DI−422
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 TOYOTA T100 (RM449U)
DTC 12 Actuator Magnetic Clutch Circuit
CIRCUIT DESCRIPTION
This circuit turns on the magnetic clutch inside the actuator during cruise control operation according to the
signal from the ECU. If a malfunction occurs in the actuator or speed sensor, etc. during cruise control opera-
tion, the rotor shaft between the motor and control plate is released.
When the brake pedal is depressed, the stop light switch turns ON, supplying electrical power to the stop
light. Power supply to the magnetic clutch is mechanically cut and the magnetic clutch is turned OFF.
When driving downhill, if the vehicle speed exceeds the set speed by 15 km/h (9 mph), the ECU turns the
safety magnet clutch OFF. If the vehicle speed later drops to within 10 km/h (6 mph) above the set speed,
then cruise control at the set speed is resumed.
DTC No.Detection ItemTrouble Area
12Short in actuator magnetic clutch circuit.
Open (0.8 sec.) in actuator magnetic clutch circuit.
Actuator
Stop light switch
Wire harness
Cruise control ECU
WIRING DIAGRAM
DI351−02

Downloaded from www.Manualslib.com manuals search engine I22680
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−425
1996 TOYOTA T100 (RM449U)
DTC 13 Actuator Position Sensor Circuit
CIRCUIT DESCRIPTION
The circuit detects the rotation position of the actuator control plate and sends a signal to the ECU.
DTC No..Detection ItemTrouble Area
13Position sensor detects abnormal voltage.
Actuator
Wire harness
Cruise control ECU
WIRING DIAGRAM
DI352−02

Downloaded from www.Manualslib.com manuals search engine I22679
VR 3
VR 2
I00006
1
3
DI−426
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
1 Check resistance between terminals VR2 and VR3 of cruise control ECU connec-
tor.
PREPARATION:
(a) Remove the ECU with connectors still connected.
(b) Turn ignition switch OFF.
CHECK:
Measure voltage between terminals VR2 and VR3 of ECU con-
nector while turning control plate slowly by hand from the decel-
eration side to the acceleration side.
OK:
Voltage:
Fully closed: Approx. 1.3 V
Fully opened: Approx. 4.0 V
As the control plate is turned, the voltage should in-
crease gradually without interruption.
NG Proceed to next circuit inspection shown in
problem symptoms table (See page DI−419).
OK
2 Check resistance between terminals VR1 and VR3 of actuator position sensor.
PREPARATION:
(a) Turn ignition switch OFF.
(b) Disconnect the actuator connector.
CHECK:
Measure resistance between actuator terminals 1 and 3 of ac-
tuator connector.
OK:
Resistance: Approx. 2.2 kΩ (25 °C)
NG Replace cruise control actuator.
OK

Downloaded from www.Manualslib.com manuals search engine I06382
2
3
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−427
1996 TOYOTA T100 (RM449U)
3 Check voltage between terminals VR2 and VR3 of actuator position sensor.
PREPARATION:
(a) Turn ignition switch ON.
(b) Connect the actuator connector.
CHECK:
Measure voltage between terminals 2 and 3 of actuator con-
nector while turning control plate slowly by hand from the decel-
eration side to the acceleration side.
OK:
Voltage: 1.3 − 4.0 V
HINT:
As the control plate is turned, the voltage should increase grad-
ually without interruption.
NG Replace cruise control actuator.
OK
4 Check for open and short in harness and connector between cruise control ECU
and actuator position sensor (See page IN−16).
NG Repair or replace harness or connector.
OK
Check and replace cruise control ECU (See
page IN−26).

