sensor TOYOTA T100 1996 Factory Service Manual

Downloaded from www.Manualslib.com manuals search engine P20822
Inward
Sensor
EM06J−03
P20821
P20499
P20823
Front
− ENGINE MECHANICAL (5VZ−FE)TIMING BELT
EM−19
1996 TOYOTA T100 (RM449U)
INSTALLATION
1. INSTALL CRANKSHAFT TIMING PULLEY
(a) Align the pulley set key with the key groove of the timing
pulley and slide on the timing pulley.
(b) Slide on the timing pulley, facing the flange side inward.
2. INSTALL NO. 1 IDLER PULLEY AND NO.2 IDLER
PULLEY
(a) Using a 10 mm hexagon wrench, install the No.1 idler
pulley with the plate washer and bolt.
Torque: 35 N·m (350 kgf·cm, 26 ft·lbf)
(b) Check that the pulley bracket moves smoothly.
(c) Install the No.2 idler pulley with the bolt.
Torque: 40 N·m (400 kgf·cm, 30 ft·lbf)
(d) Check that the pulley moves smoothly.
3. TEMPORARILY INSTALL TIMING BELT
NOTICE:
The engine should be cold.
(a) Use the crankshaft pulley bolt to turn the crankshaft and
align the timing marks on the crankshaft timing pulley and
on the oil pump body.
(b) Remove any oil or water on the crankshaft timing pulley,
idler pulley and water pump pulley, and keep them clean.
NOTICE:
Only wipe the pulleys; do not use any cleansing agent.
(c) Align the installation mark on the timing belt with the
drilled mark of the crankshaft timing pulley.
(d) Install the timing belt on the crankshaft timing pulley, No.1
idler and water pump pulleys.
4. INSTALL TIMING BELT GUIDE
Install the guide, facing the cup side outward.

Downloaded from www.Manualslib.com manuals search engine P20817
P20819
P20830
P20837
Length = 955 mm (37.60 in.)
Length = 270 mm (10.63 in.)
− ENGINE MECHANICAL (5VZ−FE)TIMING BELT
EM−23
1996 TOYOTA T100 (RM449U)
12. INSTALL TIMING BELT TENSIONER
(a) Install the tensioner with the 2 bolts.
Torque: 27 N·m (270 kgf·cm, 20 ft·lbf)
(b) Remove the 1.5 mm hexagon wrench from the tensioner.
13. CHECK VALVE TIMING
(a) Turn the crankshaft pulley 2 revolutions from TDC to TDC.
HINT:
Always turn the crankshaft clockwise.
(b) Check that each pulley aligns with the timing marks as
shown in the illustration.
If the marks do not align, remove the timing belt and reinstall it.
14. INSTALL FAN BRACKET
(a) Install the fan bracket with the bolt and nut.
(b) Install the PS pump adjusting strut with the nut.
15. INSTALL NO.2 TIMING BELT COVER
(a) Check that the timing belt cover gasket has no cracks or
peeling, etc.
If the gasket does have cracks or peeling, etc., replace it using
following steps.
Using a screwdriver and gasket scraper, remove all
the old gasket material.
Thoroughly clean all components to remove all the
loose material.
Remove the backing paper from a new gasket and
install the gasket evenly to the part of the belt cover
shaded black in the illustration.
(b) Install the belt cover with the 6 bolts.
Torque: 9 N·m (90 kgf·cm, 80 in.·lbf)
(c) Connect the 3 high−tension cord clamps to the No.2 tim-
ing belt cover.
(d) Connect the camshaft position sensor connector to the
No.2 timing belt cover.

Downloaded from www.Manualslib.com manuals search engine S05155
− ENGINE MECHANICAL (5VZ−FE)CYLINDER HEAD
EM−31
1996 TOYOTA T100 (RM449U)
21. w/ EGR:
REMOVE EGR PIPE
Remove the 6 nuts, EGR pipe and 2 gaskets.
22. REMOVE INTAKE CHAMBER STAY
(a) A/T:
Remove the bolt, 2 nuts, oil filler tube and No.1 throttle
cable clamp.
(b) Remove the 2 bolts and intake chamber stay.
23. REMOVE AIR INTAKE CHAMBER ASSEMBLY
(a) Disconnect these connectors:
VSV connector for fuel pressure control
Throttle position sensor connector
IAC valve connector
w/ EGR:
EGR gas temperature sensor connector
VSV connector for EGR
(b) Disconnect these hoses:
(1) 2 PCV hoses
(2) 2 water bypass hoses
(3) Air assist hose from throttle body
(4) 2 Vacuum sensing hoses from VSV
w/ A/C
Air hose from A/C idle−up valve
(5) EVAP hose
(6) Air hose from PS pump
(c) Remove the 4 bolts, 2 nuts, the air intake chamber as-
sembly and gasket.
24. REMOVE INTAKE AIR CONNECTOR
(a) Remove the bolt, and disconnect the engine wire.
(b) Disconnect the 2 fuel return hoses.
(c) Disconnect the brake booster vacuum hose from the in-
take air connector.
(d) Remove the bolt, and disconnect the ground strap from
the intake air connector.
(e) Disconnect the DLC1 from the bracket.
(f) w/ A/C
Disconnect the A/C idle−up valve connector.
(g) Remove the 3 bolts, 2 nuts, intake air connector and gas-
ket.

