TOYOTA VENZA 2016 Owners Manual

6416-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Tire related term Meaning
Intended outboard
sidewall (a)The sidewall that cont ains a whitewall, bears
white lettering, or bears manufacturer, brand,
and/or model name molding that is higher or
deeper than the same molding on the other
sidewall of the tire, or
(b)The outward facing sidewall of asymmetrical
tire that has a particular side that must always
face outward when mounted on a vehicle
Light truck (LT) tire A tire designated by its manufacturer as prima-
rily intended for use on lightweight trucks or
multipurpose passenger vehicles
Load rating The maximum load that a tire is rated to carry
for a given inflation pressure
Maximum load rating The load rating for a tire at the maximum per-
missible inflation pressure for that tire
Maximum permissible
inflation pressure The maximum cold inflation pressure to which
a tire may be inflated
Measuring rim The rim on which a tire is fitted for physical
dimension requirements
Open splice Any parting at any junction of tread, sidewall, or
innerliner that extends to cord material
Outer diameter The overall diameter of an inflated new tire
Overall width The linear distance between the exteriors of
the sidewalls of an inflated tire, including eleva-
tions due to labeling, decorations, or protective
bands or ribs

6426-1. Specifications
VENZA_OM_OM73030U_(U) Tire related term Meaning
Passenger car tire A tire intended for use on passenger cars, mul-
tipurpose passenger vehicles, and trucks, that
have a gross vehicle weight rating (GVWR) of
10,000 lb. or less.
Ply A layer of rubber-coated parallel cords
Ply separation A parting of rubber compound between adja-
cent plies
Pneumatic tire A mechanical device made of rubber, chemi-
cals, fabric and steel or other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load
Radial ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread
Reinforced tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Section width The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
Sidewall That portion of a tire between the tread and
bead
Sidewall separation The parting of the rubber compound from the
cord material in the sidewall

6436-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Tire related term Meaning
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely during testing

6446-1. Specifications
VENZA_OM_OM73030U_(U) * :Table 1  Occupant loading and distri bution for vehicle normal load
for various designated seating capacities Designated seating
capacity, Number of
occupants Vehicle normal load,
Number of occupants Occupant distribution in
a normally loaded
vehicle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

645 6
Vehicle specifications
VENZA_OM_OM73030U_(U) 6-2. Customization
Customizable features
Customizable features
Vehicles with TFT type multi-info rmation display: Some function
settings can be changed by opera ting the multi-information display.
(  P. 652)
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available,  = Not availableYour vehicle includes a variety of electronic features that can be
personalized to your preferen ces. Programming these preferences
requires specialized equipment and may be performed by your
Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

6466-2. Customization
VENZA_OM_OM73030U_(U) Item Function Default
setting Customized
setting
Smart key
system
(  P. 30) Smart key system ON OFF — O
Select doors to
unlock Driver’s
door All doors — O
Wireless
remote control
(  P. 45) Wireless remote
control ON OFF — O
Unlocking operation Driver’s
door
unlocked in
one step,
all doors
unlocked in
two step All doors
unlocked in
one step OO
Open door warning
function (when
locking the vehicle) ON OFF — O
Panic function ON OFF — O

6476-2. Customization
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Item Function Default
setting Customized
setting
Smart key
system
(  P. 30)
and wireless
remote control
(  P. 45) Operation signal
(Emergency
flashers) ON OFF O O
Operation signal
(Buzzer) Level 7 Level 1 to 6
—O
OFF
Time elapsed before
automatic door lock
function is activated
if door is not opened
after being unlocked 60 seconds OFF
OO30 seconds
120
seconds
Power easy
access system
(  P. 75) Driver’s seat
movement when
exiting the vehicle ON OFF — O

6486-2. Customization
VENZA_OM_OM73030U_(U) Item Function Default
setting Customized
setting
Door lock
(  P. 50) Unlocking using
a key Driver’s
door
unlocked in
one step, all
doors
unlocked in
two step All doors
unlocked in
one step —O
Speed-detecting
automatic door lock
function OFF ON O O
Shifting the shift
lever to position
other than “P” locks
all doors ON OFF O O
Shifting the shift
lever to “P” unlocks
all doors ON OFF O O
Opening driver’s
door unlocks all
doors OFF ON O O

6496-2. Customization
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Item Function Default
setting Customized
setting
Automatic light
control system
(  P. 212) Light sensor
sensitivity Level 3 Level 1 to 5 — O
Daytime running light
system (U.S.A. only) ON OFF — O
Automatic
High Beam
(if equipped) ON OFF O O
Time elapsed before
headlights
automatically turn off
after doors are
closed 30 seconds 0 seconds
OO60 seconds
90 seconds
Alarm system
(  P. 1 1 2 ) Time elapsed before
the alarm is set 14 seconds 30 seconds — O
Multi-
information
display
(TFT type only:
 P. 194) Language selection English French
OO
Spanish

6506-2. Customization
VENZA_OM_OM73030U_(U) Item Function Default
setting Customized
setting
Illumination
(  P. 430) Time period before
lights turn off 15 seconds 7.5 seconds
OO
30 seconds
Vehicles with smart
key system:
Operation after the
“ENGINE START
STOP” switch is
turned off
Vehicles without
smart key system:
Operation after the
engine switch is
turned to the “LOCK”
position ON OFF — O
Operation when the
doors are unlocked ON OFF — O
Operation when you
approach the
vehicle with the
electronic key on
your person (When
the personal/interior
light main switch is
door position.)
(vehicles with smart
key system) ON OFF — O
