− SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1996 TOYOTA T100 (RM449U)
INSPECTION
1. VEHICLES NOT INVOLVED IN A COLLISION
Do a diagnostic system check. (See page DI−365)
2. VEHICLES INVOLVED IN A COLLISION
(a) Do a diagnostic system check. (See page DI−365)
(b) If the front fender of the car or its periphery is damaged,
do a visually check for damage to the front airbag sensor,
which includes the following items even if the airbag was
not deployed:
Bracket deformation
Peeling of paint off the bracket
Cracks, dents or chips in the case
Cracks, dents, chipping and scratches the connec-
tor
Peeling of the label or damage to the series number

Downloaded from www.Manualslib.com manuals search engine RS03X−01
− SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
RS−29
1996 TOYOTA T100 (RM449U)
REPLACEMENT
REPLACEMENT REQUIREMENT
In the following cases, replace the front airbag sensor.
If the SRS has been deployed in a collision. (Replace both the left and right airbag sensors.)
If the front airbag sensor has been found to be faulty in troubleshooting.
If the front airbag sensor has been found to be faulty during the check in item
(See page RS−28).
If the front airbag sensor has been dropped.
CAUTION:
For removal and installation of the front airbag sensor, see page RS−27 and RS−30.
Be sure to follow the correct procedure.

Downloaded from www.Manualslib.com manuals search engine RS03Y−02
Z09743
Front RS−30
− SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1996 TOYOTA T100 (RM449U)
INSTALLATION
1. INSTALL FRONT AIRBAG SENSOR
(a) Install the sensor so that the arrow on the sensor faces
toward the front of the vehicle.
(b) Using a torx wrench, install the sensor with 2 screws.
Torx wrench: T40 (Part No. 09042−00020 or locally
manufactured tool)
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(c) Connect the connector.
NOTICE:
Make sure the sensor is installed to the specified
torque.
If the sensor has been dropped, or there are cracks,
dents or other defects in the case, brackets or con-
nector, replace the removed sensor, always replace
the set bolts with new ones.
The sensor set bolts which have been anti−rust
treated. When the sensor is removed, always replace
the set bolts with new ones.
After installation, shake the sensor to check that
there is no looseness.
The front sensor is equipped with an electrical con-
nection check mechanism. Be sure to lock this mech-
anism securely when connecting the connector . If
the connector is not securely locked, a malfunction
code will be detected by the diagnostic system.
2. INSTALL REMOVED PARTS

Downloaded from www.Manualslib.com manuals search engine RS03Z−02
R12498
SRS Warning Light
Steering Wheel Pad
(with Airbag) Front Airbag Sensor RH
Front Airbag Sensor LH
Spiral Cable
Center Airbag Sensor Assembly
− SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS−31
1798 Author: Date:
1996 TOYOTA T100 (RM449U)
WIRE HARNESS AND CONNECTOR
LOCATION

Downloaded from www.Manualslib.com manuals search engine RS041−01
− SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS−33
1996 TOYOTA T100 (RM449U)
REPLACEMENT
In the following cases,replace the wire harness or connector.
If any part of the SRS wire harness or any connector has been found to be faulty in troubleshoot-
ing.
If any part of the SRS wire harness or any connector has been found to be faulty during the check
in items (See page RS−32).
CAUTION:
If the wire harness used in the SRS is damaged, replace the whole wire harness assembly.
When the connector to the front airbag sensors can be repaired alone (when there is no damage
to the wire harness), use the repair wire specially designed for this purpose.

Downloaded from www.Manualslib.com manuals search engine BE−6
− BODY ELECTRICALBODY ELECTRICAL SYSTEM
1996 TOYOTA T100 (RM449U)
COMBINATION METER
Meter, Gauge and Illumination:
SymptomSuspect AreaSee page
Tachometer, fuel gauge oil Pressure and water temperature
gauge do not operate
1. GAUGE Fuse (Junction Block No.1)
2. Combination Meter Wiring Circuit
3. Wire Harness
4. Meter Circuit Plate−
BE−36
−
BE−36
Speedometer does not operate1. Vehicle Speed Sensor
2. Speedometer Driven Gear and Drive GearBE−38
−
Tachometer does not operate
1. Combination Meter Wiring Circuit
2. Wire Harness
3. Igniter
4. Meter Circuit PlateBE−36
−
−
−
BE−36
Fuel gauge does not operate or abnormal operation
1. Fuel Receiver Gauge
2. Fuel Sender Gauge
3. Combination Meter Wiring Circuit
4. Wire HarnessBE−38
BE−38
BE−36
−
Engine coolant temperature gauge does not operate
or abnormal operation
1. Engine Coolant Temperature Receiver Gauge
2. Engine Coolant Temperature Sender Gauge
3. Combination Meter Wiring Circuit
4. Wire HarnessBE−38
BE−38
BE−36
−
Oil pressure gauge does not operte or abnormal operation
1. Oil Pressure Receiver Gauge
2. Oil Pressure Sender Gauge
3. Combination Meter Wiring Circuit
4. Wire HarnessBE−38
BE−38
BE−36
−
All illumination lights do not light up
1. TAIL Fuse (Junction Block No.1)
2. Light Control Rheostat
3. Wire Harness−
BE−38
−
Brightness does not change even when rheostat turned1. Bulb
2. Wire Harness−
−
Only one illumination light does not light up1. Bulb
2. Wire Harness−
−
COMBINATION METER
Warning Lights:
SymptomSuspect AreaSee page
Warning light do not light up (Except Discharge)
1. GAUGE Fuse (Junction Block No.1)
2. Combination Meter Wiring Circuit
3. Wire Harness−
BE−36
−
Oil pressure warning light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Oil Pressure Warning Switch
4. Wire Harness−
BE−36
BE−38
−
Washer Fluid Level Warning light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Washer Fluid Level Warning Switch
4. Wire Harness−
BE−36
BE−38
−
Fuel level warning light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Fuel Level Warning Switch
4. Wire Harness−
BE−36
BE−38
−

