TOYOTA TERCEL 1996 Service Repair Manual

- DIAGNOSTICSENGINE
DI-7
1996 TERCEL (RM440U)
(b) Clear the DTC.
The following actions will erase the DTC and freezed
frame data.
(1) Operating the OBD II scan tool (complying with SAE
J1978) or TOYOTA hand-held tester to erase the
codes. (See the OBD II scan tool's instruction book
for operating instructions.)
(2) Disconnecting the battery terminals or EFI fuse.
NOTICE:
If the TOYOTA hand-held tester switches the ECM from
normal mode to check mode or vice-versa, or if the igni-
tion switch is turned from ON to ACC or OFF during check
mode, the DTC and freezed frame data will be erased.
4. FAIL-SAFE CHART
If any of the following codes is recorded, the ECM enters fail-safe mode.
DTC No.Fail-Safe OperationFail-Safe Deactivation Conditions
P0105Ignition timing fixed at 5° BTDCReturned to normal condition
P0110Intake air temp. is fixed at 20°C (68°F)Returned to normal condition
P0115Engine coolant temp. is fixed at 80°C (176°F)Returned to normal condition
P0120VTA is fixed at 0°
The following condition must be repeated at least 2 times
consecutively
When closed throttle position switch is ON:
0.1 V
VTA
0.95 V
P0141The heater circuit in which an abnormality is detected is
turned offIgnition switch OFF
P0325Max. timing retardationIgnition switch OFF
P1300Fuel cutIGF signal is detected for 4 consecutive ignitions
5. CHECK FOR INTERMITTENT PROBLEMS
HINT:
TOYOTA hand-held tester only:
By putting the vehicle's ECM in check mode, 1 trip detection logic is possible instead of 2 trip detection logic
and sensitivity to detect open circuits is increased. This makes it easier to detect intermittent problems.
(a) Clear the DTC (See page DI-13).
(b) Set the check mode (See page DI-13).
(c) Perform a simulation test (See page IN-26).
(d) Check the connector and terminal (See page IN-26).
(e) Handle the connector (See page IN-26).
6. BASIC INSPECTION
When the malfunction code is not confirmed in the DTC check, troubleshooting should be performed in the
order for all possible circuits to be considered as the causes of the problems. In many cases, by carrying
out the basic engine check shown in the following flow chart, the location causing the problem can be found
quickly and efficiently. Therefore, use of this check is essential in engine troubleshooting.
1 Is battery positive voltage 11V or more when engine is stopped ?
NO Charge or replace battery.

MA0659
Outside
Inside
DI-8
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
YES
2 Is engine cranked ?
NO Proceed to ST-13, ST-28, ST-31 and continue
to troubleshoot.
YES
3 Does engine start ?
NO Go to step 7.
YES
4 Check air filter.
PREPARATION:
Remove the air filter.
CHECK:
Visual check that the air cleaner element is not excessively dirty
or oily.
HINT:
If necessary, clean the filter with compressed air. First blow from
inside thoroughly, then blow from outside of filter.
NG Repair or replace.
OK
5 Check engine idle speed.
PREPARATION:
(a) Warm up engine to normal operating temperature.
(b) Switch off all accessories.
(c) Switch off air conditioning.
(d) Shift transmission into ºNº position.

P25914P25915A07081
TE1
E1 SST
DLC1
- DIAGNOSTICSENGINE
DI-9
1996 TERCEL (RM440U)
(e) Remove the fuse cover on the instrument panel.
(f) Connect the OBD II scan tool or TOYOTA hand-held tester to DLC3 on the vehicle.
CHECK:
Use CURRENT DATA to check the engine idle speed.
OK:
Idle speed: 700 - 800 rpm
NG Proceed to matrix chart of problem symptoms
on page DI-19.
OK
6 Check ignition timing.
PREPARATION:
(a) Warm up engine to normal operating temperature.
(b) Shift transmission into ºNº position.
(c) Keep the engine speed at idle.
(d) Using SST, connect terminals TE1 and E1 of DLC1.
SST 09843-18020
(e) Using a timing light, connect the tester to No.1 high-ten-
sion cord.
CHECK:
Check ignition timing.
OK:
Ignition timing: 10° BTDC at idle
NG Proceed to page IG-1 and continue to trouble-
shoot.
OK
Proceed to matrix chart of problem symp-
toms on page DI-19.

