- SERVICE SPECIFICATIONSBODY ELECTRICAL
SS-41
171 Author
: Date
:
1996 TERCEL (RM440U) FUEL RECEIVER GAUGE
w/ Tachometer:Resistance (W)
A - BApprox. 115.8
A - CApprox. 177.2
B - CApprox. 61.4
w/o Tachometer:Resistance (W)
A - BApprox. 171.2
A - CApprox. 272.8
B - CApprox. 101.6
FUEL SENDER GAUGE
Float position: mm (in.)Resistance (W)
F: Approx. 13.0 ± 3 (0.512 ± 0.118)Approx. 3 ± 1.0
1/2: Approx. 61.0 (2.402)Approx. 29 ± 4.8
E: Approx. 124.0 ± 3 (4.882 ± 0.118)Approx. 110 ± 7.7
ENGINE COOLANT TEMPERATURE RECEIVER GAUGE
w/ Tachometer:Resistance (W)
A - BApprox. 51.0
A - CApprox. 148.6
B - CApprox. 199.6
w/o Tachometer:Resistance (W)
A - BApprox. 54.0
A - CApprox. 175.7
B - CApprox. 229.7
DEFOGGER SWITCH
Timer Circuit:
2 - Ground (Ignition switch LOCK or ACC)No voltage
2 - Ground (Ignition switch ON)Battery positive voltage
6 - Ground (Ignition switch LOCK or ACC)No voltage
6 - Ground (Ignition switch ON)Battery positive voltage

SS0NJ-06
SS-42
- SERVICE SPECIFICATIONSBODY
172 Author
: Date
:
1996 TERCEL (RM440U)
BODY
TORQUE SPECIFICATION
Part tightenedN´mkgf´cmft´lbf
FRONT SEAT
Seat track x Body3737527
REAR SEAT
Seat back x Body1818513
Seat x Seat center hinge1818513
Seat center hinge x Body7.88069 in.´lbf
Seat x Seat hinge1818513
Seat hinge x Body7.88069 in.´lbf
FRONT SEAT BELT
Shoulder anchor x Adjustable anchor4344032
Outer belt anchor x Body4344032
ELR x Body4344032
Adjustable anchor x Body4344032
Inner belt x Seat4344032
REAR SEAT BELT
Outer belt anchor x Body4344032
ELR x Body4344032
Center belt x Body4344032
CANADA:
CRS, tether anchor x Body
2121015

SS0M9-03
- SERVICE SPECIFICATIONSAIR CONDITIONING
SS-43
173 Author
: Date
:
1996 TERCEL (RM440U)
AIR CONDITIONING
SERVICE DATA
Refrigerant charge volume650 ± 50 g (22.93 ± 1.76 oz.)
Drive belt tension New belt
Used belt160 ± 25 lbf
100 ± 20 lbf
Idle-up speed850 ± 50 rpm
Magnetic clutch clearance0.5 ± 0.15 mm (0.02 ± 0.0059 in.)

SS0MA-05
SS-44
- SERVICE SPECIFICATIONSAIR CONDITIONING
1996 TERCEL (RM440U)
TORQUE SPECIFICATION
Part tightenedN´mkgf´cmft´lbf
Compressor x Suction hose101007
Compressor x Discharge hose101007
Compressor x Compressor bracket2525018
Receiver x Liquid tube5.45548 in.´lbf
Condenser x Liquid tube5.45548 in.´lbf
Cooling unit x Liquid tube1414010
Cooling unit x Suction tube3233024
Expansion valve x Evaporator5.45548 in.´lbf
Revolution detecting sensor x Compressor1111 08
Pressure plate x Compressor1414010

DI4LC-02
Vehicle Brought to Workshop
Customer Problem Analysis
Problem Symptom Confirmation
If the engine does not start, perform steps 10 and 12 firstConnect the OBD II scan tool or TOYOTA hand-held tester to DLC3 P. DI-3
If the display indicates a communication fault in the tool, inspect DLC3 P. DI-3
Check DTC and Freeze Frame Data (Pre-check)
Record or Print DTC and Freeze Frame Data P. DI-3
Clear DTC and Freeze Frame Data P. DI-3
Visual Inspection
Setting the Check Mode Diagnosis P. DI-3
Symptom Simulation P. IN-16
Basic Inspection P. DI-3DTC Chart P. DI-13
Matrix Chart of Problem Symptom P. DI-19
Circuit Inspection P. DI-20
Adjustment, Repair
DTC Check P. DI-3
Titles insideare titles of pages in
in the bottom portion. See the indicated
pages for detailed explanations. this manual, with the page number indicated
Malfunction
occurs.Malfunction does not occur.
Parts Inspection
Check for Intermittent Problems P. DI-3
Identification of Problem
Confirmation Test
End 1
2
3
4
5
6
7
108
9
11
12
13
15 14
16
Normal Malfunction code.
17
P. DI-2
- DIAGNOSTICSENGINE
DI-1
175 Author
: Date
:
1996 TERCEL (RM440U)
ENGINE
HOW TO PROCEED WITH TROUBLESHOOTING
Troubleshoot in accordance with the procedure on the following pages.

