TOYOTA TUNDRA 2007 2.G Navigation Manual

8
1U5017aG
:To view the previous page.
:To view the next page.
:To return to the previous screen.
Map screen operation —
— Current position display
When starting the navigation system, the cur-
rent position is displayed first.
This screen displays the current vehicle posi-
tion and a map of the surrounding local area.
1U5030G
The current vehicle position mark (1) ap-
pears in the center or bottom center of the
map screen.
A street name will appear on the bottom of the
screen, depending on the scale of the map
(
2).
You can return to this map screen that shows
your current position at any time from any
screen by pushing the “MAP/VOICE” button.
While driving, the current vehicle position
mark is fixed on the screen and the map
moves.The current position is automatically set as
the vehicle receives signals from the GPS
(Global Positioning System). If the current
position is not correct, it is automatically cor-
rected after the vehicle receives signals from
the GPS.
INFORMATION
After battery disconnection, or on a
new vehicle, the current position may
not be correct. As soon as the system
receives signals from the GPS, the
correct current position is displayed.
To correct the current position manu-
ally, see “
 Current position/tire
change calibration” on page 87.

9
— Screen scroll operation
(onetouch scroll)
When any point on the map is touched, that
point moves to the center of the screen and is
shown by the cursor mark (
1).
1U5031bG
Use the scroll feature to move the desired
point to the center of the screen for looking at
a point on the map that is different from the
current position of the vehicle.
If the finger is continuously held on the
screen, the map will continue scrolling in that
direction until the finger is removed.
A street name, city name, etc. of the touched
point will be shown, depending on the scale
of the map (
2). Distance from the current
position to will also be shown (3).After the screen is scrolled, the map remains
centered at the selected location until another
function is activated. The current vehicle
position mark will continue to move along
your actual route and may move off the
screen. When the “MAP/VOICE” button is
pushed, the current vehicle position mark re-
turns to the center of the screen and the map
moves as the vehicle proceeds along the des-
ignated route.
INFORMATION
When the onetouch scroll feature is
used, the current vehicle position mark
may disappear from the screen. Move
the map with a onetouch scroll again or
push the “MAP/VOICE” button to return
to the current vehicle position map loca-
tion display.
To set the cursor position as a destina-
tion
A specific point on the map can be set as a
destination using the one−touch scroll func-
tion.
1U5006aG
Touch “Enter ”.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 43.)
If there is already a set destination, “Add to
” or “Replace ” are displayed.
“Add to
”: To add a destination.
“Replace
”: To delete the existing destina-
tions and set a new one.

10
To register the cursor position as a
memory point
Memory point registration enables easy ac-
cess to a specific point.
1U5006aG
Touch “Mark”.
When you touch “Mark”, the following screen
appears for a few seconds, and then the map
screen returns.
1U5007aG
The registered point is shown by on the
map.
To change the icon or name, etc., see “ —
Editing memory points” on page 71.
Up to 106 memory points can be registered.
If there is an attempt to register more than
106, a message appears for confirmation.
1U5008bG
To see information about the icon
where the cursor is set
1U5009G
To display information about an icon, set the
cursor on it.

11 POI INFORMATION
When the cursor is set on a POI icon, the
name and “Info.” are displayed on the top of
the screen.
1U5010G
Touch “Info.”.
1U5049aG
Information such as the name, address, and
phone number are displayed.
If “Enter
” is touched, the position of the
cursor is set as a destination.If there is already a set destination, “Add to
” and “Replace ” are displayed.
“Add to
”: To add a destination.
“Replace
”: To delete the existing destina-
tions and set a new one.
To register this POI as a memory point, touch
“Mark”. (See page 70.)
If
is touched, the registered tele-
phone number can be called.
INFORMATION
The desired Point of Interest can be
displayed on the map screen. (See “ —
Display POI icons” on page 58.)
MEMORY POINT INFORMATION
When the cursor is set on a memory point
icon, the name and “Info.” are displayed on
the top of the screen.
1U5012G
Touch “Info.”.
1U5050aG
Information such as the name, address, and
phone number are displayed.
If “Enter
” is touched, the position of the
cursor is set as a destination.