P25916
S00553
DI-10
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
7 Check fuel pressure.
PREPARATION:
(a) Be sure that enough fuel is in the tank.
(b) Turn ignition switch ON.
(c) Remove the fuse cover on the instrument panel.
(d) Connect the TOYOTA hand-held tester to DLC3 on the
vehicle.
(e) Use ACTIVE TEST mode to operate the fuel pump.
(f) If you have no TOYOTA hand-held tester, connect the
positive (+) and negative (-) leads from the battery to the
fuel pump connector (See page MF-1).
CHECK:
Check for fuel pressure in the inlet hose when it is pinched off.
HINT:
At this time, you will hear a fuel flowing noise.
NG Proceed to page MF-1 and continue to trouble-
shoot.
OK
8 Check for spark.
PREPARATION:
(a) Disconnect the high-tension cord from spark plug or re-
move the ignition coil.
(b) Remove spark plug.
(c) Install the spark plug to high-tension cord or ignition coil.
(d) Disconnect injector connector.
(e) Ground the spark plug.
CHECK:
Check if spark occurs while engine is being cranked.
NOTICE:
To prevent excess fuel being injected from the injectors
during this test, do not crank the engine for more than 5 -
10 seconds at a time.
NG Proceed to page IG-1 and continue to trouble-
shoot.
OK

- DIAGNOSTICSENGINE
DI-1 1
1996 TERCEL (RM440U)
Proceed to matrix chart of problem symp-
toms on page DI-19.
7. ENGINE OPERATING CONDITION
NOTICE:
The values given below for ºNormal Conditionº are representative values, so a vehicle may still be
normal even if its value from those listed here. So do not decide whether a part is faulty or not solely
according to the ºNormal Conditionº here.
CARB mandated signals:
TOYOTA hand-held tester displayMeasurement ItemNormal Condition*
FUEL SYS #1
Fuel System Bank 1
OPEN: Air-fuel ratio feedback stopped
CLOSED: Air-fuel ratio feedback operating
Idling after warming up: CLOSED
CALC LOAD
Calculator Load:
Current intake air volume as a proportion of max.
intake air volumeIdling: 19.7 - 47.4 %
Racing without load (2,500rpm): 18.8 - 46.4 %
COOLANT TEMP.Engine Coolant Temp. Sensor ValueAfter warming up: 80 - 95°C (176 - 203°F)
SHORT FT #1Short-term Fuel Trim Bank 10 ± 20%
LONG FT #1Long-term Fuel Trim Bank 10 ± 20%
ENGINE SPDEngine SpeedIdling: 700 - 800 rpm
VEHICLE SPDVehicle SpeedVehicle Stopped: 0 km/h (0 mph)
IGN ADVANCEIgnition Advance:
Ignition Timing of Cylinder No. 1Idling: BTDC 7 - 14°
INTAKE AIRIntake Air Temp. Sensor ValueEquivalent to Ambient Temp.
MAPAbsolute Pressure Inside Intake Manifold
Idling: 20 - 48 kPa
Racing without load (2,500 rpm):
19 - 47 kPa
THROTTLE POS
Voltage Output of Throttle Position Sensor
Calculated as a percentage:
0 V "0%, 5 V "100%Throttle Fully Closed: 6 - 16 %
Throttle Fully Open: 64 - 98 %
O2S B1, S1Voltage Output of Heated Oxygen Sensor
Bank 1, Sensor 1Idling: 0.1 - 0.9 V
O2FT B1, S1Oxygen Sensor Fuel Trim Bank 1, Sensor 1
(Same as SHORT FT #1)0 ± 20 %
O2S B1, S2Voltage Output of Oxygen Sensor
Bank 1, Sensor 2Driving at 50 km/h (31 mph): 0.1 - 0.9 V
*: If no conditions are specifically stated for ºldlingº, it means the shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.

