TOYOTA xB 2013 Accessories, Audio & Navigation (in English)

AUDIO/VIDEO SYSTEM
190
V573_E
z Your CD/DVD player
When you insert a disc, insert it with the
label side up. The CD/DVD player will
play from track 1 through to the end of
the disc. Then it will play from track 1
again.

NOTICE
Never try to disassemble or oil any
part of the CD/DVD player. Do not
insert anything other than discs into
the slot.
The player is intended for use with 12 cm
(4.7 in.) discs only.
z Apple Composite AV cable
Using an Apple Composite AV Cable
allows iPod video files to be played.
For details, see page 256.
z Rear Seat LCD Monitor
A commercially available Rear Seat
LCD Monitor can be used by con-
necting it to the RCA Relay cable's
RCA terminals.
For further information and operation
procedures, refer to the device's
manual.
This product incorporates copyright
protection technology that is pro-
tected by U.S. patents and other in-
tellectual property rights. Use of this
copyright protection technology must
be authorized by Rovi Corporation,
and is intended for home and other
limited viewing uses only unless oth-
erwise authorized by Rovi Corpora-
tion. Reverse engineering or disas-
sembly is prohibited. z
External amplifier
A commercially available external
amplifier can be connected to the
RCA Relay cable's RCA terminal to
enable the use of subwoofers etc.
For further information and operation
procedures, refer to the device's
manual.

AUDIO/VIDEO SYSTEM
191
V573_E

You can adjust the brightness, contrast,
tone and color of the screen. You can
also turn the display off, and change the
screen to either day or night mode.
z Brightness and contrast adjust-
ment
The brightness and contrast of the
screen can be adjusted depending on
the brightness of your surroundings.
You can also turn the display off.




1. Push the “AV” button.

2. Touch “DISPLAY”.


3. Select the desired button to ad-
just brightness and contrast.
“Brightness” “
(brightens)”:
Brightens the screen.
“Brightness” “
(darkens)”: Darkens
the screen.
“Contrast” “
(strengthens)”:
Strengthens the contrast of the screen.
“Contrast” “
(weakens)”: Weakens
the contrast of the screen.
4. After adjusting the screen, touch
"OK”.
The screen goes off when “Screen Off”
is touched. To turn the display screen
back on, push any button such as “AV”,
etc. The selected screen appears.


INFORMATION
When you do not touch any touch
screen button on the “Display”
screen for 20 seconds, the previous
screen will be displayed.



— Screen ad
justment

AUDIO/VIDEO SYSTEM
192
V573_E
z Tone and color adjustment
The tone and color of the screen can be
adjusted while a DVD video, iPod Video
file or Video is being played.
1. Push the “AV” button to display
the “AV Menu” screen and touch
“DISPLAY”.

2. Select the desired button to ad-
just tone and color.
“Tone” “
(strengthens)”: Strength-
ens the tone of the screen.
“Tone” “
(weakens)”: Weakens the
tone of the screen.
“Color” “
(green)”: Strengthens the
green color of the screen.
“Color” “
(red)”:
Strengthens the
red color of the screen.
3. After adjusting the screen, touch
“OK”.
The screen goes off when “Screen Off”
is touched. To turn the display screen
back on, push any button such as “AV”,
etc. The selected screen appears.


INFORMATION
When you do not touch any touch
screen button on the “Display”
screen for 20 seconds, the previous
screen will be displayed.
z
Changing between day mode and
night mode
Depending on the position of the head-
light switch, the screen changes to the
day mode or night mode.

To display the screen in the day mode
even with the headlight switch on,
touch “Day Mode” on the adjustment
screen for brightness and contrast
control.
If the screen is set in the day mode with
the headlight switch turned on, this con-
dition is memorized in the system even
with the engine turned off.

AUDIO/VIDEO SYSTEM
193
V573_E

z Listening to the radio
1. Push the “AV” button.

