TOYOTA tC 2008 Accessories, Audio & Navigation (in English)

101ADVANCED FUNCTIONS
SCION V398
DNotifying traffic restriction
When the “Traffic Restrict. Notification”
feature is turned on, the system notifies
you of traffic or seasonal restrictions.
To turn the “Traffic Restrict. Notification”
on:
1. Touch “Setup” on the “Menu”
screen.
Then touch
to display page 2 of the
“Setup” screen.
2. Touch “ON” of “Traffic Restrict. Noti-
fication”.
The selected button is highlighted.
3. Touch “OK”.
DVoice guidance in all modes
When the “Voice Guidance in All Modes”
feature is turned on, the voice guidance in
all modes can be heard.
When the “Voice Guidance in All Modes”
feature is turned off, voice guidance can-
not be heard when using the audio system.
To turn the “Voice Guidance in All Modes”
on:
1. Touch “Setup” on the “Menu”
screen.
Then touch
to display page 2 of the
“Setup” screen.
2. Touch “ON” of “Voice Guidance in
All Modes”.
The selected button is highlighted.
3. Touch “OK”.

102ADVANCED FUNCTIONS
SCION V398
DAuto voice guidance
When the “Auto Voice Guidance” feature is
turned on, the voice guidance can be
heard automatically.
When the “Auto Voice Guidance” feature is
turned off, the voice guidance can be
heard only if the“MAP/VOICE”button is
pushed.
To turn the “Auto Voice Guidance” mode
on:
1. Touch “Setup” on the “Menu”
screen.
Then touch
twice to display page 3 of
the “Setup” screen.
2. Touch “ON” of “Auto Voice Guid-
ance”.
The selected button is highlighted.
3. Touch “OK”.
DPop−up message
When the “Pop−up Message” is turned on,
the pop−up message will be displayed.
To turn the “Pop−up Message” on:
1. Touch “Setup” on the “Menu”
screen.
Then touch
twice to display page 3 of
the “Setup” screen.
2. Touch “ON” of “Pop−up Message”.
The selected button is highlighted.
3. Touch “OK”.

103ADVANCED FUNCTIONS
SCION V398
When the “Pop−up Message” is turned off,
the following messages will not displayed.
This message appears when the system is
in the POI mode and the map scale is 1
mile (1.6 km) or greater.
The message appears when the map is
switched to the dual map screen mode.
DCurrent position/tire change calibra-
tion
The current vehicle position mark can be
adjusted manually. Miscalculation of the
distance caused by tire replacement can
also be adjusted.
1. Touch “Setup” on the “Menu”
screen.
Then touch
twice to display page 3 of
the “Setup” screen.
2. Touch “Adjust” of “Calibration”.
3. Touch the desired button.
INFORMATION
For additional information on the ac-
curacy of a current vehicle position,
see “Limitations of the navigation
system” on page 180.

104ADVANCED FUNCTIONS
SCION V398
POSITION/DIRECTION CALIBRATION
When driving, the current vehicle position
mark will be automatically corrected by
GPS signals. If GPS reception is poor due
to location, you can manually adjust the
current vehicle position mark.
1. Touch “Position/Direction”.
2. Touch the eight directional touch−
screen button to move the cursorto
the desired point on the map.
3. Touch “Enter”.
4. Touch eitherorto adjust the
direction of the current vehicle position
mark.
5. Touch “Enter”.
The map screen will be displayed.

105ADVANCED FUNCTIONS
SCION V398
TIRE CHANGE CALIBRATION
The tire change calibration function will be
used when replacing the tires. This func-
tion will adjust the miscalculation caused
by the circumference difference between
the old and new tires. If this procedure is
not performed when the tires are replaced,
the current vehicle position mark may be
incorrectly displayed.
To perform a distance calibration pro-
cedure, touch “Tire Change” on the
“Calibration” screen.
The message appears and the quick dis-
tance calibration is automatically started.
A few seconds later, a map screen will be
displayed.

