TOYOTA TUNDRA 2009 2.G Navigation Manual

OTHER FUNCTIONS
172

Changing a device name
You can change a device name. If you
change a device name, the name regis-
tered in your cellular phone is not
changed.
5U5176F
1. Touch “Change”.
5U5177F
2. Use the software keyboard to input
the device name.
Changing the Bluetooth settings
You can change the display and settings of
Bluetooth
 information on the system.
The information displays the following
items.
Device Name The name in the Bluetooth
 net-
. . .
work. You can change it.
Passkey The password when you register
. . .
your cellular phone in the system.
You can change it into the figure of
4− 8 digits.
Bluetooth
∗ Device Address
The address peculiar to the system.
. . .
You cannot change it. If you have
registered two Bluetooth
 phones
with the same Device Name or
Passkey and you cannot distin-
guish one from the other, refer to it.
∗: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.

OTHER FUNCTIONS
173
When you change the Device Name or
Passkey, do the followings.
5U5178F
1. Touch “Bluetooth∗”.
5U5179F
2. Touch “Change” of “Device Name”
or “Passkey”.
5U5180F
3. Use the software keyboard to input
the Device Name.
You can input up to 20 characters.
∗: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.
5U5181F
4. Input a Passkey with 4 8 digits.
When you touch  , the inputted number is
deleted.
5U5182F
5. When you complete the setting,
touch
.

OTHER FUNCTIONS
174

Initializing the Bluetooth settings.
You can initialize the settings.
5U5183F
1. Touch “Default”.
5U5184F
2. Touch “Yes”.
Deleting a Bluetooth phone
5U5185F
1. Touch “Delete” of “Bluetooth∗
Telephone”.
5U5186F
2. Select the telephone you want to de-
lete and touch “OK”.
5U5187F
3. Touch “Yes”.
∗: Bluetooth is a registered trademark of Bluetooth SIG. Inc.

OTHER FUNCTIONS
175

Displaying the information of the
Bluetooth phone you delete
You can display the information of the
Bluetooth
 phone before you delete it
and you can make sure whether the
telephone you delete is correct or not.
5U5188F
1. Select the telephone you want to
display the information about.
5U5A90F
2. When you complete confirming it,
touch
. The speech command system enables
you to operate the navigation system
and audio system by giving a com-
mand.
XS00407
1. Push the talk switch.
A beep sounds and on screen message is
displayed with
an indicator at the top left.
Speech command system

OTHER FUNCTIONS
176
5U5190F
2. Give a command while an indicator
is shown on the display. If you want to
check the command list, touch “Help”
to display the Help screen. (See “Help
screen” on page 178.) When you touch
“Cancel”, the previous screen returns.
If the navigation system does not respond
or the confirmation screen does not disap-
pear, please push the talk switch and try
again.
If no command is given, a beep sounds
and the indicator disappears 6 seconds
later.
If the system does not recognize your
speech, the system will respond with this
message (“System does not recognize
this command, please rephrase your
command.”). Start the operation from the
beginning.
XS00405
 Microphone (Type A)
XS00406
Microphone (Type B)
It is unnecessary to speak directly into
the microphone when giving a com-
mand.

OTHER FUNCTIONS
177
Speech command example: Searching
for a route to your home.
1. Push the talk switch.
2. Say “Home” .
You can also say the street name or ad-
dress.
∗ (ex. say “Woodridge Avenue” .)∗: “Hawaii” or Hawaii area is not covered
by the voice recognition.
If your home is not registered, you will hear
“Home is not registered”.
5U5191F
3. If the system recognized the com-
mand, the recognition result “Home” is
displayed on the top of the screen with
the screen message. (Displayed mes-
sage and the touchscreen buttons on
the screen depend on the situation.)
Touch or say “Cancel”, and the system will
be canceled. T ouch or say “Help”, and dis-
plays the “Help” screen.
5U5192F
4. Touch “Enter” or say “Enter
destination” , and the system starts
searching for a route to your home. (If
the destination is already registered,
“Add to
” or “Replace ” is
displayed on the screen.)
Touch or say “Cancel”, and the search will
be canceled.
When you search the destination by
“POI Name”, this screen is displayed.
5U5193F
Touch “Enter” or say “Enter destination” .

OTHER FUNCTIONS
178
When you touch “Show List”, you can
search another spot in its category.
INFORMATION
In the following conditions, the sys-
tem may not recognize the command
properly and using speech com-
mands may not be possible.
The command is not correct or
clear. Note that certain words, ac-
cents, or speech patterns may be
difficult for the system to recog-
nize.
There are some noises such as
wind noise, etc.
This system has a function which dis-
plays the voice recognition help
screen. You can see the command list
and operating guide on it.
(a) Command List
1. If the “Operating Guide” screen is
displayed, touch “Command List” on
the upper side of the screen.
5U5194F
2. Select the desired category by
touching the buttons on the right side of
the “Command List” screen.
3. You can scroll through the list of the
command list by touching “
” or
“
”.
Touch “OK” after you check it.
Help screen

OTHER FUNCTIONS
179
(b) Operating Guide
1. If the “Command List” screen is dis-
played, touch “Operating Guide” on the
upper side of the screen.
5U5195F
2. Select the desired category by
touching the buttons on the right side of
the “Operating Guide” screen.
3. You can scroll through the list of the
operating guide by touching “
” or
“
”.
Touch “OK” after you check it. The brightness or contrast of the
screen can be adjusted depending on
the brightness of your surroundings.
You can also turn the display off.
XS00408
1. To display the “Display” screen,
push the “DISP” button.
5U5196F
Contrast and brightness adjustment
2. Touch the desired button to adjust
contrast and brightness.
“Contrast” “+”:
Strengthens the contrast of the screen.
“Contrast” “”:
Weakens the contrast of the screen.
“Brightness” “+”:
Brightens the screen.
“Brightness” “”:
Darkens the screen.
3. After adjusting the screen, touch
“OK”.
Screen adjustment

OTHER FUNCTIONS
180
If your vehicle is equipped with the rear
seat entertainment system, the rear
screen turns on or off when “Rear” is
touched.
The screen goes off when “Screen Off” is
touched. To turn the display screen back
on, push any button such as “INFO”, etc.
The selected screen appears.
INFORMATION
When you do not touch any touch
screen button on the screen for 20
seconds the “Display” screen goes
off.
5U5197F
Color and tone adjustment (with rear
seat entertainment system)
1. Touch the desired button to adjust
color and tone.
You can adjust the color and the tone while
the DVD video and video CD are being
played.
“Color” “R”:
Strengthens the red color of the screen.
“Color” “G”:
Strengthens the green color of the screen.
“Tone” “+”: Strengthens the tone of the
screen.
“Tone” “”: Weakens the tone of the
screen.
2. After adjusting the screen, touch
“OK”.
The rear screen turns on or off when
“Rear” is touched.
The screen turns off when “Screen Off” is
touched. To turn the screen back on, push
any button such as “INFO” , etc. The se-
lected screen appears.
INFORMATION
When you do not touch any touch
screen button on the screen for 20
seconds the “Display” screen goes
off.

OTHER FUNCTIONS
181
5U5198F
Depending on the position of the head-
light switch, the screen changes to ei-
ther day mode or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “Day
Mode” on the adjustment screen for
brightness and contrast control.
If the screen is set in the day mode with the
headlight switch turned on, this condition is
memorized in the system even with the en-
gine turned off.
XS00403
1. Push the “INFO” button to display
the “Information” screen.
5U5199aF
2. Touch “Screen Setting”.
Screen setting
