torque TOYOTA TERCEL 1996 Service Repair Manual

IN00U-36
N17080
Filler Cap
Float
Reservoir
 Grommet
Clip
Slotted Spring Pin
: Specified torque
 Non-reusable partCylinder
Piston
Push Rod
Washer
Snap Ring
Boot
 Gasket
Lock Nut
Clevis Pin
Clevis
N´m (kgf´cm, ft´lbf)
12 (120, 9)
15 (155, 11)
- INTRODUCTIONHOW TO USE THIS MANUAL
IN-1
1 Author
: Date
:
1996 TERCEL (RM440U)
HOW TO USE THIS MANUAL
GENERAL INFORMATION
1. INDEX
An INDEX is provided on the first page of each section to guide you to the item to be repaired. To assist you
in finding your way through the manual, the section title and major heading are given at the top of every page.
2. PRECAUTION
At the beginning of each section, a PRECAUTION is given that pertains to all repair operations contained
in that section.
Read these precautions before starting any repair task.
3. TROUBLESHOOTING
TROUBLESHOOTING tables are included for each system to help you diagnose the problem and find the
cause. The fundamentals of how to proceed with troubleshooting are described on page IN-16.
Be sure to read this before performing troubleshooting.
4. PREPARATION
Preparation lists the SST (Special Service Tools), recommended tools, equipment, lubricant and SSM (Spe-
cial Service Materials) which should be prepared before beginning the operation and explains the purpose
of each one.
5. REPAIR PROCEDURES
Most repair operations begin with an overview illustration. It identifies the components and shows how the
parts fit together.
Example:

Illustration:
what to do and where
21. CHECK PISTON STROKE OF OVERDRIVE BRAKE
(a)
Task heading : what to do
SST 09350-30020 (09350-06120)
Set part No. Component part No.
Detailed text : how to do task
(b)
Piston stroke: 1.40
1.70 mm (0.0551
0.0669 in.)
Specification
Place SST and a dial indicator onto the overdrive brake pis-
ton as shown in the illustration.
Measure the stroke applying and releasing the compressed
air (392
785 kPa, 4
8 kgf/cm
2 or 57
114 psi) as shown
in the illustration. IN-2
- INTRODUCTIONHOW TO USE THIS MANUAL
2 Author
: Date
:
1996 TERCEL (RM440U)
The procedures are presented in a step-by-step format:

The illustration shows what to do and where to do it.

The task heading tells what to do.

The detailed text tells how to perform the task and gives other information such as specifications
and warnings.
Example:
This format provides the experienced technician with a FAST TRACK to the information needed. The upper
case task heading can be read at a glance when necessary, and the text below it provides detailed informa-
tion. Important specifications and warnings always stand out in bold type.
6. REFERENCES
References have been kept to a minimum. However, when they are required you are given the page to refer
to.
7. SPECIFICATIONS
Specifications are presented in bold type throughout the text where needed. You never have to leave the
procedure to look up your specifications. They are also found in Service Specifications section for quick ref-
erence.
8. CAUTIONS, NOTICES, HINTS:

CAUTIONS are presented in bold type, and indicate there is a possibility of injury to you or other
people.

NOTICES are also presented in bold type, and indicate the possibility of damage to the components
being repaired.

HINTS are separated from the text but do not appear in bold. They provide additional information to
help you perform the repair efficiently.
9. SI UNIT
The UNITS given in this manual are primarily expressed according to the SI UNIT (International System of
Unit), and alternately expressed in the metric system and in the English System.
Example:
Torque: 30 N´m (310 kgf´cm, 22 ft´lbf)

BE1367
Medium Current Fuse and High Current Fuse
Equal Amperage Rating
V00076
Abbreviation Part Name Symbol Illustration
FUSE
MEDIUM CURRENT FUSE
HIGH CURRENT FUSE
FUSIBLE LINK
CIRCUIT BREAKERFUSE
M-FUSE
H-FUSE
FL
CB
- INTRODUCTIONREPAIR INSTRUCTIONS
IN-5
5 Author
: Date
:
1996 TERCEL (RM440U)
(3) Precoated parts are indicated in the component il-
lustrations by the º
º symbol.
(g) When necessary, use a sealer on gaskets to prevent
leaks.
(h) Carefully observe all specifications for bolt tightening
torques. Always use a torque wrench.
(i) Use of special service tools (SST) and special service ma-
terials (SSM) may be required, depending on the nature
of the repair. Be sure to use SST and SSM where speci-
fied and follow the proper work procedure. A list of SST
and SSM can be found in Preparation section in this
manual.
(j) When replacing fuses, be sure the new fuse has the cor-
rect amperage rating. DO NOT exceed the rating or use
one with a lower rating.

