TOYOTA TACOMA 2005 Owners Manual (in English)

1812005 TACOMA from Mar. ’05 Prod. (OM35862U)
LS17007
With the vehicle traveling at a speed of
25 km/h (15 mph) or less, release your
foot from the accelerator or brake pedal
to activate the system. The vehicle will
descend the hill at a low speed. While the
system is operating, the slip indicator light
on the instrument panel will flash and the
stop lights and high mounted stoplight will
be lit.
If you push the “DAC” switch to turn the
system off while it is in operation, the
system will stop operating gradually. The
downhill assist control system indicator
light will flash to alert the driver. To con-
tinue driving at a low speed, push the
“DAC” switch to turn the system on. The slip indicator light and downhill assist
control system indicator light come on for
a few seconds when the ignition key is
turned to “ON”. If any of the indicator
lights does not come on when the ignition
is turned on, contact your Toyota dealer.
If the system is used frequently, the
brake actuator temperature may become
too high and a buzzer will sound inter-
mittently.
If this happens, the downhill assist control
system indicator light will flash and a
buzzer will sound intermittently. When the
temperature of the brake actuator de-
creases, the system will begin to operate
again. Until it restarts, the traction control
system and hill
−start assist control system
will not operate; however, the conventional
brake can be operated.
The brake actuator temperature increases
during continuous operation of the follow-
ing systems under conditions such as on
slippery roads.
Downhill assist control system
Hill− start assist control system
Traction control system If the brake actuator temperature becomes
too high while any of the systems is oper-
ating, a buzzer will start to sound intermit-
tently to indicate that the downhill assist
control system can no longer operate. In
this case, stop your vehicle immediately at
a safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
At this time, the slip indicator light will
come on and the downhill assist control
system stops operating temporarily in or-
der to protect the brake actuator. (Al-
though the downhill assist control system
does not operate, it is no problem to con-
tinue your driving.) The system will be
automatically restored after a short time
and the slip indicator light goes out.

1822005 TACOMA from Mar. ’05 Prod. (OM35862U)
LS17017
If there is any abnormality in the sys-
tem, the “VSC TRAC” warning light will
come on. When the “DAC” switch is
pushed, the downhill assist control sys-
tem indicator light also flash.
If the “VSC TRAC” warning light comes
on, there may be an abnormality in any
of the following system in addition to the
downhill assist control system.
Hill−start assist control system
Traction control system
Vehicle stability control system
Downhill assist control system “VSC TRAC” warning light
When the system is normal and the igni-
tion key is turned to “ON”, the warning
light will come on and will go off after a
few seconds.
It is not a malfunction that the warning
light may stay on for 60 seconds after the
ignition key is turned to the “ON” position.
Depressing the brake pedal repeatedly
may turn on the light. It is normal if it
goes out after a few seconds.
If the warning light comes on while driv-
ing, the system does not work. However,
as normal braking operates when being
applied, it is no problem to continue your
driving.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition key is turned to “ON”.
The warning light remains on after the
ignition key is turned to “ON”.
The warning light comes on while driv-
ing.
The hillstart assist control system as-
sists you in starting to move up a
steep or slippery hill. When you start
to move up the hill slope, the system
helps to prevent the vehicle from roll-
ing backward in the interval while you
move your foot from the brake pedal to
the accelerator pedal.
CAUTION
Do not rely excessively on the h
ill
start assist control system. The ve-
hicle may not be able to start
smoothly on road surfaces or off
road surfaces such as extremely
steep slopes or icy roads, on which
sliding can occur very easily.
Do not use the hillstart assist con-
trol system to stop the vehicle. This
system is not designed as a func-
tion for stopping the vehicle on a
uphill slope.
Hillstart assist control
system (automatic
transmission only)

