wiper blades TOYOTA SUPRA 2023 Owners Manual

1263-1. CONTROLS
2"Vehicle settings"
3 "Exterior lighting"
4 "One-touch turn signal"
5 Select the desired setting.
Press the lever to the resistance
point and hold it there for as
long as you want the turn signal
to flash.
Push the lever forward or pull it
backward.
1 High beams on, arrow 1.
The high beams light up when the
low beams are switched on.
2High beams off/headlight
flasher, arrow 2.
Do not use the wipers if the
windshield is dry, as this may
damage the wiper blades or cause them to become worn
more quickly.
The wipers can be operated in
the standby state.
Signaling briefly
High beams, headlight
flasher
Washer/wiper system
General information
Safety information
WARNING
If the wipers start moving in the
folded away state, body parts can
be jammed or damage may occur
to parts of the veh icle. There is a
risk of injury or risk of damage to
property. Make sure that the vehi-
cle is switched off when the wip-
ers are in the folded away state
and the wipers are folded in when
switching on.
NOTICE
The wiper blades can wear out or
become damaged prematurely
when wiping on a dry window for
a longer period of time. The wiper
motor can overheat. There is a
risk of damage to property, among
other potential damage. Do not
use the wipers when the window
is dry.
NOTICE
If the wipers are frozen to the
windshield, the wiper blades can
be torn off and th e wiper motor
can overheat whe n switching on.
There is a risk of damage to prop-
erty, among other potential dam-
age. Defrost the windshield prior
to switching the wipers on.

1293-1. CONTROLS
3
CONTROLS
The windshield washer nozzles
are automatically heated while
standby state is switched on.
In the fold-out position, the wip-
ers can be folded out from the
windshield, which is important,
for instance, when changing the
wiper blades or for folding away
under frosty conditions.1
Switch on standby state.
2 Move the wiper lever to the
lowest position and hold it
there until the wipers stop at
a nearly vertical position.
3 Fold the wipers all the way
away from the windshield.
After the wipers are folded back
down, the wiper system must be
reactivated.
1 Fold the wipers back down
onto the windshield.
2 Switch on standby state and
press and hold the wiper
lever down again.
Windshield washer nozzles
Fold-away position of the
wipers
Principle
Safety information
WARNING
If the wipers start moving in the
folded away state, body parts can
be jammed or damage may occur
to parts of the vehicle. There is a
risk of injury or risk of damage to
property. Make sure that the vehi-
cle is switched off when the wip-
ers are in the folded away state
and the wipers are folded in when
switching on.
NOTICE
If the wipers are frozen to the
windshield, the wiper blades can
be torn off and the wiper motor
can overheat when switching on.
There is a risk of damage to prop-
erty. Defrost the windshield prior
to switching the wipers on.
Folding away the wipers
Folding down the wipers

2995-1. MOBILITY
5
MOBILITY
1Pull lever, arrow 1.
Hood is unlocked.
2After the lever is released,
pull the lever again, arrow 2.
Hood can be opened.
3Be careful of protruding parts
on the hood.
Energetically close the hood
from approx. 20 in/50 cm.
The hood must engage on both
sides.
WARNING
There are protruding parts, for
instance locking hook, on the
inside of the hood. There is a risk
of injury. If the hood is open, pay
attention to protruding parts and
keep clear of these areas.
WARNING
An incorrectly locked hood can
open while driving and restrict vis-
ibility. There is a risk of an acci-
dent. Stop immediately and
correctly close the hood.
WARNING
Body parts can be jammed when
opening and closing the hood.
There is a risk of injury. Make sure
that the area of movement of the
hood is clear during opening and
closing.
NOTICE
Folded-away wipers can be
jammed when the hood is
opened. There is a risk of damage
to property. Make sure that the
wipers with the wiper blades
mounted are folded down onto the
windshield before opening the
hood.
Opening
Closing

