15


Maintenance Expense
Normal maintenance services such as:
• Engine tune-ups
• Replacement of fluids and filters
• Lubrication
• Cleaning and polishing
•
Replacement of spark plugs and fuses
•
Replacement of worn wiper blades,
brake pads/linings and clutch linings
Vehicles with Altered Odometer
Failure of a vehicle on which the odometer
has been altered so that actual vehicle
mileage cannot be readily determined.
Salvage or Total-Loss Vehicles
Any vehicle that has ever been issued a
“salvage” title or similar title under any
state’s law, or has ever been declared a
“total loss” or equivalent by a financial
institution or insurer, such as by payment
for a claim in lieu of repairs because the
cost of repairs exceeded the cash value of
the vehicle. This exclusion does not apply to
the emission control warranties, including
Emission Control Warranty Enhancements
or any open Safety Recalls/SSCs/LSCs.


Incidental Damages
Incidental or consequential damages
associated with a vehicle failure. Such
damages include but are not limited to
inconvenience; the cost of transportation,
telephone calls and lodging; the loss of
personal or commercial property; and the
loss of pay or revenue.
Disclaimer of Extra
Expenses and Damages
The performance of necessary repairs
and adjustments is the exclusive remedy
under this warranty or any implied
warranty. Toyota does not authorize
any person to create for it any other
obligation or liability in connection with
this vehicle. Toyota shall not be liable
for incidental or consequential damages
resulting from breach of this written
warranty or any implied warranty. Any
implied warranty of merchantability or
fitness for a particular purpose is limited
to the duration of this written warranty,
except in states where this limitation
is not allowed.
NEW VEHICLE LIMITED WARRANTY
Your Warranties in Detail
WARRANTY

25


WHAT IS NOT COVERED
These warranty obligations do not apply
to failures or noncompliance caused by:
•
The use of replacement parts not
certified in accordance with aftermarket
parts certification regulations.
•
The use of replacement parts not
equivalent in quality or design to
original equipment parts.
Provisions under the “What Is Not Covered”
section of the New Vehicle Limited Warranty
also apply to this warranty.
PARTS LIST:
LONG-TERM EMISSION
DEFECT WARRANTY
The parts listed here are covered for seven
years or 70,000 miles from the vehicle’s
in-service date, whichever occurs first.
Air Induction/Exhaust System
• Brake system control module
• Camshaft position sensor
• Camshaft timing gear assembly
• I
ntake camshaft timing gear
center bolt assembly
• Intake manifold
• Servo motor (servo actuator)
• Throttle body
• Turbocharger
•
Turbocharger actuator and
link assembly



Catalyst System
• Camshaft timing exhaust gear assembly
• Exhaust manifold
(including manifold converter)
•
Exhaust manifold to head gasket for
models equipped with 30iDB23
•
Exhaust pipe (including catalytic converter)
for models equipped with 30iDB23
Evaporative Control System
• Charcoal canister
• Fuel tank
Fuel Control System
• Engine control computer
(engine control module)
• Fuel delivery pipe
• Fuel pump
• Fuel tank inlet pipe subassembly
• Fuel temperature sensor
• High pressure fuel pump
• Injector
Other Parts Used in
Systems Listed
• Crankshaft position sensor
• Cylinder head cover gasket
• Malfunction indicator lamp
• Torque converter
• Transmission valve body
CALIFORNIA EMISSION CONTROL WARRANTY
Your Warranties in Detail
WARRANTY

37
Engine Oil Selection
Please refer to your Owner’s Manual for the
specific oil viscosity rating recommended
for your vehicle/engine type.
Additional Maintenance
In addition to scheduled maintenance,
your Toyota requires ongoing general
maintenance, such as fluid checks and
visual inspections. These procedures are
explained in the “Maintenance” section of
the Owner’s Manual. Be sure to perform
these procedures regularly to ensure the
most trouble-free operation of your vehicle.
SuperChrome and
Alloy Wheel Care
If you purchased Genuine Toyota Accessory
SuperChrome or Aluminum Alloy Wheels,
follow these cleaning guidelines to maintain
the appearance of your wheels:
•
If wheels are hot, wait for them to cool
before washing.
•
Use a soft sponge or cotton cloth to
apply the same mild car-wash soap as
used for the vehicle body. Quickly rinse
off with water. Use a soft cloth to apply
the same car wax as used for the
vehicle body.
•
DO NOT USE: Any kind of chemical-
based cleaners, alcohol, solvents,
gasoline, steam cleaners, scouring
pads, wire brushes or coarse abrasives
to clean your wheels. Aggressive, acidic
or alkaline cleaning agents can destroy the
protective layer of adjacent components,
such as the brake disc.
Maintenance Log
USING THE MAINTENANCE LOG CHARTS
MAINTENANCE

