VENZA_U (OM73013U)
3-6. Using the interior lightsInterior lights list .................. 446
• Personal/interior light main switch ....................... 447
• Personal/interior lights ...... 448
• Luggage compartment light ................................... 448
3-7. Using the storage features List of storage features ....... 450
• Glove box.......................... 451
• Console boxes .................. 452
• Overhead console............. 454
• Cup holders ...................... 455
• Bottle holders .................... 457
• Auxiliary boxes.................. 458
3-8. Other interior features Sun visors ........................... 461
Vanity mirror........................ 462
Power outlets ...................... 463
Seat heaters........................ 466
Armrest ............................... 468
Floor mats ........................... 469
Luggage compartment features ............................. 471
Garage door opener............ 473
Compass ............................. 480 4-1. Maintenance and care
Cleaning and protecting the vehicle exterior ........... 486
Cleaning and protecting the vehicle interior ............ 489
4-2. Maintenance Maintenance requirements .................... 492
General maintenance ......... 495
Emission inspection and maintenance (I/M)
programs .......................... 498
4-3. Do-it-yourself maintenance Do-it-yourself service precautions....................... 499
Hood ................................... 503
Positioning a floor jack ....... 505
Engine compartment .......... 507
Tires ................................... 522
Tire inflation pressure ......... 529
Wheels ............................... 533
Air conditioning filter ........... 536
Key battery ......................... 539
Checking and replacing fuses................................. 543
Light bulbs .......................... 553
4Maintenance and care

TABLE OF CONTENTSIndex
6
VENZA_U (OM73013U)
5-1. Essential informationEmergency flashers ........... 568
If your vehicle needs to be towed .......................... 569
If you think something is wrong ............................ 573
If noise can be heard from under vehicle .................... 574
Fuel pump shut off system .............................. 575
5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer
sounds... ......................... 576
If a warning message is displayed .......................... 590
If you have a flat tire ........... 591
If the engine will not start .................................. 602
If the shift lever cannot be shifted from “P”................. 605
If you lose your keys .......... 606
If the electronic key does not operate properly
(vehicles with smart key
system) ............................ 607
If the battery is discharged ....................... 610
If your vehicle overheats .... 615
If the vehicle becomes stuck................................. 618
If your vehicle has to be stopped in an
emergency ....................... 620 6-1. Specifications
Maintenance data (fuel, oil level, etc.) ........... 624
Fuel information .................. 638
Tire information................... 642
6-2. Customization Customizable features ........ 657
6-3. Initialization Items to initialize ................. 664
Reporting safety defects for U.S. owners ................. 666
Seat belt instructions for Canadian owners
(in French) ........................ 667
SRS airbag instructions for Canadian owners
(in French) ........................ 669
5When trouble arises6Vehicle specifications
7For owners

29
1-1. Key information
1
Before driving
VENZA_U (OM73013U)
Using the mechanical key (vehicles with smart key system)
Take out the mechanical key.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery depletes or entry
function does not operate prop-
erly, you will need the mechanical
key. (P. 607)
■Key number plate
Keep the plate in a safe place such as your wallet, not in the vehicle. In the
event that a key is lost, a new key can be made at your Toyota dealer using
the key number plate. ( P. 606)
■ When riding in an aircraft
When bringing a key onto an aircraft, make sure you do not press any but-
tons on the key while inside the aircraft cabin. If you are carrying a key in
your bag etc., ensure that the buttons are not likely to be pressed acciden-
tally. Pressing a button may cause the key to emit radio waves that could
interfere with the operation of the aircraft.
NOTICE
■To prevent key damage
● Do not subject the keys to strong shocks, expose them to high tempera-
tures by placing them in direct sunlight, or get them wet.
● Do not expose the keys to electromagnetic materials or attach any mate-
rial that blocks electromagnetic waves to the key surface.
● Do not disassemble the key.

35
1-2. Opening, closing and locking the doors
1
Before driving
VENZA_U (OM73013U)
■
Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
■ When the door cannot be locked using the topside sensor area
■ Conditions aff ecting operation
The smart key system uses weak radio waves. In the following situations,
the communication between the electronic key and the vehicle may be
affected, preventing the smart key system and wireless remote control from
operating properly. (Way of coping P. 607)
● When the electronic key battery is depleted
● Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electri-
cal noise
● When carrying a portable radio, ce llular phone, cordless phone or other
wireless communication devices
● When the electronic key has come into contact with, or is covered by a
metallic object
● When multiple electronic keys are in the vicinity
● When carrying or using the electronic key together with the following
devices that emit radio waves
• Another vehicle’s electronic key
• A wireless key that emits radio waves
• Personal computer
● If window tint with a metallic content or metallic objects are attached to
the rear window
If the door will not lock even when the
topside sensor area is touched, try touch-
ing both the topside and underside sen-
sor areas at the same time.

