TOYOTA SUPRA 1998 Owners Manual

SUPRA (U)
182
ÐRear side marker lights
60473F09
Use a Phillips- head screwdriver.
60473F10
60473F11
60473F14
Use a Phillips- head screwdriver.
ÐRear turn signal, stop and
tail, and back- up lights

SUPRA (U)183
60473F1560473F13a: Rear turn signal light
b: Stop and tail light
c: Back- up light

SUPRA (U)
184
ÐLicense plate lights
60463F36
Use a Phillips- head screwdriver.
60463F37

SUPRA (U)185
Part 8
SPECIFICATIONS
Dimensions and weight
Engine
Fuel
Service specifications
Ti r es
Fuses
Dimensions and weight
Overall length mm (in.) 4515 (177.7)
Overall width mm (in.) 1810 ( 71.3)
Overall height mm (in.) 1275 ( 50.2)
*
Wheelbase mm (in.) 2550 (100.4)
Front tread mm (in.) 1520 ( 59.9)
Rear tread mm (in.) 1525 ( 60.1)
Vehicle capacity weight
(occupants + luggage) kg (lb.) 330 (725)
* : Unladen vehicle Engine
Model:
2JZ- GE and 2JZ- GTE
Type:
2JZ- GE engine
6 cylinder in line, 4 cycle, gasoline
2JZ- GTE engine
6 cylinder in line, 4 cycle, gasoline
(with turbocharger)
Bore and stroke, mm (in.):
86.0
y 86.0 (3.39 y 3.39)
Displacement, cm 3
(cu. in.):
2997 (182.9)

SUPRA (U)
186
Fuel
Fuel type:
Premium unleaded gasoline, Octane Rat-
ing 91 (Research Octane Number 96)
or higher for optimum engine perfor-
mance. However, if such premium type
cannot be obtained, you may temporarily
use unleaded gasoline with an Octane
Rating as low as 87 (Research Octane
Number 91).
Fuel tank capacity, L (gal., Imp. gal.):
70 (18.5, 15.4) Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.25Ð0.35 (0.010Ð0.014)
Spark plug type:
2JZ- GE engine
DENSO PK16TR11
NGK BKR5EKPB11
2JZ- GTE engine
DENSO PK20R11
NGK BKR6EP11
Spark plug gap, mm (in.):
1.1 (0.043)
ENGINE LUBRICATION
Oil capacity (drain and ref
ill),
L (qt., Imp. qt.):
2JZ- GE engine
With filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
2JZ- GTE engine
With filter 5.0 (5.3, 4.4)
Without filter 4.7 (5.0, 4.1)
Oil grade:
API grade SH, ºEnergy- Conserving IIº or
SJ, ºEnergy- Conservingº multigrade engine
oil or ILSAC multigrade engine oil is rec-
ommended. Recommended oil viscosity (SAE):
2JZ- GE engine
2JZ- GTE engine

SUPRA (U)187
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
2JZ-GE engine 8.0 (8.5, 7.0)
2JZ- GTE engine
With manual transmission
8.9 (9.4, 7.8)
With automatic transmission
8.8 (9.3, 7.7)
Coolant type:
With ethylene- glycol antifreeze
(Do not use alcohol type.)
BATTERY
Open voltage
*
at 20 C (68 F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8Ð12.0 V Discharged
* : Voltage that is checked 20 minutes after
the key is removed with all the lights
turned off
Charging rates:
5 A max. CLUTCH
Pedal freeplay, mm (in.):
5Ð15 (0.2±0.6)
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.):
1.8 (1.9, 1.6)
Oil type:
ESSO ATF DEXRON
D- 21065,
TOYOTA GEAR OIL V160 or
equivalent
AUTOMATIC TRANSMISSION
Fluid capacity (drain and ref ill),
L (qt., Imp. qt.):
2JZ- GE engine Up to 1.6 (1.7, 1.4)
2JZ- GTE engine Up to 1.9 (2.0, 1.7)
Fluid type: Automatic transmission fluid TYPE
T - IV or equivalent DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.):
1.35 (1.43 1.19)
Oil type:
Hypoid gear oil API GL- 5
Recommended oil viscosity:
Above ±18
5C (0 5F)
SAE 90
Below ±18 5C (0 5F)
SAE 80W or 80W- 90 BRAKES
Minimum pedal clearance when depressed
with the pressure of 490 N (50 kgf, 110
lbf) with the engine running, mm (in.):
2JZ-GE engine 72 (2.8)
2JZ- GTE engine 70 (2.8)