39
40,000 miles or 48 months
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■
Inspect radiator, condenser and/or intercooler
■Inspect wiper blades
■Perform road test
■
Replace cabin air filter
■Replace engine air filter
■Replace engine oil and oil filter3
■Replace spark plugs6
■Reset tire pressure settings in central information display (CID)
■
Visually inspect brake linings/drums and brake pads/discs4
Inspect the following:
_Brake lines and hoses
_Coolant level and coolant composition
_Heater/air conditioning blower motor
_
Horn, headlight flashers and hazard warning flashers
_Lighting system
_Mobility system7
_Seat belts
Dealer Service verification:
Date:Mileage: 1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on inspection results.2 Driving in heavy traffic, on dirt roads or in urban, dusty or desert areas may shorten the life of the engine air filter and may require replacement.3 replace the engine oil and oil filter when the engine oil warning light appears, even if 12 months have not passed or when driven less than 10,000 miles since the last oil change. reset maintenance reminder light if oil was changed.4 replace brake pads when the brake warning light appears.5 initial replacement at 36 months. replace every 24 months thereafter.6 Maintenance services of spark plugs are required under the terms of the emissions control Warranty.7 check the sealant container expiration date during inspection. replace the sealant container with a new one before the expiration date. refer to the

40
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■Inspect wiper blades
■Replace brake fluid
■
Replace engine oil and oil filter3
■
Visually inspect brake linings/drums and brake pads/discs4
Dealer Service verification:
Date:Mileage:
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■Inspect engine air filter2
■
Inspect radiator, condenser and/or intercooler
■Inspect wiper blades
■
Replace cabin air filter
■Replace engine oil and oil filter3
■
Visually inspect brake linings/drums and brake pads/discs4


Dealer Service verification:
Date:Mileage:
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■Inspect wiper blades
■Replace brake fluid
■
Replace engine oil and oil filter3
■
Visually inspect brake linings/drums and brake pads/discs4
60,000 miles or 72 months
50,000 miles or 60 months
70,000 miles or 84 months
Dealer Service verification:
Date:Mileage:
Maintenance Log
MAINTENANCE LOG
MAINTENANCE

41
80,000 miles or 96 months
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■
Inspect radiator, condenser and/or intercooler
■Inspect wiper blades
■Perform road test
■
Replace cabin air filter
■Replace engine air filter
■Replace engine oil and oil filter3
■Replace spark plugs5
■Reset tire pressure settings in central information display (CID)
■
Visually inspect brake linings/drums and brake pads/discs4
Inspect the following:
_Brake lines and hoses
_Coolant level and coolant composition
_Heater/air conditioning blower motor
_
Horn, headlight flashers and hazard warning flashers
_Lighting system
_Mobility system6
_Seat belts
Dealer Service verification:
Date:Mileage:
_Steering linkage and boots
_tires
_
vehicle underbody and all other visible components
_ Warning triangle
_Wiper and washer system
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on inspection results.2 Driving in heavy traffic, on dirt roads or in urban, dusty or desert areas may shorten the life of the engine air filter and may require replacement. 3 replace the engine oil and oil filter when the engine oil warning light appears, even if 12 months have not passed or when driven less than 10,000 miles since the last oil change. reset maintenance reminder light if oil was changed.4 replace brake pads when the brake warning light appears.5 Maintenance services of spark plugs are required under the terms of the emissions control Warranty.6 check the sealant container expiration date during inspection. replace the sealant container with a new one before the expiration date. refer to the

