156
Do not leave the engine running in
an area with snow buildup, or
where it is snowing. If snowbanks
build up around the vehicle while
the engine is running, exhaust
gases may collect and enter the ve-
hicle. This may lead to death or a
serious health hazard.
When taking a nap in the vehicle,
always turn the engine off. Other-
wise, you may accidentally move
the shift lever or depress the accel-
erator pedal, which could cause an
accident or fire due to engine over-
heating. Additionally, if the vehicle
is parked in a poorly ventilated
area, exhaust gases may collect and
enter the vehicle, leading to death
or a serious health hazard.
FUNCTIONS OF ENGINE OIL
Engine oil has the primary functions of
lubricating and cooling the inside of the
engine, and plays a major role in main-
taining the engine in proper working order.
ENGINE OIL CONSUMPTION
It is normal that an engine should con-
sume some engine oil during normal
engine operation. The causes of oil
consumption in a normal engine are as
follows.
Oil is used to lubricate pistons, piston
rings and cylinders. A thin film of oil
is left on the cylinder wall when a pis-
ton moves downwards in the cylinder.
High negative pressure generated when
the vehicle is decelerating sucks some
of this oil into the combustion chamber.
This oil as well as some part of the oil
film left on the cylinder wall is burned
by the high temperature combustion
gases during the combustion process.
Oil is also used to lubricate the stems
of the intake valves. Some of this oil
is sucked into the combustion chamber
together with the intake air and is
burned along with the fuel. High tem-
perature exhaust gases also burn the
oil used to lubricate the exhaust valve
stems.
The amount of engine oil consumed de-
pends on the viscosity of the oil, the
quality of the oil and the conditions the
vehicle is driven.
More oil is consumed by high −speed driv-
ing and frequent acceleration and decel-
eration.
A new engine consumes more oil, since
its pistons, piston rings and cylinder walls
have not become conditioned.
Oil consumption: Max. 1.0 L per 1000
km (1.1 qt./600 miles, 0.9 lmp.qt./600
miles)
When judging the amount of oil con-
sumption, note that the oil may become
diluted and make it difficult to judge
the true level accurately.
Facts about engine oil
consumption

189
When encountering flooded roads
Do not drive on a road that has flooded
after heavy rain etc. Doing so may cause
serious damage to the vehicle.
NOTICE
Driving on a flooded road may cause
the engine to stall as well as cause
serious vehicle malfunctions such as
shorts in electrical components and
engine damage from water immersion.
In the event that you drive on a
flooded road and the vehicle is
flooded, be sure to have your Scion
dealer check brake function, changes
in quantity and quality of engine oil,
transaxle fluid, etc. and lubricant con-
dition for the bearings and suspen-
sion joints (where possible) and the
function of all joints and bearings.
Winter driving tips
Make sure you have a proper freeze
protection for engine coolant.
Only use “Toyota Super Long Life Coolant”
or similar high quality ethylene glycol
based non−silicate, non −amine, non −nitrite,
and non− borate coolant with long −life
hybrid organic acid technology. (Coolant
with long −life hybrid organic acid
technology is a combination of low
phosphates and organic acids.)
See “Checking the engine coolant level”
on page 242 for details of coolant type
selection.
“Toyota Super Long Life Coolant” is a
mixture of 50% coolant and 50% deionized
water. This coolant provides protection
down to about –35 C (–31 F).
NOTICE
Do not use plain water alone.
Check the condition of the battery and
cables.
Cold temperatures reduce the capacity of
any battery, so it must be in top shape
to provide enough power for winter start-
ing. Section 7− 3 tells you how to visually
inspect the battery. Your Scion dealer and
most service stations will be pleased to
check the level of charge.
Make sure the engine oil viscosity is
suitable for the cold weather.
See page 241 for recommended viscosity.
Leaving a heavy summer oil in your ve-
hicle during winter months may cause
harder starting. If you are not sure about
which oil to use, call your Scion deal-
er—they will be pleased to help.
Keep the door locks from freezing.
Squirt lock de −icer or glycerine into the
locks to keep them from freezing. To open
a frozen lock, try heating the key before
inserting it.

