TOYOTA SUPRA 1995 Service Repair Manual

SERVICE SPECIFICATIONS
SERVICE DATA










Starter









Rated voltage and output power
No±load characteristics Current
rpm
Brush length STD
Minimum
Spring installed load
Commutator
Diameter STD
Minimum
Undercut depth STD
Minimum
Circle runout Maximum









12 V 1.4 kW
90 A or less at 11.5 V
3,000 rpm or more
15.5 mm (0.610 in.)
10.0 mm (0.394 in.)
18±24 N (1.79±2.41 kgf, 3.9±5.3 lbf)
30.0 mm (1.181 in.)
29.0 mm (1.412 in.)
0.6 mm (0.024 in.)
0.2 mm (0.008 in.)
0.05 mm (0.0020 in.)
TORQUE SPECIFICATIONS
 Part tightened NVm kgfVcm ftVlbf
 End cover X Brush holder 1.5 15 13 in.Vlbf
 Starter housing X Magnetic switch 5.9 60 52 in.Vlbf
 End cover X Starter housing 5.9 60 52 in.Vlbf Lead wire of field frame X Magnetic switch 7.9 81 70 in.Vlbf Starter X Clutch housing 39 400 29
± STARTING SYSTEMSERVICE SPECIFICATIONSST±13

STEERING
SR±1

PRECAUTION
wCare must be taken to replace parts properly because they could affect the
performance of the steering system and result in a driving hazard.
wThe steering wheel pad has an SRS (Supplemental Restraint System) airbag built in,
so take all due precautions when handling it. For more details, see the RS section.
TROUBLESHOOTING
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, repair or replace these parts.
SA±3SA±4SR±7SA±27SR±49SR±47SA±16
Tires (improperly inflated)Steering column (Binding)Suspension arm ball joints (Worn)Steering system joints (Worn)Drive belt (Loose)Fluid level (Low)Front wheel alignment (Incorrect)Electronic controlSolenoid valveSteering gear housingSliding yoke (Worn)Front wheel bearing (Worn)
Hard steering
Abnormal noise
Excessive play
Poor return
See page
Parts
Name
Trouble
SA±30
SR±2± STEERINGTROUBLESHOOTING

PREPARATION
SST (SPECIAL SERVICE TOOLS)
09608±30012
(09608±04030)
09612±00012
09612±30012
09616±00010
09620±30010
(09624±30010)
(09626±30010)
(09627±30010)
(09631±00020)
09630±24013
(09620±24010)
(09620±24020)
Front Hub & Drive Pinion Bearing
Tool Set
Front Hub Inner Bearing Cone
Replacer
Rack & Pinion Steering Rack
Housing Stand
Steering Worm Bearing Puller
Vane pump shaft
Rack housing bearing and oil seal
Control Valve Shaft
Rack housing oil seal
Rack housing bearing
Steering Gear Box Replacer Set
Steering worm Bearing Adjusting
Socket
Steering Sector Shaft Oil Seal
Replacer
Steering Worm Front Bearing
Replacer
Steering Sector Shaft Bushing
Replacer
Handle
Steering Rack Oil Seal Tool Set
Cylinder end stopper
Valve Cup Oil Seal Remover
Valve Cup Oil Seal Replacer
Control valve housing oil seal
and bearing
Control valve housing oil seal
± STEERINGPREPARATIONSR±3

(09620±24030)
09631±10030
09631±12020
09631±12071
09631±20031
09631±20081
Valve Cup Bearing Replacer
Oil Seal Remover
Handle
Steering Rack Oil Seal Test Tool
Control valve housing bearing
Control valve teflon rings
Rack housing oil seal and spacer
Seal Ring Tool
Oil Seal ªBº Remover
Vane pump front housing oil seal
09631±20102
09631±22070
09631±32020
09633±00020
09910±00015
(09911±00011)
(09912±00010)
09922±10010)
Steering Rack Cover ªHº
Seal Ring Tool
Oil Seal Replacer
Power Steering Hose Nut Wrench
Puller Clamp
Puller Set
Variable Open Wrench
Puller Slide Hammer
Rack housing oil seal
Hydraulic reaction chamber teflon
rings
Tilt No.2 bolt
Tilt No.2 bolt
SR±4± STEERINGPREPARATION

(09957±04010)
09950±40010
(09958±04010)
09950±50010
(09951±05010)
(09952±05010)
(09953±05020)
(09954±05020)
09960±10010
Puller B Set
Attachment
Holder
Puller C Set
Slide Arm
Hanger 150
Center Bolt 150
Variable Pin Wrench Set
Claw No.2
Vane pump pulley
Main shaft assembly
Main shaft assembly
RECOMMENDED TOOLS
Total preload
Steering wheel pad
Compression spring
Snap Ring No.1 Expander
TOYOTA Electrical Tester Set
Torx Socket T30
Torque Wrench (30 kgf
cm)09025±00010
09042±00010
09082±00050
09905±00012
± STEERINGPREPARATIONSR±5

