PROBLEM SYMPTOM CONFIRMATION
Taking into consideration the results of the customer problem analysis, try to reproduce the symptoms of
the trouble. If the problem is that the transmission does not up±shift, does not down±shift, or the shift point
is too high or too low, conduct the following road test to confirm the automatic shift schedule and simulate
the problem symptoms.
ROAD TEST
NOTICE: Do the test at normal A/T fluid operating temp.
50±805C (122±1765F).
1. D POSITION TEST (NORM PATTERN)
Shift into the D position and keep the accelerator pedal
constant at the full throttle valve opening position, and check
the following points:
(a) Check up±shift operation.
Check that 1±2, 2±3 and 3±O/D up±shift takes place, at the
shift point shown in the automatic shift schedule.
(See page AT2±116)
HINT:
(1) O/D Gear Up±shift Prohibition Control.
wCoolant temp. is 605C (1405F) or less.
wIf there is a 10 km/h (6 mph) difference between the set
cruise control speed and vehicle speed.
wO/D main switch is pushed ON.
`(During O/D OFF, indicator light lights up.)
(2) O/D Gear Lock±up Prohibition Control.
wBrake pedal is depressed.
wCoolant temp. is 605C (1405F) or less.
(b) Check for shift shock and slip.
Check for shock and slip at the 1±2, 2±3, and 3±O/ D up±
shifts.
(c) Check for abnormal noise and vibration.
Run at the D position lock±up or O/D gear and check for ab-
normal noise and vibration.
HINT: The check for the cause of abnormal noise and vibra-
tion must be performed very thoroughly as it could also be
due to loss of balance in the, torque converter clutch, etc.
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTINGAT2±37

(d) Check kick±down operation.
While running in the D position, 2nd, 3rd and O/D gears,
check to see that the possible kick±down vehicle speed limits
for 2
" 1, 3 " 2 and O/D " 3 kick±downs conform to those
indicated on the automatic shift schedule.
(See page AT2±116)
(e) Check for abnormal shock and slip at kick±down.
(f) Check the lock±up mechanism.
(1) Drive in D position, O/D gear, at a steady speed (lock±up
ON) of about 59 km/h (37 mph).
(2) Lightly depress the accelerator pedal and check that the
RPM does not change abruptly.
If there is a big jump in RPM, there is no lock±up.
2. D POSITION TEST (MANU PATTERN)
Shift into the D position and hold the accelerator pedal
constant at the full throttle valve opening position, and check
the following points:
(a) Check up±shift operation.
2±3 and 3±O/D up shifts should take place, and shift points
should conform to those shown in the automatic shift sched-
ule.
(See page AT2±116)
HINT:
wO/D up±shift or lock±up will not occur when the engine
coolant temp. is below 605C (1405F) and speed is under
60 km/h (37 mph), or if there is a 10 km/h (6 mph)
difference between the set cruise control speed.
w3rd up±shift or lock±up will not occur when engine
coolant temp. is 355C (955F) and speed is under 40 km/h
(25 mph).
(b) Check for shift shock and slip.
In the same manner, check the shock slip at the 2
" 3 and
3
" O/D up±shifts. AT2±38
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTING

(c) Check for abnormal noise and vibration.
Run at the D position lock±up or O/D gear and check for ab-
normal noise and vibration.
HINT: The check for the cause of abnormal noise and vibra-
tion must be made with extreme care as it could also be due
to loss of balance in the propeller shaft, differential, torque
converter clutch, etc.
(d) Check kick±down operation.
While running in the D position, 2nd, 3rd and O/D gears,
check to see that the possible kick±down vehicle speed limits
for 3
" 2 and O/D " 3 kick±downs conform to those indicated
on the automatic shift schedule.
(See page AT2±116)
(e) Check for abnormal shock slip at kick±down.
(f) Check the lock±up mechanism.
(1) Drive in D position, O/D gear, at a steady speed (lock±up
ON) of about 195 km/h (121 mph).
(2) Lightly depress the accelerator pedal and check that the
engine RPM does not change abruptly.
If there is big jump in the engine RPM there is no lock ±up.
3. 2 POSITION TEST (NORM PATTERN)
Shift into the 2 position and, while driving with the accelerator
pedal held constantly at the full throttle valve opening posi-
tion, check on the following points:
(a) Check up±shift operation.
Check to see that the 1
" 2 up±shift takes place and that the
shift point conforms to the automatic shift schedule.
(See page AT2±116)
HINT: There is no O/D up±shift and lock±up in the 2 position.
(b) Check engine braking.
While running in the 2 position and 2nd gear, release the ac-
celerator pedal and check the engine braking effect.
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTINGAT2±39