199
4. Start your engine in the normal way.After starting, run it at about 2000 rpm
for several minutes with the accelerator
pedal lightly depressed.
5. Carefully disconnect the cables in the exact reverse order: the negative cable
and then the positive cable.
If the cause of your battery discharging is
not apparent (for example, lights left on),
you should have it checked at your Scion
dealer.
If the first start attempt is not success-
ful...
Check that the clamp on the jumper
cables are tight. Recharge the discharged
battery with the jumper cables connected
for several minutes and restart your en-
gine in the normal way.
If the another attempt is not successful,
the battery may be depleted. Have it
checked at your Scion dealer. If your engine stalls while driving...
1. Reduce your speed gradually, keeping a straight line. Move cautiously off the
road to a safe place.
2. Turn on your emergency flashers.
3. Try starting the engine again.
If the engine will not start, see “If your
vehicle will not start” on page 196.
CAUTION
If the engine is not running, the pow-
er assist for the brakes and steering
will not work so steering and braking
will be much harder than usual.
If your vehicle overheats
If your engine coolant temperature
gauge indicates overheating, if you ex-
perience a loss of power, or if you hear
a loud knocking or pinging noise, the
engine has probably overheated. You
should follow this procedure...
1. Pull safely off the road, stop the ve- hicle and turn on your emergency
flashers. Put the transmission in “P”
(automatic) or neutral (manual) and ap-
ply the parking brake. Turn off the air
conditioning if it is being used.
2. If coolant or steam is boiling out of the radiator or reservoir, stop the engine.
Wait until the steam subsides before
opening the hood. If there is no coolant
boiling over or steam, leave the engine
running and make sure the electric
cooling fan is operating. If it is not,
turn the engine switch off.
CAUTION
To help avoid personal injury, keep
the hood closed until there is no
steam. Escaping steam or coolant is
a sign of very high pressure.
If your engine stalls while
driving

241
ENGINE OIL SELECTION
“Genuine Motor Oil” is used in your Scion
vehicle. Use Scion approved “Genuine Mo-
tor Oil” or equivalent to satisfy the follow-
ing grade and viscosity.
Oil grade:ILSAC multigrade engine oil
Recommended viscosity: SAE 5W −20 or 0W −20
Outside temperature
SAE 5W20 or 0W20 engine oil may be
used. However, SAE 0W20 is the best
choice for good fuel economy, and
good starting in cold weather.
API02
Oil identification mark
The ILSAC (International Lubricant Stan-
dardization and Approval Committee) Certi-
fication Mark is added to some oil con-
tainers to help you select the oil you
should use.

263
Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):Intake 0.19 – 0.29 (0.007 – 0.012)
Exhaust 0.38 – 0.48 (0.015 – 0.019)
Spark plug type: DENSO SK20R11
NGK IFR6A11
Spark plug gap, mm(in.): 1.1 (0.043)
ENGINE LUBRICATION
Oil capacity (drain and refill), L (qt.,
Imp.qt.): With filter 4.3 (4.5, 3.8)
Without filter 4.1 (4.3, 3.6)
“Genuine Motor Oil” is used in your Scion
vehicle. Use Scion approved “Genuine Mo-
tor Oil” or equivalent to satisfy the follow-
ing grade and viscosity. Oil grade:
ILSAC multigrade engine oil
Please contact your Scion dealer for fur-
ther details.
Recommended oil viscosity: SAE 5W −20 or 0W −20
Outside temperature
COOLING SYSTEM
Total capacity, L (qt., Imp.qt.):
Manual transmission 6.0 (6.3, 5.3)
Automatic transmission 5.9 (6.2, 5.2)
Coolant type:
“Toyota Super Long Life Coolant” is
used in your Scion vehicle at factory fill.
In order to avoid technical problems,
only use “Toyota Super Long Life Cool-
ant” or similar high quality ethylene gly-
col based non −silicate, non− amine, non−
nitrite, and non −borate coolant with
long− life hybrid organic acid technology.
(Coolant with long −life hybrid organic
acid technology is a combination of low
phosphates and organic acids.)
Do not use plain water alone.
Please contact your Scion dealer for fur-
ther details.
BATTERY
Open voltage* at 20 C (68 F):
12.6 – 12.8 V Fully charged
12.2 – 12.4 V Half charged
11.8 – 12.0 V Discharged
*: Voltage that is checked 20 minutes after the key is removed with all the
lights turned off
Charging rates: 5 A max.

