TOYOTA VENZA 2010 Owners Manual (in English)

631
6-1. Specifications
6
Vehicle specifications
VENZA_U (OM73007U)
Tire related termMeaning
Passenger car tire A tire intended for use on passenger cars, mul-
tipurpose passenger vehicles, and trucks, that
have a gross vehicle weight rating (GVWR) of
10,000 lb. or less
Ply A layer of rubber-coated parallel cords
Ply separation A parting of rubber compound between adja-
cent plies
Pneumatic tire A mechanical device made of rubber, chemi-
cals, fabric and steel or
other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load
Radial ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread
Reinforced tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Section width The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
Sidewall That portion of a tire between the tread and
bead
Sidewall separation The parting of the rubber compound from the
cord material in the sidewall

632 6-1. Specifications
VENZA_U (OM73007U)
Tire related termMeaning
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing

633
6-1. Specifications
6
Vehicle specifications
VENZA_U (OM73007U)
*:Table 1  Occupant loading and distri
bution for vehicle normal load
for various designated seating capacities
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehicle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

634
VENZA_U (OM73007U)
6-2. Customization
Customizable features
Customizable features
ItemFunctionDefault settingCustomizedsetting
Wireless
remote
control
( P. 43) Wireless remote control ON OFF
Unlocking operation
*
Driver’s door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in one step
Automatic door locking
function (if a door is not
opened after being
unlocked)
*
ON OFF
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked
*
60 seconds 30 seconds
120 seconds
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences. Programming these preferences
requires specialized equipment and may be performed by an autho-
rized Toyota dealership.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.
Vehicles with TFT type multi-information display
Some function settings can be changed by operating the multi-
information display.

635
6-2. Customization
6
Vehicle specifications
VENZA_U (OM73007U)
ItemFunctionDefault settingCustomized
setting
Wireless
remote
control
( P. 43) Operation signal
(Emergency flashers)
*ON
OFF
Operation signal
(Buzzer) ON
OFF
Operation signal
(Buzzer volume) Level 7Level 1 to 6
OFF
Open door warning
function
(when locking the vehi-
cle) ON
OFF
Panic function ONOFF
Door lock
( P. 48) Unlocking using a key
Driver’s door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in one step
Speed-detecting auto-
matic door lock func-
tion
*
OFF ON
Shifting the shift lever to
position other than “P”
locks all doors
*
ON OFF
Shifting the shift lever to
“P” unlocks all doors
*ON OFF
Opening driver’s door
unlocks all doors
*OFF ON

636 6-2. Customization
VENZA_U (OM73007U)
ItemFunctionDefault settingCustomizedsetting
Smart key
system
( P. 28) Smart key system ON OFF
Operation signal
(Emergency flashers)
ON OFF
Operation signal
(Buzzer) ON OFF
Automatic
light control
system
( P. 196) Light sensor sensitivity Level 3 Level 1 to 5
Daytime running light
system (U.S.A. only)
ON
OFF
Automatic High Beam
(if equipped)
*ON OFF
Time elapsed before
headlights automati-
cally turn off after doors
are closed
*
30 seconds 0 seconds
60 seconds
90 seconds
Alarm
system
( P. 99) Time elapsed before
the alarm is set
14 seconds 30 seconds
Multi-
information
display
( P. 178) Language selection
*English
French
Spanish

637
6-2. Customization
6
Vehicle specifications
VENZA_U (OM73007U)
*: For vehicles with TFT type multi-information display, the setting can be
changed by operating the multi-information display. ( P. 638)
ItemFunctionDefault settingCustomized
setting
Illumination
( P. 387) Time period before
lights turn off
*15 seconds
7.5 seconds
30 seconds
Vehicles with smart key
system: Operation after
the “ENGINE START
STOP” switch is turned
off
Vehicles without smart
key system: Operation
after the engine switch
is turned to the “LOCK”
position ON OFF
Operation when the
doors are unlocked ON OFF
Operation when you
approach the vehicle
with the electronic key
on your person (When
the personal/interior
light main switch is door
position.) (vehicles with
smart key system) ON OFF
Seat belt
reminder
( P. 557) Vehicle speed linked
seat belt reminder
buzzer
ON
OFF

638 6-2. Customization
VENZA_U (OM73007U)
Customizing the features by using the multi-information display
(vehicles with TFT type mu lti-information display)
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 10
seconds, the display will revert to
the previous screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, and press
the “SELECT RESET” button.
If you select “Exit” and press the
“SELECT RESET” button, the
display will revert to the previous
screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, and press
the “SELECT RESET” button.
The illustration assumes that
“Door” was chosen in .
The current setting is indicated by
yellow text.
If you select “Return” and press
the “SELECT RESET” button, the
display will revert to the “Custom
Settings” screen.
STEP1
STEP2
STEP3
STEP2

639
6-2. Customization
6
Vehicle specifications
VENZA_U (OM73007U)
Choose a desired setting by
pressing the “INFO” or “SETUP”
button, and press the “SELECT
RESET” button.
If any settings are changed, the
display will revert to the previous
screen.
The illustration assumes that
“Auto Locking” was chosen in
.
The current setting is indicated by
yellow text.
If you select “Return” and press
the “SELECT RESET” button, the
display will revert to the previous
screen.
■ Restoring default settings
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 10
seconds, the display will revert to
the previous screen.
STEP4
STEP3
STEP1

640 6-2. Customization
VENZA_U (OM73007U)Select “Default Settings” by
pressing the “INFO” or “SETUP”
button, and press the “SELECT
RESET” button.
If you select “Exit” and press the
“SELECT RESET” button, the
display will revert to the previous
screen.
Select “Yes” by pressing the
“INFO” or “SETUP” button, and
press the “SELECT RESET” but-
ton.
“Default Settings Restored” is dis-
played, and the default settings
are restored.
If you select “No” and press the
“SELECT RESET” button, the
display will revert to the “Custom
Settings” screen without restor-
ing the default settings.
STEP2
STEP3
■
If the vehicle is moved while setti ngs are being changed on the multi-
information display
 P. 190
