2. Fully extend the shoulder belt to put itin the lock mode. When the belt is
then retracted even slightly, it cannot
be extended.
To hold the infant seat securely, make
sure the belt is in the lock mode before
letting the belt retract.3. While pressing the infant seat firmly against the seat cushion and seatback,
let the shoulder belt retract as far as
it will go to hold the infant seat secure-
ly.CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.

’02 Tacoma U (L/O 0109)
862002 MY TACOMA_U (OM35786U)
4. To remove the infant seat, press thebucklerelease button and allow the
belt to retract completely. The belt will
move freely again and be ready to
work for an adult or older child passen-
ger.(B) CONVERTIBLE SEAT INSTALLATION
A convertible seat is used in forward
facing and rearfacing position depend-
ing on the child’s age and size. When
installing, follow the manufacturer’s in-
structions about the applicable child’s
age and size as well as directions for
installing a child restraint system.CAUTION
Never install a rearfacing child re-
straint system on the front passen-
ger seat because the force of the
rapid inflation of the front passen-
ger airbag can cause death or seri-
ous injury to the child.

’02 Tacoma U (L/O 0109)
872002 MY TACOMA_U (OM35786U)
Move seat
fully back
A forwardfacing child restraint sys-
tem should be allowed to be
installed on the front seat only
when it is unavoidable. Always
move the seat as far back as pos-
sible, because the force of the de-
ploying airbag could cause death or
serious injury to the child.Do not put a rearfacing child re-
straint system in the rear seat if it
interferes with the lock mechanism
of the front seats. This can cause
death or serious injury to the child
and front passenger in case of sud-
den braking or a collision.1. Run the lap and shoulder belt throughor around the convertible seat following
the instructions provided by its
manufacturer and insert the tab into
the buckle taking care not to twist the
belt. Keep the lap portion of the belt
tight.

’02 Tacoma U (L/O 0109)
882002 MY TACOMA_U (OM35786U)
CAUTION
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and
buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
2. Fully extend the shoulder belt to put itin the lock mode. When the belt is
then retracted slightly, it cannot be ex-
tended.
To hold the convertible seat securely,
make sure the belt is in the lock mode
before letting the belt retract.3. While pressing the convertible seat firmly against the seat cushion and
seatback, let the shoulder belt retract
as far as it will go to hold the convert-
ible seat securely.

’02 Tacoma U (L/O 0109)
892002 MY TACOMA_U (OM35786U)
CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
4. To remove the convertible seat, pressthe bucklerelease button and allow the
belt to retract completely. The belt will
move freely again and be ready to
work for an adult or older child passen-
ger.(C) BOOSTER SEAT INSTALLATION
A booster seat is used in forwardfac-
ing position only.

’02 Tacoma U (L/O 0109)
902002 MY TACOMA_U (OM35786U)
Move seat
fully back
CAUTION
A forwardfacing child restraint sys-
tem should be allowed to be put on
the front seat only when it is un-
avoidable. Always move the seat as
far back as possible, because the
force of the deploying airbag could
cause death or serious injury to the
child.
1. Sit the child on a booster seat. Runthe lap and shoulder belt through or
around the booster seat and child fol-
lowing the instructions provided by its
manufacturer and insert the tab into
the buckle taking care not to twist the
belt.
Make sure the shoulder belt is correctly
across the child’s shoulder and that the
lap belt is positioned as low as possible
on child’s hips. See “Seat belts” for de-
tails.
CAUTION
Always make sure the shoulder belt
is positioned across the center of
child’s shoulder. The belt should be
kept away from child’s neck, but
not falling off child’s s houlder. Fail-
ure to do so could reduce the
amount of protection in an accident
and cause serious injuries in a col-
lision.
Both highpositioned lap belts and
loosefitting belts could cause seri-
ous injuries due to sliding under
the lap belt during a collision or
other unintended result. Keep the
lap belt positioned as low on a
child’s hips as possible.
For child’s safety, do not place the
shoulder belt under child’s arm.
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.

’02 Tacoma U (L/O 0109)
912002 MY TACOMA_U (OM35786U)
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
2. To remove the child restraint system,press the bucklerelease button and al-
low the belt to retract.Regular cab with bench seat
Regular cab with separate seat
— U sin g a to p st rap
(regular
and double cab
models)

’02 Tacoma U (L/O 0109)
922002 MY TACOMA_U (OM35786U)
Double cab with rear seat
Follow the procedure below for a child
restraint system that requires the use
of a top strap.
Anchor
brackets
Regular cab with bench seat
Anchor
bracket
Regular cab with separate seat
Anchor
brackets
Double cab with rear seat
Use the anchor bracket on the back panel
to attach the top strap.
Regular cab models— Anchor brackets are installed for (each)
passenger seating position.
Double cab models— Anchor brackets are installed for each
rear seating position.

’02 Tacoma U (L/O 0109)
932002 MY TACOMA_U (OM35786U)
TO USE THE ANCHOR BRACKET:
Regular cab with bench seat—1. Pull the seatback release lever and swing the seatback forward slightly,
then latch the hook onto the anchor
bracket.
Return the seatback to its original
position.2. Fix the child restraint system withthe seat belt and tighten the top
strap.
For instructions on installing the child re-
straint system, see “Child restraint” in this
section.
CAUTION
When returning the seatback to its
original position, make sure the
seatback is securely locked by
pushing forward and rearward on
the top of the seatback.
Make sure the top strap is securely
latched, and check that the child
restraint system is secure by push-
ing and pulling it in different direc-
tions. Follow all the installation in-
structions provided by its manufac-
turer.

’02 Tacoma U (L/O 0109)
942002 MY TACOMA_U (OM35786U)
Regular cab with separate seat—1. Remove the passenger head re- straint.2. Pull the seatback release lever andswing the seatback forward slightly,
then latch the hook onto the anchor
bracket.
Return the seatback to upright posi-
tion.3. Fix the child restraint system withthe seat belt and tighten the top
strap.
Replace the passenger head re-
straint.
For instructions on installing the child re-
straint system, see “Child restraint” in this
section.
