423-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
If applicable, a Check Control
message is displayed if the sys-
tem fails.
The detection of objects with
ultrasound measurements can
run into physical limits, e.g., in
the following situations:
• In case of dirty sensors.
• In case of covered sensors,
such as due to labels.
• If the sensor is not aligned
correctly, for instance due to
parking damage.
• After improperly performed
work on the vehicle paint in
the area of the sensors.
• For small children and ani-
mals.
• For persons with certain cloth-
ing, for instance coats.
• In case of external interfer-
ence of the ultrasound, for
instance from passing vehi-
cles, loud machines or other
ultrasonic sources.
• Under certain weather condi-tions, e.g., high relative
humidity, wet conditions,
snowfall, cold, extreme heat,
or strong wind.
• With tow bars and trailer cou-
plings of other vehicles.
• With thin or wedge-shaped
objects.
• With moving objects.
• With elevated, protruding
objects such as ledges.
• With objects with corners,
edges, and smooth surfaces.
• With objects with a fine sur-
face structure such as fences.
• For objects with porous sur-
faces.
• With small and low objects,
for instance boxes.
• With soft obstacles or obsta-
cles covered in foam material.
• With plants and bushes.
• In automatic car washes.
• On uneven surfaces, such as
speed bumps.
• Due to heavy exhaust.
• Cargo that extends beyond
the perimeter of the vehicle is
not taken into account by the
ultrasonic sensors.
If applicable, a Check Control
message is displayed if the sys-
tem fails.
Ultrasound sensors
Ultrasound sensors in the
front/rear bumpers
Ultrasound sensors of
the Parking Sensor, for
instance in the bum-
pers.
System limits of the ultra-
sound sensors

2785-1. MOBILITY
Supra Owner's Manual_U (from Nov. '20 Prod.)
While the tire is being filled with
sealant, the tire inflation pres-
sure may sporadically reach
approx. 5 bar. Do not switch off
the compressor at this point.
1Switch off the compressor.
2Read the tire inflation pres-
sure on the tire pressure
gauge.
To continue the trip, a tire infla-
tion pressure of at least 2 bar
must be reached.
1Unscrew the filling hose of
the sealant container from
the tire valve.
2Press the red unlocking
device.
3Remove the sealant con-
tainer from the compressor.
4Wrap and store the sealant
container in suitable material
to avoid dirtying the cargo
area.1Pull the connector out of the
power socket inside the vehi-
cle.
2Drive 33 ft/10 m forward and
back to distribute the sealant
in the tire.
3Screw the connection hose of
the compressor directly onto
the tire valve stem.
4Insert the connector into the
power socket inside the vehi-
cle.
5With standby state switched
on or the engine running,
switch on the compressor.
If a tire inflation pressure of at least
2 bar cannot be reached, contact
your Toyota dealer.
If a tire inflation pressure of at least
Checking and adjusting
the tire inflation pressure
Checking
Removing and stowing the
sealant container
Minimum tire inflation pres-
sure is not reached

2795-1. MOBILITY
5
MOBILITY
Supra Owner's Manual_U (from Nov. '20 Prod.)2 bar is reached, see Minimum tire
inflation pressure is reached.
6Unscrew the connection
hose of the compressor from
the tire valve.
7Pull the connector out of the
power socket inside the vehi-
cle.
8Stow the Mobility System in
the vehicle.
1Unscrew the connection
hose of the compressor from
the tire valve.
2Pull the connector out of the
power socket inside the vehi-
cle.
3Stow the Mobility System in
the vehicle.
4Immediately drive approx. 5
miles/10 km to ensure that
the sealant is evenly distrib-
uted in the tire.
Do not exceed a speed of 50
mph/80 km/h.
If possible, do not drive at speeds
less than 12 mph/20 km/h.
1Stop at a suitable location.2Screw the connection hose of
the compressor directly onto
the tire valve stem.
3Insert the connector into the
power socket inside the vehi-
cle.
4Correct the tire inflation pres-
sure to at least 2.0 bar.
• Increase tire inflation pres-
sure: with standby state
switched on or the engine
running, switch on the com-
pressor.
• Reduce tire inflation pressure:
press the button on the com-
pressor.
5Unscrew the connection
hose of the compressor from
the tire valve.
6Pull the connector out of the
power socket inside the vehi-
cle. Minimum tire inflation pres-
sure is reached
Adjustment

3205-1. MOBILITY
Supra Owner's Manual_U (from Nov. '20 Prod.)
If the electrical system has
failed, clearly identify the vehicle
being towed by placing a sign or
a warning triangle in the rear
window.
The tow fittings used should be
on the same side on both vehi-
cles.
Should it prove impossible to
avoid mounting the tow bar at
an offset angle, please follow
the following:
Maneuvering capability is lim-
ited going around corners.
The tow bar will generate lat-
eral forces if it is secured with
an offset.Observe the following notes
when using the tow rope:
Use nylon ropes or straps,
which will enable the vehicle
to be towed without jerking.
Make sure the tow rope is not
twisted when fastening.
Check the fastening of the
tow fitting and tow rope in reg-
ular intervals.
Do not exceed a towing
speed of 30 mph/50 km/h.
Do not exceed a towing dis-
tance of 3 miles/5 km.
When starting to tow the vehi-
cle, make sure that the tow
rope is taut.
The screw-in tow fitting should
always be carried in the vehicle.
The tow fitting can be screwed
in at the front or rear of the vehi-
cle. Safety information
WA R N I N G
If the approved gross vehicle
weight of the towing vehicle is
lighter than the vehicle to be
towed, the tow fitting can tear off
or it will not be possible to control
the vehicle's response. There is a
risk of an accident. Make sure
that the gross vehicle weight of
the towing vehicle is heavier than
the vehicle to be towed.
NOTICE
If the tow bar or tow rope is
attached incorrectly, damage to
other vehicle parts can occur.
There is a risk of damage to prop-
erty. Correctly attach the tow bar
or tow rope to the tow fitting.
To w b a r
To w r o p e
Tow fitting
General information

