TOYOTA SIENNA 2019 Owners Manual (in English)

331
SIENNA_OM_OM08025U_(U)
5Interior features
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system ........ 332
Rear automatic air conditioning system ........ 341
Heated steering wheel/seat heaters .......... 344
• Heated steering wheel ............................ 345
• Seat heaters ................. 346 5-2. Using the interior lights
Interior lights list ................ 347• Personal/interior light main switch ................... 348
• Personal/interior
lights ............................. 348
• Rear ceiling lights ......... 349
5-3. Using the storage features List of storage features ..... 350• Glove boxes .................. 351
• Console box .................. 352
• Cup holders .................. 354
• Bottle holders ................ 356
• Door pockets................. 357
• Auxiliary boxes.............. 358
Luggage compartment features ........................... 361
5-4. Using the other interior features
Other interior features ....... 363 • Sun visors ..................... 363
• Vanity mirrors................ 363
• Conversation mirror ...... 364
• Power outlets ................ 365
• USB charging ports....... 368
• Armrests ....................... 370
• Assist grips ................... 371
• Rear side sunshades .... 372
• Grocery bag hooks ....... 373
Garage door opener.......... 374
Compass ........................... 381
Safety Connect ................. 385

332
SIENNA_OM_OM08025U_(U)
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system
■Adjusting the temperature setting
Turn the “TEMP” dial clockwise to increase the temperature and
counterclockwise to dec rease the temperature.
If is not pressed, the system will blow ambient temperature
air or heated air.
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Air conditioning controls

SIENNA_OM_OM08025U_(U)
3335-1. Using the air conditioning system and defogger
5
Interior features
■The “SYNC” button
The air conditioning system switches between individual (indica -
tor(s) off) and simultaneous (indicators on) modes.
When the air conditioning syste m is in simultaneous mode, the p as-
senger and/or rear side temperature will be synchronized with
driver side’s.
The air conditioning system switches simultaneous
Press the “SYNC” button. (indicators on)
Driver side indicator
Passenger side indicator
When the indicator is on, the
passenger side temperature will
be synchronized with driver
side.
Rear side indicator
When the indicator is on*, the
rear side temperature will be
synchronized with driver side.
*: When the rear air conditioning system is on. ( P. 335)
The air conditioning system switches individual
The temperature for the driver, passenger and/or rear seats sid e
can be adjusted separately.
When all indicators on the “SYNC” button are on: • Press the “SYNC” button. (A ll indicators will turn off.)
• The “PASS TEMP” dial is turned. (The passenger side indicator will turn off.)
• The “REAR TEMP” dial is turned. (The rear side indicator will turn off.)
When two indicators on th e “SYNC” button are on:
• Press the “SYNC” button a seco nd time. (All indicators will turn
off.)
If both the temperature of the passenger and rear seats side ar e
changed, all indicators on the button will be off.
1
2
3

3345-1. Using the air conditioning system and defogger
SIENNA_OM_OM08025U_(U)■
Adjusting the fan speed setting
Press “
” on to increase the fan speed and “ ” to
decrease the fan speed.
Press to turn the fan off.
■
Change the airflow mode
To change the air outlets, press
the “MODE” button.
The air outlets used are
switched each time the button is
pressed.
Air flows to the upper
body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and
the windshield defogger
operates.1
2
3
4

SIENNA_OM_OM08025U_(U)
3355-1. Using the air conditioning system and defogger
5
Interior features
Press (“AUTO” appears on the display).
Adjust the temperature setting.
To stop the operation, press .
■Automatic mode indicator
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
■Adjusting the temperature setting
Press the “REAR” button (indicator and rear temperature on the
display on).
Turn the “REAR TEMP” dial clockwise to increase the tempera-
ture and counterclockwise to decrease the temperature.
The air conditioning system switches between individual (the lo wer side
indicator on the “SYNC” button is off) and simultaneous (the lo wer side
indicator on the “SYNC” button is on) modes each time the “SYNC ” but-
ton is pressed.
■
Adjusting the fan speed
Press “ ” on to increase the fan speed and “ ” to
decrease the fan speed.
Press to turn the fan off.
■
Changing the air outlets
Press the “REAR MODE” button.
The air outlets switch each time the button is pressed. ( P. 342)
Using the automatic mode
Changing the rear setting
1
2
3
1
2

