253
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xB_OM_OM12G46U_(U)
■When replacing wheels
The wheels of your vehicle are equipped with tire pressure warning
valves and transmitters that allow the tire pressure warning system to
provide advance warning in the event of a loss in tire inflation pressure.
Whenever wheels are replaced, tire pressure warning valves and trans-
mitters must be installed. (
P. 241)
CAUTION
■When replacing wheels
●Do not use wheels that are a different size from those recommended in
the Owner’s Manual, as this may resu lt in a loss of handling control.
●Never use an inner tube in a leaking wheel which is designed for a
tubeless tire. Doing so may result in an accident, causing death or seri-
ous injury.
■When installing the wheel nuts
●Never use oil or grease on the wheel bolts or wheel nuts.
Oil and grease may cause the wheel nuts to be excessively tightened,
leading to bolt or disc wheel damage. In addition, the oil or grease can
cause the wheel nuts to loosen and the wheel may fall off, causing an
accident and resulting in death or serious injury. Remove any oil or
grease from the wheel bolts or wheel nuts.
●Be sure to install the wheel nuts with
the tapered end faci ng inward. Install-
ing the nuts with the tapered end fac-
ing outward can cause wheel to
break and eventually cause a wheel
to come off while driving, which could
lead to an accident resulting in death
or serious injury.Tapered
portion

5
When trouble arises
295
5-2. Steps to take in an emergency
Scion_xB_OM_OM12G46U_(U)
Stop the vehicle immediately.
The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Scion dealer.
Warning lightWarning light/Details
Charging system warning light Indicates a malfunction in the vehicle’s charging system.
Low engine oil pressure warning light Indicates that the engine oil pressure is too low.
High engine coolant temperature warning light Indicates that the engine is almost overheating.
(P. 328)

389
Alphabetical index
Scion_xB_OM_OM12G46U_(U)
Tires
Chains .................................. 163
Checking .............................. 240
Compact spare tire ............... 308
If you have a flat tire ............. 307
Inflation pressure .................. 248
Inflation pressure sensor ...... 241
Information ........................... 349
Replacing ............................. 307
Rotating tires ........................ 240
Size ...................................... 344
Snow tires............................. 163
Spare tire .............................. 307
Tire pressure warning system................................ 240
Tools......................................... 307
Total load capacity .................. 162
Towing Dinghy towing ............... 169, 170
Emergency towing ................ 286
Trailer towing ........................ 168
TRAC ........................................ 152
Traction control ....................... 152
Trailer towing........................... 168
Transmission shift
switches................................. 125
Turn signal lights Replacing light bulbs ............ 272
Switch ................................... 128
Wattage ................................ 345
Valet key..................................... 24
Vanity mirrors .......................... 195
Vehicle data recordings............ 17
Vehicle identification number................................... 336
Vehicle stability control .......... 152
VSC ........................................... 152
Warning buzzers Brake system........................ 294
Seat belt reminder ................ 298 Warning lights
Anti-lock brake system ..........296
Brake assist system ..............296
Brake system ........................294
Charging system .... ...............295
Electric power steering system
warning light........................297
Electronic engine control system ................................296
High coolant temperature ......295
Low engine oil pressure ........295
Low fuel level ........................298
Low tire pressure...................300
Low washer fluid ...................298
Malfunction indicator lamp ....296
Open door .............................298
Pretensioners ........................296
Seat belt reminder light .........298
SRS airbags ..........................296
Tire pressure warning light ....300
Washer Checking ...............................238
Preparing and checking
before winter .......................163
Switch....................................143
Washing and waxing ...............206
Weight Cargo capacity ......................157
Load limits .............................162
Weight ...................................336
Wheels ......................................252
Window glasses ........................59
Window lock switch ...................59
Windows
Power windows .......................59
Rear window defogger ..........180
Washer ..................................143
Windshield wipers ...................143
Wireless remote control key Locking/Unlocking ...................27
Replacing the battery ............258
Wireless remote control key ....27
V
W

392 What to do if...
Scion_xB_OM_OM12G46U_(U)
■Warning lights
P. 300
or
P. 2 9 4P. 298
P. 2 9 5P. 297
P. 2 9 5P. 298
P. 298
or
P. 2 9 6P. 298
P. 2 9 6P. 298
P. 295
or
P. 2 9 6P. 297
P. 2 9 9P. 297
*: The light flashes to indicate a malfunction.
Brake system warning
lightTire pressure warning
light
Charging system
warning light
Open door warning light
Malfunction indicator
lampLow fuel level warning
light
Driver’s seat belt
reminder light
SRS warning light
ABS warning light
Slip indicator light
Maintenance required
reminder lightCruise control indicator
light
*
Low engine oil
pressure warning light
Front passenger’s seat
belt reminder
light
High engine coolant
temperature
warning light Low windshield
washer fluid
warning light
Electric power
steering system
warning light