344Alphabetical Index
Supra Owner's Manual_U (from Nov. '20 Prod.)
Alphabetical Index
A
A/C button, see Air conditioning
............................................... 228
ABS, Antilock Brake System . 194
ACC, see Dynamic radar cruise
control with full-speed range
............................................... 203
Acceleration Assistant, see
Launch Control..................... 131
Accessories and parts ............... 6
Activated charcoal filter ........ 232
Active Guard, see Toyota Supra
Safety .................................... 173
Adaptive brake assist ............ 195
Adaptive variable suspension
............................................... 225
Additional coolant tank cooling,
Capacity ................................ 332
Additives, engine oil types .... 297
Air circulation, see Recircu-
lated-air mode....................... 230
Air conditioning ...................... 228
Air distribution, manual ......... 231
Air flow, automatic air condition-
ing .......................................... 230
Air outlets, see Ventilation .... 232
Air pressure, tires .................. 264
Airbags .................................... 161
Airbags, indicator and warning
light........................................ 163
Alarm system ............................ 92
Alarm, unintentional................. 93
All-season tires, see Winter tires
............................................... 274
Antilock Brake System, ABS . 194
Anti-slip control, see VSC ..... 195
Anti-theft protection, locking .. 79
Anti-theft protection, see Lug
bolt lock ................................ 289
Apple CarPlay, connection to the
vehicle ..................................... 73Approved axle load ................331
Approved total weight ............331
Assistance when driving off, see
Hill-start assist control.........195
Assistance with breakdown ..315
AUTO program, automatic air
conditioning ..........................229
Auto Start/Stop function ........ 116
Automatic air conditioning ....227
Automatic cruise control with
Stop & Go ..............................203
Automatic Curb Monitor, exte-
rior mirror ..............................106
Automatic deactivation,
front-seat passenger airbags
...............................................171
Automatic headlight control ..154
Automatic high-beam .............157
Automatic locking ....................91
Automatic transmission.........126
Automatic transmission, Fluid
...............................................332
Automatic transmission, see
Automatic transmission.......126
Automatic unlocking ................91
Automatic vehicle wash .........322
Autonomous Emergency Brak-
ing ..........................................192
Axle loads, weights ................331
B
Backrest curvature, see Lumbar
support ....................................99
Backrest tilt ...............................99
Backrest, seats .........................96
Backrest, width .........................99
Bar for tow-starting/towing....320
Battery, changing, remote con-
trol of the vehicle ....................81
Battery, disposing of ..............306
Battery, vehicle .......................305

354Alphabetical Index
Supra Owner's Manual_U (from Nov. '20 Prod.)SPORT, see Sport mode switch
............................................... 132
Stability control systems ....... 194
Standard equipment, see Vehicle
features and options ................ 4
Standard view, Head-up Display
............................................... 151
Standby state, idle state and
drive-ready state .................... 44
Start/Stop button .................... 115
Start/stop, automatic function116
Status control display, tires .. 282
Status information, Toyota Supra
Command................................ 47
Status of Owner's Manual ......... 5
Status, vehicle ........................ 150
Steering wheel, adjusting ...... 107
Steering wheel, buttons ........... 36
Steering wheel, see Memory
function ................................. 107
Steptronic Sport transmission,
see Automatic transmission 126
Storage compartments, locations
............................................... 245
Storage, tires .......................... 274
Storing the vehicle ................. 328
Stowing and securing cargo . 248
Straps for cargo, see Lashing
eyes in the cargo area ......... 248
Summer tires, tread ............... 271
Sun visor ................................. 239
Supplementary SMS text mes-
sage ....................................... 135
Suspension settings, see Sport
mode switch ......................... 132
Switch for driving dynamics, see
Sport mode switch ............... 132
Switches, see Cockpit ............. 36
Symbols and displays ............... 4
T
Tail lights, see Lights and bulbs
...............................................304
Technical changes, see For Your
Own Safety ................................5
Technical data .........................330
Temperature display, see Exter-
nal temperature.....................141
Temperature, automatic air con-
ditioning ................................228
Temperature, engine oil .........141
Theft alarm system, see Alarm
system .....................................92
Tilt alarm sensor .......................93
Tilt, backrest .............................99
Tilting the passenger's side mir-
ror, see Automatic Curb Moni-
tor, exterior mirror ................106
Time ...........................................60
Tire brands, recommended ...273
Tire damage ............................271
Tire identification marks ........268
Tire inflation pressure ............264
Tire pressure ...........................264
Tire Pressure Monitor TPM ....280
Tire repair kit, see Mobility Sys-
tem .........................................275
Tire sealant, see Mobility System
...............................................275
Tire settings ............................281
Tire tread .................................271
Tires and wheels.....................264
Tires, changing .......................272
Tool ..........................................303
Torque display, see Sport dis-
plays ......................................149
Touchscreen .............................53
Tow bar ....................................320
Tow fitting................................320
Tow rope ..................................320
Towing .....................................319
