TOYOTA VENZA 2015 Owners Manual (in English)

381
3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
3
Interior features
Status display
You can check indicators such as signal strength and battery charge
on the phone screen.
Connection status
Signal strength
Battery charge
IndicatorsConditions
Connection status
Good Poor Not connected
(Blue) (Gray)
Battery chargeFullEmpty
Signal strengthExcellent Poor

382
3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
Making a call
DialingDisplay the phone screen. ( P. 379)
Select the “Dial Pad” tab and enter a phone number.
To delete the input phone number, select .
For the first digit, you can enter “+” by selecting “ ” for a while.
Press the switch on the steering wheel or select .
Dialing from the contacts list
You can dial a number from the c ontact data imported from your cel-
lular phone. The system has one contact for each registered phone.
Up to 2500 contacts may be stored in each contact.
Display the phone screen. ( P. 379)
Select “Contacts” tab.
Choose the desired contact to call from the list.
Choose the number and then press the switch on the
steering wheel or select .
When the contact is empty
You can transfer the phone numbers in a Bluetooth
® phone to the
system.
Operation methods differ between PBAP (Phone Book Access Pro-
file) compatible and PBA P incompatible Bluetooth
® phones. If the
cellular phone does not support either PBAP or OPP (Object Push
Profile) service, you ca nnot transfer contacts.
Once a Bluetooth® phone is registered, you can make a call using
the following procedure:
STEP1
STEP2
STEP3
STEP1
STEP2
STEP3
STEP4

383
3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
3
Interior features
■
For PBAP compatible Bluetooth® phones
When “Automatic Contact/History Transfer” is set to off Select the desired item.
Select to transfer new con-
tacts from a cellular phone,
select “Always” and then
enable “Automatic Contact/
History Transfer”.
Select to transfer all the con-
tacts from a connected cellular
phone only once.
Select to cancel transferring.
■ For PBAP incompatible but OPP compatible Bluetooth
®
phones
Select the desired item.
Select to transfer the contacts
from the connected cellular
phone.
Select to add a new contact
manually.
Select to cancel transferring.
When “Transfer” is selected Follow the steps in “Update contacts from phone” from . ( P. 402)
When “Add” is selected Follow the steps in “Registering a new contact to the contacts
list” from . ( P. 403)
STEP1
STEP1
STEP2
STEP2
STEP2
STEP2

384 3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
Calling using favorites list
You can make a call using numbers registered in the contact. Display the phone screen. ( P. 379)
Select “Favorites” tab.
Select the desired number to make a call.
Dialing from call history
You can make a call using the call history, which has the 3 functions
below. : calls which you missed
: calls which you received
: calls which you made Display the phone screen. ( P. 379)
Select “Call History” tab.
Select or the desired entry from the list.
When is selected Check that the “Call” screen is displayed.
When the desired contact is selected
Select the desired number.
Check that the “Call” screen is displayed.
STEP1
STEP2
STEP3
STEP1
STEP2
STEP3
STEP4
STEP4
STEP5

385
3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
3
Interior features
■
Call history list
●If you make a call to or receive a call from a number registered in the
contact, the name is displayed in the call history.
● If you make multiple calls to the same number, only the last call made is
displayed in the call history.
■ International calls
You may not be able to make international calls, depending on the mobile
phone in use.

386
3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
Receiving a call
To answer the phonePress the switch on the
steering wheel or select .
To refuse a callPress the switch on the steering wheel or select .
To adjust the incoming call volumeTurn the “PWR VOL” knob. You can also adjust the volume using the
steering switches.
When a call is received, the follo wing screen is displayed together
with a sound.
■ International calls
Received international calls may not be displayed correctly depending on
the cellular phone in use.

387
3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
3
Interior features
Speaking on the phone
To adjust the call volumeSelect “-” or “+”. You can also adjust the volume using the steering
switches or the volume knob.
To prevent the other party from hearing your voiceSelect “Mute”.
Inputting tonesWhen using phone services such as an answering service or a bank,
you can store phone numbers and code numbers in the contact. Select “0-9”.
Input the number.
■ Release Tones
“Release Tones” appear when a cont inuous tone signal(s) contain-
ing a (w) is registered in the contact list.
Select “Release Tones”.
The following screen is displayed when speaking on the phone.
STEP1
STEP2
STEP1

388 3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
■Release Tones
●A continuous tone signal is a character string that consists of numbers
and the characters p or w. (e.g.056133w0123p#1 )
● When the “p” pause tone is used, the tone data up until the next pause
tone will be automatically sent after 2 seconds have elapsed. When the
“w” pause tone is used, the tone data up until the next pause tone will be
automatically sent after a user operation is performed.
● Release tones can be used when automated operation of a phone based
service such as an answering machine or bank phone service is desired.
A phone number with continuous tone signals can be registered in the
contact list.
● Tone data after a “w” pause tone can be operated on voice command
during a call.

389
3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
3
Interior features
To transfer a call
Select “Handset Mode” to on from a hands-free call to a cellular
phone call.
Select “Handset Mode” to off from a cellular phone call to a hands-
free call.
Transmit volume setting Select “Transmit Volume”.
Select the desired level for the transmit volume.
Select “OK”.
To hang upPress the switch on the steering wheel or select .
Call waitingWhen a call is interrupted by a third party while talking, an incoming
call message will be displayed. To talk with the other party:
• Press the switch on thesteering wheel.
•Select .
To refuse the call:
• Press the switch on the steering wheel.
•Select .
Every time you press the switch on the steering wheel or select during call waiting, you will be switched to the other party.
STEP1
STEP2
STEP3

390 3-2. Using the audio system (Entune Audio)
VENZA_OM_OM73023U_(U)
■Transferring calls
●If you transfer from the cellular phone to hands-free, the hands-free
screen will be displayed, and you can operate the system using the
screen.
● Transfer method and operation may vary according to the cellular phone
used.
● For operation of the cellular phone in use, see the phone’s manual.
■ Call waiting operation
Call waiting operation may differ depending on your phone company and
cellular phone.