(c) Check for abnormal noise at acceleration and deceleration,
and for shock at up±shift and down±shift.
4. 2 POSITION TEST (MANU PATTERN)
Shift into the 2 position and while driving with the accelerator
pedal held constantly at the full throttle valve opening posi-
tion, push in one of the pattern selectors and check these
points:
(a) Check no up±shift.
While running in the 2 position, check to see that there is no
up±shift to 3rd gear.
(b) Check engine braking.
While running in the 2 position and 2nd gear, release the ac-
celerator pedal and check the engine braking effect.
(c) C h e c k f o r abnormal noise during acceleration and
deceleration.
5. L POSITION TEST
Shift into the L position and while driving with the accelerator
pedal held constantly at the full throttle valve opening posi-
tion, check these points:
(a) Check no up±shift.
While running in the L position, check that there is no up±shift
to 2nd gear. AT2±40
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTING

(b) Check engine braking
While running in the L position, release the accelerator pedal
and check the engine braking effect.
(c) C h e c k f o r abnormal noise during acceleration and
deceleration.
6. R POSITION TEST
Shift into the R position and while starting at full throttle,
check for slipping.
CAUTION: Before conducting this test ensure that the
test area is free from personnel and obstruction.
7. P POSITION TEST
Stop the vehicle on a gradient (more than 55) and after shift-
ing into the P position, release the parking brake.
Then check to see that the parking lock pawl holds the ve-
hicle in place.
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTINGAT2±41

PRELIMINARY CHECK
1. CHECK FLUID LEVEL
HINT:
wDrive the vehicle so that the engine and transmission
are at normal operating temperature.
Fluid temp.: 70±805C (158±1765F)
wOnly use the COOL position on the dipstick as a rough
reference when the fluid is replaced or the engine does
not run.
(a) Park the vehicle on a level surface and set the parking brake.
(b) With the engine idling and the brake pedal depressed, shift
the shift lever into all positions from P to L position and return
to P position.
(c) Pull out the oil level gauge and wipe it clean.
(d) Push it back fully into the pipe.
(e) Pull it out and check that the fluid level is in the HOT position.
If the level is at the low side, add fluid.
Fluid type:
ATF TYPE T±II or Equivalent
NOTICE: Do not overfill
2. CHECK FLUID CONDITION
If the fluid smells burnt or is black, replace it.
3. REPLACE TRANSMISSION FLUID
(a) Remove the drain plug and drain the fluid.
(b) Reinstall the drain plug securely.
(c) With the engine OFF, add new fluid through the oil filler pipe.
Fluid type:
ATF TYPE T±II or Equivalent
Capacity:
Dry fill: 8.2 liters (8.7 US qts, 7.2 Imp. qts)
Drain and refill: 1.9 liters (2.0 US qts, 1.6 Imp. qts)
(d) Start the engine and shift the shift lever into all positions from
P to L position and then shift into P position.
(e) With the engine idling, check the fluid level. Add fluid up to the
COOL level on the dipstick.
(f) Check the fluid level at the normal operating temperature
70±805C (158±1765F) and add as necessary.
NOTICE: Do not overfill.
4. CHECK FLUID LEAKS
Check for leaks in the transmission.
If there are leaks, it is necessary to repair or replace O ±rings,
seal packings, oil seals, plugs or other parts. AT2±42
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTING

