TOYOTA SUPRA 1997 Service Owner's Guide

PR02H-01
- PROPELLER SHAFTTROUBLESHOOTING
PR-1
1674 Author
: Date
:
1997 SUPRA (RM502U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, replace these parts.
SymptomSuspect AreaSee page
Noise
1. Center support bearing (Worn)
2. Sleeve yoke spline (Worn)
3. Spider bearing (Worn or stuck)PR-7
-
PR-7
Vibration
1. Transmission extension housing rear bushing (Runout)
2. Sleeve yoke spline (Stuck)
3. Propeller shaft (Runout)
4. Propeller shaft (Imbalance)-
-
PR-7
-

PR06W-01
R06873
R06872
SST
R07096
120°
Phasemarks
- PROPELLER SHAFTPROPELLER SHAFT ASSEMBLY
PR-1 1
1684 Author
: Date
:
1997 SUPRA (RM502U)
INSTALLATION
1. 2JZ-GE:
INSTALL PROPELLER SHAFT
(a) Apply grease to the flexible coupling centering bushings.
Grease:
Molybdenum disulfide lithium base, NLGI No.2.
(b) Remove the SST.
(c) Install the propeller shaft to the transmission.
(d) Insert the propeller shaft from the vehicle's rear and con-
nect the transmission and differential.
NOTICE:
Support the center support bearing by hand so that the
transmission and intermediate shaft, and propeller shaft
and differential, remain in a straight line.
(e) Temporarily install the 2 center support bearing set bolts
with the adjusting washers.
HINT:
Use the adjusting washers which were removed.
(f) Align the matchmarks and install the propeller shaft on
the differential with the 3 bolts, washers and nuts.
NOTICE:
Bolts should be inserted from the propeller shaft side.
Torque: 79 N´m (805 kgf´cm, 58 ft´lbf)
(g) If using a new propeller shaft.
(1) w/ Phasemarks:
Install the propeller shaft phasemarks and differen-
tial phasemarks so the their respective alignment
phasemarks match.
If the propeller shaft phasemarks and differential
phasemarks do not align, install the propeller shaft
and differential alignment phasemarks as close to-
gether as possible.
(2) w/o Phasemarks:
Install the propeller shaft.

R07250
12.5 ± 1 mm (0.492 ± 0.04 in.)
R06873
Z10404
12.5 ± 1 mm (0.492 ± 0.04 in.) PR-12
- PROPELLER SHAFTPROPELLER SHAFT ASSEMBLY
1685 Author
: Date
:
1997 SUPRA (RM502U)
(h) Torque the 2 center support bearing set bolts.
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
HINT:
Adjust the center support bearing to keep the dimension, as
shown with the vehicle in the unladen condition.
Under the same condition, check if the center line of the center
support bearing is at right angles to the shaft axial direction.
2. 2JZ-GTE:
INSTALL PROPELLER SHAFT
(a) Apply grease to the flexible coupling centering bushings.
Grease:
Molybdenum disulfide lithium base, NLGI No.1 or
No.2.
(b) Align the matchmarks on the flanges and connect the
flanges with the 4 nuts and washers.
(c) Torque the 4 nuts.
Torque: 56 N´m (570 kgf´cm, 41 ft´lbf)
(d) Insert the propeller shaft from the vehicle's rear and con-
nect the transmission and differential.
NOTICE:
Support the center support bearing by hand so that the
transmission and intermediate shaft, and propeller shaft
and differential, remain in a straight line.
(e) Temporarily install the 2 center support bearing set bolts
with the adjusting washers.
HINT:
Use the adjusting washers which were removed.
(f) Align the matchmarks and install the propeller shaft on
the differential with the 3 bolts, washers and nuts.
NOTICE:
Bolts should be inserted from the propeller shaft side.
Torque: 79 N´m (805 kgf´cm, 58 ft´lbf)
(g) Torque the 2 center support bearing set bolts.
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
HINT:
Adjust the center support bearing to keep the dimension, as
shown with the vehicle in the unladen condition.
Under the same condition, check if the center line of the center
support bearing is at right angles to the shaft axial direction.

R06864
SST
- PROPELLER SHAFTPROPELLER SHAFT ASSEMBLY
PR-13
1686 Author
: Date
:
1997 SUPRA (RM502U)
(h) Using SST, torque the adjust nut.
SST 09922-10010
Torque: 50 N´m (515 kgf´cm, 37 ft´lbf)
HINT:
Use torque wrench with a fulcrum length of 34.5 cm (13.6 in.).
3. ADJUST PROPELLER SHAFT JOINT ANGEL (See
page PR-14)
NOTICE:
The joint angle should be checked when the propeller shaft
is removed and installed.
4. NORMAL ROOF:
INSTALL CENTER FLOOR CROSSMEMBER BRACE
Install the center floor crossmember brace and 4 bolts.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
5. SPORT ROOF:
INSTALL CENTER FLOOR CROSSMEMBER BRACE
Install the center floor crossmember brace and 6 bolts.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
6. INSTALL HEAT INSULATOR
Install the heat insulator and torque the 4 nuts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
7. INSTALL EXHAUST PIPE (See page EM-94)
8. INSTALL OXYGEN SENSOR
Install the oxygen sensor with heat insulator and torque the 2
nuts.
Torque: 44 N´m (450 kgf´cm, 34 in.´lbf)

