91
(e) Low Oil Pressure Warning Light
This light warns that the engine oil pres-
sure is too low.
If it flickers or stays on while you are
driving, pull off the road to a safe place
and stop the engine immediately. Call a
Toyota dealer or qualified repair shop for
assistance.
The light may occasionally flicker when
the engine is idling or it may come on
briefly after a hard stop. There is no
cause for concern if it then goes out when
the engine is accelerated slightly.
The light may come on when the oil level
is extremely low. It is not designed to
indicate low oil level, and the oil level
must be checked using the level dipstick.
NOTICE
Do not drive the vehicle with thewarning light onÐeven for one block.It may ruin the engine.
(f) Malfunction indicator lamp
This lamp comes on in the following
cases.
a. The fuel tank is completely empty. (See
Fuel gaugeº in Chapter 1- 5 for instruc-
tions.)
b. The fuel tank cap is not tightened se-
curely. (See Fuel tank capº in Chapter
1- 2 for instructions.)
c. There is a problem somewhere in your
engine or automatic transmission electrical
system.
If it comes on while you are driving in
case c, have your vehicle checked/re-
paired by your Toyota dealer as soon as
possible.
(g) Low Fuel Level Warning Light
This light comes on when the fuel level
in the tank becomes nearly empty. Fill up
the tank as soon as possible.
On inclines or curves, due to the move-
ment of fuel in the tank, the low fuel level
warning light may come on earlier than
usual. (h) ABSº Warning Light
This light warns that there is a problem
somewhere in your anti- lock brake sys-
tem.
If the light comes on while you are driv-
ing, have your vehicle checked by your
Toyota dealer as soon as possible.
The light will come on when the ignition
key is turned to the ONº position. After
a few seconds, the light will go off.
When the ABSº warning light is on (and
the brake system warning light is off), the
brake system operates conventionally but
anti- lock brake system is not assisting
brake performance so that the wheels can
lock- up during sudden braking or braking
on slippery road surfaces.
(i) Open Door Warning Light
This light remains on until all the doors
are completely closed.
ProCarManuals.com

TUNDRA (34413U)
92
(j) SRS Warning Light
This light will come on when the igni-
tion key is turned to the ACCº or
ONº position. After about 6 seconds,
the light will go off. This means the
system of the airbag and front seat belt
pretensioners are operating properly.
The warning light system monitors the air-
bag sensor assembly, front airbag sen-
sors, seat belt pretensioner assemblies,
inflators, warning light, interconnecting wir-
ing and power sources.
If either of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.

The light does not come on when the
ignition key is turned to the ACCº or
ONº position or remains on.

The light comes on or flashes while
driving.(k) Unengaged Parkº Warning Light
(with automatic transmission and
front drive control lever)
This light warns that the transmission
Parkº mechanism is not engaged. If the
front drive control lever is in the Nº posi-
tion while the selector lever is in the Pº
position, the transmission will disengage
and the wheels will not lock.
CAUTION
To restore the park function, shift the
front drive control lever out of Nº,
or the vehicle can move.
(l) Automatic Transmission Fluid Tem- perature Warning Light
This light warns that the automatic trans-
mission fluid temperature is too high.
If this light comes on while you are driv-
ing, slow down and pull off the road. Stop
the vehicle at a safe place and put the
selector lever in Pº. With the engine id-
ling, wait until the light goes off. If the
light goes off, you may start the vehicle
again. If the light does not go off, call a
Toyota dealer or qualified repair shop for
assistance. (m) Low Windshield Washer Fluid Level
Warning Light (with daytime running
light system)
This light warns that the windshield wash-
er fluid level is too low. Add washer fluid
at your earliest opportunity. (For instruc-
tions, see Adding washer fluidº in Chapter
7- 3.)
(n) Key Reminder Buzzer
This buzzer reminds you to remove the
key when you open the driver 's door with
the ignition key in the ACCº or LOCKº
position.
(o) Four- wheel drive system warning buzzer
This buzzer reminds you that the transfer
mode is not selected correctly.
If the buzzer sounds when you shift the
transfer from 2WDº to 4HIº, 4LOº to
4HIº, 4HIº to 4LOº, or 4LOº to 2WDº
mode, follow the instructions in Four-
wheel drive systemº in Chapter 1- 6.
ProCarManuals.com

TUNDRA (34413U)
93
CHECKING SERVICE REMINDER INDICA-
TORS (except the low fuel level warning
light and low windshield washer fluid
level warning light)1. Apply the parking brake.
2. Open one of the doors. The open door warning light should
come on.
3. Close the door. The open door warning light should go
off.
4. Turn the ignition key to ACCº. The SRS warning light should come on.
It goes off after about 6 seconds.
5. Turn the ignition key to ONº, but do not start the engine.
All the service reminder indicators ex-
cept the open door warning light and
SRS warning light should come on. The
ABSº warning light goes off after a
few seconds.
If any service reminder indicator or warn-
ing buzzer does not function as described
above, either the bulb is burned out or the
circuit is in need of repair. Have it
checked by your Toyota dealer as soon as
possible.
ProCarManuals.com

