1212-1. Instrument cluster
2
Vehicle status information and indicators
• Compass (heading-up display) (if equipped)
• Audio system operation status
*: Make sure to enable this display when using the driving support
systems
 Display angle
Select to adjust the angle of the
head-up display.
■Enabling/disabling of the head-
up display
If the head-up display is disabled, it
will remain disabled when the power
switch is turned off then back to ON.
■Display brightness
The brightness of the head-up dis-
play can be adjusted on the
screen of the mult i-information dis-
play. Also, it is automatically
adjusted according to the ambient
brightness.
■Head-up display automatic
position adjustment
If the display position is recorded
into memory, the head-up display
will be automatically adjusted to the
desired position. ( P.159)
■When the 12-volt battery is dis-
connected
The customize settings of the head-
up display will be reset.
Displays the operational status
of the following systems:
 LTA (Lane Tracing Assist)
( P.244)
 Dynamic radar cruise control
with full-speed range
( P.257)
Details of content d isplayed on the
head-up display may differ from
that displayed on the multi-informa-
tion display. For details, refer to the
explanation of each system.
Pop-up displays for the following
WARNING
■Caution for changing settings
of the head-up display
As the hybrid system needs to be
operating while changing the set-
tings of the head-up display,
ensure that the vehicle is parked
in a place with adequate ventila-
tion. In a closed area such as a
garage, exhaust gases including
harmful carbon monoxide (CO)
may collect and enter the vehicle.
This may lead to death or a seri-
ous health hazard.
NOTICE
■When changing the settings
of the head-up display
To prevent 12-vo lt battery dis-
charge, ensure that the hybrid
system is operating while chang-
ing the settings of the head-up
display.
Driving support system
display area
Pop-up display

1222-1. Instrument cluster
systems will be displayed when
necessary.
■Driving support systems
Displays a warning/sugges-
tion/advice message or the
operating state of a relevant
system.
 PCS (Pre-Collision System)
( P.236)
 Parking Support Brake func-
tion (static objects) (if
equipped) ( P.286)
 Brake Override System
( P.185)
 Drive-Start Control (DSC)
( P.190)
 LTA (Lane Tracing Assist)
( P.244)
 Dynamic radar cruise control
with full-speed range
( P.257)
Details of content displayed on the
head-up display may differ from
that displayed on the multi-informa-
tion display. For details, refer to the
explanation of each system.
■ / icons
Displays the following multi-
information display linked icons:
: Master warning icon
Displayed when a warning mes-
sage is displayed on the multi-infor-
mation display.
: Information icon
Displayed when a suggestion /
advice pop-up display is displayed on the multi-information display.
■Warning message
Some warning messages are
displayed when necessary,
according to certain conditions.
Details of content d isplayed on the
head-up display may differ from
that displayed on the multi-informa-
tion display.
■Audio system operation
status
Displayed when an audio
remote control switch on the
steering wheel is operated.
■Hands-free system status
Displayed when the hands-free
system is operated.
■When a pop-up display is dis-
played
When a pop-up display is displayed,
a current display may no longer be
displayed. In this case, the display
will return afte r the pop-up display
disappears.
■Hybrid System Indicator
Hybrid System Indica-
tor/tachometer/Outside
temperature area

1232-1. Instrument cluster
2
Vehicle status information and indicators
Charge area
Hybrid Eco area
Eco area
Power area
Displayed content is the same as
that displayed on the meter (Hybrid
System Indicator).
For details, refer to P.94.
■Tachometer
Displays the engine speed in
revolutions per minute.
■Outside temperature dis-
play
This is displayed when the
power switch is turned on or the
low temperature indicator
flashes.
■Outside temperature display
●When the ambient temperature is
approximately 37°F (3°C) or
lower, the low outside temperature
indicator will flash for approxi-
mately 10 seconds and the out-
side temperature display will turn
off. In this case, the display will be
displayed again when the outside
temperature becomes approxi-
mately 41°F (5°C) or higher.
●In the following si tuations, the cor-
rect outside tempe rature may not
be displayed, or the display may
take longer than normal to
change:
• When stopped, or driving at low speeds (less than 12 mph [20
km/h])
• When the outside temperature has changed su ddenly (at the
entrance/exit of a garage, tunnel,
etc.)
●When “--” or “E” is displayed, the
system may be malfunctioning. Take your vehicle to your Toyota
dealer.
A
B
C
D

