TOYOTA tC 2008 Accessories, Audio & Navigation (in English)

131
SCION V398
AUDIO/VIDEO SYSTEM
DAuto volume adjustment
(AUTO VOLUME)
The volume can be set to increase auto-
matically to match road noise, which varies
based on the driving speed.
1. Touch “AUTO VOL” to display the
“AUTO VOLUME” screen.
2. Touch “AUTO VOL 1” to “AUTO VOL
5”.
Touch“OFF”to clear the settings.
Touch
when settings are complete.
DEQ (Equalizer) adjustments
The equalizer can be adjusted to the pre-
ferred sound quality based on a variety of
music genres and sources.
ADJUSTING THE SOUND QUALITY
The currently set equalizer curve can be
selected and set to the preferred sound
quality.
1. Touch “EQ” to display the “EQUAL-
IZER” screen.
2. Touch the touch−screen button to
select the desired sound quality mode,
from the list written below.
Touch
when settings are complete.
EQ 1:POP
EQ 2:ROCK
EQ 3:JAZZ
EQ 4:CLASSICAL
EQ 5:VOCAL
FLAT:No EQ offset

132AUDIO/VIDEO SYSTEM
SCION V398
ADJUSTING AND STORING THE EQ
CURVE
Allows the equalizer curve to be adjusted
to a sound quality other than the currently
set equalizer curve and then stored in the
memory.
1. Imagine your preferred equalizer
curve and then trace that curve slowly
with a finger.
2. To perform fine adjustments, direct-
ly touch the frequency bar to be ad-
justed, and then touch the “+” and “−”
switches on the right of the screen.
The selected frequency bar is then high-
lighted.
3. Touch the switch to be stored in the
memory from “EQ 1” to “EQ 5” until a
beep sounds.
By touching“FLAT“until a beep sounds,
it is possible to return the stored equalizer
curve to the originally setting.
Touch
when settings are complete.
DSSP (SCION SOUND PROCESSING)
settings
SSP is a modified DSP (Digital Signal
Processing) system that provides a cus-
tomized sound for your vehicle. You can
select from the modes below.
“NEUTRAL”:A subdued sound that does
not interfere with conversations.
“HEAR”:A powerful, energetic, “live”
sound.
“FEEL”:Player ’s sound−> reproduces
the sound on the stage that musicians
hear.
For more details, please visit the SCION
Web site at http://www.scion.com/ .
1. Touch “SSP” to display the “SCION
SOUND PROCESSING” screen.
2. Touch sound type.
Touch“OFF”to cancel the SSP settings
and return to the“Sound”screen.
3. Touch vehicle type.

133
SCION V398
AUDIO/VIDEO SYSTEM
4. Touch “OK”.
Touch
to change the setting.
When SSP has been determined, the sys-
tem is automatically set to the optimum EQ
value.
DVolume balance adjustments
(FAD BAL)
By individually adjusting the volume bal-
ance for the front, rear, left, and right
speakers, it is possible to enhance the
sound from distant speakers.
1. Touch “FAD BAL” to display the
“FAD·BAL” screen.
2. Touch the preferred balance point.
Touch“Y”,“B”,“A”,or“"”to make
fine adjustments.
Touch“OK”when adjustment is com-
plete.
Touch“Reset”to clear the setting.