1832005 TACOMA from Mar. ’05 Prod. (OM35862U)
The hillstart assist control system will
operate for 5 seconds maximally when
all of the following conditions apply.
5speed automatic transmission—
When the transmission is in any of
positions “D”, “4”, “3”, “2” or “L”
4speed automatic transmission—
When the transmission is in any of
positions “D”, “3”, “2” or “L”
When the brake pedal is not de-
pressed
The system is designed to operate when
the vehicle is starting on an uphill slope;
therefore, if the transmission is in “P” or
“N” it will not operate. It will not operate
either if the vehicle starts to move in
reverse on a slope with the transmission
in the “R” or the rear differential is locked.
(with the rear differential lock)
LS17007
When the hill −start assist control system
is operating, the slip indicator light flashes
and an alarm sounds intermittently. At the
same time, the stop lamps and high
mounted stoplight are lit.
The slip indicator light comes on for a few
seconds when the ignition key is turned
to “ON”. If the indicator light does not
come on when the ignition is turned on,
contact your Toyota dealer. Keep in mind the following when driv-
ing.
The hill−
start assist control system op-
erates for 5 seconds maximally. If both
the brake and accelerator pedals re-
main unexpressed for longer than 5
seconds, the buzzer will sound at more
frequent intervals and the system will
gradually stop operating.
The hill −start assist control system is
not designed as a function for stopping
the vehicle on a uphill slope. When
stopping the vehicle, be sure to de-
press the brake pedal.
If the system is used frequently, the
brake actuator temperature may become
too high and a buzzer will sound inter-
mittently.
In this case, a buzzer will sound intermit-
tently. When the temperature of the brake
actuator goes down, the system will begin
to operate again. Until it restarts, the trac-
tion control system, “AUTO LSD” system,
hill −start assist control system and down-
hill assist control system will not operate;
however, the conventional brake can be
operated.

1842005 TACOMA from Mar. ’05 Prod. (OM35862U)
The brake actuator temperature increases
during continuous operation of the follow-
ing systems under conditions such as on
slippery roads.
Hill−start assist control system
Downhill assist control system
Traction control system
“AUTO LSD” system
If the brake actuator temperature becomes
too high while any of the systems is oper-
ating, a buzzer will start to sound intermit-
tently to indicate that the hill −start assist
control system can no longer operate. In
this case, stop your vehicle immediately at
a safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
At this time, the slip indicator light will
come on and the hill −start assist control
system stops operating temporarily in or-
der to protect the brake actuator. (Al-
though the hill −start assist control system
does not operate, it is no problem to con-
tinue your driving.) The system will be
automatically restored after a short time
and the slip indicator light goes out.
LS17017
If there is any abnormality in the sys-
tem, the “VSC TRAC” warning light will
come on.
If the system malfunctions, the “VSC
TRAC” warning light will come on.
If the “VSC TRAC” warning light comes
on, there may be an abnormality in any
of the following systems in addition to the
hill −start assist control system.
Downhill assist control system
Traction control system
“AUTO LSD” system
Vehicle stability control system “VSC TRAC” warning light
When the system is normal and the igni-
tion key is turned to “ON”, the warning
light will come on and will go off after a
few seconds.
It is not a malfunction that the warning
light may stay on for 60 seconds after the
ignition key is turned to “ON”.
Depressing the brake pedal repeatedly
may turn on the light. It is normal if it
goes out after a few seconds.
If the warning light comes on while driv-
ing, the system does not work. However,
as normal braking operates when being
applied, it is no problem to continue your
driving.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition key is turned to “ON”.
The warning light remains on after the
ignition key is turned to “ON”.
The warning light comes on while driv-
ing.

1852005 TACOMA from Mar. ’05 Prod. (OM35862U)
LS17011
The rear differential lock system is pro-
vided for use only when wheel spinning
occurs in a ditch or on a slippery or
ragged surface.
This differential lock system is effective in
case one of the rear wheels is spinning.
Four−wheel drive models—
Before using the rear differential lock sys-
tem, first shift the four −wheel drive control
into “L4” to see if this is sufficient. If this
has no effect, additionally use the rear
differential lock system.
CAUTION
Do not use the rear differential lock
in the conditions other than above.
Large steering effort and careful cor-
nering control will be required.
LS17013
To lock the rear differential, push the
switch.
Be sure to stop the wheels before locking
the differential.
For easy locking, depress the clutch ped-
al, push the lock switch and slowly re-
lease the clutch pedal.
The indicator light will blink when the
switch is turned on. Wait a few seconds
for the system to complete operation. Af-
ter the differential is locked, the light will
stop blinking and remain on.
Rear differential lock system

