DI4WG-01
DI-560
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
788 Author: Date:
1997 SUPRA (RM502U)
DIAGNOSTIC TROUBLE CODE CHART
DTC No.
(See Page)Detection ItemTrouble AreaSRS
Warning Light
(N l)System normal-OFF(Normal)
(DI-595)Source voltage dropBattery
Airbag sensor assemblyON
11
(DI-564)
Short in squib circuit (to ground)Steering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
12
(DI-571)
Short in squib circuit (to B+)Steering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
13
(DI-577)
Short in D squib circuitSteering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
14
(DI-582)
Open in D squib circuitSteering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
31
(DI-586)Airbag sensor assembly malfunctionAirbag sensor assemblyON
53
(DI-588)Short in P squib circuitFront passenger airbag assembly (P squib)
Airbag sensor assembly
Wire harness
ON
54
(DI-592)Open in P squib circuitFront passenger airbag assembly (P squib)
Airbag sensor assembly
Wire harness
ON
HINT:
When the SRS warning light remains lit up and the DTC is the normal code, this means a source voltage
drop.
This malfunction is not stored in memory by the airbag sensor assembly and if the power source volt-
age returns to normal, after approx. 10 seconds the SRS warning light will automatically go out.
When 2 or more codes are indicated, the codes will be displayed in numeral order starting from the
lowest numbered code.
If a code not listed on the chart is displayed, the airbag sensor assembly is faulty.
Page 852 of 1807
DI4WH-01
W02646
SRS Waring Light
(Telltale Light RH)
Front Passenger
Airbag Assembly
Steering Wheel Pad
(with Airbag)
Spiral Cable
Airbag Sensor Assembly
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-561
789 Author: Date:
1997 SUPRA (RM502U)
PARTS LOCATION
Page 853 of 1807
DI4WI-01
W02759
65 43
10921
7 8 BA
DI-562
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
790 Author: Date:
1997 SUPRA (RM502U)
TERMINALS OF ECM
No.SymbolTerminal Name
A-Electrical Connection Check Mechanism
B-Electrical Connection Check Mechanism
1P-Squib (Passenger)
2P+Squib (Passenger)
3LASRS Warning Light
4D-Squib (Driver)
5D+Squib (Driver)
6TcDiagnosis
7E2Ground
8E1Ground
9IG2Power Source (IGN Fuse)
10ACCPower Source (CIG Fuse)
Page 854 of 1807
DI4WJ-01
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-563
791 Author: Date:
1997 SUPRA (RM502U)
PROBLEM SYMPTOMS TABLE
Proceed with troubleshooting of each circuit in the table below.
Problem SymptomInspection ItemPage
WIth the ignition switch at ACC or ON, the SRS warning light
sometimes lights up after approx. 6 seconds have elapsed.
SRS warning light lights up even when ignition switch is in the
LOCK position.
SRS warning light system malfunction (Always lit up when
ignition switch is in LOCK position.)DI-598
WIth the ignition switch at ACC or ON, the SRS warning light
does not light up.SRS warning light system malfunction (Does not light up
when ignition switch is turned to ACC or ON.)DI-600
DTC not displayed.
SRS warning light is always lit up with a DTC check procedure.
DTC displayed without Tc and E
1 terminal connection.
Tc terminal circuitDI-603
Page 855 of 1807
DI4WK-01
W01021
P squib
D squib
A34
A34
A34
A34L
Y
R
WAirbag Sensor
Assembly
P+3
2
7
6 1
2
1
2D
+
D-
P-
Spiral
Cable
DI-564
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
792 Author: Date:
1997 SUPRA (RM502U)
CIRCUIT INSPECTION
DTC 11 Short in Squib Circuit (to Ground)
CIRCUIT DESCRIPTION
The squib circuit consists of the airbag sensor assembly, spiral cable, steering wheel pad and front passen-
ger airbag assembly. It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see FUNCTION OF COMPONENTS on page RS-2.
DTC 11 is recorded a when ground short is detected in the squib circuit.
DTC No.DTC Detecting ConditionTrouble Area
11
Short circuit in squib wire harness (to ground).
Squib malfunction.
Spiral cable malfunction.
Airbag sensor assembly malfunction.Steering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
Page 856 of 1807
R05894R14301H07909
P squibAirbag Sensor
Assembly
D squib
D
+
Spiral
Cable
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-565
793 Author: Date:
1997 SUPRA (RM502U)
INSPECTION PROCEDURES
1 Preparation (See step 1 on page DI-595).
2 Check D squib circuit.
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and steering wheel pad, measure the resistance between
D
+ and body ground.
OK:
Resistance: 1 MW or higher
NG Go to step 7.
OK
Page 857 of 1807
R05898R14301H07910
P squibAirbag Sensor
Assembly
D squib
P
+
Spiral
Cable
DI-566
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
794 Author: Date:
1997 SUPRA (RM502U)
3 Check P squib circuit.
PREPARATION:
For the connector (on the airbag sensor assembly side) be-
tween the airbag sensor assembly and front passenger airbag
assembly, measure the resistance between P
+ and body
ground.
OK:
Resistance: 1 MW or higher
NG Repair or replace harness or connector be-
tween the airbag sensor assembly and front
passenger airbag assembly.
OK
Page 858 of 1807
AB0069R05902AB0118AB0119AB0057
AB0069
N19819H07911
P squibAirbag Sensor
Assembly
D squibSpiral
Cable
ACC
ON
or
E
1Tc DLC1
Code 11
P+P-
D+D-
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-567
795 Author: Date:
1997 SUPRA (RM502U)
4 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to airbag sensor assembly.
(b) Using a service wire, connect D
+ and D- on spiral cable
side of connector between spiral cable and steering
wheel pad.
(c) Using a service wire, connect P
+ and P- on airbag sensor
assembly side of connector between airbag sensor as-
sembly and front passenger airbag assembly.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least 20
seconds.
(b) Clear malfunction code stored in memory.
(See page DI-557)
(c) Turn the ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(e) Using SST, connect the terminals Tc and E
1 of DLC1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 859 of 1807
H03221
P squibAirbag Sensor
Assembly
D squib
Spiral
Cable
ACC
ON
E
1Tc DLC1 Code 11or
DI-568
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
796 Author: Date:
1997 SUPRA (RM502U)
5 Check D squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least 90 seconds.
(c) Connect the steering wheel pad connector.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least 20
seconds.
(b) Clear malfunction code stored in memory.
(See page DI-557)
(c) Turn the ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(e) Using SST, connect the terminals Tc and E
1 of DLC1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace steering wheel pad.
OK
Page 860 of 1807
H03222
P squib
Spiral
Cable
ACC
ON
E
1Tc DLC1 Code 11orAirbag Sensor
Assembly
D squib
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-569
797 Author: Date:
1997 SUPRA (RM502U)
6 Check P squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least 90 seconds.
(c) Connect the front passenger airbag assembly connector.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(b) Clear malfunction code stored in memory.
(See page DI-557)
(c) Turn the ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(e) Using SST, connect the terminals Tc and E
1 of DLC1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace front passenger airbag assembly.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
