128-7907A
12 of 32
Figure 1a. Remote Control
-5-
1. POWER Button* – Press this button to turn M1 or M2
Monitor ON. Press the button again to turn M1 or M2
Monitor OFF.
2. Monitor Select (M1 and M2 Buttons) – Press
corresponding button to change the Remote Control
code to enable control of the M1 or M2 Monitor.
3. NUMBER Buttons – Allows the user to enter the
numbers 0 to 9 for selection of CD tracks, DVD
chapters, and password setting.
4. UP/DOWN (+/-) Buttons – Use these buttons
to make picture adjustments in the picture select
mode.
5. PIX Button (PICTURE SELECT) – Each time this button
is pressed, the on screen picture adjustment displays
the “adjustment bar” for BRIGHTNESS, CONTRAST,
COLOR or TINT. Once the desired adjustment bar is
displayed, use the (+) / (–) button to adjust the setting.
The OSD will automatically turn off if no adjustments are
made within 6 seconds, or if any other button is pressed.
REMOTE CONTROL FUNCTIONAL
DESCRIPTION
* Function control is available on the unit and remote control.
NOTE: To control the individual units (M1 Monitor / M2 Monitor)
press either M1 or M2 before pressing any other button. For
example, to turn M1 Monitor ON, press M1 and then the power
button.

128-7907A
13 of 32
7
109 8 6A
11
M1 M2
+–6B
6C
Figure 1b. Remote Control
6a.Up (S)/Down (T) Buttons – Use these buttons to scroll
upward and downward, respectively, in menu options.
6b. LEFT (W)/Right (X) Buttons – Use these buttons to shift
left and right, respectively, in the menu options.
6c. ENTER Button – Used to implement a selected setting.
7. SETUP Button – Press to display the Setup Menu which
allows the user to change the DVD player options such
as TV DISPLAY, OSD LANGUAGE, PARENTAL
CONTROL etc. Refer to the Settings and Adjustments
section for more information.
8. REPEAT Button – Allows the user to repeat a selected
Title, Chapter or Track of a DVD, CD or MP3. Refer to
repeat function in this manual for each type of disc.
9. A-B Button – Allow user to repeat the playback from
point A to point B.
10. RETURN Button – Not used on this model.
11. MENU Button – Allows the user to access the DVD
(DVD MODE) root menu.
-6-

128-7907A
15 of 32
Figure 1d. Remote Control
16. AUDIO Button – Press to display and select the
AUDIO language in DVD mode. Each time you press
the button, the language changes.
NOTE: The languages for audio vary from disc to disc.
17. DISPLAY Button – Press to display the current
disc information while the disc is playing. Press the
cursor (STWX) buttons to highlight the desired
option. For title and chapter selection use the
number buttons to enter the desired title or chapter
number for angle, audio, and subtitle. Press the
ENTER button repeatedly to change the item.
Title
Chapter
Angle
Audio
Subtitle
18. IRT ON/OFF Button – Press this button to turn the
selected unit (M1/M2) IR Transmitter ON/OFF.
17 18
M1 M2
+–
16
-8-

128-7907A
18 of 32
There are six (6) buttons on the M1 unit and M2 unit:
1. POWER Button – Press this button to turn the unit
ON/OFF.
2. SOURCE Button – Press this button to select between
DVD, AV1, and AUX.
3. SCREEN MODE Button – Press this button to select
between Wide (16:9), Normal (4:3) aspect ratio or screen
off (display OFF).
4. PLAY Button – Press this button to start playback.
5. STOP Button – Press this button to stop playback.
6. EJECT Button – Press this button to eject the disc.
OPERATION INSTRUCTIONS
Control Button Functions (M1/M2 Unit)
SAUX
123 4 56
-11-
Figure 4. Monitor Button Functions

128-7907A
25 of 32
-18- Playing MP3 Discs
Selecting a Play Mode
You can choose what order the songs will play on a disc temporarily.
The default play mode is FOLDER NORMAL. Press the STOP button,
then press X to highlight the play mode. Press the ENTER button
consecutively to select the desired play mode. The play mode options
are:
• FOLDER NORMAL- Plays all songs in a folder once.
• FOLDER REPEAT- Plays all songs in a folder
repetitively.
• DISC NORMAL- Plays entire disc.
• DISC REPEAT- Repeats entire disc.
• SHUFFLE- Plays the songs in a folder in random
order from within the selected folder. Each song in a
folder can be played once.
• PROGRAM BEGIN/PROGRAM END- Follow the
instructions for selecting a play mode. Select
PROGRAM BEGIN. Select the desired tracks within
the selected folder using the number buttons on the
remote control. When all the tracks have been
entered press the ENTER button and PROGRAM
END is displayed. Press the PLAY button and
playback of the programmed tracks will begin.
• SINGLE TRACK- Plays a single track.
• REPEAT SINGLE- Plays a single track repetitively. Use the Next (XXl) button on the remote control to move to the
next song. Use the Previous (lWW) button to move to the
previous song.MP3 is a format for storing digital audio. An audio CD song
can be compressed into the MP3 format with very little loss of
quality while taking up much less space. CD-R discs that have
been encoded in MP3 format can be played in the DVD player.
The DVD player plays the songs in the order they were burned
on to the disc. When play back is started the elapsed time of
the track that is playing will be displayed. Press the DISPLAY
button to turn the display off.
Selecting Folders and Songs
When an MP3 is loaded in the player, the navigation menu
appears automatically.
1. Press S or T to move the highlight to the desired folder
on the left side of the Menu and press ENTER. The
songs in the folder will be displayed on the right side of
the Menu.
2. Press S or T to move the highlight to the desired song
and press ENTER to begin playback of the highlighted
song.
MP3 Format