1862005 TACOMA from Mar. ’05 Prod. (OM35862U)
The following systems do not operate
when the rear differential is locked. It is
normal operation for the “ABS” warning
light ,“VSC OFF” indicator light and slip
indicator light to be on at this time.
With the downhill assist control system: If
the “DAC” switch turns on, the downhill
assist control system indicator light
flashes.
Anti−lock brake system
Brake assist system
Vehicle stability control system
Traction control system
Downhill assist control system
Hill −start assist control system
CAUTION
Do not lock the differential until the
wheels have stopped spinning.
Otherwise, the vehicle may move in
an unexpected direction when the
differential lock is engaged, result-
ing in an accident. This may also
lead to possible damage to differen-
tial lock component parts.
Do not drive over 8 km/h (5 mph)
when the differential is locked.
To unlock the differential, push the
switch once again.
Unlock the differential as soon as the ve-
hicle moves out.
For easy unlocking, slightly turn the steer-
ing wheel in either direction while the ve-
hicle is in motion.
When the differential lock is disengaged,
the indicator light will go out.
Four −wheel drive models—
The differential will also unlock if you shift
the front drive control switch knob to the
“H2” or “H4” position. Never forget to turn
off the switch after using this feature.
To check the indicator bulb, turn the igni-
tion key to the “ON” position, but do not
start the engine.
CAUTION
Do not keep driving with the differen-
tial lock switch on.
LS17018
Pedal type
LS17019
Lever type
Parking brake

1872005 TACOMA from Mar. ’05 Prod. (OM35862U)
When parking, firmly apply the parking
brake to avoid inadvertent creeping.
Pedal type—
To set: Fully depress the parking brake
pedal. For better holding power, first de-
press the brake pedal and hold it while
setting the parking brake.
To release: Depress the parking brake
pedal once again.
Lever type—
To set: Pull out on the lever. For better
holding power, first depress the brake
pedal and hold it while setting the parking
brake.
To release: Press the lock release button
(1), turn the lever clockwise (2), then
push it in (3).
To remind you that the parking brake is
set, the parking brake reminder light in
the instrument panel remains on until you
release the parking brake.
CAUTION
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.
The cruise control allows you to cruise
the vehicle at a desired speed over 40
km/h (25 mph) even with your foot off
the accelerator pedal.
Your cruising speed can be maintained up
or down grades within the limits of engine
performance, although a slight speed
change may occur when driving up or
down the grades. On steeper hills, a
greater speed change will occur so it is
better to drive without the cruise control.
CAUTION
To help maintain maximum control
of your vehicle, do not use the
cruise control when driving in
heavy or varying traffic, or on slip-
pery (rainy, icy or snowcovered) or
winding roads.
Avoid vehicle speed increases when
driving downhill. If the vehicle
speed is too fast in relation to the
cruise control set speed, cancel the
cruise control then downshift the
transmission to use engine braking
to slow down.
LS17020b
TURNING THE SYSTEM ON
To operate the cruise control, press the
“ON−OFF” button. This turns the system
on. The indicator light in the instrument
panel shows that you can now set the
vehicle at a desired cruising speed. Anoth-
er press will turn the system completely
off.
CAUTION
To avoid accidental cruise control en-
gagement, keep the “ONOFF” switch
off when not using the cruise control.
Cruise control