Downloaded from www.Manualslib.com manuals search engine I00414
Speed Sensor
ECTOD/TRIP METER
Cruise Control ECU 4 pulse/
1 rotation
of rotor shaft4 pulse/
1 rotation
of rotor shaft
I22673
DI−428
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 TOYOTA T100 (RM449U)
DTC 21 Vehicle Speed Sensor Circuit
CIRCUIT DESCRIPTION
The vehicle speed siggnal is sent to cruise control ECU from the vehicle speed sensor.
The rotor shaft is driven by the gear of the transmission.
For each rotation of the shaft, the vehicle speed sensor sends a 4−pulse signal through the combination
meter to the cruise control ECU (See the following).
This signal is converted inside the combination meter and sent as a 4−pulse signal to the cruise control ECU.
The ECU calculates the vehicle speed from this pulse frequency.
DTC No.Detection ItemTrouble Area
21Speed signal is not input to the cruise control ECU while
cruise control is set.Vehicle speed sensor
Wire harness
Cruise control ECU
WIRING DIAGRAM
DI353−02

Downloaded from www.Manualslib.com manuals search engine Input SignalIndicator Light
Blinking Pattern
Drive at about
40 km/h (25 mph)
or below
Drive at about
40 km/h (25 mph)
or higherLightON
OFF
LightON
OFF
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−429
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
1 Input signal check.
CHECK:
(a) See input signal check on page DI−410.
(b) Check indicator light operation when driving at vehicle
speed above 40 km/h (25 mph), and at vehicle speed be-
low 40 km/h (25 mph).
OK:
Vehicle speed above 40 km/h (25 mph):
Indicator light blinks
Vehicle speed below 40 km/h (25 mph):
Indicator light stays on
OK Check and replace cruise control ECU (See
page IN−26).
NG
2 Check speedometer circuit (See Combination meter troubleshooting on page
BE−36).
NG Repair or replace harness, connector or com-
bination meter assembly.
OK
3 Check harness and connector between cruise control ECU and combination me-
ter, combination meter and vehicle speed sensor (See page IN−16).
NG Repair or replace harness or connector.
OK

Downloaded from www.Manualslib.com manuals search engine DI−430
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 TOYOTA T100 (RM449U)
4 Check vehicle speed sensor (See page BE−38).
NG Replace vehicle speed sensor.
OK
Check and replace cruise control ECU (See
page IN−26).

Downloaded from www.Manualslib.com manuals search engine I22676
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−437
1996 TOYOTA T100 (RM449U)
Idle Switch Circuit
CIRCUIT DESCRIPTION
When the idle switch is turned ON, a signal is sent to the ECU. The ECU uses this signal to correct the dis-
crepancy between the throttle valve position and the actuator position sensor value to enable accurate
cruise control at the set speed. If the idle switch is malfunctioning, problem symptoms also occur in the en-
gine, so also inspect the engine.
WIRING DIAGRAM
DI356−02

Downloaded from www.Manualslib.com manuals search engine I22837
DI−438
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
1 Check voltage between terminal IDL of cruise control ECU connector and body
ground.
PREPARATION:
(a) Remove the ECU with connector still connected.
(b) Disconnect the ECM and ABS ECU connectors.
(c) Turn ignition switch ON.
CHECK:
Measure voltage between terminal IDL of ECU connector and
body ground when the throttle valve is fully closed and fully
opened.
OK:
Throttle valve positionVoltage
Fully opened10 − 16 V
Fully closedBelow 1 V
OK Proceed to next circuit inspection shown in
problem symptoms table (See page DI−419).
NG
2 Check harness and connector between ECM and throttle position sensor (See
page IN−16).
NG Repair or replace harness or connector.
OK
3 Check throttle position sensor circuit.
(3RZ−FE: See page MF−25)
(5VZ−FE: See page SF−31)
NG Replace throttle position sensor.
OK

Downloaded from www.Manualslib.com manuals search engine I22686
Throttle Position Sensor
1
2
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−439
1996 TOYOTA T100 (RM449U)
4 Check throttle position sensor.
PREPARATION:
Disconnect the throttle position sensor connector.
CHECK:
Measure resistance between terminals 1 and 2 of throttle posi-
tion sensor connector when the throttle valve is fully closed and
fully opened.
OK:
Throttle valve positionResistance
Fully opened1 MΩ or higher
Fully closedBelow 500 Ω
NG Replace throttle position sensor.
OK
5 Check for open and short in harness and connector between cruise control ECU
and throttle position sensor, throttle position sensor and body ground (See page
IN−16).
NG Repair or replace harness or connector.
OK
Check and replace cruise control ECU (See
page IN−26).