Downloaded from www.Manualslib.com manuals search engine P21245
P21193
P21192
P21195
EM−32
− ENGINE MECHANICAL (5VZ−FE)CYLINDER HEAD
1996 TOYOTA T100 (RM449U)
25. DISCONNECT ENGINE WIRE
(a) Disconnect these connectors:
Oil pressure sensor connector
Crankshaft position sensor connector
6 Injector connectors
ECT sender gauge connector
ECT sensor connector
Knock sensor connector
Camshaft position sensor connector
(b) Disconnect the 3 engine wire clamps.
(c) Remove the 3 bolts, and disconnect the engine wire from
the cylinder head.
26. REMOVE CAMSHAFT POSITION SENSOR
27. REMOVE NO.3 TIMING BELT COVER
Remove the 6 bolts and timing belt cover.
28. REMOVE FUEL PRESSURE REGULATOR
29. REMOVE INTAKE MANIFOLD ASSEMBLY
(a) Disconnect the fuel inlet hose.
(b) Remove the 2 bolts and the intake manifold stay.
(c) Remove the 8 bolts, 4 nuts, 4 plate washers, intake man-
ifold, delivery pipes and injectors assembly and 2 gas-
kets.
30. REMOVE PS PUMP BRACKET
31. REMOVE OIL DIPSTICK AND GUIDE
(a) Remove the 2 bolts holding the dipstick guide to the gen-
erator bracket.
(b) Pull out the dipstick guide together with the dipstick from
the oil pan.
(c) Remove the O−ring from the dipstick guide.
32. REMOVE GENERATOR BRACKET
33. REMOVE EXHAUST CROSSOVER PIPE
Remove the 6 nuts, crossover pipe and 2 gaskets.
34. REMOVE LH AND RH EXHAUST MANIFOLDS
(a) Remove the 6 nuts and exhaust manifold heat insulators.
(b) Remove the 12 nuts, LH, RH exhaust manifolds and gas-
ket.

Downloaded from www.Manualslib.com manuals search engine P21192
P21198
L = 165 mm (6.50 in.) L = 165 mm (6.50 in.)
Join Line
L = 130 mm
(5.12 in.)
L = 265 mm
(10.43 in.)L = 145 mm
(5.71 in.)
L = Length
Join Line
EM−58
− ENGINE MECHANICAL (5VZ−FE)CYLINDER HEAD
1996 TOYOTA T100 (RM449U)
(d) Install the dipstick guide with the 2 bolts.
Torque: 8 N·m (80 kgf·cm, 71 in.·lbf)
(e) Install the dipstick.
16. INSTALL PS PUMP BRACKET
Torque: 18.5 N·m (185 kgf·cm, 13 ft·lbf)
17. INSTALL INTAKE MANIFOLD ASSEMBLY
(a) Install 2 new gaskets and the intake manifold, delivery
pipe and injectors assembly with the 8 bolts, 4 plate wash-
ers and 4 nuts.
Torque: 18 N·m (180 kgf·cm, 13 ft·lbf)
(b) Install the intake manifold stay with the 2 bolts.
Torque: 18.5 N·m (185 kgf·cm, 13 ft·lbf)
(c) Connect the fuel inlet hose.
18. INSTALL FUEL PRESSURE REGULATOR
(See page SF−16)
19. INSTALL NO.3 TIMING BELT COVER
(a) Check that the timing belt cover gaskets have no cracks
or peeling, etc.
If the gaskets do have cracks or peeling etc., replace them us-
ing these steps:
Using a screwdriver and gasket scraper, remove all
the old gasket material.
Thoroughly clean all components to remove all the
loose material.
Remove the backing paper from a new gasket and
install the gasket evenly to the part of the timing belt
cover shaded black in the illustration.
(b) Install the timing belt cover with the 6 bolts.
Torque: 9 N·m (90 kgf·cm, 80 in.·lbf)
20. INSTALL CAMSHAFT POSITION SENSOR
Torque: 8 N·m (80 kgf·cm, 71 in.·lbf)