1882005 TACOMA from Mar. ’05 Prod. (OM35862U)
LS17021b
SETTING AT A DESIRED SPEED
On vehicles with automatic transmission,
the transmission must be in “D” before
you set the cruise control speed.
Bring your vehicle to the desired speed,
push the lever down in the “−SET” direc-
tion and release it. This sets the vehicle
at that speed. If the speed is not satisfac-
tory, tap the lever up for a faster speed,
or tap it down for a slower speed. Each
tap changes the set speed by 1.6 km/h
(1.0 mph). You can now take your foot off
the accelerator pedal. If you need acceleration—for example,
when passing—depress the accelerator
pedal enough for the vehicle to exceed
the set speed. When you release it, the
vehicle will return to the speed set prior
to the acceleration.
CAUTION
For manual transmission:
While driving with the cruise control
on, do not shift to neutral without
depressing the clutch pedal, as this
may cause engine racing or overrev-
ving.
CANCELLING THE PRESET SPEED
You can cancel the preset speed by:
a. Pulling the lever in the “CANCEL” direction and releasing it
b. Depressing the brake pedal
c. Depressing the clutch pedal (manual transmission)
d. Pushing “ON −OFF” switch
If cancelled by any of “a.” to “c.”, the
preset speed is retained in memory. How-
ever, in case of “d.”, the preset speed
data is cleared, and you must set the
speed from the beginning. In the following cases, the preset speed
automatically cancels out:
a. The vehicle speed falls bellow about 40 km/h (25 mph).
b. If the vehicle speed drops 16 km/h (10 mph) below the preset speed.
If cancelled by “a.”, the preset speed is
retained in memory. However, in case of
“b.”, the preset speed data is cleared, and
you must set the speed from the begin-
ning.
If the preset speed automatically cancels
out other than for the above cases, have
your vehicle checked by your Toyota deal-
er at the earliest opportunity.
RESETTING TO A FASTER SPEED
Push the lever up in the “+RES” direction
and hold it. Release the lever when the
desired speed is attained. While the lever
is held up, the vehicle will gradually gain
speed.
However, a faster way to reset is to ac-
celerate the vehicle and then push the
lever down in the “− SET” direction.

1892005 TACOMA from Mar. ’05 Prod. (OM35862U)
RESETTING TO A SLOWER SPEED
Push the lever down in the “−SET” direc-
tion and hold it. Release the lever when
the desired speed is attained. While the
lever is held down, the vehicle speed will
gradually decrease.
However, a faster way to reset is to de-
press the brake pedal and then push the
lever down in the “− SET” direction.
On vehicles with automatic transmission,
even if you downshift from “D” to “4”
(5 −speed automatic transmission) or “3”
(4 −speed automatic transmission), with the
cruise control on, engine braking will not
be enabled because the cruise control is
not cancelled. To decrease the vehicle
speed, reset to a slower speed with the
cruise control lever or depress the brake
pedal. If you use the brake pedal, cruise
control is cancelled.
RESUMING THE PRESET SPEED
If the preset speed is cancelled by pulling
the control lever or by depressing the
brake pedal or clutch pedal, pushing the
lever up in the “+RES” direction will re-
store the speed set prior to cancellation. If the preset speed is cancelled when ve-
hicle speed falls below about 40 km/h (25
mph), the preset speed will be resumed
when vehicle speed exceeds about 40
km/h (25 mph) again.
CRUISE CONTROL FAILURE WARNING
If the “CRUISE” indicator light in the
instrument cluster flashes when using the
cruise control, press the “ON
−OFF” button
to turn the system off and then press it
again to turn it on.
If any of the following conditions then oc-
curs, there is some trouble in the cruise
control system.
The indicator light does not come on.
The indicator light flashes again.
The indicator light goes out after it
comes on.
If this is the case, contact your Toyota
dealer and have your vehicle inspected.
LS17022
To crank the engine without depressing
the clutch pedal, push the switch with
the ignition on.
The switch stays on as long as the igni-
tion is on. And it will automatically turn off
when the ignition is off. An indicator light
will illuminate to indicate the system is
operating.
This switch cancels the clutch start sys-
tem, which is designed to keep the starter
motor from operating if the clutch pedal is
not depressed all the way down.
The switch allows the vehicle to be driven
out of difficult situations by cranking the
engine with the clutch engaged.
Clutch start cancel switch

1902005 TACOMA from Mar. ’05 Prod. (OM35862U)
Never use the switch for normal engine
starting. Be sure to follow the starting
procedure instructed in “How to start the
engine” on page 282 in Section 3.