3365-1. Using the air conditioning system and defogger
SIENNA_OM_OM08025U_(U)■
Switching between outside air
and recirculated air modes
Press .
The mode switches between outside air mode ( appears on the
display) and recirculated air mode ( appears on the display) ea ch
time the button is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press
.
Set to outside air mode if the recirculated air mode is used. (It
may switch automatically.)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
To return to the previous mode, press again when the wind-
shield is defogged.
■
Rear window defogger, outside r ear view mirror defoggers (if
equipped) and windshield wi per de-icer (if equipped)
Defoggers are used to defog the rear window, and to remove rain -
drops, dew and frost from the outside rear view mirrors. The wi nd-
shield wiper de-icer is used to prevent ice from building up on the
windshield and wiper blades.
Press .
The defoggers and windshield wiper de-icer will automatically t urn off
after a period of time.
Other functions

SIENNA_OM_OM08025U_(U)
3375-1. Using the air conditioning system and defogger
5
Interior features
■Location of air outlets
The air outlets and air volume
changes according to the
selected air flow mode.
■Adjusting the air flow direction and opening/closing the air
outlets
Turn the knob to open o r close the vent.
Direct air flow to the le ft or right, up or down.
Air outlets
Center outletsRight and left side outlets
1
2

3385-1. Using the air conditioning system and defogger
SIENNA_OM_OM08025U_(U)
■Using automatic mode
Fan speed is adjusted automatically according to the temperatur e setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
■ When the outside temperature exceeds 75°F (24°C) and the air co ndition-
ing system is on
● In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically.
This may also reduce fuel consumption.
● Recirculated air mode is selected as a default mode when the en gine switch
is turned to the “ON” position (vehicles without a smart key sy stem) or
IGNITION ON mode (vehicles with a smart key system).
● It is possible to switch to outside air mode at any time by pre ssing .
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Pressing on will dehumidify the air from the outlets and defog the
windshield effectively.
● If you turn “A/C” off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
■ Outside/recirculated air mode
●When driving on dusty roads such as tunnels or in heavy traffic , set
to the recirculated air mode. This is effective in preventing outside air from
entering the vehicle interior. During cooling operation, setting the recircu-
lated air mode will also cool the vehicle interior effectively.
● Outside/recirculated air mode may automatically switch dependin g on the
temperature setting or the inside temperature.

SIENNA_OM_OM08025U_(U)
3395-1. Using the air conditioning system and defogger
5
Interior features
■Temperature display
The temperature display on the multi-information display can be changed.
( P. 540)
■ When
is selected for the air outlets used
For your driving comfort, air flowing to the feet may be warmer than air flow-
ing to the upper body depending on the temperature setting.
■ When the outside t emperature is low
The dehumidification function may not operate even when is pre ssed.
■ When “A/C ON” flashes in the display
Press and turn off the air conditioning system before turning it on once
more. There may be a problem in the air conditioning system if “A/C ON” con-
tinues to flash. Turn the air conditioning system off and have it inspected by
your Toyota dealer.
■ Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the out side air mode.
● During use, various odors from inside and outside the vehicle m ay enter into
and accumulate in the air conditioning system. This may then ca use odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to o utside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short peri od of time
immediately after the air conditioning system is started in aut omatic
mode.
■ Air conditioning filter
P. 434
■ Customization
Settings (e.g. linked operation) can be changed.
(Customizable features: P. 546)

3405-1. Using the air conditioning system and defogger
SIENNA_OM_OM08025U_(U)
WARNING
■To prevent the windshield from fogging up
● Do not use during cool air operation in extremely humid weathe r.
The difference between the temperature of the outside air and t hat of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
■ To prevent burns
● Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers (vehicles with outside rear view mirror defoggers ) are on.
● Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (vehicle s with wind-
shield wiper de-icer)
NOTICE
■ To prevent battery discharge
Do not leave the air conditioning system on longer than necessa ry when the
engine is stopped.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.