134AUDIO/VIDEO SYSTEM
SCION V398
DListening to the radio
Push the “MODE” button and touch
“FM” to receive FM radio broadcasts,
and “AM” to receive AM radio broad-
casts.
Push the“AUDIO”button to display the
radio operation screen.
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. “ST” appears on the screen. If the
signal becomes weak, the radio reduces
the amount of channel separation to pre-
vent the weak signal from creating noise.
If the signal becomes extremely weak, the
radio switches from stereo to mono recep-
tion. In this case, “ST” disappears from the
screen.
DPresetting a station
1. Select the broadcasting station to
be stored in the memory.
2. Touch the preset switch (1 — 8) to be
stored in the memory until a beep
sounds.
The broadcasting station (frequency) will
be stored in the memory.
Each radio mode can store up to 8 station-
s. Follow the same procedure to change
the preset station to a different one.
Touch
to display preset switches“5”to
“8”.
The preset station memory is cleared if the
power source is interrupted by a battery
disconnection or a blown fuse.
DSelecting a station
Tune in the desired station using one of the
following methods.
Normal station selection:Push the“Y”
or“B”button of“TRACK/TUNE”.
The displayed frequency moves UP/
DOWN one step each time one of the but-
tons is pushed. (1step is 10kHz for AM and
0.2MHz for FM.)
Auto station selection:Push the“Y”or
“B”button of“TRACK/TUNE”until a
beep sounds.
The broadcasting station nearest to the
frequency displayed at the screen is auto-
matically selected and the search process
stops when the station is received. Push
again to cancel in the middle of a search.
Preset switch station selection:Sta-
tions can be selected by touching their pre-
set switches. Touch
to display preset
switches“5”to“8”.
INFORMATION
It may not be possible to perform auto
station selection in areas with weak
reception area.
To scan all the frequencies:Touch
“SCAN”. The system searches for a
broadcasting station and after receiving a
detected station for several seconds, then
searches for the next station. Touch
“SCAN”again when the desired station is
reached.
To scan the preset stations:Touch
“P.SCAN”. After receiving the preset
broadcasting station for several seconds,
the system moves on to the next preset
station. Touch“P.SCAN”again when the
desired station is reached.
— Radio operation

135
SCION V398
AUDIO/VIDEO SYSTEM
To listen to a satellite radio broadcast in
your vehicle, an additional genuine SCION
satellite receiver and antenna must be pur-
chased and installed, separately and the
subscription to the XM satellite radio is
also necessary.
DHow to subscribe to an XM satellite
radio
An XM satellite radio is a tuner designed
exclusively to receive broadcasts provided
under a separate subscription. Availability
is limited to the 48 contiguous states.
How to subscribe:You must enter into a
separate service agreement with the XM
radio in order to receive satellite broadcast
programming in the vehicle. Additional ac-
tivation and service subscription fees ap-
ply that are not included in the purchase
price of the vehicle and optional digital sat-
ellite tuner. For complete information on
subscription rates and terms, or to sub-
scribe to the XM radio, visit XM on the web
at www.xmradio.com
or call an XM’s Lis-
tener Care at (800) 967−2346. The XM ra-
dio is solely responsible for the quality,
availability and content of the satellite ra-
dio services provided, which are subject to
the terms and conditions of the XM radio
customer service agreement.
Customers should have their radio ID
ready; the radio ID can be found by select-
ing “channel 000” on the radio. For details,
see the “Displaying the radio ID” that fol-
lows.
All fees and programming are the respon-
sibility of the XM satellite radio and are
subject to change.
Satellite tuner technology notice:
Toyota’s satellite radio tuners are awarded
Type Approval Certificates from XM
Satellite Radio Inc. as proof of
compatibility with the services offered by
the XM satellite radio.
DDisplaying the radio ID
Each XM tuner is identified with a unique
radio ID. You will need the radio ID when
activating XM service or when reporting a
problem.
If you select the “CH 000” using the
“TRACK/TUNE”button, the ID code of 8
alphanumeric characters appears. If you
select another channel, display of the ID
code is canceled. The channel (000) alter-
nates the display between the radio ID and
the specific radio ID code.
— Radio operation
(XM satellite radio
broadcast)

136AUDIO/VIDEO SYSTEM
SCION V398
DListening to satellite radio
Push the “MODE” button and then
touch “Satellite Radio”.
Push the“AUDIO”button to display the
satellite radio operation screen.
DChanging the band
The band changes each time “SAT2” is
touched.
The band changes sequentially between
“SAT1”,“SAT2”, and“SAT3”.
DChannel category
Touch either“TYPEA”or“TYPE"”to go
to the next or previous category.

