TOYOTA SIENNA 2019 Owners Manual (in English)

361
SIENNA_OM_OM08025U_(U)
5-3. Using the storage features
5
Interior features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
Raise the hook to use.
Cargo hooks
WARNING
To avoid injury, always return the cargo hooks to their positio ns when they
are not in use.
Cargo net hooks
Pattern 1Pattern 2
NOTICE
To prevent damage to the cargo net hooks, avoid hanging things other than
a cargo net on them.

362
SIENNA_OM_OM08025U_(U)
5-3. Using the storage features
Engage the latch buckle.
Storage box (if equipped)

363
SIENNA_OM_OM08025U_(U)
5-4. Using the other interior features
5
Interior features
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover.
The light turns on when the cover
is opened.
■ To prevent battery discharge
If the vanity lights remain on for 20 minutes while the engine is off, the lights
will turn off automatically.
Sun visors
1
2
3
Vanity mirrors

364
SIENNA_OM_OM08025U_(U)
5-4. Using the other interior features
Push the lid and allow the lid to
open.
Push the lid. To first locked
position.
Conversation mirror
1
2

SIENNA_OM_OM08025U_(U)
3655-4. Using the other interior features
5
Interior features
The power outlet can be used for the following components:
12 V: Accessories that run on less than 10 A
120 V AC: Accessories t hat use less than 100 W
■12 V
Open the cover.
Power outlets
Center panel type ACenter panel type B
Luggage compartment

366
SIENNA_OM_OM08025U_(U)
5-4. Using the other interior features
■120 V AC (if equipped)
Open the cover.
Power outlet socket console
box type APower outlet socket console
box type B
Power outlet socket luggage
compartment

SIENNA_OM_OM08025U_(U)
3675-4. Using the other interior features
5
Interior features
■The power outlet can be used when
Vehicles without a smart key system
12 V: The engine switch is in the “ACC” or “ON” position.
120 V AC: The engine switch is in the “ON” position.
Vehicles with a smart key system
12 V: The engine switch is in ACCESSORY or IGNITION ON mode.
120 V AC: The engine switch is in IGNITION ON mode.
NOTICE
■ To avoid damaging the power outlet
Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter the power outlet may caus e a short cir-
cuit.
■ To prevent blown fuse
12 V
Do not use an accessory that uses more than 12 V 10 A.
120 V AC
Do not use a 120 V AC appliance that requires more than 100 W.
If a 120 V AC appliance that consumes more than 100 W is used, the pro-
tection circuit may cut the power supply.
■ To prevent battery discharge
Do not use the power outlet longer than necessary when the engi ne is not
running.
■ Appliances that may not operate properly (120 V AC)
The following 120 V AC appliances may not operate properly even if their
power consumption is under 100 W:
● Appliances with high initial peak wattage
● Measuring devices that process precise data
● Other appliances that require an extremely stable power supply

368
SIENNA_OM_OM08025U_(U)
5-4. Using the other interior features
The USB charging ports are used to supply 2.1 A of electricity at 5 V
to external devices.
The USB charging ports are for charging only. They are not desi gned
for data transfer or other purposes.
Depending on the external device, it may not charge properly. R efer to
the manual included with the dev ice before using a USB charging
port.
■Using the USB charging ports
USB charging ports
Center panel (if equipped)Console box type A
(if equipped)
Open the lid Open the lid
Console box type B
(if equipped) Auxiliary box (third seat left-
hand side)
Open the lid Ope n the auxiliary box lid and
open the lid.

SIENNA_OM_OM08025U_(U)
3695-4. Using the other interior features
5
Interior features
■The USB charging ports can be used when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ Situations in which the USB charg ing ports may not operate correctly
● If a device which consumes more than 2.1 A at 5 V is connected
● If a device designed to communicate with a personal computer, s uch as a
USB memory device, is connected
● If the connected external device is turned off (depending on de vice)
● If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun
■ About connected external devices
Depending on the connected external device, charging may occasi onally be
suspended and then start again. This is not a malfunction.
NOTICE
■ To prevent damage to the USB charging ports
● Do not insert foreign objects into the ports.
● Do not spill water or other liquids into the ports.
● When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.
● Do not apply excessive force to or impact the USB charging port s.
● Do not disassemble or modify the USB charging ports.
■ To prevent damage to external devices
● Do not leave external devices in the vehicle. The temperature i nside the
vehicle may become high, resulting in damage to an external dev ice.
● Do not push down on or apply unnecessary force to an external device or
the cable of an external device while it is connected.
■ To prevent battery discharge
Do not use the USB charging ports for a long period of time wit h the engine
stopped.

370
SIENNA_OM_OM08025U_(U)
5-4. Using the other interior features
Pull the armrest down for use.
■Adjusting the front seat armrest s with lock release button (if equipped)
Armrests
Front seatSecond seat (if equipped)
Push the armrest down while pressing the
button.
NOTICE
To prevent damage to the armrest, do not apply too much load on the arm-
rest.
