fuel pump TOYOTA TACOMA 2013 Owners Manual (in English)

TABLE OF CONTENTSIndex
4
3-5. Other interior featuresSun visors .......................... 269
Vanity mirrors ..................... 270
Clock .................................. 271
Outside temperature display (vehicles with
auto anti-glare inside
rear view mirror) ............... 272
Power outlets (12V DC) ..... 277
Power outlet (120V AC) ..... 278
Seat heaters ....................... 284
Seatback table ................... 286
Floor mat ............................ 287
Luggage compartment features ............................ 289
Garage door opener ........... 298
Compass (vehicles with auto anti-glare inside rear
view mirror) ...................... 307
4-1. Maintenance and care Cleaning and protecting the vehicle exterior ........... 316
Cleaning and protecting the vehicle interior ............ 319
4-2. Maintenance Maintenance requirements .................... 322
General maintenance ......... 324
Emission inspection and maintenance (I/M)
programs .......................... 327 4-3. Do-it-yourself maintenance
Do-it-yourself service precautions ....................... 328
Hood ................................... 332
Engine compartment .......... 334
Tires.................................... 350
Tire inflation pressure ......... 359
Wheels................................ 364
Air conditioning filter ........... 367
Wireless remote control battery .............................. 370
Checking and replacing fuses ................................. 372
Light bulbs .......................... 382
5-1. Essential information Emergency flashers ............ 394
If your vehicle needs to be towed ........................... 395
If you think something is wrong ................................ 401
Fuel pump shut off system .............................. 402
4Maintenance and care
5When trouble arises

When trouble arises5
393
5-1. Essential informationEmergency flashers ......... 394
If your vehicle needs to be towed ............................. 395
If you think something is wrong ............................. 401
Fuel pump shut off system ........................... 402 5-2. Steps to take in an
emergency
If a warning light turns on or a warning buzzer
sounds... ........................ 403
If you have a flat tire......... 413
If the engine will not start ................................ 430
If the shift lever cannot be shifted from P (vehicles
with an automatic
transmission) ................. 431
If you lose your keys ........ 432
If the vehicle battery is discharged ..................... 433
If your vehicle overheats ....................... 437
If the vehicle becomes stuck .............................. 440
If your vehicle has to be stopped in
an emergency ................ 442

402
5-1. Essential information
Fuel pump shut off system
Follow the procedure below to restart the engine after the system is
activated.Turn the engine switch to the ACC or LOCK position.
Restart the engine.
NOTICE
■Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked onto the ground, the fuel system has been
damaged and is in need of repair. Do not restart the engine.
To minimize the risk of fuel leakage when the engine stalls or an air-
bag inflates upon collision, the fuel pump shut off system stops sup-
plying fuel to the engine.

467
6-1. Specifications
6
Vehicle specifications
Fuel infor mation
■Fuel tank opening fo r unleaded gasoline
To help prevent incorrect fueling, your Toyota has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
■ If your engine knocks
●Consult your Toyota dealer.
● You may occasionally notice light knocking for a short time while
accelerating or driving uphill. This is normal and there is no need for
concern.
■ Gasoline quality
In very few cases, driveability problems may be caused by the brand of
gasoline you are using. If driveability problems persist, try changing the
brand of gasoline. If this does not correct the problem, consult your Toyota
dealer.
■ Gasoline quality standards
●Automotive manufacturers in the US, Europe and Japan have developed
a specification for fuel quality called World-Wide Fuel Charter (WWFC)
that is expected to be applied worldwide.
● The WWFC consists of four categories that are based on required
emission levels. In the US, category 4 has been adopted.
● The WWFC improves air quality by lowering emissions in vehicle fleets,
and customer satisfaction through better performance.
Your vehicle must use only unleaded gasoline.
Select octane rating 87 (Research Octane Number 91) or higher. Use
of unleaded gasoline with an octane rating lower than 87 may result
in engine knocking. Persistent kno cking can lead to engine damage.
At minimum, the gasoline you use should meet the specifications
of ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada.

468 6-1. Specifications
■Toyota recommends the use of gaso line containing detergent additives
● Toyota recommends the use of gasoline that contains detergent additives
to avoid build-up of engine deposits.
● All gasoline sold in the U.S. contains minimum detergent additives to
clean and/or keep clean intake systems, per EPA’s lowest additives
concentration program.
● Toyota strongly recommends the use of Top Tier Detergent Gasoline. For
more information on Top Tier Detergent Gasoline and a list of marketers,
please go to the official website www.toptiergas.com.
■ Toyota recommends the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains
oxygenates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is
available in many areas.
Toyota recommends the use of cleaner burning gasoline and appropriately
blended reformulated gasoline. These types of gasoline provide excellent
vehicle performance, reduce vehicle emissions and improve air quality.
■ Toyota does not recomm end blended gasoline
● If you use gasohol in your Toyota, be sure that it has an octane rating no
lower than 87.
● Toyota does not recommend the use of gasoline containing methanol.
●Use only gasoline containing a maxi-
mum of 10% ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 10% etha-
nol, including from any pump labeled
E15, E30, E50, E85 (which are only
some examples of fuel containing more
than 10% ethanol).DO NOT use gasoline
containing more than
10% ethanol.
(15% ethanol)
(50% ethanol)
(85% ethanol)

515
Alphabetical index
Front side marker lights
Replacing light bulbs ............ 386
Switch ................................... 162
Wattage ................................ 466
Front turn signal lights
Lever .................................... 151
Replacing light bulbs ............ 387
Switch ................................... 151
Wattage ................................ 466
Fuel Capacity ............................... 453
Fuel gauge ........................... 155
Fuel pump shut off system ... 402
Gas station information ........ 524
Information ........................... 467
Refueling ................................ 79
Type ..................................... 453
Warning light ........................ 406
Fuel door .................................... 79
Fuel filler door ........................... 79
Fuel pump shut off system .... 402
Fuses Fuses.................................... 372
Locations ...................... 375, 379
Garage door opener ................ 298
Gas station information .......... 524
Gauges ..................................... 155
Glove box ................................. 262
Grocery bag hooks ................. 296 Hazard lights
Switch....................................394
Head restraints Adjusting ................................56
Headlights
Replacing light bulbs .............383
Switch....................................162
Wattage .................................466
Heaters Seat heaters ..........................284
High mounted stoplight
Replacing ..............................389
Wattage .................................466
Hill-start assist control ............198
Hood ..........................................332
Hooks Cargo net ..............................297
Deck hooks ...........................291
Grocery bag ..........................296
Tie-down cleats .....................292
Horn...........................................154
I/M test.......................................327
Identification Engine ...................................452
Tire ........................................471
Vehicle ..................................451
Ignition switch ..........................141
Illuminated entry system .........259
Immobilizer system....................82
Indicator lights .........................158
Initialization
Items to initialize....................485
Inside rear view mirror ..............68
Interior lights
Interior lights..........................260
Personal lights.......................260
Switch....................................260
Wattage .................................466
Instrument panel light
control ....................................156