DI-12
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
TOYOTA Enhanced Signals:
TOYOTA hand-held tester displayMeasurement ItemNormal Condition*
MISFIRE RPMEngine RPM for first misfire rangeMisfire 0: 0 rpm
MISFIRE LOADEngine load for first misfire rangeMisfire 0: 0 g/r
INJECTORFuel injection time for cylinder No.1Idling: 2.66 - 3.9 ms
IAC DUTY RATIOIntake Air Control Valve Duty Ratio
Opening ratio rotary solenoid type IAC valveIdling: 25.5 - 43 %
STARTER SIGStarter SignalCranking: ON
CTP SIGClosed Throttle Position SignalThrottle Fully Closed: ON
A/C SIGA/C Switch SignalA/C ON: ON
PNP SWPark/Neutral Position Switch SignalP or N position: ON
FC IDLFuel Cut Idle: Fuel cut when throttle valve fully
closed, during decelerationFuel cut operating: ON
FC TAUFuel Cut TAU: Fuel cut during very light loadFuel cut operating: ON
CYL#1, CYL#2, CYL#3, CYL#4Abnormal revolution variation for each cylinder0%
IGNITIONTotal number of ignition for every 1,000 revolu-
tions0 - 2,000 rpm
FUEL PUMPFuel Pump SignalIdling: ON
TOTAL FT B1Total Fuel Trim Bank 1: Average value for fuel
trim system of bank 1Idling: 0.8 - 1.2 V
O2 LR B1, S1
Oxygen Sensor Lean Rich Bank 1, Sensor 1 Re-
sponse time for oxygen sensor output to switch
from lean to rich.
Idling after warmed up: 0 - 1,000 msec.
O2 RL B1, S1
Oxygen Sensor Rich Lean Bank 1, Sensor 1 Re-
sponse time for oxygen sensor output to switch
from rich to lean.
Idling after warmed up: 0 - 1,000 msec.
*: If no conditions are specifically stated for ºldlingº, it means the shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.

DI4LF-02
- DIAGNOSTICSENGINE
DI-13
1996 TERCEL (RM440U)
DIAGNOSTIC TROUBLE CODE CHART
HINT:
Parameters listed in the chart may not be exactly the same as your reading due to the type of instrument
or other factors.
If a malfunction code is displayed during the DTC check in check mode, check the circuit for that code listed
in the table below, for details of each code, turn to the page referred to under the ''See page '' for the respec-
tive ''DTC No.'' in the DTC chart.
SAE Controlled:
DTC No.
(See Page)Detection ItemTrouble AreaMIL*Memory
P0105
(DI-20)
Manifold Absolute
Pressure/Barometric
Pressure Circuit
MalfunctionOpen or short in manifold absolute pressure sensor circuit
Manifold absolute pressure sensor
ECM

P0106
(DI-23)
Manifold Absolute
Pressure/Barometric
Pressure Circuit
Range/Performance Problem
Manifold absolute pressure sensor
P0110
(DI-24)Intake Air Temp. Circuit
MalfunctionOpen or short in intake air temp. sensor circuit
Intake air temp. sensor
ECM

P0115
(DI-28)Engine Coolant Temp. Circuit
MalfunctionOpen or short in engine coolant temp. sensor circuit
Engine coolant temp. sensor
ECM

P0116
(DI-32)Engine Coolant Temp. Circuit
Range/Performance ProblemEngine coolant temp. sensor
Cooling system
P0120
(DI-33)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
MalfunctionOpen or short in throttle position sensor circuit
Throttle position sensor
ECM

