77
YOUR RADIO ANTENNA
To lower a manual antenna, carefully
push
it down.
To prevent damage to the entenna,
make sure it is retracted before
driving your Toyota through anautomatic car wash.
NOTICE
YOUR CASSETTE PLAYER
When you insert a cassette, the exposed tape should be to the right.
Do not oil any part of the player anddo not insert anything other than
cassette tapes into the slot, or thetape player may be damaged.
NOTICE

78Details of specific buttons, controls, and
features are described in
the alphabetical
listing that follows.
ÐUsing your audio system: controls and features
Type 1-1

79
Details of specific buttons, controls, and
features are described in
the alphabetical
listing that follows.

Type 1-2

801 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and tune in radio stations.
To preset a station to a button: Tune in the
desired station (see TUNEº). Push and
hold down
the button until you hear a beep
Ð this will set the station to the button.
The button number will appear on the dis-
play.
To tune in to a preset station: Push the
button for the station you want. The button
number and station frequency will appear
on the display.
These systems can store one AM and one
FM station for each button. The preset
station memory will be canceled out if the
power source is interrupted (battery dis-
connected or fuse blown). AM V FM
Push AM VFMº to switch between the AM
and FM bands. AMº or FMº will appear
on the display.
If the audio system is off, you can turn on the radio by pushing AM VFMº. BAL (Balance)
This knob lets you adjust the balance be- tween the right and left speakers.
Type 1-1ÐMove the BALº ring around
TONEº to adjust the right/left balance.
Type 1-2ÐPush BAL/FADEº so that it
pops
out of its retracted position. Turn the
knob to adjust the balance. Push the knob
back into its retracted position. BASS
Type 1-2 only This knob lets you adjust the bass level. Push BASS/TREBº so that it pops out of
its retracted position. Turn the knob to ad-
just the bass. Push the knob back into its
retracted position.
FADE
Type 1-2 only
This knob lets you adjust the balance be- tween the front and rear speakers. Push BAL/F ADEº so that it pops out of its
retracted position. Pull out the knob. Turn
the knob to adjust the front/rear balance. Push the knob back into its retracted posi-
tion. PWR
VVOL (Power VVolume)
Push PWR VVOLº to turn the audio sys-
tem on and off. Turn the PWR VVOLº knob
to adjust the volume. SCAN
Type 1-2 only When you push SCANº, the radio finds
the next station up the station band, plays
it for 5 seconds, and than scans again. To select a station, push SCANº a secondtime.
ST (Stereo reception) display
Your radio automatically changes to ste-
reo reception when a stereo broadcast is
received. STº appears on the display. If the signal becomes weak, the radio re-
duces the amount of channel separation to prevent the weak signal from creating
noise. If the signal becomes extremelyweak, the radio switches from stereo to mono reception.
TONE
Type 1-1 only
Turn TONEº to adjust the tone.

81
TREB (Treble)
Type 1-2 only
This knob lets you adjust the treble level.Push BASS/TREBº so that it pops out of
its retracted position. Pull out the knob.
Turn the knob to adjust the treble. Pushthe knob back into its retracted position. TUNE
Tuning
Your Toyota has an electronic tuning radio (ETR). Push and release the
~º (up) or  !º
(down) side of TUNEº to step up or down
the station band. If you hear a beep, you
held the button too long and the radio will
go into the seek mode. Seeking
In the seek mode, the radio finds and plays the next station up or down the sta-tion band.
To seek a station, push and hold the  ~º or
 ! º side of TUNEº until you hear a beep.
Do this again to find another station.

82Details of specific buttons, controls and
features are described in
the alphabetical
listing that follows.

Type 2-1

83
Details of specific buttons, controls and
features are described in
the alphabetical
listing that follows.

Type 2-2

841 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and tune in radio stations.
To preset a station to a button: Tune in the
desired station (see TUNEº). Push and
hold down the button until you hear abeepÐthis will set the station to the but-
ton.
The button number will appear on the
display.
To tune in to a preset station: Push the
button for the station you want. The button
number and station frequency will appear
on the display.
Type 2-1-These systems can store one AM and one FM station for each button.
The preset station memory will be can-
celed out if the power source is inter- rupted (battery disconnected or fuseblown).
Type 2-2ÐThese systems can store one
AM and two FM stations for each button.
(The display will show AMº, FM1º, or
FM2º when you push AM VFMº.) To can-
cel out the preset station memory, push
1:, 2º, and 3º at the same time and hold
them in until you hear a beep.
(Eject button)
Push this button to eject a cassette.
After you turn the ignition to LOCKº, you
will be able to eject a cassette but you will
not be able to reinsert it. AM VFM
Push AM VFMº to switch between the AM
and FM bands.
Type 2-1-AMº or FMº will appear on the
display.
Type 2-2-ºAMº, FMº or FM2º will ap-
pear on the display.
If the audio system is off, you can turn on
the radio by pushing AM VFMº. Also, push
the AM VFMº button to switch from cas-
sette operation to radio operation. APS (Automatic porgram selection)
Type 2-2 only
The automatic program selection (AS)
feature allows you to program your cas-
sette player to skip forward or backward
to locate the song you want to hear. You can skip up to nine tracks at a time. Push APSº. APSº and 1º will appear on
the display. Next, push APS until the number on the
display reaches the number of tracks you want to skip. If you push APSº ten times,
the APS feature will be turned off.
If you choose the number 1º, the play- er will rewind to the beginning of the
current track.
 When counting the number of tracksyou want to rewind, remember to count the current track as well. For ex-
ample, if you want to rewind to a song
that is two before the song you are lis-
tening to, push APSº until 3º appears
on the display.
Finally, push REWº or FFº to choose the
direction you want to skip. The player will
rewind or fast forward the selected num-
ber of tracks and play.
The APS number you select can be higher
than the number of tracks remaining on
the current cassette side. After the begin-
ning or end of the tape is reached, the
player will automatically reverse sides
and rewind or fast forward the additional
number of tracks.