43
120,000 miles or 144 months
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■
Inspect radiator, condenser and/or intercooler
■Inspect wiper blades
■Perform road test
■
Replace cabin air filter
■Replace engine air filter
■Replace engine oil and oil filter3
■Replace spark plugs5
■Reset tire pressure settings in central information display (CID)
■
Visually inspect brake linings/drums and brake pads/discs4
Inspect the following:
_Brake lines and hoses
_Coolant level and coolant composition
_Heater/air conditioning blower motor
_
Horn, headlight flashers and hazard warning flashers
_Lighting system
_Mobility system6
_Seat belts
Dealer Service verification:
Date:Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on inspection results.2 Driving in heavy traffic, on dirt roads or in urban, dusty or desert areas may shorten the life of the engine air filter and may require replacement. 3 replace the engine oil and oil filter when the engine oil warning light appears, even if 12 months have not passed or when driven less than 10,000 miles since the last oil change. reset maintenance reminder light if oil was changed.4 replace brake pads when the brake warning light appears.5 Maintenance services of spark plugs are required under the terms of the emissions control Warranty.6 check the sealant container expiration date during inspection. replace the sealant container with a new one before the expiration date. refer to the

44
EXPLANATION OF MAINTENANCE ITEMS
T
he following descriptions are
provided to give you a better
understanding of the maintenance
items that should be performed on your
vehicle. The scheduled maintenance log
indicates at which mileage/time intervals
each item should be performed. Please
note that many maintenance items should
be performed by a Toyota dealership
or another qualified service center or repair
shop. Records of regular maintenance
and repair work should be retained.

For further information on maintenance
items you can perform yourself, see
the “Maintenance” section of the
Owner’s Manual.
Brake Fluid
Replace using fluid type specified in your
Owner’s Manual. Toyota recommends
maintenance and repair be performed by
a Toyota dealership or another qualified
service center or repair shop.
Brake Lines and Hoses
Visually inspect for proper installation.
Check for chafing, cracks, deterioration
and signs of leakage. Replace any
deteriorated or damaged parts. Toyo t a
recommends maintenance and repair
be performed by a Toyota dealership
or another qualified service center or
repair shop.
Brake Linings/Drums
and Brake Pads/Discs
Check brake pads and rotors for excessive
wear; check brake rotors for runout. Check
brake calipers for fluid leakage. Toyo t a
recommends maintenance and repair be
performed by a Toyota dealership or another
qualified service center or repair shop.
Cabin Air Filter
Replace at specified intervals.
Driver’s Floor Mat
•
Only use the driver’s floor mat
designed specifically for the model
and model year of your vehicle.
•
Always properly secure the driver’s
floor mat using the retaining hooks.
•
Never install another floor mat on top
of the existing driver’s floor mat.
•
Never install the driver’s floor mat
upside down.
Engine Air Filter
Inspect or replace at specified intervals.
When performing inspections, check for
damage, excessive wear and oiliness, and
replace if necessary.
Maintenance Log
MAINTENANCE

45
EXPLANATION OF MAINTENANCE ITEMS


Engine Coolant
Check the coolant levels and coolant
composition of both coolant reservoirs
and refill as needed. Inspect hoses and
connections for corrosion and leaks. Toyota
recommends maintenance and repair be
performed by a Toyota dealership or another
qualified service center or repair shop.
For further details, refer to the “Operating
materials” section of the Owner’s Manual. Engine Oil and Oil Filter
Replace the oil filter and drain and refill
the engine oil at specified intervals. For
recommended oil grade and viscosity,
refer to the Owner’s Manual.
NOTE: Your vehicle is certified with Toyota
Genuine Motor Oil SN 0W-20 C5. Replace
the oil filter and drain and refill the engine oil
every 12 months or 10,000 miles, or when the
oil maintenance reminder appears, whichever
comes first. Toyota recommends you have
your Toyota dealer change the engine oil.
Lighting System
Check that all exterior and interior lights are
operational. The manufacturer of your vehicle
recommends work on the lighting system,
including bulb replacement, be performed by
your Toyota dealer.



R o a d Te s t
While driving the vehicle, check for proper
operation of engine, transmission, brakes
and steering. Also check the parking brake,
and check for ab
normal noise or vibration
from any part of the vehicle.
Spark Plugs
Replace at specified intervals. Install
new plugs of the same type as originally
equipped. Toyota recommends maintenance
and repair be performed by a Toyota
dealership or another qualified service
center or repair shop.
Maintenance Log
MAINTENANCE