5. INSPECT AND ADJUST SHIFT LEVER POSITION
When shifting the shift lever from the N position to other posi-
tions, check that the lever can be shifted smoothly and accu-
rately to each position and that the position indicator correctly
indicates the position.
If the indicator is not aligned with the correct position, carry
out the following adjustment procedures:
(a) Loosen the nut on the control shaft lever.
(b) Push the control shaft lever fully rearward.
(c) Return the control shaft lever 2 notches to N position.
(d) Set the shift lever to N position.
(e) While holding the shift lever lightly toward the R position side,
tighten the shift lever nut.
(f) Start the engine and make sure that the vehicle moves
forward when shifting the lever from the N to D position and
reverses when shifting it to the R position.
6. INSPECT AND ADJUST PARK/NEUTRAL POSITION
SWITCH
Check that the engine can be started with the shift lever only
in the N or P position, but not in other positions.
If not as stated above, carry out these adjustment proce-
dures:
(a) Loosen the park/neutral position switch bolt and set the shift
lever to the N position.
(b) Align the groove and neutral basic line.
(c) Hold in position and tighten the bolt.
Torque: 12 NVm (125 kgfVcm, 9 ftVlbf)
For continuity inspection of the park/neutral position switch,
see page AT2±101.
7. INSPECT IDLE SPEED
Idle speed:
650+50 rpm
(In N position and air conditioner OFF)
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTINGAT2±43

MECHANICAL SYSTEM TESTS
STALL TEST
The object of this test is to check the overall performance of the transmission and engine by measuring
the stall speeds in the D and R positions.
NOTICE:
wDo the test at normal operating fluid temp. 50±805C (122±1765F).
wDo not continuously run this test longer than 5 seconds.
wTo ensure safety, conduct this test in a wide, clear, level area which provides good traction.
wThe stall test should always be carried out in pairs. One technician should observe the conditions of
wheels or wheel stoppers outside the vehicle while the other is doing the test.
MEASURE STALL SPEED
(a) Chock the 4 wheels.
(b) Fully apply the parking brake.
(c) Connect a tachometer to the engine.
(d) Start the engine and check idle.
(e) Keep you foot pressed firmly on the brake pedal.
(f) Shift into the D position. Fully depress the accelerator pedal.
Quickly read the stall speed.
Stall speed:
2,600+150 rpm
(g) Do the same test in R position.
Quickly read the stall speed.
Stall speed:
2,600+150 rpm
AT2±44± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTING

EVALUATION
 Problem Possible cause

 (a) Stall speed low in D and Rpositions
 Engine output may be insufficient.
 Stator one±way clutch is operating properly
HINT:

(a) Stall speed low in D and R positions. HINT:
If more than 600 rpm below the specified value, the
torque converter clutch could be faulty.

 (b) Stall speed high in Dposition
 Line pressure too low.
 Forward clutch slipping


(b) Stall speed high in D position Forward clutch sli ing
 No.2 one±way clutch not operating properly
 O/D one±way clutch not operating properly

 (c) Stall speed high in Rposition
 Line pressure too low
 Direct clutch slipping


(c) Stall speed high in R position. Direct clutch sli ing
 First and reverse brake slipping
 O/D clutch slipping

(d) Stall speed high in D and Rpositions
 Line pressure too low
Improper fluid level (d) Stall speed high in D and R positions. Improper fluid level
 O/D one±way clutch not operating properly
± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTINGAT2±45

TIME LAG TEST
When the shift lever is shifted while the engine is idling, there will be a certain time lapse or lag before the
shock can be felt. This is used for checking the condition of the O/D direct clutch, forward clutch, direct
clutch, and first and reverse brake.
NOTICE:
wDo the test at normal operating fluid temp. 50±805C (122±1765F).
wBe sure to allow 1 minute interval between tests.
wTake 3 measurements and take the average value.
MEASURE TIME LAG
(a) Fully apply the parking brake
(b) Start the engine and check idle speed.
Idle speed:
650+50 rpm (In N position and air conditioner OFF)
(c) Shift the shift lever from N to D position. Using a stop watch, measure the time it takes from shifting the
lever until the shock is felt.
In same manner, measure the time lag for N " R.
Time lag:
N
"D Less than 1.2 seconds
N
"R Less than 1.5 seconds
AT2±46± A340E (2JZÐGTE) AUTOMATIC TRANSMISSIONTROUBLESHOOTING