- INTRODUCTIONTERMS
IN-37
1996 TERCEL (RM440U) HO2S
Heated Oxygen SensorHeated Oxygen Sensor (HO2S)
IACIdle Air ControlIdle Speed Control (ISC)
IATIntake Air TemperatureIntake or Inlet Air Temperature
ICMIgnition Control Module-
IFIIndirect Fuel InjectionIndirect Injection (IDL)
IFSInertia Fuel-Shutoff-
ISCIdle Speed Control-
KSKnock SensorKnock Sensor
MAFMass Air FlowAir Flow Meter
MAPManifold Absolute PressureManifold Pressure
Intake Vacuum
MCMixture Control
Electric Bleed Air Control Valve (EBCV)
Mixture Control Valve (MCV)
Electric Air Control Valve (EACV)
MDPManifold Differential Pressure-
MFIMultiport Fuel InjectionElectronic Fuel Injection (EFI)
MILMalfunction Indicator LampCheck Engine Lamp
MSTManifold Surface Temperature-
MVZManifold Vacuum Zone-
NVRAMNon-V olatile Random Access Memory-
O2SOxygen SensorOxygen Sensor, O2 Sensor (O2S)
OBDOn-Board DiagnosticOn-Board Diagnostic System (OBD)
OCOxidation Catalytic ConverterOxidation Catalyst Convert (OC), CCo
OPOpen LoopOpen Loop
PAIRPulsed Secondary Air InjectionAir Suction (AS)
PCMPowertrain Control Module-
PNPPark/Neutral Position-
PROMProgrammable Read Only Memory-
PSPPower Steering Pressure-
PTOXPeriodic Trap OxidizerDiesel Particulate Filter (DPF)
Diesel Particulate Trap (DPT)
RAMRandom Access MemoryRandom Access Memory (RAM)
RMRelay Module-
ROMRead Only MemoryRead Only Memory (ROM)
RPMEngine SpeedEngine Speed
SCSuperchargerSupercharger
SCBSupercharger BypassE-ABV
SFISequential Multiport Fuel InjectionElectronic Fuel Injection (EFI), Sequential Injection
SPLSmoke Puff Limiter-
SRIService Reminder Indicator-
SRTSystem Readiness Test-
STScan Tool-
TBThrottle BodyThrottle Body
TBIThrottle Body Fuel InjectionSingle Point Injection
Central Fuel Injection (Ci)
TCTurbochargerTurbocharger
TCCTorque Converter ClutchTorque Converter

MA02M-05
- MAINTENANCEBODY
MA-9
47 Author
: Date
:
1996 TERCEL (RM440U)
BODY
INSPECTION
1. TIGHTEN BOLTS AND NUTS ON CHASSIS AND BODY
(a) Tighten the front seat-to-body mounting bolts.
Torque: 37 N´m (375 kgf´cm, 27 ft´lbf)
(b) Under Severe Conditions:
In addition to the above maintenance items, check for
loose or missing nuts and bolts on the steering system,
drive train, suspension system, fuel tank mounts, engine
mounts, etc.
2. FINAL INSPECTION
(a) Check the operation of the body parts:

Hood:
Auxiliary catch operates properly
Hood locks securely when closed

Front and rear doors:
Door lock operates properly
Doors close properly

Luggage compartment door:
Door lock operates properly

Seats:
Seat adjusts easily and locks securely in any posi-
tion
Front seat back locks securely in any position
Folding-down rear seat backs lock securely
(b) Road test:

Check the engine and chassis for abnormal noises.

Check that the vehicle does not wander or pull to
one side.

Check that the brakes work properly and do not
drag.
(b) Be sure to deliver a clean car.
Especially check the steering wheel, shift lever knob, all
switch knobs, door handles and seats.

PP18P-01
- PREPARATIONMAINTENANCE
PP-1
48 Author
: Date
:
1996 TERCEL (RM440U)
MAINTENANCE
EQUIPMENT
MirrorBrake hose
Torque wrench

PP18S-01
PP-6
- PREPARATIONENGINE MECHANICAL
1996 TERCEL (RM440U)
EQUIPMENT
Caliper gauge
CO/HC meter
Compression gauge
Connecting rod aligner
Cylinder gauge
Dial indicator
Dye penetrant
Engine tune-up tester
Heater
Magnetic finger
Micromerer
OBD II scan toolIdle speed
Piston ring compressor
Piston ring expander
Plastigage
Precision straight edge
Soft brush
Spring testerValve spring
Steel squareValve spring
Torque wrench
Valve seat cutter
Vernier calipers

PP18U-04
- PREPARATIONEMISSION CONTROL
PP-9
1996 TERCEL (RM440U)
EQUIPMENT
HeaterTVV
ThermometerTVV
Torque wrench
Vacuum gauge

PP18X-01
- PREPARATIONMFI
PP-13
1996 TERCEL (RM440U)
EQUIPMENT
Carburetor cleaner
OBD II scan tool
Soft brushThrottle body
Sound scopeInjector
Thermometer
Torque wrench
Vacuum gauge

PP190-02
PP-16
- PREPARATIONCOOLING
1996 TERCEL (RM440U)
EQUIPMENT
Radiator cap tester
Torque wrench