DI4LD-02
ENGINE CONTROL SYSTEM Check Sheet
Customer's Name
Driver's Name
Date Vehicle
Brought in
License No.
Model and Model
Year
Frame No.
Engine Model
Odometer Reading
km
miles
Problem Symptoms
Engine does
not Start
Difficult to
Start
Poor Idling
Poor
Driveaability
Engine Stall
Others
Engine does not crankNo initial combustionNo complete combustion
Engine cranks slowly
Other
Incorrect first idleIdling rpm is abnormalHigh ( rpm)Low ( rpm)
Rough idling
Other
HesitationBack fireMuffler explosion (after-fire)Surging
Knocking
Other
Soon after startingAfter accelerator pedal depressed
After accelerator pedal released
During A/C operation
Shifting from N to D
Other
Datas Problem
Occurred
Problem Frequency
Condition When
Problem Occurs
Weather
Engine Operation
Engine Temp. Place Outdoor
TemperatureConstant
Sometimes ( times per day/month)Once only
Other
Fine
CloudyRainySnowyVarious/Other
Hot
Warm CoolCold (approx. °F/ °C)
Highway
SuburbsInner CityUphillDownhill
Rough road
Other
Cold
Warming upAfter Warming upAny temp.Other
Starting
Just after starting ( min.)IdlingRacing
Driving
Constant speedAccelerationDeceleration
A/C switch ON/OFF
Other
Condition of MILRemains on Sometimes light up Does not light up
NormalMalfunction code(s) (code )
Freeze frame data ( )
NormalMalfunction code(s) (code )
Freeze frame data ( )
Normal mode
(Pre-check)
Check Mode DTC InspectionInspector's
Name
DI-2
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
CUSTOMER PROBLEM ANALYSIS CHECK

FI0534
DI4LE-02
P19552
TOYOTA Hand-Held Tester
DLC3
- DIAGNOSTICSENGINE
DI-3
1996 TERCEL (RM440U)
PRE-CHECK
1. DIAGNOSIS SYSTEM
(a) Description

When troubleshooting OBD II vehicles, the only dif-
ference from the usual troubleshooting procedure
is that you need to connect OBD II scan tool comply-
ing with SAE 1978 or TOYOTA hand-held tester to
the vehicle and read off various data output from the
vehicle's ECM.

OBD II regulations require that the vehicle's on-
board computer lights up the Malfunction Indicator
Light (MIL) on the instrument panel when the com-
puter detects a malfunction in the computer itself or
in a drive system components which affect vehicle
emissions. In addition to the MIL lighting up when
a malfunction is detected, the applicable Diagnostic
Trouble Code (DTC) prescribed by SAE J2012 are
recorded in the ECM memory (See page DI-13).
If the malfunction does not reoccur in 3 trips, the MIL goes off
but the DTC remain recorded in the ECM memory.

To check the DTC, connect the OBD II scan tool or
TOYOTA hand-held tester to Data Link Connector
3 (DLC3) on the vehicle. The OBD II scan tool or
TOYOTA hand-held tester also enables you to
erase the DTC and check freezed frame data and
various forms of engine data (For operating instruc-
tions, see the OBD II scan tool's instruction book.).

DTC include SAE controlled codes and manufac-
turer controlled codes. SAE controlled codes must
be set as prescribed by the SAE, while manufactur-
er controlled codes can be set freely by the
manufacturer within the prescribed limits (See DTC
chart on page DI-13).

N09214
DTC3 DI-4
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)

The diagnosis system operates in normal mode
during normal vehicle use. It also has a check mode
for technicians to simulate malfunction symptoms
and troubleshoot. Most DTC use 2 trip detection
logic* to prevent erroneous detection, and ensure
thorough malfunction detection. By switching the
ECM to check mode when troubleshooting, the
technician can cause the MIL to light up for a mal-
function that is only detected once or momentarily
(TOYOTA hand-held tester only) (See page
DI-3).

*2 trip detection logic:
When a logic malfunction is first detected, the mal-
function is temporarily stored in the ECM memory.
If the same malfunction is detected again during the
second drive test, this second detection causes the
MIL to light up.

The 2 trip repeats the same mode a 2nd time (How-
ever, the IG switch must be turned OFF between the
1st trip and 2nd trip.).