1242-1. Instrument cluster
Vehicles with 8-inch displayMulti-information display
“MENU” button
Multimedia system screen
Meter control switches
( P.97)
Vehicles with 12.3-inch dis-
play
Multi-information display
Navigation system screen
Meter control switches
( P.107)
The energy monitor can be used
to check the vehicle drive status,
hybrid system operation status
and energy regeneration status.
■Display procedure
Multi-information display
(vehicles with 4.2-inch dis-
play)
Press or of the meter
control switches on the steering
wheel and select , and
then press or to select
the energy monitor display.
Multi-information display
(vehicles with 7-inch display)
Press or of the meter
control switches on the steering
Energy monitor/con-
sumption screen
The state of the hybrid sys-
tem can be viewed on the
multi-information display
and Multimedia system
screen (vehicles with 8-inch
display) or navigation sys-
tem screen (vehicles with
12.3-inch display).
The energy monitor and fuel
consumption screen can be
displayed on the “Home”
screen of the multimedia
display (vehicles with 8-inch
display only).
System components
A
B
C
D
(QHUJ\PRQLWR\
U
A
B
C

1252-1. Instrument cluster
2
Vehicle status information and indicators
wheel and select , and
then press or to select
the energy monitor display.
Multimedia system screen
(vehicles with 8-inch display)
1 Press the “MENU” button.
2 Select “Info” on the “Menu”
screen.
3 Select “ECO” on the “Info”
screen.
If a screen other than “Energy Mon-
itor” is displayed, select “Energy”.
Navigation system screen
(vehicles with 12.3-inch dis-
play)
1 Select on the Toyota
multi-operation touch
( P.344).
2 Select “Energy” on the split-
screen.
Displaying a screen in full
screen(P.345)
■Reading the display
The arrows will appear in accor-
dance with the energy flow.
When there is no energy flow,
arrows will not be displayed.
The color of the arrows will change as follows.
Green: When the hybrid battery
(traction battery) is regenerated or
charged.
Yellow: When the
hybrid battery
(traction battery) is in use.
Red: When the gasoline engine is
in use.
Multi-information display
The image shows all the arrows as
an example. The ac tual display will
vary depending on conditions.
Gasoline engine
Hybrid battery (traction bat-
tery)
Front tires
Rear tires
Multimedia system screen
(vehicles with 8-inch display)
The image shows all the arrows as
an example. The ac tual display will
A
B
C
D

1262-1. Instrument cluster
vary depending on conditions.
Gasoline engine
Front electric motor (traction
motor)
Rear electric motor (traction
motor)
Hybrid battery (traction bat-
tery)
Front tires
Rear tires
Navigation system screen
(vehicles with 12.3-inch dis-
play) (when displayed full
screen)
The image shows all the arrows as
an example. The actual display will
vary depending on conditions.
Gasoline engine
Front electric motor (traction
motor)
Rear electric motor (traction
motor)
Hybrid battery (traction bat-
tery)
Front tires
Rear tires
Navigation system screen
(vehicles with 12.3-inch dis-
play) (when displayed split-
screen)
The image shows all the arrows as
an example. The actual display will
vary depending on conditions.
Gasoline engine
Hybrid battery (traction bat-
tery)
Tire
Multimedia system screen
(vehicles with 8-inch display)
(“Home” screen)
Gasoline engine
Hybrid battery (traction bat-
tery)
Tire
A
B
C
D
E
F
A
B
C
D
E
F
A
B
C
A
B
C