Downloaded from www.Manualslib.com manuals search engine P21245
S02073
− ENGINE MECHANICAL (5VZ−FE)CYLINDER HEAD
EM−59
1996 TOYOTA T100 (RM449U)
21. CONNECT ENGINE WIRE
(a) Install the engine wire with the 3 bolts.
(b) Connect the 3 engine wire clamps.
(c) Connect these connectors:
Oil pressure sensor connector
Crankshaft position sensor connector
6 Injector connectors
ECT sender gauge connector
ECT sensor connector
Knock sensor connector
Camshaft position sensor connector
22. INSTALL INTAKE AIR CONNECTOR
(a) Install a new gasket and the intake air connector with the
3 bolts and 2 nuts.
Torque: 18.5 N·m (185 kgf·cm, 13 ft·lbf)
(b) Connect the DLC1 to the bracket.
(c) Install the bolt, and connect the ground strap to the intake
air connector.
(d) Connect the brake booster vacuum hose to the intake air
connector.
(e) Connect the 2 fuel return hoses.
(f) Install the engine wire with the bolt.
(g) w/ A/C
Connect the A/C idle−up valve connector.

Downloaded from www.Manualslib.com manuals search engine Z19131
EM−60
− ENGINE MECHANICAL (5VZ−FE)CYLINDER HEAD
1996 TOYOTA T100 (RM449U)
23. INSTALL AIR INTAKE CHAMBER ASSEMBLY
(a) Install a new gasket and the air intake chamber assembly
with the 4 bolts and 2 nuts.
Torque: 18.5 N·m (185 kgf·cm, 13 ft·lbf)
(b) Connect these hoses:
2 PCV hoses
2 water bypass hoses
Air assist hose to throttle body
w/ EGR:
Water bypass hose
EVAP hose
Air hose to PS pump
w/ A/C
Air hose to A/C idle−up valve
(c) Connect these connectors:
VSV connector for fuel pressure control
Throttle position sensor connector
IAC valve connector
w/ EGR:
EGR gas temperature sensor connector
VSV connector for EGR
24. INSTALL AIR INTAKE CHAMBER STAY
(a) Install the air intake chamber stay with the 2 bolts.
Torque:
14 mm head bolt: 40 N·m (400 kgf·cm, 30 ft·lbf)
12 mm head bolt: 18.5 N·m (185 kgf·cm, 13 ft·lbf)
(b) A/T:
Install a new O−ring to the oil filler tube.
(c) Apply soapy water to the O−ring.
(d) Push in the oil filler tube end into the tube hole of the oil
pan.
(e) Install the oil filler tube and No.1 throttle cable clamp with
the 2 nuts, bolt.
(f) Install the dipstick.
25. w/ EGR:
INSTALL EGR PIPE
Install 2 new gaskets and the EGR pipe with the 6 nuts.
Torque:
Nut A: 18.5 N·m (185 kgf·cm, 13 ft·lbf)
Nut B: 8 N·m (80 kgf·cm, 71 in.·lbf)
26. TEMPORARILY INSTALL GENERATOR

Downloaded from www.Manualslib.com manuals search engine Z14701
P20501
P21435
P21441
P21437
EM−66
− ENGINE MECHANICAL (5VZ−FE)ENGINE UNIT (2WD)
1996 TOYOTA T100 (RM449U)
(3) Fuel return hose
(4) Fuel inlet hose
17. DISCONNECT STARTER WIRE AND CONNECTOR
(a) Remove the bolt, and disconnect the ground strap.
(b) Remove the 2 nuts, disconnect the positive (+) terminal
cable from battery.
(c) Disconnect the 2 starter wire clamps and connector.
18. DISCONNECT GENERATOR WIRE
(a) Disconnect the generator connector.
(b) Remove the nut, and disconnect the generator wire and
wire clip.
19. REMOVE FRONT DOOR SCUFF PLATE AND COWL
SIDE TRIM
20. DISCONNECT ENGINE WIRE AND CONNECTORS
(a) Remove the 3 bolts and ECM.
(b) M/T:
Disconnect the 3 ECM connectors.
(c) A/T:
Disconnect the 4 ECM connectors.
(d) Disconnect the 2 connectors from the cowl wire.
(e) Disconnect these wires and connectors:
Igniter connector
Ground strap
(f) Disconnect the 6 engine wire clamps.
(g) Pull out the engine wire from the cabin.
21. M/T:
REMOVE SHIFT LEVER
(a) Remove the shift lever knob.
(b) Remove the 4 screws and shift lever boot.
(c) Remove the shift lever.
22. REMOVE STABILIZER BAR
(See page SA−16)
23. REMOVE PROPELLER SHAFT
(See page PR−3)
24. DISCONNECT SPEEDOMETER CABLE
NOTICE:
Do not lose the felt protector and washers.
25. REMOVE FRONT EXHAUST PIPE
(a) Disconnect the 2 heated oxygen sensor connectors.
(b) Remove the 2 bolts, and retainer holding the front ex-
haust pipe to the center exhaust pipe.