P0121
(DI-37)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
Range/Performance Problem
Throttle position sensor
P0125
(DI-38)Insufficient Coolant Temp. for
Closed Loop Fuel ControlOpen or short in oxygen sensor circuit
Oxygen sensor
P0130
(DI-41)Oxygen Sensor Circuit
Malfunction (Bank 1 Sensor 1)Heated oxygen sensor
Fuel trim malfunction
P0133
(DI-44)Oxygen Sensor Circuit
Slow Response
(Bank 1 Sensor 1)
Oxygen sensor
P0136
(DI-45)Heated Oxygen Sensor Circuit
Malfunction
(Bank 1 Sensor 2)
Heated oxygen sensor
P0141
(DI-47) Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 2)Open or short in heater circuit of heated oxygen sensor
Heated oxygen sensor heater
ECM

*:


MIL lights up

DI-14
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)DTC No.
(See Page)
Detection ItemTrouble AreaMIL*Memory
P0171
(DI-49)System too Lean
(Fuel Trim)
Air intake (hose loose)
Fuel line pressure
Injector blockage
Oxygen sensor malfunction
Manifold absolute pressure sensor
Engine coolant temp. sensor

P0172
(DI-49)System too Rich
(Fuel Trim)
Fuel line pressure
Injector blockage, leak
Oxygen sensor malfunction
Manifold absolute pressure sensor
Engine coolant temp. sensor

P0300
(DI-52)Random/Multiple Cylinder
Misfire DetectedIgnition system
Injector
FlliP0301
P0302
P0303
P0304
(DI-52)Misfire Detected
- Cylinder 1
- Cylinder 2
- Cylinder 3
- Cylinder 4Fuel line pressure
Compression pressure
Valve clearance not to specification
Valve timing
Manifold absolute pressure sensor
Engine coolant temp. sensor

P0325
(DI-57)Knock Sensor 1 Circuit
MalfunctionOpen or short in knock sensor 1 circuit
Knock sensor 1 (looseness)
ECM

P0335
(DI-60)Crankshaft Position Sensor
Circuit ºAº Malfunction
Open or short in crankshaft position sensor circuit
Crankshaft position sensor
Starter
ECM

P0340
(DI-63)Camshaft Position Sensor
Circuit Malfunction
Open or short in camshaft position sensor circuit
Camshaft position sensor
Starter
ECM

P0420
(DI-73)Catalyst System Efficiency
Below ThresholdThree-way catalytic converter
Open or short in (heated) oxygen sensor circuit
(Heated) oxygen sensor

P0500
(DI-76)Vehicle Speed Sensor
Malfunction
Open or short in vehicle speed sensor circuit
Vehicle speed sensor
Speedometer cable
ECM

P0505
(DI-78)Idle Control System
Malfunction
IAC valve is stuck or closed
Open or short in IAC valve circuit
Open or short in AC1 switch circuit
Air intake (hose loose)

*:


MIL lights up

- DIAGNOSTICSENGINE
DI-15
1996 TERCEL (RM440U)
Manufacturer Controlled:
DTC No.
(See Page)Detection ItemTrouble AreaMIL*Memory
P1300
(DI-84)Igniter Circuit Malfunction
Open or short in IGF or IGT circuit from igniter to ECM
Igniter
ECM

P1335
(DI-89)Crankshaft Position Sensor
Circuit Malfunction
(during engine running)Open or short in crankshaft position sensor circuit
Crankshaft position sensor
ECM
-
P1600
(DI-92)ECM BATT MalfunctionOpen in back up power source circuit
ECM
P1780
(DI-94)Park/Neutral Position Switch
MalfunctionShort in park/neutral position switch circuit
Park/neutral position switch
ECM

*:-


MIL does not light up



MIL lights up

DI4LG-02
A15676
DI-16
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
PARTS LOCATION