PR02N-02
R06878
R06879
R06880
SST
R01139
SST PR-14
- PROPELLER SHAFTJOINT ANGLE
1687 Author
: Date
:
1997 SUPRA (RM502U)
JOINT ANGLE
ADJUSTMENT
NOTICE:
When doing operations which involve the removal and
installation of the propeller shaft, always check the joint.
Make adjustments if necessary.
1. STABILIZE PROPELLER SHAFT AND DIFFERENTIAL
(a) Turn the propeller shaft several times by hand to stabilize
the center support bearing and flexible couplings.
(b) Using a jack, raise and lower the differential to stabilize
the differential mounting cushion.
2. CHECK JOINT ANGLE OF NO.2 JOINT AND NO.3
JOINT
(a) Using SST, measure the installation angle of the inter-
mediate shaft and propeller shaft.
SST 09370-50010
HINT:
The SST should be directly underneath the tube.
(b) Using the SST, measure the installation angle of the dif-
ferential.
HINT:
Measure the installation angle by placing the SST in the posi-
tion, as shown in the illustration.

F01960
2JZ-GE
2JZ-GTENo.2 Joint No.3 Joint
A - B = -1°09' ± 36'
No.2 Joint
A - B = -1°09' ± 36'B - C = 44' ± 36'
No.3 Joint
B - C = 44' ± 36'Joint Angle- :
+ :
A
B
C
A
B
C>>
- PROPELLER SHAFTJOINT ANGLE
PR-15
1688 Author
: Date
:
1997 SUPRA (RM502U)
(c) Calculate the No.2 joint angle.
No.2 joint angle:
A - B = -1°09' ± 36'
A: Intermediate shaft installation angle
B: Propeller shaft installation angle
(d) Calculate the No.3 joint angle.
No.3 joint angle:
B - C = 44' ± 36'
B: Propeller shaft installation angle
C: Differential installation angle
If the measured angle is not within the specification, adjust it
with the center support bearing adjusting washer and differen-
tial adjusting shim.
Center support bearing adjusting washer thickness
Thickness mm (in.)Thickness mm (in.)
2.0 (0.079)6.0 (0.236)
4.0 (0.157)8.5 (0.335)
NOTICE:

Left and right washers should be the same thickness.

2 washers should not be assembled together.

Some vehicles are not assembled with washers.

R07370
-16' -1'
R07371
PR-16
- PROPELLER SHAFTJOINT ANGLE
1689 Author
: Date
:
1997 SUPRA (RM502U)
Differential adjusting shim thickness
Thickness mm (in.)Thickness mm (in.)
1.0 (0.039)2.0 (0.079)
1.6 (0.063)-
NOTICE:

Left and right washers should be the same thickness.

This shim is installed on top of the upper mount stop-
per and it used for adjustment.
3. HOW TO READ THIS CHART
Take measurements, then calculate the No.2 and No.3 joint
angle.
Make the calculated values on the chart and read the coordi-
nates.
Replace the adjusting washer and shim in accordance with the
coordinates read and adjust the joint angles.
Example
Measurements (Installation angle):
Intermediate shaft: 1°50'
Propeller shaft: 2°14'
Differential: 2°15'
Joint angle:
No.2: 1°50' - 2°14' = -24'
No.3: 2°14' - 2°15' = -1'
Adjustment:
Center support bearing
Standard parts: 4 mm - 2 mm = 2 mm
Use adjusting washers which are 2 mm (0.079 in.)
thicker.
Differential
Use adjusting shims which are 1.6 mm (0.063 in.)
thicker.

F03463
2JZ-GE 2JZ-GTE Differential
Adjusting WasherAdjusting Shim
Upper Mount Shim
R07372
ADJUSTMENT CHART
Center Support Bearing
(Adjusting Washer)No.2 Joint Angle
Differential
Mount Upper
Stopper or
Adjusting Shim (+)No.3 Joint Angle
- PROPELLER SHAFTJOINT ANGLE
PR-17
1690 Author
: Date
:
1997 SUPRA (RM502U)
HINT:

Maintain the same thickness for the adjusting washers
and adjusting shims on both the left and right sides.

If a washer and shim of the exact thickness are not avail-
able, use the parts which are the nearest in thickness.
NOTICE:
Check the joint angle once again after making the adjust-
ment.

PR06U-01
PR-2
- PROPELLER SHAFTPROPELLER SHAFT ASSEMBLY
1675 Author
: Date
:
1997 SUPRA (RM502U)
PROPELLER SHAFT ASSEMBLY
COMPONENTS

Q09642
2JZ-GE
2JZ-GTE Intermediate Shaft Sub-assemblyCenter Support BearingWasherWasher Plate
Universal Joint FlangePropeller Shaft


Intermediate Shaft Sub-assembly
Propeller Shaft
Center Support Bearing Adjusting NutDust Boot
Dust Deflector

Snap Ring

Non-reusable part: Specified torque
N´m (kgf´cm, ft´lbf)
See page PR-8
* For use with SST
69 (700, 51)
* 50 (515, 37)
74 (750, 54)
- PROPELLER SHAFTPROPELLER SHAFT ASSEMBLY
PR-3
1676 Author
: Date
:
1997 SUPRA (RM502U)