37
1-2. Opening, closing and locking the doors
1
Before driving
VENZA_U (OM73013U)
■
Battery-saving function
In the following circumstances, the entry function is disabled in order to pre-
vent the vehicle and electronic key batteries from discharging.
● When the entry function has not been used for 2 weeks or more
● When the electronic key has been left within approximately 3 ft. (1 m) of
the vehicle for 10 minutes or more
The system will resume operation when...
● The vehicle is locked using the door handle lock switch.
● The vehicle is locked/unlocked using the wireless remote control function
(P. 45) or the mechanical key. ( P. 607)
■ Electronic key battery depletion
● The standard battery life is 1 to 2 years. (The battery becomes depleted
even if the electronic key is not used.) If the smart key system or the
wireless remote control function does not operate, or the detection area
becomes smaller, the battery may be depleted. Replace the battery when
necessary. ( P. 539)
● If the battery becomes low, an alarm will sound in the cabin when the
engine stops. ( P. 40)
● To avoid serious deterioration, do not leave the electronic key within 3 ft.
(1 m) of the following electrical appliances that produce a magnetic field.
•TVs
• Personal computers
• Recharging cellular phones or cordless phones
• Table lamps

42 1-2. Opening, closing and locking the doors
VENZA_U (OM73013U)
*1: A message will be shown on the multi-information display in the instru-ment cluster.
*2: If the engine does not start when the electronic key is inside the vehicle,the electronic key battery may be depleted or there may be difficulties
receiving signal from the key. ( P. 607)
AlarmSituationCorrection procedure
Interior alarm
pings once
*1
The electronic key has a
low battery Replace the electronic
key battery
An attempt was made to
start the engine without the
electronic key being
present, or the electronic
key was not functioning
normally Start the engine with
the electronic key
present
*2
Interior alarm
pings once and
exterior alarm
sounds 3 times
*1
The driver’s door was
closed after the key was
carried outside the vehicle,
and the “ENGINE START
STOP” switch was not
turned OFFTurn the “ENGINE
START STOP” switch
OFF and close the
driver’s door again
An occupant carried the
electronic key outside the
vehicle and closed the
door while the “ENGINE
START STOP” switch was
not OFF Bring the electronic
key back into the vehi-
cle

43
1-2. Opening, closing and locking the doors
1
Before driving
VENZA_U (OM73013U)
■
If the smart key system does not operate properly
● Locking and unlocking the doors: Use the mechanical key. ( P. 607)
● Starting the engine ( P. 161)
■ When the electronic key battery is fully depleted
 P. 539
■ Customization that can be configured at Toyota dealer or by the TFT
type multi-information display
Settings (e.g. smart key system) can be changed.
(Customizable features P. 657)
■ Certification for the smart key system
For vehicles sold in the U.S.A.
FCC ID: HYQ14ACX FCC ID: HYQ14ADF
FCC ID: HYQ13CZD FCC ID: HYQ13CZE
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsi-
ble for compliance could void the user’s authority to operate the equip-
ment.

47
1-2. Opening, closing and locking the doors
1
Before driving
VENZA_U (OM73013U)
■
Door lock buzzer
If a door or back door is not fully closed, a buzzer sounds continuously for 10
seconds if an attempt to lock the door is made. Fully close the door to stop
the buzzer, and lock the vehicle once more.
■ Security feature
 P. 4 0
■ Alarm
Using the wireless remote control to lock the door will set the alarm system.
(P. 102)
■ Key battery depletion
Vehicles with smart key system
P. 539
Vehicles without smart key system
The standard battery life is 1 to 2 years. (The battery becomes depleted
even if the key is not used.) If the wireless remote control function does
not operate, the battery may be depleted. Replace the battery when nec-
essary. ( P. 539)
■ If the wireless remote cont rol does not operate properly
Vehicles with smart key system
● Locking and unlocking the doors: Use the mechanical key. ( P. 607)
● Starting the engine ( P. 161)
Vehicles without smart key system
Locking and unlocking the doors: Use the key. ( P. 50)

63
1-2. Opening, closing and locking the doors
1
Before driving
VENZA_U (OM73013U)
CAUTION
■
Power back door (if equipped)
Observe the following precautions when operating the power back door.
Failure to do so may cause death or serious injury.
● Check the safety of the surrounding area to make sure there are no obsta-
cles or anything that could cause any of your belongings to get caught.
● If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.
● On an incline, the back door may fall after it opens. Make sure the back
door is fully open and secure.
● In the following situations, the power back door may detect an abnormali\
ty
and automatic operation may be stopped. In this case, the back door has
to be operated manually. Take extra care when on an incline, as the back
door may open or close abruptly.
• When the back door contacts an obstacle
• Vehicles with smart key system:
When the battery voltage suddenly drops, such as when the “ENGINE
START STOP” switch is turned to IGNITION ON mode or the engine is
started during automatic operation
Vehicles without smart key system:
When the battery voltage suddenly drops, such as when the engine
switch is turned to the “ON” position or the engine is started during
automatic operation
● If a bicycle carrier or similar heavy object is attached to the back door, the
power back door may not operate, causing itself to malfunction, or the
back door may fall closed again after being opened, causing someone’s
hands, head or neck to be caught and injured. When installing an acces-
sory part to the back door, using a genuine Toyota part is recommended.

102
1-6. Theft deterrent system
VENZA_U (OM73013U)
Alarm
: If equipped
The system sounds the alarm and flashes lights when forcible entry
is detected.
■ Triggering of the alarm
The alarm is triggered in the fo llowing situations when the alarm
is set.
● A locked door is unlocked or o pened in any way other than by
using the entry function (vehicles with smart key system), the
wireless remote control door lo ck function or the mechanical
key. (The doors will lock again automatically.)
● The hood is opened.
● The battery is reconnected.
● The side windows are tapped or broken.
■ Setting the alarm system
Close the doors and hood,
and lock all doors using the
entry function (vehicles with
smart key system) or the wire-
less remote control. The sys-
tem will be set automatically
after 30 seconds.
The indicator light changes
from being on to flashing when
the system is set.
