TOYOTA TACOMA 2007 Owners Manual (in English)

812007 TACOMA from Sep. ’06 Prod. (OM35877U)
LS13137
Do not attach a microphone or any
other device or object around the
area where the curtain shield airbag
activates such as on the windshield
glass, side door glass, front and
rear pillars, roof side rail and assist
grips. When the curtain shield air-
bags inflate, the microphone or oth-
er device or object will be thrown
away with great force or the curtain
shield airbags may not activate cor-
rectly, resulting in death or serious
injury.
Do not hook a hanger, heavy or
sharp pointed objects on the coat
hook. If the curtain shield airbag
inflates, those items will be thrown
away with great force or the curtain
shield airbag may not activate cor-
rectly, resulting in death or serious
injury. When you hang clothes,
hang them on the coat hook direct-
ly.
Do not use seat accessories which
cover the parts where the side air-
bags inflate. Such accessories may
prevent the side airbags from acti-
vating correctly, causing death or
serious injury.
Do not modify or replace the seats
or upholstery of the seats with side
airbags. Such changes may prevent
the side airbag system from activat-
ing correctly, disable the system or
cause the side airbags to inflate ac-
cidentally, resulting in death or seri-
ous injury.
Do not disassemble or repair the
front and rear pillars and roof side
rail containing the curtain shield
airbags. Such changes may disable
the system or cause the curtain
shield airbags to inflate accidental-
ly, resulting in death or serious in-
jury.
Do not modify or change the sus-
pension system. Such changes may
cause the curtain shield airbags to
inflate accidentally, which could re-
sult in death or serious injury.
Do not use tires or wheels other
than the manufacturer ’s recom-
mended size. Such a use may cause
the curtain shield airbags to inflate
accidentally, which could result in
death or serious injury. For details,
see “Checking and replacing tires”
on page 376 in Section 72.
Failure to follow these instructions
can result in death or serious injury.
Consult your Toyota dealer about any
repair and modification.

822007 TACOMA from Sep. ’06 Prod. (OM35877U)
If you wish to modify your vehicle for
a person with a physical disability,
consult your Toyota dealer. It may
dangerously interfere with the SRS
side airbags and curtain shield air-
bags operation.
NOTICE
Do not perform any of the following
changes without consulting your
Toyota dealer. Such changes can
interfere with proper operation of the
SRS side airbag and curtain shield
airbag system in some cases.
Installation of electronic devices
such as a mobile twoway radio,
cassette tape player or compact
disc player
 Modification of the suspension sys-
tem
 Modification of the side structure of
the passenger compartment
 Repairs made on or near the con-
sole or front seat
LS13104
This indicator comes on when the igni-
tion key is turned to the “ON” position.
It goes off after about 6 seconds. This
means the SRS side airbags and curtain
shield airbags are operating properly. This warning light system monitors the
airbag sensor assembly, front airbag
sensors, side and curtain shield airbag
sensors, curtain shield airbag sensors,
driver ’s seat position sensor, driver ’s seat
belt buckle switch, front passenger
occupant classification system
∗ and
indicator light, seat belt pretensioner
assemblies, inflators, “RSCA OFF”
indicator light, interconnecting wiring and
power sources. (For details, see “Service
reminder indicators and warning buzzers”
on page 156 in Section 1 −6.)
∗: The front passenger occupant classifica-
tion system includes the front passenger
occupant classification ECU, load sensor
and front passenger ’s seat belt buckle
switch.
If either of the following conditions occurs,
this indicates a malfunction of the airbags
or seat belt pretensioners. Contact your
Toyota dealer as soon as possible.
The light does not come on when the
ignition key is turned to the “ON” posi-
tion or remains on for more than 6
seconds.
The light comes on while driving.

832007 TACOMA from Sep. ’06 Prod. (OM35877U)
The SRS warning light will come on and
front passenger occupant classification in-
dicator light will indicate “OFF” if there is
a malfunction in the front passenger occu-
pant classification system.
LS13138c
In the following cases, contact your Toyota
dealer as soon as possible:
Any of the SRS side airbags and cur-
tain shield airbags have been inflated.
The portion of the doors (shaded in the
illustration) was involved in an accident
that was not severe enough to cause
the SRS side airbags and curtain
shield airbags to inflate.
The surface of the seats with the side
airbag (shaded in the illustration) is
scratched, cracked, or otherwise dam-
aged.
The portion of the front pillars, rear
pillars or headlining (padding) contain-
ing the curtain shield airbag inside
(shaded in the illustration) is scratched,
cracked, or otherwise damaged.
NOTICE
Do not disconnect the battery cables
before contacting your Toyota dealer.

