TOYOTA SUPRA 1997 Service Repair Manual

SF0HU-01
S03269
EGR Gas Temperature Sensor
EGR Gas Temperature
Sensor Connector SF-76
- SFI (2JZ-GTE)EXHAUST GAS RECIRCULATION (EGR) GAS
TEMPERATURE SENSOR
1402 Author
: Date
:
1997 SUPRA (RM502U)
EXHAUST GAS RECIRCULATION (EGR) GAS
TEMPERATURE SENSOR
COMPONENTS

SF0HV-01
P03193
Oil
- SFI (2JZ-GTE)EXHAUST GAS RECIRCULATION (EGR) GAS
TEMPERATURE SENSORSF-77
1403 Author
: Date
:
1997 SUPRA (RM502U)
INSPECTION
1. REMOVE EGR GAS TEMPERATURE SENSOR
2. INSPECT EGR GAS TEMPERATURE SENSOR
Using an ohmmeter, measure the resistance between the ter-
minals.
Resistance:
At 50°C (122°F)64 - 97 kW
At 100°C (212°F)11 - 16 kW
At 150°C (302°F)2 - 4 kW
If the resistance is not as specified, replace the sensor.
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
3. REINSTALL EGR GAS TEMPERATURE SENSOR

SF0I4-01
P11410
Turbo Pressure
Sensor
Turbo Pressure Sensor
Connector
Vacuum Hose SF-78
- SFI (2JZ-GTE)TURBO PRESSURE SENSOR
1404 Author
: Date
:
1997 SUPRA (RM502U)
TURBO PRESSURE SENSOR
COMPONENTS

SF0I5-01
P11390
Disconnect
P11419
Voltmeter
E2VC
P11984
P12022
Disconnect
- SFI (2JZ-GTE)TURBO PRESSURE SENSOR
SF-79
1405 Author
: Date
:
1997 SUPRA (RM502U)
INSPECTION
1. INSPECT POWER SOURCE VOLTAGE OF TURBO
PRESSURE SENSOR
(a) Disconnect the turbo pressure sensor connector.
(b) Turn the ignition switch ON.
(c) Using a voltmeter, measure the voltage between connec-
tor terminals VC and E2 of the wiring harness side.
Voltage: 4.5 - 5.5 V
(d) Turn the ignition switch OFF.
(e) Reconnect the turbo pressure sensor connector.
2. INSPECT SUPPLY POWER OF TURBO PRESSURE
SENSOR
(a) Disconnect the ECM from the ECU bracket.
(See page SF-86)
(b) Install SST (check harness) between the ECM and wiring
connectors.
(See page DI-164)
SST 09990-01000
(c) Turn the ignition switch ON.
(d) Disconnect the vacuum hose from the turbo pressure
sensor.

Z09082
VoltmeterVacuum
E2PIMSSTECMApplied
Vacuum
kPa
mmHg
in. Hg.
Voltage
drop V13.3
100
3.9426.7 40.0 53.3 66.7
200
7.87
300
11.81400
15.75500
19.69
0.15 -
0.350.4 -
0.60.65 -
0.850.9 -
1.11.15 -
1.35
P11986
Insert SF-80
- SFI (2JZ-GTE)TURBO PRESSURE SENSOR
1406 Author
: Date
:
1997 SUPRA (RM502U)
(e) Connect a voltmeter to terminals PIM and E2 of the ECM,
and measure the output voltage under ambient atmo-
spheric pressure.
(f) Apply vacuum to the turbo pressure sensor in 13.3 kPa
(100 mmHg, 3.94 in.Hg) segments to 66.7 kPa (500
mmHg, 19.69 in.Hg).
(g) Measure the voltage drop from step (c) above for each
segment.
Voltage drop:
(h) Remove the SST.
SST 09990-01000
(i) Reinstall the ECM. (See page SF-86)
(j) Reconnect the vacuum hose to the turbo pressure sen-
sor.