TUNDRA (34413U)
94
ProCarManuals.com

TUNDRA (34413U)
95
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 6
Ignition switch,
Transmission and
Parking brake

Ignition switch with steering lock

Automatic transmission

Manual transmission

Four- wheel drive system

P ar k ing br ak e

Cruise control

Clutch start cancel switchSTARTºÐStarter motor on. The key
will return to the ONº position when
released.
For starting tips, see Part 3.
ONºÐEngine on and all accessories
on.
This is the normal driving position.
ACCºÐAccessories such as the radio
operate, but the engine is off.
If you leave the key in the ACCº or
LOCKº position and open the driver's
door, a buzzer will remind you to remove
the key.
LOCKºÐEngine is off and the steering
wheel is locked. The key can be re-
moved only at this position. You must push in the key to turn the key
from ACCº to the LOCKº position. On
vehicles with an automatic transmission,
the selector lever must be in the Pº posi-
tion before pushing the key.
When starting the engine, the key may
seem stuck at the LOCKº position. To
free it, first be sure the key is pushed all
the way in, and then rock the steering
wheel slightly while turning the key gently.
CAUTION
For manual transmission:
Never remove the key when the ve-
hicle is moving, as this will lock the
steering wheel and result in loss of
steering control.
NOTICE
Do not leave the key in the ONº
position if the engine is not running.The battery will discharge and theignition could be damaged.
Ignition switch with steering
lock
ProCarManuals.com

TUNDRA (34413U)
96
Automatic transmission
Shift while pulling the selector
lever toward you With the brake pedal depressed,
shift while pulling the selector lever
toward you. (The ignition switch
must be in ONº or ACCº position.)Parking, engine starting and
key removal position
Reverse position
Neutral position
Normal driving position
Position for engine braking
Position for stronger engine
braking than that in 2º position
Shift normally Overdrive switch
For selecting either a three- speed or
four- speed transmission
OFFº position
(Shifting into overdrive
not possible) ONº position
(Shifting into
overdrive possible)
O/D OFFº indicator light
Shows the overdrive switch
is in OFFº position
Vehicles with cruise controlÐWhen the cruise control is being used, even if you downshift the transmission by turning off the o verdrive
switch, engine braking will not be applied because the cruise control is not cancelled. For ways to decrease the vehicle speed, see
Cruise controlº in this chapter.
ProCarManuals.com

TUNDRA (34413U)
97
Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of Pº position when the
brake pedal is depressed (with the ignition
switch in ONº or ACCº position and the
selector lever pulled toward you).
(a) Normal driving1. Start the engine as instructed in How to start the engineº in Part 3. The
transmission must be in Pº or Nº.
2. With your foot holding down the brake pedal, shift the selector lever to Dº.
When the lever is in Dº position, the
automatic transmission system will select
the most suitable gear for running condi-
tions such as normal cruising, hill climb-
ing, hard towing, etc.
Always turn the overdrive switch on for
better fuel economy and quieter driving. If
the engine coolant temperature is low, the
transmission will not shift into the over-
drive gear even with the overdrive switch
on.
CAUTION
Never put your foot on the accelera-
tor pedal while shifting.
3. Release the parking brake and brake pedal. Depress the accelerator pedal
slowly for smooth starting.
(b) Using engine braking
To use engine braking, you can downshift
the transmission as follows:

Turn off the overdrive switch. The O/D
OFFº indicator light will come on and
the transmission will downshift to the
third gear.

Shift into the 2º position. The trans-
mission will downshift to the second
gear when the vehicle speed drops
down to or lower than the following
speed, and more powerful engine brak-
ing will be obtained.
Two- wheel drive models 5VZ- FE engine 115 km/h (71 mph)
2UZ- FE engine 120 km/h (75 mph)
Four- wheel drive models
5VZ- FE engine Front drive control lever in H2º or
H4º
109 km/h (68 mph)
Front drive control lever in L4º 37 km/h (23 mph) 2UZ- FE engine
2WDº or 4HIº mode is selected 120 km/h (75 mph)
4LOº mode is selected 41 km/h (25 mph)

Shift into the Lº position. The trans-
mission will downshift to the first gear
when the vehicle speed drops down to
or lower than the following speed, and
maximum engine braking will be ap-
plied.
Two- wheel drive models
5VZ- FE engine 55 km/h (34 mph)
2UZ- FE engine 58 km/h (36 mph)
Four- wheel drive models 5VZ- FE engine Front drive control lever in H2º or
H4º
52 km/h (32 mph)
Front drive control lever in L4º 10 km/h ( 6 mph)
2UZ- FE engine 2WDº or 4HIº mode is selected 58 km/h (36 mph)
4LOº mode is selected 11 km/h ( 7 mph)
ProCarManuals.com