842007 TACOMA from Sep. ’06 Prod. (OM35877U)
Your vehicle is equipped with a front
passenger occupant classification sys-
tem. The system detects conditions
1—4 (Shown in the table on page 86)
Based on these conditions, the systems
below are activated or deactivated:
Front passenger airbag
Front passenger ’s seat belt pretension-
er
The system monitors the weight and
load on the front passenger seat, and
the seat belt buckle switch to determine
conditions 1—4.
In order to ensure that the system de-
tects the conditions correctly:
Do not place a heavy load on the front
passenger seat or the seatback table,
etc.
Do not attach a commercial seatback
table or other heavy item to the back
of the front passenger seat.
Do not apply pressure to the front pas-
senger seat by resting hands or legs
on the seatback.
LS13139a
The front passenger occupant classifi-
cation indicator light indicates the ac-
tuation of the front passenger airbag
and front passenger seat belt preten-
sioner.
The front passenger occupant classifi-
cation indicator light will indicate “ON”
and “OFF” when the ignition key is
turned to the “ON” position. After
about four seconds, it will go off. After
that, the front passenger occupant clas-
sification system operates and judges
whether to indicate “ON” or “OFF”.
The indicator light will indicate “OFF”
when the ignition switch is in the “ON”
position with the condition 2 in the table
shown below. If the front passenger occupant classifica-
tion system determines that a person of
adult size sits in the front passenger seat
but the “OFF” indicator is illuminated, one
of the following is likely to have occurred:
A rear passenger lifts the front passen-
ger seat cushion with their legs.
Objects are placed under the front pas-
senger seat.
The front passenger seatback is in
contact with the rear seat or the back
wall.
To ensure that the system correctly de-
tects the presence or absence of a person
of adult size sitting in the front passenger
seat, make sure that none of the above
occur.
Make sure that the “ON” indicator is illu-
minated when a person of adult size is
seated in the front passenger seat. If the
“OFF” indicator is illuminated, follow the
procedure below: 1. Turn the ignition off.
2. Make sure the airbag off switch is set to the “AUTO” position.
Front passenger occupant
classification system (regular cab
models with separate seats and
access cab models)

852007 TACOMA from Sep. ’06 Prod. (OM35877U)
3. Make sure the front passenger seatbelt is worn correctly.
4. Ask the front passenger to adjust the seatback to the upright position and to
sit up straight on the center of the seat
cushion, with his/her legs comfortably
extended forward.
5. Turn the ignition on, having the pas- senger remain in that position until the
front passenger occupant classification
system indicator light indicates “ON”.
If the “OFF” indicator remains illuminated,
either ask the passenger to move to the
rear seat, or if that is not possible, move
the front passenger seat fully rearward.
LS13140
The SRS warning light will come on
and the front passenger occupant clas-
sification indicator light will indicate
“OFF” if there is a malfunction in the
front passenger occupant classification
system. Contact your Toyota dealer as
soon as possible.

862007 TACOMA from Sep. ’06 Prod. (OM35877U)
Condition and operation in the front passenger occupant classification systemCondition detected bythe front passenger
occupant classification system
Passenger
airbag off switch position
Indicator/warning lightDevices
Front passenger
occupant
classification
indicator light
SRS warning
light
Front
passenger ’s seat belt
reminder light
Front passenger
airbag
Front
passenger ’s seat belt
pretensioner
1. Adult∗ 1“AUTO”“ON”OffFlashing∗4ActivatedActivated“OFF”“OFF”Deactivated
2. Child∗2 or child
restraint system∗ 3
“AUTO”“OFF”∗5OffFlashing∗4DeactivatedActivated“OFF”
3. Unoccupied“AUTO”Not illuminatedOffOffDeactivated“OFF”“OFF”
4. There is a
malfunction in the
system“AUTO”
“OFF”OnOffDeactivatedActivated“OFF”
∗1: The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may
recognize him/her as a child depending on his/her physique and posture.
∗2: When a larger child who has outgrown a child restraint system sits in the front passenger seat, the system may recognize him/h er
as an adult depending on his/her physique or posture.
∗ 3: Never install a rear −facing child restraint system on the front passenger seat. A forward −facing child restraint system should only be
installed on the front passenger seat when it is unavoidable. (See “Child restraint” on page 95 in this Section as for installi ng the
child restraint system.)
∗ 4: In the event the front passenger does not wear a seat belt.
∗5: In case the indicator is not illuminated, see “Child restraint” on page 95 as for installing the child restraint system proper ly.

