TOYOTA VENZA HYBRID 2023 Owners Manual

1112-1. Instrument cluster
2
Vehicle status information and indicators
turned on/off. (Customizable fea-
tures: P.502)
Following information is dis-
played on the multi-information
display.
Content display area (left)
Content display area (center)
Content display area (right)
Driving support system infor-
mation display area
When driving information support
Multi-information dis-
play (12.3-inch multi-
information display)
The multi-information dis-
play is used to display fuel
efficiency related informa-
tion and various types of
driving-related information.
The multi-information dis-
play can also be used to
change the display settings
and other settings.
Display contents
A
B
C
D

1122-1. Instrument cluster
system is displayed on the content
display area, the system operating
state will not be displayed in this
area.
RSA (Road Sign Assist) dis-
play area (if equipped)
■Content display area (cen-
ter)
 Driving support system infor-
mation display
 Settings display
 Warning message display
■Content display area (cen-
ter)
 Fuel Economy ( P.114)
 ECO Accelerator Guid-
ance/“Eco Score” ( P.114)
 Driving time since starting/EV
Driving Ratio ( P.116)
 Driving support system infor-
mation display
 Navigation system-linked
information display ( P.116)
(if equipped)
 Audio system-linked display
( P.116)
 Drive information ( P.116)
 Energy monitor ( P.128)
 Tire pressure ( P.402)
 AWD operation status display
( P.117)
■Liquid crystal display
Small spots or light spots may
appear on the display. This phe-
nomenon is character istic of liquid crystal displays, and there is no
problem continuing to use the dis-
play.
■When changing driving mode
Background color of the multi-infor-
mation display is changed following
the selected driving mode.
(  P.304)
/ : Change the screen
and move the cursor
up/down
/ : Change displayed
content and scroll up/down
the screen
Press: Enter/Set
E
WARNING
■Caution for use while driving
●When operating the multi-infor-
mation display while driving,
pay extra attention to the safety
of the area around the vehicle.
●Do not look continuously at the
multi-informatio n display while
driving as you may fail to see
pedestrians, objects on the
road, etc. ahead of the vehicle.
■The information display at
low temperatures
 P.98
Meter control switches
A
B

1132-1. Instrument cluster
2
Vehicle status information and indicators
Press and hold: Reset, dis-
play the cursor and display
customizable items
Move the main meter and
return to the previous screen
Call sending/receiving and
history display
Linked with the hands-free system,
sending or receiving call is dis-
played. For details regarding the
hands-free system, refer to the
“MULTIMEDIA OWNER’S MAN-
UAL”.
The multi-information display is
operated using the meter control
switches.
■Changing the meter display
type setting
The meter display type setting
can be changed on .
( P.117)
■Changing the screen
Select items from the combina-
tion of 3 screens to display on
each 3 content display areas.
Press or of the meter
control switch to scroll the
screen.
■Changing the display con-
tents
Switches items displayed on
each contents display area
(left/center/right).
1 Press and hold of the
meter control switch to dis-
play cursor on the content
display area (center).
2 Press or to move the
cursor and select the content
display area.
3 Press or to select the
items.
■Items displayed in the con-
tent display area
Select to enable/disable items
on the content display area
(left/right).
1 Press and hold of the
meter control switch to dis-
play cursor on the content
display area (center).
Changing the display
C
D

1142-1. Instrument cluster
2Press or to move the
cursor and select the content
display area.
3 Contents display area (left):
Press to display contents
list.
Contents display area (right):
Press to display contents
list.
4 Press or to select the
items.
5 Press to select
enable/disable items.
Current fuel economy
Displays the driving range with
remaining fuel.
Average fuel economy
Displays the average fuel economy
since the function was reset or the
average fuel economy after starting
or refueling.
*1, 2, 3
The average fuel economy selected
by “Fuel Economy” on the
screen is displayed.
*1: Use the displayed fuel consump- tion as a reference only.
*2: Average fuel economy after starting is reset each time the
hybrid system stops.
*3: Average fuel economy since the function was res et can be reset
by pressing and holding .
Displays a reference operation
range for using the accelerator
pedal according to driving condi-
tions, and a score result that
evaluates the current driving
status.
ECO Accelerator Guidance
“Eco Score”
WARNING
■Caution for use while driving
For safety, avoid operating the
meter control swit ch while driving
as much as possible, and do not
look continuously at the multi-
information display while driving.
Stop the vehicle and operate the
meter control switch. Failure to do
so may cause a steering wheel
operation error, resulting in an
unexpected accident.
Fuel Economy
A
(&2$FFHOHUDWRU*XLG
DQFH³(FR6F\
RUH´
B
[ˆ[¦[²[c[–[¦[²[µ[¨
[–[·[¤[µ[·
[–[·[²[³
[†[µ[¸[¬[¶[¨
A
B