Downloaded from www.Manualslib.com manuals search engine − BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−7
1996 TOYOTA T100 (RM449U) A/T Oil temperature warning indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. A/T Oil Temperature Sensor
4. Wire Harness−
BE−36
BE−38
−
SRS warning light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Center Airbag Sensor Assembly
4. Wire Harness−
BE−36
DI−372
−
Malfunction indicator does not light up
1. Bulb
2. ECM
3. Wire Harness−
−
−
−
Seat belt warning light does not light up
1. Bulb
2. Integration Relay
3. Wiring Harness−
−
−
Discharge warning light does not light up
1. IGN Fuse (Junction Block No.1)
2. Bulb
3. Wire Harness
4. Generator−
−
−
−
Brake warning light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Parking Brake Switch
4. Brake Fluid Level Warning Switch−
BE−36
BE−38
BE−38
COMBINATION METER
Indicator Lights:
SymptomSuspect AreaSee page
O/D OFF indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. O/D OFF Switch
4. Wire Harness−
BE−36
DI−311
−
High beam indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Wire Harness
4. Headlight System−
BE−36
−
BE−2
Turn indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Wire Harness
4. Turn Signal and Hazard Warning System−
BE−36
−
BE−2
Shift indicator lights do not light up (ALL)
1. Bulb
2. Combination Meter Wiring Circuit
3. PNP Switch
4. Wire Harness−
BE−36
DI−306
−
Shift indicator lights do not light up (L, 2, D)
1. Bulb
2. Combination Meter Wiring Circuit
3. PNP Switch
4. Light Control Rheostat
5. Wire Harness−
BE−36
DI−306
BE−38
−
Only one shift indicator does not light up1. Bulb
2. Combination Meter Wiring Circuit−
BE−36

Downloaded from www.Manualslib.com manuals search engine BE03F−03
Z09689
A w/ Tachometer
w/o Tachometer
A B
B BE−38
− BODY ELECTRICALCOMBINATION METER
1996 TOYOTA T100 (RM449U)
INSPECTION
1. INSPECT SPEEDOMETER ON−VEHICLE
(a) Using a speedometer tester, inspect the speedometer for
allowable indication error and check the operation of the
odometer.
HINT:
Tire wear and tire over or under inflation will increase the indica-
tion error.
If error is excessive, replace the speedometer.
(b) Check the speedometer for pointer vibration and abnor-
mal noise.
USA (mph)CANADA (km/h)
Standard indication Allowable rangeStandard indication Allowable range
20 18 − 24 20 17 − 24
40 38 − 44 40 38 − 46
60 58 − 66 60 57.5 − 67
80 78 − 88 80 77 − 88
100 98 − 11 0 100 96 − 109
120 118 − 132 120 115 − 130
140 134 − 151.5
160 153 − 173
2. INSPECT VEHICLE SPEED SENSOR OPERATION
Check that there is continuity between terminals A and B four
times for every revolution of the speedometer shaft.
If operation is not as specified, replace the speedometer.

Downloaded from www.Manualslib.com manuals search engine N14519
Drain Hose
N17949
− AIR CONDITIONINGAIR CONDITIONING SYSTEM
AC−9
1996 TOYOTA T100 (RM449U)
(b) Bring the gas leak detector close to the drain hose before
performing the test.
HINT:
After the blower motor has stopped, leave the cooling unit
for more than 15 minutes.
Expose the gas leak detector sensor under the drain
hose.
When bring the gas leak detector close to the drain hose,
make sure that the gas leak detector does not react to the
volatile gases.
If such reaction is unavoidable, the vehicle must be lifted up.
(c) If gas leak is not detected on the drain hose, remove the
blower resistor from the cooling unit. Then insert the gas
leak detector sensor into the unit and perform the test.
(d) Disconnect the connector and leave the pressure switch
for approx. 20 minutes. Then bring the gas leak detector
close to the pressure switch and perform the test.
(e) Bring the gas leak detector close to the refrigerant lines
and perform the test.