872007 TACOMA from Sep. ’06 Prod. (OM35877U)
CAUTION
To avoid potential death or serious
injury when the front passenger occu-
pant classification system does not
detect the conditions correctly, ob-
serve the following.
Make sure the front passenger oc-
cupant classification indicator light
indicates “ON” when using the seat
belt extender for the front passen-
ger seat. If the indicator light indi-
cates “OFF”, disconnect the extend-
er tongue from the seat belt buckle,
then reconnect the seat belt. Recon-
nect the seat belt extender after
making sure the indicator light indi-
cates “ON”. If you use the seat belt
extender while the indicator light
indicates “OFF”, the front passen-
ger airbag may not activate correct-
ly, which could cause death or seri-
ous injury in the event of collision.
Do not recline the front passenger
seatback so far that it touches a
rear seat or a backwall. This may
cause the “OFF” indicator to be il-
luminated, which indicates that the
passenger ’s airbags will not deploy
in the event of a severe accident.
If the seatback touches the rear
seat or backwall, return the seat-
back to a position where it does
not touch the rear seat or backwall.
Keep the front passenger seatback
as upright as possible when the ve-
hicle is moving. Reclining the seat-
back excessively may lessen the ef-
fectiveness of the seat belt system.
If an adult sits in the front passen-
ger seat, the occupant classification
indicator light should indicate “ON”.
If the “OFF” indicator is illumi-
nated, ask the passenger to sit up
straight, well back in the seat, feet
on the floor, and with the seat belt
worn correctly. If the “OFF” indica-
tor still remains illuminated, either
ask the passenger to move to the
rear seat, or if that is not possible,
move the front passenger seat fully
rearward.
Wear the seat belt properly.
Make sure the front passenger ’s
seat belt tab has not been left in-
serted in the buckle before some-
one sits in the front passenger
seat.
Do not place a heavy load on the
front passenger seat or the seat-
back table, etc.
Do not apply pressure to the front
passenger seat by resting hands or
legs on the seatback.
Do not let a rear passenger lift the
front passenger seat with their feet
or press on the seatback with their
legs.
Do not put objects under the front
passenger seat.
Do not attach a commercial seat-
back table or other heavy item to
the back of the front passenger
seat.
Child restraint systems installed on
the rear seat should not contact the
front seatbacks.

882007 TACOMA from Sep. ’06 Prod. (OM35877U)
When it is unavoidable to install the
forwardfacing child restraint sys-
tem on the front passenger seat,
install the child restraint system on
the front passenger seat in the
proper order. (As for the installation
order, see “—Installation with seat
belt” on page 98 in this Section.)
Do not modify or remove the front
seats.
Do not kick the front passenger
seat or subject it to severe impact.
Otherwise, the SRS warning light
may come on to indicate a malfunc-
tion of the detection system. In this
case, contact your Toyota dealer im-
mediately.
The front passenger occupant
classification indicator light may indicate
“ON” (the front passenger airbag may
deploy) even if observing the above
cautions, when a child sits in, or a
forward−facing child restraint system is
installed on the front passenger seat.
Refer to all the cautions in “SRS driver
airbag and front passenger airbag” on
page 55 and “Child restraint” on page 95. Your vehicle is equipped with a front
passenger occupant classification sys-
tem. The system detects conditions
1—4 (Shown in the table on page 91)
Based on these conditions, the systems
below are activated or deactivated:
Front passenger airbag
Side airbag on the front passenger
seat
Front passenger ’s seat belt pretension-
er
The system monitors the weight and
load on the right front passenger seat
(regular cab models with bench seat) or
front passenger seat (double cab mod-
els), and the seat belt buckle switch to
determine conditions 1—4.
In order to ensure the system detects
the conditions correctly:
Double cab models—Do not place a
heavy load on the front passenger seat
or the seatback table, etc.
Regular cab models with bench seat—
Do not place a heavy load on the front
passenger seat.
Double cab models—Do not attach a
commercial seatback table or other
heavy item to the back of the front
passenger seat.
Do not apply pressure to the front pas-
senger seat by resting hands or legs
on the seatback.
Regular cab models with bench seat—
Do not use a seat accessory, such as
a cushion or seat cover, that covers
the seat cushion surface.
Front passenger occupant
classification system (regular cab
models with bench seat and double
cab models)

892007 TACOMA from Sep. ’06 Prod. (OM35877U)
LS13139b
The front passenger occupant classifi-
cation indicator light indicates the ac-
tuation of the front passenger airbag,
side airbag on the front passenger seat
and front passenger seat belt preten-
sioner.
The front passenger occupant classifi-
cation indicator light will indicate “ON”
and “OFF” when the ignition key is
turned to the “ON” position. After
about four seconds, it will go off. After
that, the front passenger occupant clas-
sification system operates and judges
whether to indicate “ON” or “OFF”.The indicator light will indicate “OFF”
when the ignition switch is in the “ON”
position with the condition 2 in the table
shown below.
If the front passenger occupant classifica-
tion system determines that a person of
adult size sits in the front passenger seat
but the “OFF” indicator is illuminated, one
of the following is likely to have occurred:
A rear passenger lifts the front passen-
ger seat cushion with their legs.
Objects are placed under the front pas-
senger seat.
Double cab models—The front passen-
ger seatback is in contact with the rear
seat.
To ensure that the system correctly de-
tects the presence or absence of a person
of adult size sitting in the front passenger
seat, make sure that none of the above
occur. Make sure that the “ON” indicator is illu-
minated when a person of adult size is
seated in the right front passenger seat
(regular cab models with bench seat) or
front passenger seat (double cab models).
If the “OFF” indicator is illuminated, ask
the passenger to sit up straight, well back
in the seat, and with the seat belt worn
correctly. If the “OFF” indicator remains
illuminated, either ask the passenger to
move to the rear seat, or if that is not
possible, move the front passenger seat
fully rearward.

902007 TACOMA from Sep. ’06 Prod. (OM35877U)
LS13140
The SRS warning light will come on
and the front passenger occupant clas-
sification indicator light will indicate
“OFF” if there is a malfunction in the
front passenger occupant classification
system. Contact your Toyota dealer as
soon as possible.