1272-1. Instrument cluster
2
Vehicle status information and indicators
■Hybrid battery (traction battery)
status
The display changes in 8 levels
according to the remaining charge
amount of the hybrid battery (trac-
tion battery).
• The figure shows the multi-infor- mation display as an example for
explanation.
• These images are examples only, and may vary slight ly from actual
conditions.
Low
High
■Remaining charge amount
warning of hybrid battery (trac-
tion battery)
●The buzzer sounds intermittently
when the hybrid battery (traction
battery) remains without charging
while the shift leve r is in N, or the
remaining charge amount drops
below a certain level. If the
remaining charge amount drops
further, the buzzer sounds contin-
uously.
●When a warning message is
shown on the multi-information
display and the buzzer sounds,
follow the instructions displayed
on the screen to p erform trouble-
shooting.
■Display procedure
Multimedia system screen
(vehicles with 8-inch display)
1 Press the “MENU” button.
2 Select “Info” on the “Menu”
screen.
3 Select “ECO” on the “Info”
screen.
If a screen other than “Trip Informa-
tion” is displayed, select “Trip Infor-
mation”.
Navigation system screen
(vehicles with 12.3-inch dis-
play)
1 Select on the Toyota
multi-operation touch
( P.344).
2 Select “Trip Info” on the split-
screen.
Displaying a screen in full
screen( P.345)
A
B
Trip information screen

1282-1. Instrument cluster
■DisplayFuel consumption in the past
15 minutes
Regenerated energy in the
past 15 minutes
One symbol indicates 50 Wh. Up to
5 symbols are shown.
Resetting the consumption
data
Current fuel consumption
Average vehicle speed since
the hybrid system was
started.
Elapsed time since the hybrid
system was started.
Cruising range
The average fuel consumption his-
tory is divided by color into past
averages and the average fuel con-
sumption since the last updated.
Use the displayed average fuel
consumption as a reference.
The image is an example only, and
may vary slightly f rom actual condi-
tions.
■Display procedure
Multimedia system screen
(vehicles with 8-inch display)
1 Press the “MENU” button.
2 Select “Info” on the “Menu”
screen.
3 Select “ECO” on the “Info”
screen.
If a screen other than “History” is
displayed, select “History”.
Navigation system screen
(vehicles with 12.3-inch dis-
play)
1 Select on the Toyota
multi-operation touch
( P.344).
2 Select “History” on the split-
screen.
Displaying a screen in full
screen( P.345)
+
A
B
C
D
E
F
G
History screen

1292-1. Instrument cluster
2
Vehicle status information and indicators
■DisplayBest recorded fuel consump-
tion
Latest fuel consumption
Previous fuel consumption
record
Resetting the history data
Updating the latest fuel con-
sumption data
The average fuel consumption his-
tory is divided by color into past
averages and the average fuel con-
sumption since the last updated.
Use the displayed average fuel
consumption as a reference.
The image is an example only, and
may vary slightly f rom actual condi-
tions.
■Updating the history data
Update the latest fuel consumption
by selecting “Upda te” to measure
the current fuel consumption again.
■Resetting the data
The fuel consumption data can be
deleted by selecting “Clear”.
■Cruising range
Displays the estimated maximum
distance that can be driven with the
quantity of fuel remaining. This distance is computed based on
your average fuel consumption.
As a result, the actual distance that
can be driven may differ from that
displayed.
■“Home” screen (vehicles with 8-
inch display only)
The average fuel consumption and
distance to empty can be displayed
on the “Home” scre en of the multi-
media display.
For details of the “Home” screen,
refer to the separate “NAVIGATION
AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
A
B
C
D
E

129
3
3
Before driving
Before driving
3-1. Key informationKeys ............................ 130
3-2. Opening, closing and locking the doors
Side doors ................... 133
Back door .................... 138
Smart key system ....... 150
3-3. Adjusting the seats Front seats .................. 155
Rear seats................... 156
Driving position memory .................................. 158
Head restraints............ 162
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............ 164
Inside rear view mirror 165
Digital Rear-view Mirror .................................. 166
Outside rear view mirrors .................................. 177
3-5. Opening, closing the win- dows
Power windows ........... 179