LUBRICANT
EQUIPMENT
SSM (SPECIAL SERVICE MATERIALS)
09905±00013Snap ring Pliers
Power steering fluid
Total1.0 liters (1.1 US qts, 0.9 Imp.qts)ATF DEXRON[
II
PS vane pump
PS vane pump
Steering rack
Rotor and vane plate
Vacuum gauge
Torque wrench
Pull scale
Oil pressure gauge
Micrometer
Feeler gauge
Caliper gauge
Dial indicator
Steering effort
Gear housing
08833±00080Adhesive 1344,
THREE BOND 1344,
LOCTITE 242 or equivalentRack housing cap
rack guide spring cap
Rack guide spring cap lock nut
ItemCapacityClassification
SR±6± STEERINGPREPARATION

ON±VEHICLE INSPECTION
STEERING WHEEL FREEPLAY CHECK
With the vehicle stopped and tires pointed straight ahead,
rock the steering wheel gently back and forth with light finger
pressure.
Freeplay should not exceed the maximum.



 Freeplay mm(in.)
Maximum30 (1 18) Maximum30 (1.18)
IDLE±UP CHECK
1. TURN AIR CONDITIONING SWITCH OFF
2. CHECK IDLE±UP
(a) Start engine and run it at idle.
(b) Fully turn the steering wheel.
(c) Check that the engine speed decreases when the air control
valve hose is pinched.
(d) Check that the engine speed increases when the hose is
released.
FLUID LEVEL CHECK
1. KEEP VEHICLE LEVEL
2. CHECK FLUID LEVEL
Check the fluid level in the reservoir.
If necessary, add fluid.
Fluid:
ATF DEXRON[ II
HINT: Check that the fluid level is within the HOT LEVEL
range on the dipstick of the reservoir cap. If the fluid is cold,
check that it is within the COLD LEVEL range.
3. BOOST FLUID TEMPERATURE
(a) Start the engine and run it at idle.
(b) Turn the steering wheel from lock to lock several times to
boost fluid temperature.
Fluid temperature:
805C (1765F)
± STEERINGON±VEHICLE INSPECTIONSR±7

4. CHECK FOR FOAMING OR EMULSIFICATION
If there is foaming or emulsification, bleed power steering
system.
(See page SR±9)
5. CHECK FLUID LEVEL RISE
(a) With the engine idling, measure the fluid level in the reservoir.
(b) Stop the engine.
(c) Wait a few minutes and remeasure the fluid level in the
reservoir.



  Fluid level rise mm (in.)
Maximum5(02) Maximum5 (0.2)
If a problem is found, bleed power steering system.
(See page SR±9)
6. CHECK FLUID LEVEL
POWER STEERING FLUID
REPLACEMENT
1. JACK UP FRONT OF VEHICLE AND SUPPORT IT WITH
STANDS
2. DRAIN FLUID
(a) Disconnect the return hose from the PS vane pump.
(b) Turn the steering wheel from lock to lock.
3. FILL OIL RESERVOIR
(a) Fill oil reservoir with fresh fluid.
Fluid:
ATF DEXRON[ II
(b) Start engine.
(c) After 1 or 2 seconds, fluid will begin to discharge from the
return hose.
(d) Stop the engine immediately.
NOTICE: Take care that some fluid remains in the oil res-
ervoir.
(e) Repeat steps (a), (b), (c) and (d) until there is no more air in
fluid.
(f) Connect the return hose.
4. BLEED POWER STEERING SYSTEM
(See page SR±9) SR±8
± STEERINGON±VEHICLE INSPECTION

POWER STEERING SYSTEM BLEEDING
1. JACK UP FRONT OF VEHICLE AND SUPPORT IT WITH
STANDS
2. TURN STEERING WHEEL
With the engine stopped, turn the steering slowly from lock
to lock several times.
NOTICE: Take care that some fluid remains in the oil res-
ervoir.
3. LOWER VEHICLE
4. START ENGINE
Run the engine at idle for a few minutes.
5. TURN STEERING WHEEL
(a) With the engine at idling, turn the wheel to left or right full lock
and keep it there for 2±3 seconds, then turn the wheel to the
opposite full lock and keep it there for 2±3 seconds.
(b) Repeat (a) several times.
6. STOP ENGINE
7. CHECK FOR FOAMING OR EMULSIFICATION
If the system has to be bled twice specifically because of
foaming or emulsification, check for fluid leaks in the system.
8. CHECK FLUID LEVEL
(See page SR±7)
± STEERINGON±VEHICLE INSPECTIONSR±9