Freeze frame data:
Freeze frame data records the engine condition
when a misfire (DTC P0300 - P0304) or fuel trim
malfunction (DTC P0171, P0172) or other malfunc-
tion (first malfunction only), is detected, as freeze
frame data records the engine conditions (fuel sys-
tem, calculator load, engine coolant temperature,
fuel trim,engine speed, vehicle speed, etc.) when
the malfunction is detected, when troubleshooting
it is useful for determining whether the vehicle was
running or stopped, the engine warmed up or not,
the air-fuel ratio lean or rich, etc. at the time of the
malfunction.
Priorities for troubleshooting:
If troubleshooting priorities for multiple DTC are given in the ap-
plicable DTC chart, these should be followed.
If no instructions are given troubleshoot DTC according to the
following priorities.
(1) DTC other than fuel trim malfunction (DTC P0171,
P0172) and misfire (DTC P0300 - P0304).
(2) Fuel trim malfunction (DTC P0171, P0172).
(3) Misfire (DTC P0300 - P0304).
(b) Check the DLC3.
The vehicle's ECM uses ISO 9141-2 for communication.
The terminal arrangement of DLC3 complies with SAE
J1962 and matches the ISO 9141-2 format.

S00840
- DIAGNOSTICSENGINE
DI-5
1996 TERCEL (RM440U)Terminal No.
Connection / Voltage or ResistanceCondition
7Bus + Line / Pulse generationDuring transmission
4Chassis Ground - Body Ground / 1 W or lessAlways
5Signal Ground - Body Ground / 1 W or lessAlways
16Battery Positive - Body Ground / 9 - 14 VAlways
HINT:
If your display shows ºUNABLE TO CONNECT TO VEHICLEº
when you have connected the cable of the OBD II scan tool or
TOYOTA hand-held tester to DLC3, turned the ignition switch
ON and operated the scan tool, there is a problem on the ve-
hicle side or tool side.

If communication is normal when the tool is connected to
another vehicle, inspect DLC3 on the original vehicle.

If communication is still not possible when the tool is con-
nected to another vehicle, the problem is probably in the
tool its self, so consult the Service Department listed in
the tool's instruction manual.
2. Normal Mode:
INSPECT DIAGNOSIS
(a) Check the MIL.
(1) The MIL comes on when the ignition switch is turned
ON and the engine is not running.
HINT:
If the MIL does not light up, troubleshoot the combination meter.
(2) When the engine started, the MIL should go off. If
the lamp remains on, the diagnosis system has de-
tected a malfunction or abnormality in the system
(b) Check the DTC.
NOTICE:
TOYOTA hand-held tester only: When the diagnosis sys-
tem is switched from the normal mode to the check mode,
it erases all DTC and freeze frame data recorded in the nor-
mal mode. So before switching modes, always check the
DTC and freeze frame data, and note them down.
(1) Prepare the OBD II scan tool (complying with SAE
J 1978) or TOYOTA hand-held tester.
(2) Connect the OBD II scan tool or TOYOTA hand-
held tester to DLC3 in the fuse box at the lower left
of the instrument panel.
(3) Turn the ignition switch ON and turn the OBD II scan
tool or TOYOTA hand-held tester switch ON.
(4) Use the OBD II scan tool or TOYOTA hand-held
tester to check the DTC and freezed frame data;
note them down (For operating instructions, see the
OBD II scan tool's instruction book.).
(5) See page DI-13 to confirm the details of the
DTC.

FI3605
Flashing
ON
OFF
0.13 Seconds
DI-6
- DIAGNOSTICSENGINE
1996 TERCEL (RM440U)
NOTICE:
When simulating symptoms with an OBD II scan tool (ex-
cluding TOYOTA hand-held tester) to check the DTC, use
the normal mode. For code on the DTC chart subject to º2
trip detection logicº, turn the ignition switch OFF after the
symptom is simulated the first time. Then repeat the simu-
lation process again. When the problem has been simu-
lated twice, the MIL lights up and the DTC are recorded in
the ECM.
3. Check Mode:
INSPECT DIAGNOSIS
HINT:
TOYOTA hand-held tester only:
Compared to the normal mode, the check mode has an in-
creased sensitivity to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
the normal mode can also be detected in the check mode.
(a) Check the DTC.
(1) Initial conditions.

Battery positive voltage 11V or more.

Throttle valve fully closed.

Transmission in ºPº or ºNº position.

Air conditioning switched OFF.
(2) Turn the ignition switch OFF.
(3) Prepare the TOYOTA hand-held tester.
(4) Connect the TOYOTA hand-held tester to DLC3 in
the fuse box at the lower left of the instrument panel.
(5) Turn the ignition switch ON and switch the TOYOTA
hand-held tester ON.
(6) Switch the TOYOTA hand-held tester normal mode
to check mode. (Check that the MIL flashes.)
(7) Switch the engine. (The MIL goes out after the en-
gine start.)
(8) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTC, etc.
(9) After simulating the malfunction conditions, use the
TOYOTA hand-held tester diagnosis selector to
check the DTC and freezed frame data, etc.
HINT:
Take care not to turn the ignition switch OFF. Turning the ignition
switch OFF switches the diagnosis system from check mode to
normal mode, so all DTC, etc. are erased.
(10) After checking the DTC, inspect the applicable cir-
cuit.