Downloaded from www.Manualslib.com manuals search engine P21436
P21441
P21435
EM−70
− ENGINE MECHANICAL (5VZ−FE)ENGINE UNIT (2WD)
1996 TOYOTA T100 (RM449U)
5. A/T:
INSTALL CROSS SHAFT
(a) Install the cross shaft with the 4 bolts and nut.
(b) Connect the shifting rod with the clip.
6. M/T:
INSTALL CLUTCH RELEASE CYLINDER
(a) Install the clutch release cylinder with the 2 bolts.
Torque: 12 N·m (120 kgf·cm, 9 ft·lbf)
(b) Connect the clutch line with the 3 bolts.
7. INSTALL FRONT EXHAUST PIPE
(a) Install 2 new gaskets and the front exhaust pipe assembly
with new 3 nuts.
Torque: 62 N·m (630 kgf·cm, 46 ft·lbf)
(b) Install the support bracket with the 3 bolts.
Torque: 44 N·m (450 kgf·cm, 33 ft·lbf)
(c) Connect a new gasket and the front exhaust pipe assem-
bly to the center exhaust pipe with the 2 bolts and retainer.
Torque: 48 N·m (490 kgf·cm, 35 ft·lbf)
(d) Connect the 2 heated oxygen sensor connectors.
8. CONNECT SPEEDOMETER CABLE
9. INSTALL PROPELLER SHAFT
(See page PR−9)
10. INSTALL STABILIZER BAR (See page SA−125)
11. M/T:
INSTALL SHIFT LEVER
(a) Install the shift lever.
(b) Install the shift lever boot with the 4 screws.
(c) Install the shift lever knob.
12. CONNECT ENGINE WIRE AND CONNECTORS
(a) Push in the engine wire through the cowl panel.
(b) Connect the 6 engine wire clamps
(c) Connect these wire and connectors:
Ground strap
Igniter connector
(d) Connect 2 connectors to cowl wire.
(e) M/T:
Connect 3 connectors to the ECM.
(f) A/T:
Connect 4 connectors to the ECM.
(g) Install the ECM with the 3 bolts.

Downloaded from www.Manualslib.com manuals search engine P21463
EM1OW−01
P21465
P21464
P21466
EM−84
− ENGINE MECHANICAL (5VZ−FE)CYLINDER BLOCK
1996 TOYOTA T100 (RM449U)
DISASSEMBLY
1. M/T:
REMOVE FLYWHEEL
2. A/T:
REMOVE DRIVE PLATE
3. REMOVE REAR END PLATE
Remove the bolt and end plate.
4. INSTALL ENGINE TO ENGINE STAND FOR DIS-
ASSEMBLY
5. REMOVE TIMING BELT AND PULLEYS (See page
EM−13)
6. REMOVE CYLINDER HEADS (See page EM−30)
7. REMOVE WATER BYPASS PIPE WITH KNOCK SEN-
SOR WIRE
(a) Disconnect the 2 knock sensor connectors.
(b) Remove the 2 bolts, nut and water bypass pipe.
8. REMOVE NO.2 IDLER PULLEY BRACKET
Remove the 3 bolts and idler pulley bracket.
9. REMOVE KNOCK SENSORS
Using SST, remove the 2 knock sensors.
SST 09816−30010
10. REMOVE WATER PUMP (See page CO−5)
11. REMOVE GENERATOR ADJUSTING BAR
12. REMOVE OIL PRESSURE SWITCH
Using SST, remove the oil pressure switch.
SST 09816−30010
13. REMOVE OIL FILTER AND OIL FILTER UNION
(a) Using SST, remove the oil filter.
SST 09228−07501
(b) Using 12 mm hexagon wrench, remove the union.
14. REMOVE RH AND LH ENGINE MOUNTING BRACKET
15. REMOVE COOLANT DRAIN COCK
16. w/o OIL COOLER:
REMOVE OIL HOLE COVER PLATE