1152-1. Instrument cluster
2
Vehicle status information and indicators
■ECO Accelerator GuidanceECO area
Shows that the vehicle is being
driven in an Eco-friendly manner.
Power area
Shows that an Eco-friendly driving
range is being exceeded (during full
power driving etc.).
Current acceleration
Reference operation range
A zone is display ed in blue under
the Eco area which can be used as
a reference operation range for
using the accelerator pedal accord-
ing to driving conditions such as
starting off and cruising.
The ECO Accelera tor Guidance
display changes according to the
driving status, such as when start-
ing off or cruising.
It is easier to drive in an Eco-
friendly manner by driving accord-
ing to the display showing the
accelerator pedal operations and
staying within the reference opera-
tion range.
■“Eco Score”
The driving status for the follow-
ing 3 situations are evaluated in
5 levels: Smooth start-off accel-
eration (“Start”), driving without sudden acceleration (“Cruise”)
and smooth stopping (“Stop”).
Each time the vehicle is
stopped, a score result is dis-
played out of a perfect score of
100 points.
Score result
Eco start status
Eco cruise status
Eco stop status
3 situations are displayed with each
icon while driving.
How to read the bar display:
After starting off, “Eco Score” dis-
play does not start until the vehicle
speed exceeds approximately 19
mph (30 km/h).
The “Eco Score” is reset each time
the vehicle starts off to start a new
evaluation.
A
B
C
D
6FRUH%DUGLVSOD\
8QUDWHG
/RZ
+LJK
A
B
C
D

1162-1. Instrument cluster
■ECO Accelerator Guid-
ance/“Eco Score” will not oper-
ate when
The ECO Accelerator Guid-
ance/“Eco Score” will not operate in
the following situations:
●The Hybrid System Indicator is not
operating.
●The vehicle is being driven using
the dynamic radar cruise control.
EV driving ratio after starting
Displays the percen tage of EV driv-
ing since the hybrid system was
started.
*
Elapsed time after starting
Displays the elapsed time since
hybrid system was started.
*
*
: It is reset each time the hybrid system stops.
Select to display the operational
status of the following systems:
 PCS (Pre-Collision System)
( P.239)
 LTA (Lane Tracing Assist) (
P.250)
 Dynamic radar cruise control
with full-speed range
( P.262)
Select to display the following
navigation system-linked infor-
mation.
 Route guidance to destination
 Street name
 Compass
Select to enable selection of an
audio source or track on the
meter
■Drive information
2 items that are selected using
the “Drive Info Items” setting
(average speed and distance)
can be displayed vertically.
Use the displayed information as a
reference only.
• Average Speed: Displays the average vehicle speed since
hybrid system start
*
• Distance: Displays the dis-tance driven since hybrid sys-
tem start
*
EV Ratio/EV Driving Ratio
Driving support system
information display
A
B
1DYLJDWLRQV\\
VWHPOLQNHG
GLVSOD\LI\
HTXLSSHG\f
$XGLRV\VWHPOLQNHGGLV
SOD\
'ULYLQJLQIRU\
PDWLRQGLV
SOD\

1172-1. Instrument cluster
2
Vehicle status information and indicators
• Elapsed time: Displays elapsed time since hybrid sys-
tem start
*
*: These items are reset each time the hybrid system stops.
■Trip information
2 items that are selected using
the “TRIP A Items” or “TRIP B
Items” setting (average speed
and distance) can be displayed
vertically.
Use the displayed information
as a reference only.
• Average Speed: Displays the average vehicle speed since
the display was reset
*
• Distance: Displays the dis-tance driven since the display
was reset
*
• Elapsed time: Displays
elapsed time since the display
was reset
*
*: To reset, display the desired item
and press and hold .
 P.128
 P.402
■Tire pressure
●It may take a few minutes to dis-
play the tire inflation pressure
after the power switch is turned to
ON. It may also take a few min-
utes to display the tire inflation pressure after infl
ation pressure
has been adjusted.
●“---” may be displayed if the tire
position information cannot be
determined due to unfavorable
radio wave conditions.
●Tire inflation pressure changes
with temperature. The displayed
values may also be different from
the values measured using a tire
pressure gauge.
Torque distribution display
Displays the drive status of each
wheel in 6 steps from 0 to 5.
The illustration used is intended as
an example, and may differ from
the image that is actually displayed
on the multi-information display.
Vehicle settings and the content
displayed on the screen can be
changed by using the meter
control switches.
■Setting procedure
1 Press and hold of the
meter control switch to dis-
play cursor on the content
display area (center).
Energy monitor
Tire Pressure
AWD system display
Settings display
A