2. Touch these touch screen buttons
to choose either an AM or FM station.
“AM”, “FM1” or “FM2” appears on the
screen.
Push the “AV” button and touch
“AUDIO” to display the radio operation
screen.
Changing between FM1 and FM2: Touch
“FM1” or “FM2” on the screen.
Your radio can receive terrestrial digital
broadcasts. When terrestrial digital
broadcasts are received, FM reception
has the same quality as a CD, and AM
reception has the same quality as con-
ventional FM sound. Depending on the
reception status, HD Radio™ receiver
can also receive analog broadcasts,
which means reception is still possible in
regions with no digital coverage.

HD Radio™ Technology Manufactured
Under License From iBiquity Digital
Corporation. U.S. and Foreign Patents.
HD Radio™ and the HD and HD Radio
logos are proprietary trademarks of iBiq-
uity Digital Corp.
z
Presetting a station

1. Tune in the desired station.
2. Touch one of the channel selector
touch screen buttons (1 — 8) you
want and hold it until a beep is heard.
This sets the station to the touch screen
button and the frequency appears on the
touch screen button.
Each radio mode can store up to 8 sta-
tions. To change the preset station to a
different one, follow the same procedure.
The preset station memory is cancelled
when the power source is interrupted by
battery disconnection or a blown fuse.


— Radio o
peration

AUDIO/VIDEO SYSTEM
194
V573_E
z Selecting a station
Tune in the desired station using one of
the following methods.
Preset tuning: Touch the channel se-
lector (1 — 8) for the station you want.
The touch screen button is highlighted
and the station frequency appears on the
screen.
Frequency adjustment: Push the “S ”
or “T ” button of “TRACK/TUNE” to
increase or decrease the frequency.
Seek tuning: Push and hold the “S ” or
“ T ” button of “TRACK/TUNE” . The
radio will begin seeking up or down for a
station of the nearest frequency and will
stop when a station is received. Each
time the button is pushed, the next
available station will be played.
To scan all the frequencies: Touch
“SCAN” on the screen. The radio will
find the next station and stay there for a
few seconds, and then scan again. To
select a station, touch “SCAN” again.
To scan the preset stations: Touch
“P.SCAN” on the screen. The radio
will tune in the next preset station, stay
there for a few seconds, and then move
to the next preset station. To select a
station, touch “P.SCAN” again.
z
Listening to HD Radio Broadcasts

Touch “HD ON”.
When the HD Radio signal is being re-
ceived, the sub channel number and the
total number of sub channels are dis-
played on the upper side of the display.
Push the “S ” or “T ” button of
“TRACK/TUNE” to change between sub
channels. The reception status mark is
displayed at the top of the display.
Displayed: Normal reception.
Blinking: Weak reception.
Not displayed: No reception.
If a HD Radio signal with broadcast in-
formation is received, touching “TITLE”
will display the album name, song title
and artist name.

AUDIO/VIDEO SYSTEM
195
V573_E

z Using iTunes Tagging

Touch “TAG”.
iTunes Tagging can be used when the
HD Radio signal is being received and a
song with Tag data is broadcast.
Touching “TAG” while a song is being
played on HD Radio stores information
about that song, allowing it to be pur-
chased through iTunes. Tag data for up
to 50 songs can be stored in the vehi-
cle’s audio system.
When an iPod or iPhone is connected to
the vehicle's audio system, the Tag data
will be moved to the iPod or iPhone.
The Tag data will then automatically be
erased from the vehicle’s audio system.
When the recorded Tag data on the iPod
or iPhone is synced with a computer, the
tagged songs will appear in a Tagged
playlist in iTunes. These tagged songs
can then be previewed and purchased.
For details, refer to the relevant User’s
Guide.

INFORMATION
z iTunes Tagging is compatible
with iTunes version 7.4 or later.
For compatible iPods and
iPhones, see “ ● Supported iPods”
on page 255.
z If the Tag data cannot be moved
to your iPod or iPhone, reconnect
your iPod or iPhone and try again.
z iPod and iTunes are trademarks
of Apple Inc., registered in the
U.S. and other countries.
z iPhone is a trademark of Apple
Inc.

