key TOYOTA SOLARA 2007 Accessories, Audio & Navigation (in English)

120
Incoming call display
You can select the method of the receiving
call display.
Touch “Full” or “Icon”.
“Full” mode When a call is received,. . . . .
the Hands−free screen is
displayed and you can
operate it on the screen.
“Icon” mode The message is displayed . . . . .
on the upper side of the
screen. You can only op-
erate the steering switch.
Auto answer
When a call is received, the display auto-
matically changes to the talking screen
and you can start to talk on the phone
(without touching any button) after the
preset time.
Touch “ON” of “Auto Answer” and “” or
“+” to adjust the waiting time of auto an-
swer within 1 60 seconds.
The Bluetooth connection status at
startup
When the ignition key is in the “ACC” or
“ON” position and the Bluetoothr is auto-
matically connected, the connection
check is displayed.

124
Editing the name
When you don’t input the name, the num-
ber is displayed.
1. Touch “Name”.
2. Use the software keyboard to input the
name.
Editing the phone number
You can register a phone number in
“TEL1” and “TEL 2” separately. Up to 2
numbers a person can be registered.
1. Touch “TEL1” or “TEL2”.
2. Input the number and touch “OK”.
3. Select the desired icon.

131
Selecting a group icon
1. Touch “Icon”.
2. Select the desired icon.
Editing a group name
1. Touch “Name”.
2. Use the software keyboard to input the
name.
Deleting a group name
You can delete the group names individu-
ally or all at once. If you delete a group
name, that group will return to the default
setting (excluding “No Group”).
1. Touch “Delete” of “Group Name”.
2. Select the group you want to delete the
name of.

137
Displaying Bluetooth information
You can see or set the information of the
Bluetooth phone on the system.
“Device Name”
The name of Bluetooth phone . . . .
which is displayed on the screen.
You can change it into a desired
name.
“Bluetooth* Device Address”
The address peculiar to the sys- . . . .
tem. You cannot change it.
1. Select the desired phone and touch
“Information”.
*: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.
2. Touch “Change”.
3. When you complete the setting, touch
.
Changing a device name
You can change a device name. If you
change a device name, the name regis-
tered in your cellular phone is not
changed.
1. Touch “Change”.
2. Use the software keyboard to input the
device name.

138
Changing the Bluetooth settings
You can change the display and settings of
Bluetooth information on the system.
The information displays the following items.
“Device Name”
The name in the Bluetooth net- . . . .
work. You can change it.
“Passkey”
The password when you register . . . .
your cellular phone in the system.
You can change it into the figure of
4−8 digits.
“Bluetooth* Device Address”
The address peculiar to the sys- . . . .
tem. You can not change it. If you
have registered two Bluetooth
phones with the same Device
Name or Passkey and you cannot
distinguish one from the other, re-
fer to it.
When you change the device name or
Passkey, do the followings.
1. Touch “Bluetooth*”.
2. Touch “Change” of “Device Name” or
“Passkey”.
*: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.
3. Use the software keyboard to input the
device name.
You can input up to 20 characters.
4. Input a Passkey with 4 8 digits.
When you touch , the input number is de-
leted.

151
8“AUDIO” button
Push this button to display the audio
control screen. For details, see page
152.
9“SEEK/TRACK” button
Push either side of this button to seek up
or down for a station, or to access a de-
sired track or file. For details, see pages
156, 160, 166 and 169.
10“PWR·VOL” knob
Push this knob to turn the audio system
on and off, and turn it to adjust the volu-
me. For details, see page 152.
Using your audio system —
— Some basics
This section describes some of the basic fea-
tures of your audio system. Some information
may not pertain to your system.
Your audio system works when the ignition
key is in the “ACC” or “ON” position.
NOTICE
To prevent the battery from being dis-
charged, do not leave the audio system
on longer than necessary when the en-
gine is not running.
Speech command system
By pushing the switch above, you can op-
erate the speech command system.
For the operation of the speech command
system and the list of commands, see pages
141 and 143.
