SERVICE SPECIFICATIONS
SERVICE DATA
 Refrigerant charge volume 700 + 50g. 24.96 + 1.76 oz.
 Idle speed
 2JZ±GE (M/T)

  Magnetic clutch not engaged

 Approx. 700 rpm
  Magnetic clutch engaged Approx. 900 rpm
 2JZ±GE (A/T)

  Magnetic clutch not engaged
 Approx. 700 rpm
  Magnetic clutch engaged Approx. 800 rpm
 2JZ±GTE
  Magnetic clutch not engaged Approx. 650 rpm
  Magnetic clutch engaged

 Approx. 800 rpm
TORQUE SPECIFICATIONS

 Part tightened
 NVm
 kgfVcm
 ftVlbf
 Suction hose x Compressor 10 100 7
 Discharge hose x Compressor 10 100 7
 Compressor x Engine Stud bolt 26 265 19.2
 Other bolts and nut

 52

 530

 38.3
 Liquid tube x Receiver 5.4 55 48 in.Vlbf
 Liquid tube x Condenser 10 100 7

 Discharge tube x Condenser
 10
 100
 7
 Expansion valve x Evaporator 5.4 55 48 in.Vlbf
 Suction tube x A/C unit 10 100 7
 Liquid tube x A/C unit 10 100 7
 Pressure switch x Liquired tube

 10

 100

 7
 Revolution detecting sensor x Compressor 6.0 60 52 in.Vlbf
 Condenser upper mounting x Body 4.1 42 36 in.Vlbf

 Liquid lines
 10
 100
 7
 Discharge lines 10 100 7
 Suction lines 10 100 7
