Page 10 SCION
ALARM INFORMATION
ALARM DESCRIPTIONS
Regular ALARMWhen an ALARMis triggered in any way other than initial detection by the RADARSENSOR,
the following occur:
The horn sounds repeatedly for 60 seconds.
The headlights flash repeatedly for 60 seconds.
The tail and marker or turn signal lights flash repeatedly for 60 seconds.
The starter is disabled (no engine start) until the system is D
ISARMED.
The door lock will be relocked if someone reaches in and unlocks the inside lock button.
After 60 seconds of A
LARM, the system will REARMand continue to protect the vehicle.
STOPPING AN ALARM
Simply DISARMthe system using the remote control or key as described on page 6.
THE HORN
SOUNDS
FOR 60 SECONDS
HEAD LIGHTS
FLASH
FOR 60 SECONDS
THE STARTER IS DIS-
ABLED UNTIL THE SYSTEM
IS DISARMED
MARKER OR TURN
SIGNAL LIGHTS
FLASH
FOR 60 SECONDS
TAIL OR TURN SIG-
NAL LIGHTS FLASH
FOR 60 SECONDS
1
1

SCIONPage 11
RADAR SENSOR INFORMATION
RADAR SENSOR CHECK PROCEDURE
1. ARMthe system.
Press the LOCK button on the remote control or lock the doors
with the key.
(Remember, the system will not ARM if any door is open.)
2. Wait until the S
TATUSMONITOR’SLED starts flashing.
The LED will flash 30 seconds after the last door or hatch is closed.
3. Move inside the vehicle.
When movement occurs inside the vehicle, an alarm will be triggered
immediately. If sensor detects 2nd movement within 60 seconds after
the 1st warn away alarm trigger, then a regular ALARM activates for 60
seconds.
Note: If you find that the system does not perform as expected, contact
your Toyota dealer for more information.
4. D
ISARMthe system to stop the ALARM.
Press the UNLOCK button on the remote control or use the key to
DISARM the system.
RADAR SENSOR OFF MODE
THE RADAR SENSOR CAN BE DEACTIVATED. PERFORM THE FOLLOWING:
1. Open the driver’s door .
The LED turns off. The system is now DISARMED.
2. Lock, then unlock the driver’s door inside lock button 3 times,
within 5 seconds.
The LED flash quickly.
3. Close the driver’s door.
4. ARM
THE SYSTEM WITH THE REMOTE CONTROL OR KEY WHILE THELEDIS
BLINKING.THE RADAR SENSOR WILL DEACTIVATE DURING ARMING.
NOTE: IF YOU DISARM THE SYSTEM AFTER YOU SET THE RADAR SENSOROFF, YOU HAVE TO REPEAT THE ABOVE PROCEDURE WHEN YOU ARM
THE SYSTEM IF YOU WANT TO DEACTIVATE THE RADAR SENSOR AGAIN.
THE SYSTEM WILL AUTOMATICALLY CANCEL THE RADAR SENSOR OFF
MODE WHEN DISARMED.