TUNDRA (34413U)
98
Vehicles with cruise controlÐWhen the
cruise control is being used, even if you
downshift the transmission by turning off
the overdrive switch, engine braking will
not be applied because the cruise control
is not cancelled. For ways to decrease
the vehicle speed, see Cruise controlº in
this chapter.
CAUTION
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.
(c) Using 2º and Lº positions
The 2º and Lº positions are used for
strong engine braking as described pre-
viously.
With the selector lever in 2º or Lº, you
can start the vehicle in motion as with the
lever in Dº.
With the selector lever in 2º, the vehicle
will start in the first gear and automatical-
ly shift to the second gear.
With the selector lever in Lº, the trans-
mission is engaged in the first gear.
NOTICE

Be careful not to overrev the en-gine. Watch the tachometer to keepengine rpm from going into the redzone. The approximate maximum al-
lowable speed for each position isgiven below for your reference:
Two- wheel drive models
5VZ- FE engineÐ2º 115 km/h (71 mph) . . . . . . . . .
Lº 60 km/h (37 mph)
. . . . . . . . . .
2UZ- FE engineÐ 2º 120 km/h (75 mph)
. . . . . . . . .
Lº 65 km/h (40 mph)
. . . . . . . . . .
Four- wheel drive models
5VZ- FE engineÐFront control lever in H2º or
H4º 2º 110 km/h (68 mph)
. . . . . . . . .
Lº 60 km/h (37 mph)
. . . . . . . . . .
Front control lever in L4º 2º 40 km/h (25 mph)
. . . . . . . . . .
Lº 20 km/h (12 mph)
. . . . . . . . . .
2UZ- FE engineÐ
2WDº or 4HIº mode is selected 2º 120 km/h (75 mph) . . . . . . . . .
Lº 65 km/h (40 mph)
. . . . . . . . . .
4LOº mode is selected 2º 45 km/h (28 mph)
. . . . . . . . . .
Lº 25 km/h (16 mph)
. . . . . . . . . .

Do not continue hill climbing for a
long time in the 2º or Lº posi-tion. This may cause severe auto-
matic transmission damage fromoverheating. To prevent such dam-age, use Dº position for hill climb-
ing or hard towing.
(d) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the selector lever to the
Rº position.
NOTICE
Never shift into reverse while the ve-hicle is moving.
ProCarManuals.com

TUNDRA (34413U)
99
(e) Parking1. Bring the vehicle to a complete stop.
2. With the brake pedal pressed down, fully depress the parking brake pedal
to apply the parking brake securely.
3. With the brake pedal pressed down, shift the selector lever to the Pº posi-
tion.
CAUTION
While the vehicle is moving, never
attempt to move the selector lever
into Pº position under any circum-
stances. Serious mechanical damage
and loss of vehicle control may re-
sult.
(f) Good driving practice

If the transmission repeatedly shifts up
and down between third gear and over-
drive when climbing a gentle slope, the
overdrive switch should be turned off.
Be sure to turn the switch on immedi-
ately afterward.

When towing a trailer, in order to main-
tain engine braking efficiency, do not
use overdrive.
CAUTION
Always keep your foot on the brake
pedal while stopped with the engine
running. This prevents the vehicle
from creeping.
NOTICE
Do not hold the vehicle on an up-
grade with the accelerator pedal. Itcan cause the transmission to over-heat. Always use the brake pedal or
parking brake.
(g) Rocking your vehicle if stuck
CAUTION
If your vehicle becomes stuck in
snow, mud, sand, etc., then you may
attempt to rock the vehicle free by
moving it forward and backward. Do
not attempt this procedure if people
or objects are anywhere near the ve-
hicle. During the rocking operation
the vehicle may suddenly move for-
ward or backward as it becomes un-
stuck, causing injury or damage to
nearby people or objects.
NOTICE
If you rock your vehicle, observe thefollowing precautions to prevent dam-age to the transmission and otherparts.

Do not depress the accelerator ped-al while shifting the selector leveror before the transmission is com-
pletely shifted to forward or reversegear.
ProCarManuals.com

TUNDRA (34413U)
100

Do not race the engine and avoidspinning the wheels.

If your vehicle remains stuck afterrocking the vehicle several times,
consider other ways such as tow-ing.
Manual transmission
The shift pattern is as shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest your foot on the pedal while driving,
because it will cause clutch trouble. And
do not use the clutch to hold the vehicle
when stopped on an uphill gradeÐuse the
parking brake. Recommended shifting speeds
The transmission is fully synchronized and
upshifting or downshifting is easy.
For the best compromise between fuel
economy and vehicle performance, you
should upshift or downshift at the following
speeds:
gear km/h (mph)
1 to 2 or 2 to 1 24 (15)
2 to 3 or 3 to 2 40 (25)
3 to 4 or 4 to 3 64 (40)
4 to 5 or 5 to 4 72 (45)
Downshift to the appropriate gear if accel-
eration is needed when you are cruising
below the above downshifting speeds.
Upshifting too soon or downshifting too
late will cause lugging, and possibly ping-
ing. Regularly revving the engine to maxi-
mum speed in each gear will cause ex-
cessive engine wear and high fuel
consumption.
ProCarManuals.com