SF0I6-01
Z16477
Heated Oxygen Sensor Connector
Front Lower Arm Bracket
Stay
Upper Front Crossmember
Extension Heated
Oxygen
Sensor
(Bank 1
Sensor 2)Front Driver's Seat
Floor Carpet
Heated Oxygen
Sensor Connector
for Sensor Side
Heated Oxygen
Sensor Connector
for Wiring Side
Heated Oxygen Sensor
(Bank 1 Sensor 2)

Gasket Bank 1 Sensor 2 Bank 1 Sensor 1

Non-reusable part
- SFI (2JZ-GTE)HEATED OXYGEN SENSOR
SF-81
1407 Author
: Date
:
1997 SUPRA (RM502U)
HEATED OXYGEN SENSOR
COMPONENTS

SF0I7-01
P11993
Ohmmeter
+BHT Bank 1 Sensor 1
P11483
Ohmmeter
+BHT Bank 1 Sensor 2 SF-82
- SFI (2JZ-GTE)HEATED OXYGEN SENSOR
1408 Author
: Date
:
1997 SUPRA (RM502U)
INSPECTION
1. INSPECT HEATER RESISTANCE OF HEATED
OXYGEN SENSOR (BANK 1 SENSOR 1)
(a) Disconnect the oxygen sensor connector.
(b) Using an ohmmeter, measure the resistance between the
terminals +B and HT.
Resistance: 11 - 16 W at 20°C (68°F)
If the resistance is not as specified, replace the sensor.
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
(c) Reconnect the oxygen sensor connector.
2. INSPECT HEATER RESISTANCE OF HEATED
OXYGEN SENSOR (BANK 1 SENSOR 2)
(a) Remove the driver's seat.
(b) Take out the console box side of the floor carpet.
(c) Disconnect the oxygen sensor connector.
(d) Using an ohmmeter, measure the resistance between the
terminals +B and HT.
Resistance: 11 - 16 W at 20°C (68°F)
If the resistance is not as specified, replace the sensor.
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
(e) Reconnect the oxygen sensor connector.
(f) Reinstall the floor carpet.
(g) Reinstall the driver's seat.

SF0I8-01
P20904
Fuel Pump ECU
Fuel Pump ECU
Connector
RH Deck Trim
Side Board
Rear Deck Trim CoverInner Quarter
Wheel Hose Cover
Stay Support Cover
Removal Roof Stay
Service Hole Cover
Floor Carpet
x4
x3
- SFI (2JZ-GTE)FUEL PUMP ECU
SF-83
1409 Author
: Date
:
1997 SUPRA (RM502U)
FUEL PUMP ECU
COMPONENTS

SF0IA-01
Z16615
Floor Carpet
ECM Protector
ECM
ECM Connector
Scuff Plate
- SFI (2JZ-GTE)ENGINE CONTROL MODULE (ECM)
SF-85
1411 Author
: Date
:
1997 SUPRA (RM502U)
ENGINE CONTROL MODULE (ECM)
COMPONENTS

SF0IB-01
P11983
P11985
Bolt
Z06725
(Before Connection) (After Connection)
Connector Bolt
Collar
Stopper
Less than 1 mmFemale
Nut
Male
Connector
P11986
Insert SF-86
- SFI (2JZ-GTE)ENGINE CONTROL MODULE (ECM)
1412 Author
: Date
:
1997 SUPRA (RM502U)
INSPECTION
1. DISCONNECT NEGATIVE (-) TERMINAL CABLE
FROM BATTERY
2. REMOVE SCUFF PLATE
3. REMOVE ECM PROTECTOR
(a) Take out the front side of the floor carpet.
(b) Remove the 2 nuts and ECM protector.
4. REMOVE ECM
(a) Remove the nut, and disconnect the ECM from the floor
panel.
(b) Fully loosen the bolt and disconnect the 2 ECM connec-
tors, and remove the ECM.
5. INSPECT ECM
(See page DI-164)
6. REINSTALL ECM
(a) Connect the 2 ECM connectors.

Match the male connector correctly with the female
connector, then press them together.

Tighten the bolt.
Make sure the connector is completely connected
by tightening the bolt until there is a clearance of
less than 1 mm (0.04 in.) between the bottom of the
male connector and the end of the female connec-
tor.
(b) Install the ECM with the nut.
7. REINSTALL ECM PROTECTOR
8. REINSTALL SCUFF PLATE
9. RECONNECT NEGATIVE (-) TERMINAL CABLE TO
BATTERY