273
D
Defogger, Rear window90
. . . . . . . . . . . . . .
Dimmer switch, Headlight 86
. . . . . . . . . . . .
Dinghy towing 190
. . . . . . . . . . . . . . . . . . . . .
Directional signals 86
. . . . . . . . . . . . . . . . . .
Do −it−yourself maintenance
Parts and tools 235
. . . . . . . . . . . . . . . . . . .
Service precautions 233
. . . . . . . . . . . . . .
Does your vehicle need repairing? 229 . . .
Driving Automatic transmission 109
. . . . . . . . . . .
Driving tips 187, 189
. . . . . . . . . . . . . . . . .
Manual transmission 113
. . . . . . . . . . . . .
Driving in the rain 188
. . . . . . . . . . . . . . . . . .
Driving tips
Driving in the rain 188
. . . . . . . . . . . . . . . .
Driving tips in various conditions 187
. . . . . . . . . . . . . . . . . . . . .
Driving with an automatic transmission 109
. . . . . . . . .
Driving with a
manual transmission 113
. . . . . . . . . . . .
Economical driving 192
. . . . . . . . . . . . . . .
Good driving practice 109, 113
. . . . . . . . .
Winter driving tips 189
. . . . . . . . . . . . . . . .
During
Break −in 152
. . . . . . . . . . . . . . . . . . . . . . . .
E
Economical driving
Saving money on both fuel
and repairs 192 . . . . . . . . . . . . . . . . . . . .
Electrical system Battery 252 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 233 . . . . . . . . . . . . . . . . . . .
Fuses 254 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 87 . . . . . . . . . . . .
Emergency, In case of Blown fuse 254 . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 87 . . . . . . . . . .
Flat tire 200 . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot operate back door opener 216 . . . . . . . . . . . . . . .
If you cannot shift automatic
transmission selector lever 215 . . . . . .
If you lose your keys 216 . . . . . . . . . . . . . .
If your engine stalls while driving 199 . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 211 . . . . . . . . . . . . . . . . . . . .
If your vehicle will not start 196 . . . . . . . .
Jump starting 197 . . . . . . . . . . . . . . . . . . . .
Overheating 199 . . . . . . . . . . . . . . . . . . . . .
Towing 211 . . . . . . . . . . . . . . . . . . . . . . . . . .
Emissions inspection and maintenance (I/M) programs 230 . . . . . . . Engine
Before starting the engine 186 . . . . . . . . .
Checking the coolant level 242 . . . . . . . .
Emission control device 154 . . . . . . . . . . .
Engine compartment overview 232 . . . . .
Exhaust gas caution 155 . . . . . . . . . . . . . .
Hood release 21 . . . . . . . . . . . . . . . . . . . . .
Identification Number 162 . . . . . . . . . . . . .
Oil consumption 156 . . . . . . . . . . . . . . . . . .
Oil level 240 . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 199 . . . . . . . . . . . . . . . . . . . . .
Starting procedure 186 . . . . . . . . . . . . . . .
Three −way catalytic converter 154 . . . . .
Engine coolant Temperature indicator and waning light 94 . . . . . . . . . . . . . . . . . . . . .
Winter driving tips 189 . . . . . . . . . . . . . . . .
Engine oil Winter driving tips 189 . . . . . . . . . . . . . . . .
Engine switch 110 . . . . . . . . . . . . . . . . . . . . . .
Exhaust gas caution 155 . . . . . . . . . . . . . . . .