SUPRA (U)
188
Pedal freeplay, mm (in.):
1Ð6 (0.04±0.24)
Pad wear limit, mm (in.):
1.0 (0.04)
Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment when pulled with
the foce of 196 N (20 kgf, 44 lbf):
5Ð8 clicks
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel freeplay:
Less than 30 mm (1.2 in.)
Power steering fluid type:
Automatic transmission fluid DEXRON
II
or III Tires
Tire size:
Spare tire
T145/70 R 17 Except spare tire
2JZ- GE engine
225/50R 16 92V (for front use only)
245/45R 16 94V (for rear use only)
2JZ- GTE engine
235/45ZR 17 (for front use only)
255/40ZR 17 (for rear use only)
Tire pressure, kPa (kgf/cm 2
or bar, psi):
Spare tire 420 (4.2, 60)
Except spare tire 230 (2.3, 33)
Wheel size: 225/50R 16 92V 16 y 8JJ
245/45R 16 94V 16 y 9JJ
235/45ZR 17 17 y 8JJ
255/40ZR 17 17 y 9.5JJ
T145/70R 17 17 y 4T
Wheel nut torque, N´m (kgf´m, ft´lbf): 103 (10.5, 76) Fuses
80050F09

SUPRA (U)189
80050F10
80050F08
Fuses (type A) 1. EFI NO.2 30 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
2. EFI NO.1 30 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
3. AM2 30 A: Starter system
4. FOG 15 A: Front fog lights
5. HAZ- HORN 15 A: Emergency flashers,
horns
6. TRAC 7.5 A: Traction control system
7. ETCS 15 A: Electronic Traction Control
System
8. ALT- S 7.5 A: Charging system 9. DOME 7.5 A:
Interior lights, personal
lights, door courtesy lights, luggage
compartment light, ignition switch light,
open door warning light, theft deterrent
system
10. RAD NO.1 20 A: Radio cassette tape
player
11. HEAD (RH) 15 A: Right- hand headlight
12. HEAD (LH) 15 A: Left- hand headlight
13. 30 A: Spare fuse
14. 7.5 A: Spare fuse
15. 15 A: Spare fuse
16. WIPER 20 A: Windshield wipers and
washer, rear window wiper and washer
17. HTR 7.5 A: Air conditioning system
18. ST 7.5 A: Starter system
19. IGN 7.5 A: Charging system, discharge
warning light, multiport fuel injection
system/s equential multiport fuel injec-
tion system, SRS airbag system
20. PANEL 10 A: Instrument panel lights,
instrument panel lights control
21. MIR- HTR 10 A: Mirror heaters
22. TURN 7.5 A: Turn signal lights
23. STOP 15 A: Stop lights, cruise control
system cancel device

SUPRA (U)
190
24. CIG 15 A:
Cigarette lighter, air condi-
tioning system, SRS airbag system,
theft deterrent system, shift lock con-
trol system
25. RAD NO.2 7.5 A: Radio, cassette tape
player, power antenna
26. TAIL 10 A: Tail lights, parking lights,
front side marker lights, rear side
marker lights, licence plate lights
27. ECU- IG 10 A: Cruise control system,
anti- lock brake system, power steering,
power antenna, theft deterrent system,
shift lock control system, traction con-
trol system
28. GAUGE 10 A: Gauges and meters, ser-
vice reminder indicators and warning
buzzers (except discharge and open
door warning lights), rear window de-
fogger, charging system, cruise control
system, electronically controlled auto-
matic transmission system, traction
control system
29. ECU- B 10 A: Air conditioning system,
cruise control system, anti- lock brake
system, SRS airbag system, traction
control system
30. OBD - II 7.5A: On- board diagnosis sys-
tem Fuses (type B)
31. DOOR 30 A: Power window, power
door lock system, theft deterrent sys-
tem
32. DEFOG 30 A: Rear window defogger
Fuses (type C)
33. ALT 120 A: Charging system
34. MAIN 50 A: Starter system, headlights
35. HTR 50 A: Air conditioning system
36. FAN 30 A: Electric cooling fans
37. ABS NO.1 60 A: Anti- lock brake sys-
tem, traction control system
38. AM1 50 A: Electronic ignition system/
distributor ignition system
39. POWER 60 A: ºPANELº, ºSTOPº,
ºTAILº, ºECU- Bº, ºDEFOGº and
ºDOORº fuses

SUPRA (U)191
Part 9
REPORTING SAFETY
DEFECTS FOR U.S.
OWNERS AND
UNIFORM TIRE
QUALITY GRADING
Reporting safety defects for U.S.
owners
Uniform tire quality grading
If you believe that your vehicle has
a defect whi ch coul d cause a cr ash
or could cause injury or death, you
should immediately inform the Na-
tional Highway Traffic Safety Ad-
ministration (NHTSA) in addition to
notifying Toyota Motor Sales,
U.S.A., Inc.
(Toll- free: 1- 800- 331- 4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety de-
fect exists in a group of vehicles, it
may order a recall and remedy
campaign. However, NHTSA cannot
become involved in individual prob-
lems between you, your dealer, or
Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may either
call the Auto Safety Hotline toll- free
at 1- 800- 424- 9393 (or 366- 0123 in
Washington.D.C. area) or write to:
NHTSA. U.S.Department of Trans-
portation. Washington.D.C. 20590.
You can also obtain other information
about motor vehicle safety from the
Hotline.
Reporting safety defects
for U.S. owners