12 If there is already a set destination, “Add to
” and “Replace ” are displayed.
“Add to
”: To add a destination.
“Replace
”: To delete the existing destina-
tions and set a new one.
To edit a memory point, touch “Edit”. (See “
— Editing memory points” on page 71.)
To delete a memory point, touch “Delete”.
If
is touched, the registered tele-
phone number can be called.DESTINATION INFORMATION
When the cursor is set on a destination icon,
the name and “Info.” are displayed on the top
of the screen.1U5014G
Touch “Info.”.
1U5015aG
Information such as the name, address, and
phone number are displayed.
To delete a destination, touch “Delete”.
If
is touched, the registered tele-
phone number can be called.

13
— Switching the screens
Any one of the screen configurations can be
selected.
1U5032G
1. Touch this touchscreen button to dis-
play the following screen.
1U5033G
2. To select the desired screen configura-
tion, touch one of the following touch
screen buttons.Depending on the conditions, certain screen
configuration buttons cannot be selected.
:To display the single map screen.
(See page 13.)
:To display the dual map screen. (See
page 14.)
:To display the compass mode
screen. (See page 14.)
:To display the turn list screen. (See
page 50.)
:To display the arrow screen. (See
page 50.)
:To display the freeway information
screen. (See page 48.)
:To display the intersection guidance
screen or the guidance screen on the
freeway. (See page 49.)
Screen configurations
SINGLE MAP
This is a regular map screen.
While on a different screen, touching
will display the single map screen.
1U5004G
The screen shows the single map.

14 DUAL MAP
A map can be displayed split in two.
While on a different screen, touching
will display the dual map screen.
1U5034aG
The screen shows the dual map. The map on
the left is the main map.
The right side map can be edited by touching
any specific point on the right side map.
1U5035aG
This screen can perform the following proce-
dures:
1. Changing the map scale
2. Displaying the POI icon
3. Changing the orientation of the map
Touch “OK” when you complete editing.
The screen returns to the dual map screen.COMPASS MODE
Current vehicle position is indicated with a
compass, not with a map.
While on a different screen, touching
will display the compass mode screen.
1U5036aG
Information about the destination and current
position, as well as a compass, is displayed
on the screen.
The destination mark is displayed in the direc-
tion of the destination. When driving, refer to
the longitude and latitude coordinates and the
compass, to make sure that your vehicle is
headed in the direction of the destination.
INFORMATION
When the vehicle travels out of the cov-
erage area, the guidance screen
changes to the compass mode screen.

15
— Map scale
1U5018G
Touch or to change the scale of
the map display. The scale bar and indicator
at the bottom of the screen indicates the map
scale menu. The scale range is 150 feet (50
m) to 250 miles (400 km).
Touch
or until the scale bar
changes normally. By continuing to touch the
touch−screen button, the scale bar changes
smoothly.
The scale of the map display can be changed
by touching the scale bar directly. It is not
available while driving.
The map scale is displayed under the north−
up symbol or heading−up symbol at the top
left of the screen.
INFORMATION
When the map scale is at the maximum
range of 250 miles (400 km), is not
shown. When the map scale is at the
minimum range of 150 feet (50 m),
is not shown. However, in the area
where the foot print map is contained,
when the map scale is changed to 150
feet (50 m), changes to .
— Foot print map
For the area which is covered by the foot print
map (Some areas in the following cities; De-
troit, Chicago, N.Y., L.A), you can switch to
the foot print map on a scale of 75 feet (25 m).
To switch to the foot print map
changes into when the map is
scaled down to 150 feet (50 m).
1U5055G
To display the foot print map, touch .
To delete the foot print map display, touch
.

16
INFORMATION
If the map or the current position is
moved to the area which is not cov-
ered by the foot print map, the screen
scale automatically changes to 150
feet (50 m).
On the foot print map, a one way
street is displayed by .
It is not possible to perform scrolling
on the foot print map (onetouch
scroll) while driving.
To display building information
Information is available only for buildings for
which information is recorded on the map
disc.
1U5056G
1. Touch “Info.” while the foot print map
is displayed.
If the map is displayed by a split screen, the
map will change into a single map display.
1U5057G
2. Using an eightdirection arrow, move
the cursor to the position of the building to
display building information.
3. Touch “Building Info.”.

17
1U5058G
Details of POIs in some buildings may be dis-
played.
For detailed POI information, touch the build-
ing name. You can see details of the selected
POIs.
— Orientation of the map
1U5053G
Northup screen
1U5052G
Headingup screenThe orientation of the map can be changed
from North−up to Heading−up by touching the
orientation symbol at the top left of the screen.
Northup symbol
Regardless of the direction of vehicle travel,
North is always up.
Headingup symbol
The direction of vehicle travel is always up.
A red arrow indicates North.