85
There must be at
least 3 seconds of blank
space between tracks in order for the APS
feature to work correctly. In addition, the
APS feature may not work well with some
spoken word, live, or cl assical recordings.
BAL (Balance)
This knob lets you adjust the balance be- tween the right and left speakers.
Pull out PWR/VOL/BALº . Turn the knob
to adjust the right/left balance. Push the
knob back into its normal position. BASS This knob lets you adjust the bass level. Push BASS/TREBº so that it pops out of
its retracted position. Turn the knob to ad-
just the bass. Push the knob back into its
retracted position. Dolby )

NR*
Type 2-1 only If you are listening to a tape that was re-
corded with Dolby )
Noise Reduction,
push the button marked with the
double-D symbol. The double-D symbol
will appear on the display. Push the button
again to turn off Dolby )
NR. The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc- tion, play your tapes with this button on or
off according to the mode used for record-
ing the tape.
*: Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation. DOLBYº and the
double-D symbol are tradenmarks of Dolby Labratories Licens-
ing Corporation.
Dolby )

B VC*
Type 2-2 only If you are listening to a tape that was re- corded with Dolby )
B or C Noise Reduc-
tion, push the botton marked with the
double-D symbol until the appropriate symbol appears on the display. To turn off
Dolby )
, push the boutton until the symbol
disappears from the display.
The Dolby B NR mode reduces tape noise by about 10 dB. The Dolby C NR mode re- duces tape noise by another 10 dB, or
about 20 dB total. For best sound repro-
duction, select the same NR mode that was used to record the tape. *: Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation. DOLBYº and the
double-D symbol are tradenmarks of Dolby Labratories Licens-
ing Corporation. MTL (Metal) display
Type 2-2 only
If a metal or chrome equivilant cassette
tape is
put in the cassette player, the play-
er will automatically adapt to it and MTLº
will appear on the display.
FADE
Move the FADEº knob around PWR/
VOLº to adjust the front/rear balance. PROG (Program)
Push PROGº to select the other side of
a cassette tape. The display indicates
which side is currently selected ( ~º indi-
cates top side, !º indicates bottom side).
Auto-reverse featureÐAfter the cassette
player reaches the end of a tape side, it automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
PWR/VOL (Power/Volume) Push PWR/VOLº to turn the audio sys-
tem on and off. T urn the PWR/VOLº knob
to adjust the volume.
Type 2-2ÐPull out and then turn PR/
VOLº to adjust the balance between the
right and left speakers. Move FADEº
around PWR/VOLº to adjust the front/ rear balance.

86REW/FF (Rewind/Fast forward) Push
the FFº side of the button to fast for-
ward a cassette tape. FFº will appear on
the display. Push the REWº side to re-
wind a tape. REWº will appear on the dis-
play.
To stop the tape while it is fast forwarding,
push FFº or TAPEº; to stop the tape
while it is rewinding, push REWº or
TAPEº. The tape will immediately begin
to play.
If a tape side rewinds completely, the cas-
sette player will stop and then play that
same side. If a tape fast forwards com-
pletely, the cassette player will play the
other side of the tape, using the auto-re-verse feature. R.M (Radio monitor)
Type 2-2 only
The radio monitor feautre allows you to
listen to the radio while a cassette is being
rewound or fast forwarded. Push R VMº. RMº will appear on the dis-
play. Any time you are rewinding or fast
forwarding a cassette tape, the radio will
play the station that was set most recent-
ly. (You can not change the radio station
unless you switch out of the cassette play-
er function.) Push R
VMº again to turn off the R'M fea-
ture. RPT (Repeat)
Type 2-2 only
The repeat feature automatically replays the current cassette. Push RPTº while the track is playing.
RPTº will appear on the display. When
the track ends, it will automatically be re-
wound and replayed. This process will be continued until you push the button again
to turn off the repeat feature.
There must be at least 3 seconds of blank
space between tracks in order for the re-
peat feature to work correctly. SCAN Radio
You can either scan all the frequencies on a band or scan only the preset stations for
that band.
To scan the preset stations: Quickly push
and release SCANº. If you hear a beep,
you held the button too long, and the radio will scan all the frequencies. The radio will tune in the next preset station up the
band, stay there for a few seconds, and
then move to the next preset station. To
select a station, push SCANº a second time. To scan all the frequencies: Push SCANº
until you hear a beep. The radio will find
the next station up the station band, staythere for a few seconds, and then scan
again. To select a station, push SCANº a
second time. Cassette Player
Type 2-2 only
The cassette player scan feature is similar
to the radio scan feature and uses the same button.
Push SCANº. SCANº will appear on the
display. The player will fast forward to the
next cassette track,
play it for 12 seconds,
and then scan again. To select a track,
push SCANº a second time. If the player reaches the end of one side of a cassette
tape, it will continue scanning on the other
side. SKIP
Type 2-2 only
The skip feature allows you to fast forward
past long stretches of blank tape. This is
especially useful at the end of cassettes.
