cle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

815
6
Vehicle specifications
SIENNA_U (OM45477U)
6-2. Customization
Customizable features
ItemFunctionDefault settingCustomizedsetting
Smart key
system and
wireless
remote
control
(
P. 3 653) Unlocking operation
*
Drivers door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in one step
Automatic door lock
function to be activated
if door is not opened
after being unlocked
*
On Off
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked
*
60 seconds 30 seconds
120 seconds
Operation signal
*
(Emergency flashers) On Off
Operation signal
(Buzzer) On Off
Open door warning
function
(when locking the vehi-
cle) On Off
Your vehicle includes a variety of
electronic features that can be
personalized to suit your preferences. Programming these
preferences requires specialized eq uipment and may be performed
by your Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

816 6-2. Customization
SIENNA_U (OM45477U)
ItemFunctionDefault settingCustomizedsetting
Wireless
remote
control
(
P. 53) Wireless remote control On Off
Operation signal
(Buzzer volume)
Level 7Level 1 to 6
Off
Panic function On Off
Power sliding door
operation On Off
Press and hold Press twice
One short press
Power back door oper-
ation On Off
Press and hold Press twice
One short press
Smart key
system
( P. 36) Smart key system On Off
Number of permissible
times of continuous
smart lock
Twice Unlimited

817
6-2. Customization
6
Vehicle specifications
SIENNA_U (OM45477U)
ItemFunctionDefault settingCustomized
setting
Door lock
(
P. 6 0 ) Unlocking using a key
Drivers door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in one step
Speed-detecting auto-
matic door lock func-
tion
*
Off On
Opening drivers door
unlocks all doors
*Off On
Shifting gears to P
unlocks all doors
*On Off
Shifting gears to posi-
tion other than P locks
all doors
*
On Off

818 6-2. Customization
SIENNA_U (OM45477U)
ItemFunctionDefault settingCustomizedsetting
Power
sliding door
(if equipped)
(
P. 67) Operation signal
(buzzer)
Off On
Opening and closing
operation One short push Push and hold
Automatic
light control
system
( P. 266) Time elapsed before
headlights automati-
cally turn off after doors
are closed
*
30 seconds
0 second
60 seconds
90 seconds
Daytime running light
system (U.S.A. only) On Off
Light sensor sensitivity Level 3 Level 1 to 5
Automatic High Beam
(if equipped)
*On Off
Alarm
system
( P. 162) Time elapsed before
the alarm is set
14 seconds 30 seconds
Multi-
information
display
( P. 252) Language selection
*English
French
Spanish

819
6-2. Customization
6
Vehicle specifications
SIENNA_U (OM45477U)
*: For vehicles with the multi-information display, the setting can be changed by
operating the multi-information display. (
P. 820)
ItemFunctionDefault settingCustomized setting
Illumination
(
P. 566) Time elapsed before
lights turn off
15 seconds7.5 seconds
30 seconds
Operation when the
doors are unlocked On Off
Operation after the
engine switch is turned
to the “LOCK” position On Off
Rear ceiling light On Off
Outer foot lights On Off
Intuitive
parking
assist
(
P. 314) Buzzer volume Max. Min. to Max.
Seat belt
reminder
(
P. 733) Vehicle speed linked
seat belt reminder
buzzer
On Off

820 6-2. Customization
SIENNA_U (OM45477U)
Customizing the features by using the multi-information display
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 20
seconds, the display will return to
the previous screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, then press
the “SELECT RESET” button to
select.
If you select “Exit” and press the
“SELECT RESET” button, the
display will return to the previous
screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, and press
the “SELECT RESET” button.
The illustration assumes that
“Door” was chosen in .
The current setting is indicated by
yellow text.
If you select “Return” and press
the “SELECT RESET” button, the
display will return to the “Custom
Settings” screen.
STEP1
STEP2
STEP3
STEP2