AUDIO/VIDEO SYSTEM
196
V573_E
To listen to a satellite radio broadcast in
your vehicle, an additional genuine
Toyota satellite receiver and antenna
must be purchased and installed, and
the subscription to the XM
® Satellite
Radio is necessary.
z How to subscribe to an XM
® Satel-
lite Radio
An XM
® Satellite Radio is a tuner de-
signed exclusively to receive broadcasts
provided under a separate subscription.
Availability is limited to the 48 contiguous
states and 10 Canadian provinces.
How to subscribe:
You must enter into a separate service
agreement with the XM
® Satellite Radio
in order to receive satellite broadcast
programming in the vehicle. Additional
activation and service subscription fees
apply that are not included in the pur-
chase price of the vehicle and optional
digital satellite tuner.
For detailed information about XM
® Sat-
ellite Radio or to subscribe:
U.S.A.—
Visit on the web at www.xmradio.com
or
call 1 −800 −967 −2346.
Canada—
Visit on the web at www.xmradio.ca
or
call 1 −877 −438 −9677.
The XM
® Satellite Radio is solely re-
sponsible for the quality, availability and
content of the satellite radio services
provided, which are subject to the terms
and conditions of the XM
® Satellite Radio
customer service agreement.
Customers should have their radio ID
ready; the radio ID can be found by se-
lecting “channel 000” on the radio. For
details, see the “Displaying the radio ID”
that follows.
All fees and programming are the re-
sponsibility of the XM
® Satellite Radio
and are subject to change. Satellite tuner technology notice:
Toyota’s satellite radio tuners are
awarded Type Approval Certificates from
XM
® Satellite Radio Inc. as proof of
compatibility with the services offered by
the XM
® Satellite Radio.
z Displaying the radio ID
Each XM
® tuner is identified with a
unique radio ID. You will need the radio
ID when activating XM
® service or when
reporting a problem.
If you select the “CH 000” using the “S ”
or “ T” button of “TRACK/TUNE” , the
ID code of 8 alphanumeric characters
appears. If you select another channel,
display of the ID code is canceled. The
channel (000) alternates the display be-
tween the radio ID and the specific radio
ID code.
INFORMATION
Cargo loaded on the roof luggage
carrier, especially metal objects,
may adversely affect the reception
of XM
® Satellite Radio.


— Radio operation
(XM® Satellite Radio
broadcast
)

AUDIO/VIDEO SYSTEM
197
V573_E

z Listening to satellite radio
1. Push the “AV” button.

2. Touch “SAT”.
Push the “AV” button and touch
“AUDIO” to display the satellite radio
operation screen.
z
Changing the band

The band changes each time “SAT2”,
“SAT3”, and “SAT1” is touched.
The band changes sequentially between
“SAT1” , “SAT2” , and “SAT3” .

AUDIO/VIDEO SYSTEM
198
V573_E
z Channel category

Touch either “CAT ” or “CAT ” to go
to the next or previous category.
z
Presetting a channel
1. Tune in the desired channel.
2. Touch one of the channel selector
touch screen buttons and hold it until
a beep is heard.
This sets the channel to the touch screen
button and the name and number of the
channel appears on the touch screen
button.
Each touch screen button can store
three SAT channels. To change the pre-
set channel to a different one, follow the
same procedure.
The preset channel memory is cancelled
when the power source is interrupted by
battery disconnection or a blown fuse.

AUDIO/VIDEO SYSTEM
199
V573_E

z Selecting a channel
Tune in the desired channel using one of
the following methods.
Preset tuning: Touch the channel se-
lector button for the channel you want.
The touch screen button is highlighted
and channel number appears on the
screen.
To select channel within the current
category: Push the “S ” or “T ” button
of “TRACK/TUNE” . The radio will step
up or down the receivable channel within
the current channel category. If you push
and hold the “S ” or “T” button of
“TRACK/TUNE” , the radio will begin
seeking up or down for the next receiv-
able channel and will stop when the but-
ton is released. Touch either “CAT
SEEK
” or “CAT SEEK ”. The
radio will step up or down the channel
within the current channel category.

To scan the currently selected chan-
nel category: Touch “SCAN” on the
screen. The radio will find the next
channel in the same channel category,
stay there for a few seconds, and then
scan again. To select a channel, touch
“SCAN” again.
To scan the preset channels: Touch
“P.SCAN” on the screen. The radio
will find the next preset channel, stay
there for a few seconds, and then move
to the next preset channel. To select a
channel, touch “P.SCAN” again.