106ADVANCED FUNCTIONS
SCION V398

SECTIONVI
107OTHER FUNCTIONS
SCION V398
OTHER FUNCTIONS
DMaintenance information108 ..............................
Maintenance information setting 108.......................
Dealer setting 109......................................
DCalendar with memo111 ..................................
Adding a memo 112.....................................
Editing a memo 113.....................................
Memo list 114...........................................
DScreen adjustment 115.....................................
DSettings 116..............................................
DSelecting a language 118...................................
DConfirming the database version and disc coverage area 119....

108OTHER FUNCTIONS
SCION V398
When the navigation System is turned on,
the “Information” screen displays when it is
time to replace a part or certain compo-
nents. (See page 4.)
1. Push the “INFO” button.
2. Touch “Maintenance”.
3. Touch the desired button.
For details of each touch−screen button,
see “INFORMATION ITEMS” on page 108.
“Delete All”:To cancel all conditions
which have been inputted.
“Reset All”:To reset the item which has
satisfied a condition.
“Set Dealer”:To register or edit dealer in-
formation. (See “ — Dealer setting” on
page 109.)
If“ON”is selected, the system gives main-
tenance information with the “Information”
screen when the system is turned on. (See
page 4.)
If“OFF”is selected, the “Information”
screen is disabled.
When the vehicle needs to be serviced, the
touch−screen button color will change to
orange.INFORMATION ITEMS
“ENGINE OIL”:Replace engine oil
“OIL FILTER”:Replace engine oil filter
“ROTATION”:Rotate tires
“TIRES”:Replace tires
“BATTERY”:Replace battery
“BRAKE PAD”:Replace brake linings
“WIPERS”:Replace wiper blades
“LLC”:Replace engine coolant
“BRAKE OIL”:Replace brake fluid
“ATF”:Replace ATF (Automatic Trans-
mission Fluid)
“SERVICE”:Scheduled maintenance
“AIR FILTER”:Replace air filter
“PERSONAL”:New information items
can be created separately from provided
ones.
Maintenance information —
— Maintenance information
setting

109OTHER FUNCTIONS
SCION V398
4. Input the conditions.
Notice of “Date”:The next maintenance
date can be input.
Notice of “Distance”:The driving dis-
tance until the next maintenance check
can be input.
“Delete”:To cancel the date and distance
conditions.
“Reset”:To reset the date and distance
conditions.
5. Touch “OK”.
The screen then returns to the “Mainte-
nance” screen.
INFORMATION
Depending on driving or road condi-
tions, the actual date and distance
may differ from the stored date and
distance in the system.
It is possible to register a dealer in the sys-
tem. With dealer information registered,
route guidance to the dealer is available.
1. Touch “Set Dealer” on the “Mainte-
nance” screen.
2. If the dealer has not been registered,
enter the location of the dealer in the
same way as for a destination search.
(See “Destination search” on page 31.)
When “Set Dealer” registration is finished,
the “Edit Dealer” screen will be displayed.
3. Touch the button to be edited.
“Dealer”:To enter the name of a dealer.
(See page 110.)
“Contact”:To enter the name of a dealer
member. (See page 110.)
“Location”:To set a location. (See page
110.)
“Phone #”:To set a telephone number.
(See page 111.)
“Delete Dealer”:To delete the dealer in-
formation displayed on the screen.
“Enter
”:To set the displayed dealer as
a destination. (See “Starting route guid-
ance” on page 50.)
— Dealer setting

11 0OTHER FUNCTIONS
SCION V398
DTo edit “Dealer” or “Contact”
1. Touch “Dealer” or “Contact” on the
“Edit Dealer” screen.
2. Enter the name using the alphanu-
meric keys.
Up to 24 letters can be entered.
3. Touch “OK”.
The previous screen will be displayed.
DTo edit “Location”
1. Touch “Location” on the “Edit Deal-
er” screen.
2. Touch the eight directional touch−
screen button to move the cursorto
the desired point on the map.
3. Touch “Enter”.
The previous screen will be displayed.