3115-1. MOBILITY
5
MOBILITY
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
The onboard vehicle tool kit is
located under a cover on the
right side of the cargo area.
Unlock the cover of the right
side panel, arrow 1, and fold
open, arrow 2. 1
To change the wiper blades,
fold up the wiper arms, refer
to page 129.
2 Stop the vehicle.
Replacing components
Vehicle features and
options
Onboard vehicle tool kit
Wiper blades
Safety information
NOTICE
The window may sustain damage
if the wiper falls onto it without the
wiper blade installed. There is a
risk of damage to property. Hold
the wiper firmly when changing
the wiper blade. Do not fold or
switch on the wiper without a
wiper blade installed.
NOTICE
Folded-away wipers can be
jammed when the hood is
opened. There is a risk of damage
to property. Make sure that the
wipers with the wiper blades
mounted are folded down onto the
windshield before opening the
hood.
NOTICE
When replacing the wiper blades,
perform the procedure quickly
and do not leave the wiper arms
lifted without the w iper blades for
longer than necessary.
Replacing the front wiper
blades

3355-1. MOBILITY
5
MOBILITY
When cleaning the vehicle, use
only neutral wheel cleaners hav-
ing a pH value from 5 to 9. Do
not use abrasive cleaning
agents or steam jets above 140
°F/60 °C. Follow the manufac-
turer's instructions.
Aggressive, acidic or alkaline
cleaning agents can destroy the
protective layer of adjacent
components, such as the brake
disc.
After cleaning, apply the brakes
briefly to dry them. The heat
generated during braking dries
brake discs and brake pads and
protects them against corrosion.
Carefully clean components
such as the radiator grille or
door handles with plenty of
water, possibly with shampoo
added, particularly when they have been exposed to road salt.
Environmental influences can
cause surface soiling of rubber
parts and a loss of gloss. Use
only water and suitable cleaning
agents for cleaning.
Treat especially worn rubber
parts with rubber care agents at
regular intervals. When cleaning
rubber seals, do not use any sili-
con-containing vehicle care
products in order to avoid dam-
age or noises.
The wiper blades are cleaned by
using the washer system.
Avoid cleaning the wiper blades
manually, as this may reduce
wiper performance.
Clean with a microfiber cloth.
Dampen cloth lightly with water.
Do not soak the roofliner.
Safety information
NOTICE
Open hook-and-loop fasteners on
articles of clothing can damage
the seat covers. There is a risk of
damage to propert
y. Ensure that
any hook-and-loop fasteners are
closed.
Caring for special compo-
nents
Light-alloy wheels
Chrome surfaces
Rubber components
Wiper blades
Plastic components
NOTICE
Cleansers that contain alcohol or
solvents, such as lacquer thin-
ners, heavy-duty grease remov-
ers, fuel, or such, can damage
plastic parts. Ther e is a risk of
damage to property. Clean with a
microfiber cloth. Dampen cloth
lightly with water.

372Alphabetical Index
Ventilation ............................... 238
Ventilation, see Parked-car venti-lation...................................... 239
Venting, see Ventilation ......... 238
VIN, see Vehicle identification number .................................... 12
Voice activation system ........... 59
VSC Vehicle Stability Control System .................................. 200
W
Warning against cross traffic 228
Warning and indicator lights, see Vehicle messages ................ 139
Warning light in the exterior mir- ror, see Blind spot monitor . 191
Warning light in the exterior mir- ror, see RCTA (Rear cross traf-
fic alert) function .................. 228
Warning messages, see Vehicle messages .............................. 139
Warning triangle ..................... 322
Warranty ...................................... 5
Washer nozzles, windshield .. 129
Washer system ....................... 126
Washing the vehicle ............... 330
Water on roads ....................... 261
Water, see Condensation water under the parked vehicle ..... 263
Weights ................................... 341
Welcome light during unlocking ................................................. 81
Welcome lights ....................... 159
Wheel cleaner, light-alloy wheels ............................................... 335
Wheelbase, vehicle ................ 340
Wheels and tires ..................... 270
Wheels, changing ................... 279
Width, vehicle ......................... 340
Window defroster, rear .......... 238
Window, defrosting and defog- ging........................................ 237 Windows, powered ...................97
Windshield washer nozzles ...129
Windshield washer system, see
Washer/wiper system ...........126
Windshield wiper, see Wiper sys- tem .........................................126
Winter storage, see Long-term vehicle storage .....................337
Winter tires ..............................281
Winter tires, trea d ...................278
Wiper blades, replacing ......... 311
Wiper system ..........................126
Wiper, fold-away position ......129
Wiper, see Washer/wiper system ...............................................126
Wordmatch principle, see Entry comparison .............................49
Wrench, see Onboard vehicle tool kit .................................... 311