1182-1. Instrument cluster
2Press or with the cur-
sor on the content display
area (center) to select
and then press .
3 Press or of the meter
control switch and move the
cursor to select the item for
changing settings.
If the function is t urned on and off
or the volume, etc. is changed on
the setting screen, the setting is
changed each time is pressed .
For functions that allow operation
contents, display contents, etc., of
function to be selected, the setting
screen is displayed by pressing and
holding . When the setting
screen is displayed, select the set-
ting or desired va lue (time, etc.)
with .
4 After changing the settings,
press of the meter control
switches.
■HUD (Head-up display) (if
equipped) ( P.123)
Select to change the head-up
display setting.
■ LTA (Lane Tracing
Assist) (if equipped)
( P.250)
Select to set up the following
items.
 “Lane Center”
Select to enable/disable the lane
centering function.
“Alert Options”
Select to set the alert type.
“Sensitivity”
Select to set the warning sensitivity.
“Sway Warning”
Select to enable/disable the vehicle
sway warning.
“Sway Sensitivity”
Select to set the vehicle sway warn-
ing sensitivity.
■ BSM (Blind Spot Moni-
tor) ( P.277)
Select to set up the following
items.
 BSM (Blind Spot Monitor)
on/off
Select to enable/disable the
BSM system.
 “Sensitivity”
Select to change the alert tim-
ing for an approaching vehi-
cle.
 “Brightness”
Select to switch the bright-
ness of the outside rear view
mirror indicators. ( P.278)
■ PCS (Pre-Collision Sys-
tem)
Select to set up the following
items.
 PCS on/off
Select to enable/disable the
pre-collision system.
 “Sensitivity”
Select to change the pre-colli-
sion warning timing.

1192-1. Instrument cluster
2
Vehicle status information and indicators
■Intuitive parking assist
(if equipped) ( P.287)
Select to set up the following
items.
 Intuitive parking assist on/off
Select to enable/disable the
Intuitive parking assist.
 “Volume”
Select to set the volume of the
buzzer which sounds when
the Intuitive parking assist is
operated.
■ RCTA (Rear Cross Traf-
fic Alert) ( P.283)
Select to set up the following
items.
 RCTA (Rear Cross Traffic
Alert) on/off
Select to enable/disable the
RCTA system.
 “Volume”
Select to set the volume of the
buzzer which sounds when
the RCTA and the Toyota
parking assist-sensor is oper-
ated.
■ PKSB (Parking Sup-
port Brake System) (if
equipped) ( P.295)
Select to enable/disable the
Parking Support Brake function.
■ RSA (Road Sign
Assist) (if equipped)
Select to set up the following
items. 
Road Sign Assist on/off
Select to enable /disable the RSA
(Road Sign Assist).
 “Notification Method”
Select to change each notification
method used to notify the driver
when the system recognizes
excess speed and Do Not Enter
sign.
“Notification Level”
Select to change each notification
level used to notify the driver when
the system recognizes a speed limit
sign.
■ Vehicle Settings
 DRCC
Select to change the curve speed
reduction function setting.
 PBD (Power Back Door)
( P.143)
Select to set up the following
items.
• System settings Select to enable/disable the
power back door system.
• “Hands Free” (if equipped) Select to enable/disable the
Hands Free Power Back Door
operation.
• “Opening Adjustment” Select the open position when
power back door is fully open.
•“Volume” Select to enable/disable the
power back door system.
 “TPWS” (Tire Pressure Warn-
ing System) ( P.402)
• “Setting Pressure”

1202-1. Instrument cluster
Select to initialize the tire pres-
sure warning system.
• “Identifying Each Wheel & Posi- tion”
Select to change the tire pressure
warning system sensor ID code
set. To enable this function, a
second set of tire pressure warn-
ing system sensor ID codes must
be registered by a Toyota dealer.
For information regarding chang-
ing the registered ID code set,
contact your Toyota dealer.
• “Pressure unit setting” Select to change the units of
measure displayed.
 “Scheduled Maintenance”
( P.380)
Select to reset the scheduled
maintenance information
(message indicating mainte-
nance is required and dis-
tance until the next
maintenance) after all mainte-
nance is performed.
 Oil Maintenance
Select to reset the Oil mainte-
nance. ( P.392)
 Rear Seat Reminder
( P.139)
Select to enable/disable the
rear seat reminder function.
■ Settings
 “Language”
Select to change the lan-
guage on the multi-informa-
tion display.
 “Units”
Select to change the unit of measure for fuel consump-
tion.
 Meter Type
Select to change the meter
type setting.
 Meter Style
Select to change the meter
style.
 Dial Type
Select to change dial type.
( P.94)
 EV indicator
Select to enable/disable the
EV indicator.
 Fuel Economy
Select to change the display
on Fuel Economy. ( P.114)
 Hybrid System
Select to enable/disable refer-
ence operation range.
 Drive Info
Select to change displayed
items on drive information dis-
play. ( P.116)
 Pop-Up Display
Select to enable/disable the
pop-up displays, which may
appear in some situations.
 Default Settings
Select to reset the meter dis-
play settings.
■Suspension of the settings dis-
play
●Some settings cannot be changed
while driving. When changing set-
tings, park the vehicle in a safe
place.