137
SCION V398
AUDIO/VIDEO SYSTEM
DPresetting a channel
1. Select the broadcasting station to
be stored in the memory.
2. Touch the preset switch to be stored
in the memory until a beep sounds.
The broadcasting station (frequency) will
be stored in the memory.
Up to 18 channels, 6 for each of three SAT
bands can be stored in the memory. You
can reprogram preset channels by follow-
ing the same procedure.
The preset channel memory is cancelled
when the power source is interrupted by
battery disconnection or a blown fuse.
DSelecting a channel
Tune in the desired channel using one of
the following methods.
Normal station selection:Push the“Y”
or“B”button of“TRACK/TUNE”.
Push the“TRACK/TUNE”button to
change the channel once each time the
button is pushed.
Auto station selection:Touch“TYPE
SEEK”.
The next available channel within the cur-
rent category type is selected when
“TYPE SEEK”is touched.
Preset switch station selection:Sta-
tions can be selected by touching their pre-
set switches.

138AUDIO/VIDEO SYSTEM
SCION V398
To scan the currently selected channel
category:Touch“SCAN”.
The system searches for a broadcasting
station and after receiving a detected sta-
tion for several seconds, then searches for
the next station. Touch“SCAN”again
when the desired station is reached.
To scan the preset channels:Touch
“P.SCAN”.
After receiving the preset broadcasting
station for several seconds, the system
moves on to the next preset station. Touch
“P.SCAN”again when the desired station
is reached.

139
SCION V398
AUDIO/VIDEO SYSTEM
DIf the satellite radio tuner malfunctions
When problems occur with the XM tuner, a message will appear on the display. Referring
to the table below to identify the problem, take the suggested corrective action.
ANTENNA
The XM antenna is not connected. Check whether the XM antenna
cable is attached securely.
ANTENNAA short circuit occurs in the antenna or the surrounding antenna cable.
See a SCION certified dealer for assistance.
UPDATING
You have not subscribed to the XM satellite radio. The radio is being
updated with the latest encryption code. Contact the XM satellite radio
for subscription information. When a contact is canceled, you can
choose the “CH000” and all free−to−air channels.
UPDATINGThe premium channel you selected is not authorized. Wait for about 2
seconds until the radio returns to the previous channel or “CH001”. If
it does not change automatically, select another channel. If you want
to listen to the premium channel, contact the XM satellite radio.
NO
SIGNALThe XM signal is too weak at the current location. Wait until your vehicle
reaches a location with a stronger signal.
LOADINGThe unit is acquiring audio or program information. Wait until the unit
has received the information.
OFF AIRThe channel you selected is not broadcasting any programming. Select
another channel.
−−−−−There is no song/program title or artist name/feature associated with the
channel at that time. No action needed.
−−−
The channel you selected is no longer available. Wait for about 2 sec-
onds until the radio returns to the previous channel or “CH001”. If it does
not change automatically, select another channel.
The XM Listener Care Center is also available on the phone, please call (800) 852−9696
during the following hours:
Monday — Saturday: 7 a.m. — 1 a.m. Sunday: 12 p.m. — 12 a.m. (EST)

140AUDIO/VIDEO SYSTEM
SCION V398
NOTICE
This equipment has been tested and
found to comply with the limits for a
class B digital device, pursuant to
Part 15 of the FCC Rules. These lim-
its are designed to provide reason-
able protection against harmful inter-
ference in a residential installation.
This equipment generates, uses and
can radiate radio frequency energy
and, if not installed and used in ac-
cordance with the instructions, may
cause harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television re-
ception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct
the interference by one or more of the
following measures:
— Reorient or relocate the receiving
antenna.
— Increase the separation between
the equipment and receiver.
— Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
— Consult the dealer or an experi-
enced radio/TV technician for help.
Information to user
Alternation or modifications carried
out without appropriate authoriza-
tion may invalidate the user’s right to
operate the equipment.
INFORMATION
This XM tuner supports “Audio Ser-
vices” (Music and Talk) of only XM
satellite radio and “Text Informa-
tion”* linked to the respective “Audio
Services”.
*: Text Information includes, Station
Name, (Artist) Name, (Song) Title and
Category Name.
